Clearlight SANCTUARY User manual

CLEARLIGHT SANCTUARY
FULL SPECTRUM SAUNAS
OWNER’S MANUAL
Superior Quality and Service
Congratulations on your purchase of a Clearlight Infrared Sauna.
We are condent that you will enjoy the many benets of your sauna for years to come.
Please read this manual before using your Sauna for the rst time.
Please keep this manual for future reference.

Table of Contents
Welcome ------------------------------------------ 03
Installation ----------------------------------------- 04
01 | SANCTUARY 1 --------------------------------- 05
02 | SANCTUARY 2 --------------------------------- 19
03 | SANCTUARY 3 --------------------------------- 33
04 | SANCTUARY Y AND SANCTUARY RETREAT ----------- 47
05 | SANCTUARY C --------------------------------- 65
Enjoying Your Sauna---------------------------------- 80
Using Your Sauna Control Panel ------------------------- 81
Tips for Use ---------------------------------------- 85
Safety Instructions ----------------------------------- 87
Warranty ------------------------------------------ 89
Important Safeguards--------------------------------- 95
* The information contained in this manual is subject to change without notice.

4
Installation
Choosing a location
Place your sauna on a dry and level surface for best results. Garage, basement, attic, playroom, bedroom, or
garden house are just a few of the possible locations for your sauna.
Your sauna’s natural cedar or basswood exterior will beautifully compliment any location.
Outside, place the sauna on a deck or concrete pavers, available at your local building supply store, to protect
it from moisture in the ground which can wick up through the wooden feet. Outside installation also requires
our optional canvas cover.
Installation requirements for your sauna are as follows:
1. Your Clearlight® sauna is a self-contained and freestanding unit. It should not be built into any structure
without prior authorization.
2. Please maintain a minimum of 4-inch clearance on all sides of the unit to allow air to circulate while giving
access for the power cord..
Cleaning and maintenance
1. Before using your sauna for the rst time, clean the inside of the sauna with a damp cloth.
Use your favorite furniture polish on the exterior.
2. Place a towel on the oor and bench to absorb any perspiration. Wash these often to maintain a clean and
pleasant environment inside your sauna.
3. Perspiration may darken the wood over time. This can be removed by a light sanding with ne grit
sandpaper.
Please be careful when carrying and installing the glass pieces to avoid breakage. Make certain the glass is securely fastened
during installation before letting go of any individual piece that could break.

SANCTUARY 1
5
SANCTUARY 101
Packaging - - - - - - - - - - - - - - - - - - - - - - - 06
Assembly Instructions - - - - - - - - - - - - - - - - - 07

6
SANCTUARY 1
.
Packaging
Box 1 of 4 Box 2 of 4 Box 3 of 4 Box 4 of 4
1. Floor Panel 1. Left Side Wall 1. Front Wall Glass 1. Front Heaters
2. Ceiling Panel 2. Right Side Wall 2. Back Wall
3. Accessories 3. Bench & Bench Support
4. Installation Manual
CONTENTS OF BOXES
ACCESSORY BOX CONTENTS
Door Handle
Wall Security Brackets
(located installed in wall)
Glass Security
Brackets (2 sets)
Wood piece
(2 pieces)
Front Heater
Mounting Screws
(4 sets)

SANCTUARY 1
7
Assembly Instructions
Assembly of the sauna requires two adults to complete. Please read the instructions thoroughly before and
during assembly to ensure proper installation of the unit. If you encounter any problems or have questions
during assembly, please feel free to call our Customer Service department at 1-800-798-1779 or
[phone].
When determining a location for your sauna, please keep in mind the following:
1. The main power cord on the sauna must be easily accessible.
2. The location must be dry and level.
3. Panels should be installed in the following order:
1) Floor 4) Right Side Wall 7) Wood Roof
2) Back Wall 5) Under Bench Support 8) Glass Roof
3) Left Side Wall 6) Bench 9) Front Wall Glass
1. Place the bottom oor panel on the ground
near the location you will using the sauna.
Make sure the front of the oor is in the
desired location of the door. The two oor
receptacles and the door magnet indicate
the front of the sauna.
1. Place the back panel on the oor panel by placing
it in the groove of the oor panel.
1 - LOCATION OF SAUNA & INSTALLATION ORDER
2 - PLACING FLOOR PANEL 3 - CONNECTING THE BACK PANEL
TO THE FLOOR PANEL

8
SANCTUARY 1
Assembly Instructions Cont’d
The side wall panels connect to the back wall with the installed locking brackets. There are mating brackets
on the side of each panel.
1. Place the left side wall in the slot in the
oor. Lift the side wall up about 4” (10cm)
higher than the backwall panel (See Picture
1).
2. Place the side wall panel against the back
wall (See Picture 2), then slide down side
wall panel until the two panels are equal
height. (See Picture 3).
3. If the panels are not equal height or
there is an obvious gap between the two
panels, this means they are not propery
attached and you should try again.
4. Repeat the steps above for the right side
wall panel.
4 - CONNECTING SIDE WALLS
Picture 1 Picture 2 Picture 3
Right Side Wall InstalledLeft Side Wall Installed
If the panels still seem too tight to
come down all the way, try backing o
the bracket screws by one half turn
with a Phillips head screwdriver on the
female bracket.

