ClearView PhoenixView 04B-04IP94 User manual

Network Video Recorder User’s Manual
V 2.0.0

i
Table of Contents
1Features and Specifications ...............................................................................................................1
1.1 Overview........................................................................................................................................1
1.2 Features.........................................................................................................................................1
1.3 Specifications................................................................................................................................2
2Front Panel and Rear Panel...............................................................................................................5
2.1 Front Panel....................................................................................................................................5
2.2 Rear Panel ....................................................................................................................................5
2.3 Bidirectional talk ...........................................................................................................................6
2.3.1 Device-end to PC-end ..........................................................................................................6
2.3.2 PC-end to the device-end ....................................................................................................6
2.4 Mouse Operation..........................................................................................................................7
3Device Installation................................................................................................................................9
3.1 Check Unpacked NVR.................................................................................................................9
3.2 About Front Panel and Rear Panel............................................................................................9
3.3 HDD Installation............................................................................................................................9
4Local Basic Operation .......................................................................................................................11
4.1 Boot up and Shutdown..............................................................................................................11
4.1.1 Boot up..................................................................................................................................11
4.1.2 Shutdown..............................................................................................................................11
4.2 Startup Wizard............................................................................................................................11
4.3 Navigation Bar............................................................................................................................15
4.3.1 Main Menu............................................................................................................................15
4.3.2 Dual-screen operation ........................................................................................................15
4.3.3 Output Screen......................................................................................................................16
4.3.4 Tour........................................................................................................................................16
4.3.5 PTZ........................................................................................................................................16
4.3.6 Color......................................................................................................................................16
4.3.7 Search...................................................................................................................................16
4.3.8 Alarm Status.........................................................................................................................16
4.3.9 Channel Info.........................................................................................................................16
4.3.10 Remote Device....................................................................................................................17
4.3.11 Network.................................................................................................................................17
4.3.12 HDD Manager......................................................................................................................17
4.3.13 USB Manager.......................................................................................................................17
4.4 Smart Add....................................................................................................................................17
4.5 Remote Device...........................................................................................................................20
4.5.1 Remote Device Connection...............................................................................................20
4.5.2 Short-Cut Menu ...................................................................................................................22
4.5.3 Image ....................................................................................................................................22
4.5.4 Channel Name.....................................................................................................................24
4.5.5 Upgrade................................................................................................................................25
4.5.6 UPNP ....................................................................................................................................25
4.5.7 Built-in Switch Setup...........................................................................................................26

ii
4.6 Preview........................................................................................................................................26
4.6.1 Preview .................................................................................................................................26
4.6.2 Preview control interface....................................................................................................27
4.6.3 Right Click Menu .................................................................................................................28
4.6.4 Preview Display Effect Setup ............................................................................................29
4.6.4.1 Video Color..................................................................................................................29
4.6.4.2 Display.........................................................................................................................31
4.6.4.3 TV adjust......................................................................................................................32
4.6.5 Preview Tour Parameters ..................................................................................................32
4.7 PTZ...............................................................................................................................................33
4.7.1 PTZ Settings.........................................................................................................................33
4.7.2 PTZ Control..........................................................................................................................35
4.7.2.1 PTZ Function Setup...................................................................................................37
4.7.2.2 Call PTZ Function.......................................................................................................39
4.8 Record and Snapshot................................................................................................................40
4.8.1 Encode..................................................................................................................................40
4.8.1.1 Encode.........................................................................................................................40
4.8.1.2 Overlay.........................................................................................................................41
4.8.1.3 Snapshot......................................................................................................................42
4.8.2 Schedule...............................................................................................................................43
4.8.2.1 Schedule Record........................................................................................................43
4.8.2.2 Schedule Snapshot....................................................................................................46
4.8.3 Motion detect record/snapshot..........................................................................................48
4.8.3.1 Motion detect record..................................................................................................48
4.8.3.2 Motion Detect Snapshot............................................................................................50
4.8.4 Alarm Record/Snapshot .....................................................................................................51
4.8.4.1 Alarm Record..............................................................................................................51
4.8.4.2 Alarm Snapshot..........................................................................................................52
4.8.5 Manual Record/Snapshot...................................................................................................53
4.8.5.1 Manual Record ...........................................................................................................53
4.8.5.2 Manual Snapshot........................................................................................................54
4.8.6 Holiday Record/Snapshot ..................................................................................................54
4.8.6.1 Holiday Record...........................................................................................................54
4.8.6.2 Holiday Snapshot .......................................................................................................56
4.8.7 Other Record/Snapshot......................................................................................................56
4.9 Playback and Search.................................................................................................................56
4.9.1 Real-time Playback.............................................................................................................56
4.9.2 Search Interface ..................................................................................................................57
4.9.2.1 Smart Search..............................................................................................................61
4.9.2.2 Accurate playback by time........................................................................................61
4.9.2.3 Mark Playback ............................................................................................................62
4.9.3 Picture Playback..................................................................................................................63
4.10 Backup.........................................................................................................................................63
4.10.1 File Backup...........................................................................................................................63
4.10.2 Import/Export........................................................................................................................65
4.10.3 Backup Log...........................................................................................................................66

iii
4.10.4 USB Device Auto Pop-up...................................................................................................66
4.11 Alarm............................................................................................................................................67
4.11.1 Detect Alarm.........................................................................................................................67
4.11.1.1 Motion Detect..............................................................................................................67
4.11.1.2 Tampering....................................................................................................................71
4.11.1.3 Video Loss...................................................................................................................72
4.11.2 Alarm output.........................................................................................................................73
4.11.3 Alarm Setup..........................................................................................................................74
4.11.4 Abnormality...........................................................................................................................79
4.12 Network........................................................................................................................................81
4.12.1.1 TCP/IP..........................................................................................................................81
4.12.1.2 Connection ..................................................................................................................83
4.12.1.3 WIFI AP........................................................................................................................84
4.12.1.4 WIFI..............................................................................................................................85
4.12.1.5 3G.................................................................................................................................86
4.12.1.6 PPPoE..........................................................................................................................87
4.12.1.7 DDNS Setup................................................................................................................88
4.12.1.8 UPnP............................................................................................................................90
4.12.1.9 IP Filter.........................................................................................................................91
4.12.1.10 Email............................................................................................................................93
4.12.1.11 FTP...............................................................................................................................94
4.12.1.12 SNMP..........................................................................................................................96
4.12.1.13 Multicast......................................................................................................................96
4.12.1.14 Alarm Centre..............................................................................................................98
4.12.1.15 Auto register...............................................................................................................98
4.12.1.16 P2P..............................................................................................................................99
4.12.1.17 Easy Space...............................................................................................................100
4.12.1.18 SWITCH....................................................................................................................101
4.12.2 Network Test.......................................................................................................................102
4.12.2.1 Network Test..............................................................................................................102
4.12.2.2 Network Load............................................................................................................103
4.13 HDD Setup................................................................................................................................104
4.13.1 Format.................................................................................................................................104
4.13.2 HDD Information................................................................................................................105
4.13.3 Advanced............................................................................................................................107
4.13.4 HDD Detect........................................................................................................................109
4.13.4.1 Manual Detect...........................................................................................................110
4.13.4.2 Detect Report............................................................................................................110
4.13.5 RAID Manager...................................................................................................................112
4.13.5.1 RAID Config..............................................................................................................112
4.13.5.2 Hotspare disks..........................................................................................................113
4.14 Basic Setups.............................................................................................................................114
4.14.1 Device Setup......................................................................................................................114
4.14.2 Data and Time ...................................................................................................................115
4.14.3 Holiday................................................................................................................................116
4.15 Device Maintenance and Manager........................................................................................116