SANCTUARY 1
9
Assembly Instructions Cont’d
Slide down the bench heater panel by lining up its sides with the vertical guides on the left and right side
wall panel.
1. Be careful not to scratch the side panels when positioning the heater panel.
2. Push the bench heater panel all the way down until it is touching the oor panel and securely in
place.
5 - INSTALLING UNDER BENCH SUPPORT
Vertical bench heater
panel guides are found
on the side panels.
Heater must be
facing outward

10
SANCTUARY 1
Assembly Instructions Cont’d
Plug in the connectors under the bench as follows:
Left Side Wall:
1. Locate the short cable coming out of the oor with a single black and white cable and a single green
cable. This cable is comes threaded through the hole of the white cable cover.
2. Locate the cable coming out of the under bench support. Feed this cable through the open hole in the
bottom of the white cable cover.
3. Connect these cable to the cables coming out of the white box on the left side wall. You can connect
the black and white cables from the oor and underbench support to any black and white cable coming
out of the box as long as you match cable colors. You can connect the green cables to any of the green
cables coming out of the box as long as you match cable colors.
4. Screw on the cover to cover the wires on the side wall.
Back Wall:
1. Locate the longer cable coming out of the oor that feeds
through a hole in the white cover.
Connect the longer cable coming out of the oor to the like
connector in the cables coming out of the white box on the
back wall. Connect the cable with two wires to the cable
with two wires in the back all. Connect the cable with four
wires to the cable with four wires coming out of the back
wall.
2. Screw on the cover to cover the wires on the back wall.
3. The additional plate on the back wall is used to connect
the Vibration Resonance Therapy (VRT) to your sauna. If
you purchased the VRT, follow the installation instructions
included with the VRT.
6 - CONNECT HEATER CONNECTION UNDER BENCH
You can plug any male connector to any female one as long as
the colors match.

SANCTUARY 1
11
Assembly Instructions Cont’d
Install the bench panel by sliding it over the horizontal bench guides on the side panels. Be careful not to
scratch the adjacent panels when sliding in the bench.
Push the bench all the way in until it touches the back panel and is securely in place.
The bench is reversible. One side is ergonomic and one side is at. You can reverse the bench after the
sauna installation is nished. Be sure that the bench is pushed all the way back until it slides under the
heater guard to secure the bench in place.
Optional: After the bench is installed, you
can slide in the included wood pieces
to prevent the bench from sliding left to
right. One piece can be placed on each
side next to the bench. If you decide to ip
the reversible bench over, please remove
the wood pieces rst.
7 - INSTALLING THE BENCH
LLEEFFTT
TTOOPP
BBOOTTTTOOMM
FFRROONNTT
BBLLAACCKK
LEFT
TOP
BOTTOM
FRONT
BLACK
1. Set the wood portion of
the roof on the back roof
guide. Besure to slide the
roof back against the back
wall.
8 - INSTALLING WOOD PORTION OF ROOF

12
SANCTUARY 1
Assembly Instructions Cont’d
1. The side walls must be secured to the back wall and wood roof piece using the attached eye hooks.
2. Screw in one of the eye hooks between the left side wall and backwall and one between the right side
wall and backwall.
9 - INSTALLING WALL LOCKS THIS STEP IS VERY IMPORTANT.
PLEASE DO NOT OMIT THIS STEP.
Attach eye hook so
that it is screwed
into both the side
walls and back
walls.
Attach the eye hook
so that it is screwed
into side walls and
the wood roof
piece.
3. Latch the three buckles that connect the
wood roof piece to the back and side walls.

SANCTUARY 1
13
Assembly Instructions Cont’d
10 - INSTALLING GLASS PORTION OF ROOF AND RIGHT FRONT WALL
1. Locate the glass roof piece as in the photo below.
2. Locate the roof locking brackets, protective
washers and screws.
3. Attach the brackets to the roof piece as shown
below using the enclosed Allen Wrench.
4. Place the long edge of the glass roof
piece into the groove in the wood roof
piece. Center this piece in the wood
roof piece.
HOLD THIS PIECE IN PLACE UNTIL
THE RIGHT SIDE FRONT WALL AND
DOOR ARE INSTALLED
x2 x2x4 x6 x6 x2

14
SANCTUARY 1
Assembly Instructions Cont’d
1. Locate the right front wall
with right door.
2. Place the right front wall
into the groove in the oor
and align it under the glass
roof piece. Until this piece is
secured using the enclosed
brackets, someone should
hold the wall and roof in
place.
5. Repeat this process for the left front
wall and door.
10 - INSTALLING GLASS PORTION OF ROOF AND RIGHT FRONT WALL
3. Secure the left front glass window
to the roof glass using the included
brackets. You will see pre-drilled
holes in both the front glass and roof
glass.
4. Secure the outer-most Side Wall-Mounted L Shape
Brackets into the wall using the screws provided.
Sauna Roof
Outer Wall
Glass Ceiling
Glass Panel
Bracket