iv
4.15.1 System Info.........................................................................................................................116
4.15.1.1 Version.......................................................................................................................116
4.15.1.2 BPS ............................................................................................................................117
4.15.1.3 Online User ...............................................................................................................117
4.15.1.4 Remote Device Information....................................................................................118
4.15.1.5 Remote.......................................................................................................................119
4.15.1.5.1 Device Status...........................................................................................................119
4.15.1.5.2 Firmware.................................................................................................................120
4.15.2 Log.......................................................................................................................................121
4.15.3 Voice....................................................................................................................................122
4.15.3.1.1 File Manage ............................................................................................................122
4.15.3.1.2 Schedule..................................................................................................................123
4.15.4 Account...............................................................................................................................123
4.15.4.1 Add/Modify Group ....................................................................................................125
4.15.4.2 Add/Modify User.......................................................................................................126
4.15.5 Update.................................................................................................................................127
4.15.6 Default.................................................................................................................................128
4.15.7 RS232 .................................................................................................................................128
4.15.8 Auto Maintain.....................................................................................................................129
4.15.9 Logout /Shutdown/Restart................................................................................................130
5Web Operation..................................................................................................................................131
5.1 General Introduction ................................................................................................................131
5.1.1 Preparation.........................................................................................................................131
5.1.2 Log in...................................................................................................................................132
5.2 LAN Mode..................................................................................................................................133
5.3 Real-time Monitor.....................................................................................................................135
5.4 PTZ.............................................................................................................................................136
5.5 Image/Alarm-out.......................................................................................................................138
5.5.1 Image ..................................................................................................................................138
5.5.2 Alarm output.......................................................................................................................138
5.6 Zero-channel Encode ..............................................................................................................138
5.7 WAN Login................................................................................................................................139
5.8 Setup..........................................................................................................................................140
5.8.1 Camera...............................................................................................................................140
5.8.1.1 Remote Device.........................................................................................................140
5.8.1.2 Image.........................................................................................................................142
5.8.1.3 Encode.......................................................................................................................145
5.8.1.3.1 Encode.......................................................................................................................145
5.8.1.3.2 Snapshot....................................................................................................................146
5.8.1.3.3 Video Overlay ...........................................................................................................147
5.8.1.3.4 Path ...........................................................................................................................147
5.8.1.4 Channel Name..........................................................................................................148
5.8.1.5 IPC Upgrade .............................................................................................................148
5.8.2 Network...............................................................................................................................149
5.8.2.1 TCP/IP........................................................................................................................149
5.8.2.2 P2P.............................................................................................................................150

v
5.8.2.3 Connection ................................................................................................................150
5.8.2.4 WIFI AP......................................................................................................................151
5.8.2.5 WIFI............................................................................................................................152
5.8.2.6 3G...............................................................................................................................153
5.8.2.6.1 CDMA/GPRS ...........................................................................................................153
5.8.2.6.2 Mobile.......................................................................................................................154
5.8.2.7 PPPoE........................................................................................................................155
5.8.2.8 DDNS.........................................................................................................................155
5.8.2.9 IP filter........................................................................................................................156
5.8.2.10 Email...........................................................................................................................157
5.8.2.11 UPnP..........................................................................................................................158
5.8.2.12 SNMP.........................................................................................................................159
5.8.2.13 Multicast.....................................................................................................................160
5.8.2.14 Auto Register ............................................................................................................161
5.8.2.15 Alarm Centre.............................................................................................................161
5.8.2.16 HTTPS .......................................................................................................................162
5.8.2.16.1 Create Server Certificate.........................................................................................162
5.8.2.16.2 Download root certificate........................................................................................163
5.8.2.16.3 View and set HTTPS port .......................................................................................166
5.8.2.16.4 Login.......................................................................................................................166
5.8.3 Event...................................................................................................................................166
5.8.3.1 Video detect ..............................................................................................................166
5.8.3.1.1 Motion Detect ...........................................................................................................166
5.8.3.1.2 Video Loss ................................................................................................................170
5.8.3.1.3 Tampering .................................................................................................................171
5.8.3.2 Alarm..........................................................................................................................171
5.8.3.2.1 Local Alarm ..............................................................................................................171
5.8.3.2.2 Net Alarm..................................................................................................................174
5.8.3.2.3 IPC external alarm ....................................................................................................174
5.8.3.2.4 IPC Offline Alarm.....................................................................................................175
5.8.3.3 Abnormality ...............................................................................................................176
5.8.4 Storage................................................................................................................................178
5.8.4.1 Schedule....................................................................................................................178
5.8.4.2 HDD Manager...........................................................................................................180
5.8.4.2.1 Local Storage ............................................................................................................180
5.8.4.2.2 HDD..........................................................................................................................180
5.8.4.2.3 FTP............................................................................................................................180
5.8.4.3 Record Control..........................................................................................................181
5.8.4.4 RAID Manager..........................................................................................................182
5.8.4.4.1 RAID Config.............................................................................................................182
5.8.4.4.2 Hotspare disks...........................................................................................................182
5.8.4.5 Storage.......................................................................................................................183
5.8.4.5.1 Main Stream..............................................................................................................183
5.8.4.5.2 Sub Stream................................................................................................................183
5.8.4.5.3 Snapshot....................................................................................................................184
5.8.5 Setting.................................................................................................................................184

vi
5.8.5.1 General ......................................................................................................................184
5.8.5.1.1 General......................................................................................................................184
5.8.5.1.2 Date and time............................................................................................................185
5.8.5.1.3 Holiday Setup............................................................................................................186
5.8.5.2 Account......................................................................................................................186
5.8.5.2.1 User name .................................................................................................................187
5.8.5.2.2 Group ........................................................................................................................188
5.8.5.3 Display.......................................................................................................................190
5.8.5.3.1 Display......................................................................................................................190
5.8.5.3.2 Tour...........................................................................................................................190
5.8.5.4 Alarm Out...................................................................................................................191
5.8.5.5 Default........................................................................................................................192
5.8.5.6 Import/Export.............................................................................................................192
5.8.5.7 Auto maintain............................................................................................................193
5.8.5.8 Upgrade.....................................................................................................................193
5.8.5.9 RS232........................................................................................................................194
5.8.5.10 PTZ.............................................................................................................................194
5.9 Information ................................................................................................................................196
5.9.1 Version................................................................................................................................196
5.9.2 Log.......................................................................................................................................196
5.9.3 Online User.........................................................................................................................197
5.10 Playback....................................................................................................................................197
5.10.1 Search Record...................................................................................................................198
5.10.2 File List................................................................................................................................198
5.10.3 Playback .............................................................................................................................199
5.10.4 Download............................................................................................................................200
5.10.5 Load more...........................................................................................................................200
5.10.5.1 Download By File......................................................................................................200
5.10.5.2 Download by Time....................................................................................................201
5.10.5.3 Watermark.................................................................................................................202
5.11 Alarm..........................................................................................................................................202
5.12 Log out.......................................................................................................................................203
5.13 Un-install Web Control.............................................................................................................204
6Glossary.............................................................................................................................................205
7FAQ....................................................................................................................................................206
8Appendix A HDD Capacity Calculation .........................................................................................211
9Appendix B Compatible Network Camera List.............................................................................212

vii
Welcome
Thank you for purchasing our network video recorder!
This user’s manual is designed to be a reference tool for your system.
Please open the accessory bag to check the items one by one in accordance with the list below.
Contact your local retailer ASAP if something is missing or damaged in the bag.

viii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The product must be grounded to reduce the risk of electric shock.
We assume no liability or responsibility for all the fires or electric shock caused by improper
handling or installation.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Keep upwards. Handle with care.
Do not apply power to the NVR before completing installation.
Do not place objects on the NVR.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
The NVR should be installed in a cool, dry place awayfrom direct sunlight, inflammable, explosive
substances and etc.
This series product shall be transported, storage and used in the specified environments.
Environment which needs to comply with the following conditions:
The function of the ITE being investigated to IEC 60950-1 is considered not likely to require
connection to an Ethernet network with outside plant routing, including campus environment.
The installation instructions clearly state that the ITE is to be connected only to PoE networks
without routing to the outside plant.
6. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
7. Lithium battery
Improper battery use may result in fire, explosion, or personal injury!
When replace the battery, please make sure you are using the same model!
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BYAN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Before your operation please read the following instructions carefully.
Installation environment

ix
Keep away from extreme hot places and sources；
Avoid direct sunlight；
Keep away from extreme humid places；
Avoid violent vibration；
Do not put other devices on the top of the NVR；
Be installed in well ventilated place; do not block the vent.
Accessories
Check the following accessories after opening the box：
Please refer to the packing list in the box *

1
1 Features and Specifications
1.1 Overview
This series NVR is a high performance network video recorder. This series product support local preview,
multiple-window display, recorded file local storage, remote control and mouse shortcut menu operation,
and remote management and control function.
This series product supports centre storage, front-end storage and client-end storage. The monitor zone
in the front-end can be set in anywhere. Working with other front-end devices such as IPC, NVS, this
series product can establish a strong surveillance network via the CMS. In the network system, there is
only one network cable from the monitor centre to the monitor zone in the whole network. There is no
audio/video cable from the monitor centre to the monitor zone. The whole project is featuring of simple
connection, low-cost, low maintenance work.
This series NVR can be widely used in many areas such as public security, water conservancy,
transportation and education.
1.2 Features
Real-time
Surveillance
VGA, HDMI port. Connect to monitor to realize real-time surveillance.
Some series support TV/VGA/HDMI output at the same time.
Short-cut menu when preview.
Support popular PTZ decoder control protocols. Support preset, tour
and pattern.
Playback
Support each channel real-time record independently, and at the same
time it can support search, forward play, network monitor, record search,
download and etc.
Support various playback modes: slow play, fast play, backward play
and frame by frame play.
Support time title overlay so that you can view event accurate occurred
time
Support specified zone enlargement.
User
Management
Each group has different management powers that can be edited freely.
Every user belongs to an exclusive group.
Storage
Via corresponding setup (such as alarm setup and schedule setup), you
can backup related audio/video data in the network video recorder.
Support Web record and record local video and storage the file in the
client end.
Alarm
Respond to external alarm simultaneously (within 200MS), based on
user’s pre-defined relay setup, system can process the alarm input
correctly and prompt user by screen and voice (support pre-recorded
audio).
Support central alarm server setup, so that alarm information can
remotely notify user automatically. Alarm input can be derived from
various connected peripheral devices.
Alert you via email/sms.