SANCTUARY 1
15
Assembly Instructions Cont’d
1. Locate the “trap” doors that open in the wood
roof.
2. Connect the cables under the trap door to
the same colored connector in the roof (e.g,
black/white, red/black, yellow/black, etc.)
3. Connect the green ground wire that come out
of the side wall to the green ground wire that
is in the wood roof.
Push the wiring inside the roof area and close
the roof door compartments.
4. In the left side wall compartment, there will
be two connectors: 1) Heater connector. 2)
Keypad connector. The heater connector is a
two wire connector. The keypad connector is
a seven wire connector.
1. Locate the two door handles.
2. Attach the right side door handle using the enclosed screws.
3. Attach the left side door handle using the enclosed screws.
11 - CONNECT HEATERS IN ROOF
12 - INSTALLING DOOR HANDLE
BE SURE TO MATCH THE COLORS IN THE CONNECTORS.
THE BLACK WIRE SHOULD MATCH UP WITH THE BLACK WIRE, ETC.
Note: If you are using a tablet or smartphone to control your sauna, the door handle will act as
both the door handle and tablet/smartphone holder when the door is closed.

16
SANCTUARY 1
Assembly Instructions Cont’d
1. Locate the two front heaters.
2. Align the left front heater and plug the connector that comes out of the bottom of the heater into the
plug coming out of the in the oor.
3. Align the the hole in the back of the heater with the hole in the front wall glass Using the enlcosed
screws and washers, secure the heater to the glass through the pre-drilled hole. One washer will be
placed on the inside and one on the outside glass. The heater will be secured with these screws in two
locations.
4. Repeat this step for the right front heater.
13 - INSTALLING FRONT HEATERS
Front
Heater
Installed

SANCTUARY 1
17
Assembly Instructions Cont’d
Warning Notice
The infrared heaters in your sauna are a potential BURN HAZARD. Do NOT touch
the infrared heaters when they are in operation and allow to cool before servicing.
14 - LOCATING AND PLUGGING IN POWER CORD
The power cord comes out of the roof of the sauna. If you are standing facing the sauna, it comes out of
the rear left corner of the roof. Open the trap door to access the power cord and run the cord down the
back of the sauna. The power cord will plug into the appropriate electrical receptacle.
Note: We do not recommend using an extension cord for your sauna.
Please plug the sauna directly into the wall receptacle.
13 - INSTALLING FRONT HEATERS

18
SANCTUARY 1
Assembly Instructions Cont’d
Installation of your sauna is now complete. Using a damp cloth, wipe out the sauna to remove any excess
saw dust that may have settled on the wall & oor panels and the heater panels during manufacturing and
shipment.
Please refer to usage instructions located later on in this manual.
15 - INSTALLATION IS COMPLETE

SANCTUARY 1
19
SANCTUARY 202
Packaging - - - - - - - - - - - - - - - - - - - - - - - 20
Assembly Instructions - - - - - - - - - - - - - - - - - 21

20
SANCTUARY 2
Packaging
.
Box 1 of 4 Box 2 of 4 Box 3 of 4 Box 4 of 4
1. Floor Panel 1. Left Side Wall 1. Front Wall Glass 1. Front Heaters
2. Ceiling Panel 2. Right Side Wall 2. Back Wall
3. Accessories 3. Bench & Bench Support
4. Installation Manual
CONTENTS OF BOXES
ACCESSORY BOX CONTENTS
Door Handle
Wall Security Brackets
(located installed in wall)
Glass Security
Brackets (2 sets)
Wood piece
(2 pieces)
Front Heater
Mounting Screws
(4 sets)

21
SANCTUARY 2
Assembly Instructions
Assembly of the sauna requires two adults to complete. Please read the instructions thoroughly before and
during assembly to ensure proper installation of the unit. If you encounter any problems or have questions
during assembly, please fveel free to call our Customer Service department at 1-800-798-1779 or
[phone].
When determining a location for your sauna, please keep in mind the following:
1. The main power cord on the sauna must be easily accessible.
2. The location must be dry and level.
3. Panels should be installed in the following order:
1) Floor 4) Right Side Wall 7) Wood Roof
2) Back Wall 5) Under Bench Support 8) Glass Roof
3) Left Side Wall 6) Bench 9) Front Wall Glass
1. Place the bottom oor panel on the ground
near the location you will using the sauna.
Make sure the front of the oor is in the
desired location of the door. The two
plugs and the door magnet indicate the
front of the sauna.
1. Connect the back panel to the oor panel by lining
up the back panel on the groove of the oor panel.
1 - LOCATION OF SAUNA & INSTALLATION ORDER
2 - PLACING FLOOR PANEL 3 - CONNECTING THE BACK PANEL
TO THE FLOOR PANEL