2
Network
Monitor
Through network, sending audio/video data compressed by IPC or NVS
to client-ends, then the data will be decompressed and display.
Support max 128 connections at the same time.
Transmit audio/video data by HTTP, TCP, UDP, MULTICAST,
RTP/RTCP and etc.
Transmit some alarm data or alarm info by SNMP.
Support WEB access in WAN/LAN.
Window Split
Adopt the video compression and digital process to show several
windows in one monitor. Support 1/4/8/9/16/ 25/36-window display when
preview and 1/4/9/16-window display when playback.
Record
Support normal/motion detect/alarm record function. Save the recorded
files in the HDD, USB device, client-end PC, or network storage server.
You can search or playback the saved files at the local-end or via the
Web/USB device.
Backup
Support network backup, USB2.0 record backup function, the recorded
files can be saved in network storage server, peripheral USB2.0
device, burner and etc.
Network
Management
Supervise NVR configuration and control power via Ethernet.
Support management via WEB.
Peripheral
Equipment
Management
Support peripheral equipment management such as protocol setup and
port connection.
Support transparent data transmission such as RS232 (RS-422), RS485
(RS-485).
Auxiliary
Support switch between NTSC and PAL.
Support real-time system resources information and running statistics
display.
Support log file.
Local GUI output. Shortcut menu operation via mouse.
IR control function (For some series product only.). Shortcut menu
operation via remote control.
Support IPC or NVS remote video preview and control.
1.3 Specifications
Model
4-ch Series
System
System
Resources
4-ch series product support 4 HD connection respectively. Total
bandwidth supports 28Mbps.
OS
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video Decode
Type
H.264/MJPEG/MJPEG4
Decode
Capability
Max 2-ch 5M 25fps or 4-ch 3M 25fps or 4-ch 1080P 30fps
Video
Video Input
4-ch network compression video input

3
Model
4-ch Series
Video Output
1-channel VGA analog video output
HDMI
1-ch HDMI output. Version number is 1.4
Window Split
1/4-window
Audio
Audio Input
1-ch bidirectional talk input
Audio Output
1-ch bidirectional talk output
Audio
Compression
Standard
G.711a
Alarm
Alarm Input
N/A
Alarm Output
N/A
Funciton
Storage
1 built-in SATA port
Multiple-Chann
el Playback
Max 4-channel 1080P playback
Port and
Indicator
RS232 Port
N/A
RS485 Port
N/A
USB Port
2 peripheral USB2.0 ports.
Network
Connection
1 RJ45 10/100Mbps self-adaptive Ethernet port.
PoE Port
4
Power Port
1 power socket. Power adapter power supplying mode. DC 48V
power.
Power Button
1 button
Power On-off
Button
N/A
IR Receiver
Window
N/A
Clock
Built-in clock.
Indicator Light
One power status indicator light.
One network status indicator light.
One HDD status indicator light.
General
Power
Consumption
＜10W (Exclude HDD)
Working
Temperature
﹣10℃～﹢55℃

4
Model
4-ch Series
Working
Humidity
10℅～90℅
Air pressure
86kPa～106kPa
Dimension
325mm×250.58mm×51mm
Weight
0.5kg～1kg (Exclude HDD)
Installation
Mode
Desk installation

5
2 Front Panel and Rear Panel
2.1 Front Panel
The front panel is shown as in Figure 2-1.
Figure 2-1
Please refer to the following sheet for detailed information.
Icon
Name
Function
NET
Network status
indicator light
The red light becomes on when the network
connection is abnormal.
PWR
Power indicator
light
The red light becomes on when the power
connection is OK.
HDD
HDD status
indictor light
The red light becomes on when HDD is abnormal.
IR
Remote control
receiver
It is to receive signal from the remote control.
2.2 Rear Panel
The rear panel is shown as in Figure 2-2.
Figure 2-2
Please refer to the following sheet for detailed information.
Port Name
Connection
Function
USB2.0 port
USB2.0 port. Connect to mouse, USB storage
device, USB burner and etc.
Network port
10M/100Mbps self-adaptive Ethernet port.
Connect to the network cable.
HDMI
High Definition
Media Interface
High definition audio and video signal output port.
It transmits uncompressed high definition video
and multiple-channel data to the HDMI port of the
display device. HDMI version is 1.4.

6
Port Name
Connection
Function
VGA
VGA video
output port
VGA video output port. Output analog video
signal. It can connect to the monitor to view analog
video.
GND
Ground end
/
Power input port
Power socket. Input DC 48V/1.5A.
MIC IN
Audio input port
Bidirectional talk input port. It is to receive the
analog audio signal output from the devices such
as microphone, pickup.
MIC OUT
Audio output
port
Audio output port. It is to output the analog audio
signal to the devices such as the sound box.
Bidirectional talk output.
Audio output on 1-window video monitor.
Audio output on 1-window video playback.
PoE PORT
PoE port
Built-in switch. Support PoE function.
For PoE series product, you can use this port to
provide power to the network camera.
2.3 Bidirectional talk
2.3.1 Device-end to PC-end
Device Connection
Please connect the speaker or the pickup to the first audio input port in the device rear panel. Then
connect the earphone or the sound box to the audio output port in the PC.
Login the Web and then enable the corresponding channel real-time monitor.
Please refer to the following interface to enable bidirectional talk. See Figure 2-3.
Figure 2-3
Listening Operation
At the device end, speak via the speaker or the pickup, and then you can get the audio from the earphone
or sound box at the pc-end.
2.3.2 PC-end to the device-end
Device Connection
Connect the speaker or the pickup to the audio output port in the PC and then connect the earphone or
the sound box to the first audio input port in the device rear panel.

7
Login the Web and then enable the corresponding channel real-time monitor.
Please refer to the above interface (Figure 2-3) to enable bidirectional talk.
Listening Operation
At the PC-end, speak via the speaker or the pickup, and then you can get the audio from the earphone or
sound box at the device-end.
2.4 Mouse Operation
Please refer to the following sheet for mouse operation instruction.
Left click
mouse
When you have selected one menu item, left click mouse to view menu content.
Modify checkbox or motion detection status.
Click combo box to pop up dropdown list
In input box, you can select input methods. Left click the corresponding button
on the panel you can input numeral/English character (small/capitalized). Here
← stands for backspace button. ＿stands for space button.
In English input mode: _stands for input a backspace icon and ← stands for
deleting the previous character.
In numeral input mode: _ stands for clear and ← stands for deleting the
previous numeral.
Double left
click mouse
Implement special control operation such as double click one item in the file list
to playback the video.
In multiple-window mode, double left click one channel to view in full-window.
Double left click current video again to go back to previous multiple-window
mode.
Right click
mouse
In real-time monitor mode, pops up shortcut menu.
Exit current menu without saving the modification.
Press middle
button
In numeral input box: Increase or decrease numeral value.
Switch the items in the check box.
Page up or page down
Move mouse
Select current control or move control
Drag mouse
Select motion detection zone

8
Select privacy mask zone.

9
3 Device Installation
Note: All the installation and operations here should conform to your local electric safety rules.
3.1 Check Unpacked NVR
When you receive the NVR from the forwarding agent, please check whether there is any visible damage.
The protective materials used for the package of the NVR can protect most accidental clashes during
transportation. Then you can open the box to check the accessories.
Please check the items in accordance with the list. Finally you can remove the protective film of the NVR.
3.2 About Front Panel and Rear Panel
The model number in the stick on the bottom of NVR is very important; please check according to your
purchase order.
The label in the rear panel is very important too. Usually we need you to represent the serial number
when we provide the service after sales.
3.3 HDD Installation
Important：
Please turn off the power before you replace the HDD.
The pictures listed below for reference only.
For the first time install, please be aware that whether the HDDs have been installed.
You can refer to the Appendix for HDD space information and recommended HDD brand. Please use
HDD of 7200rpm or higher. Usually we do not recommend the PC HDD.
Please follow the instructions below to install hard disk.
○
1. Loosen the screws of the upper
cover and side panel.
○
2Fix four screws in the HDD
(Turn just three rounds).
○
3Place the HDD in
accordance with the four holes
in the bottom.

10
○
4Turn the device upside down and
then turn the screws in firmly.
○
5Fix the HDD firmly.
○
6Connect the HDD cable
and power cable.
○
7Put the cover in accordance with
the clip and then place the upper cover
back.
○
8Secure the screws in the rear panel and the side panel.
