COMBI OVEN-STEAMER
Options & Accessories
SECT. IIB PAGE 12
0707
by
by
Cleveland
Cleveland
™
Kleensteam II
(with Prefilter, two Carbon-Block Cartridges & one Scale Stick Cartridge)
Cleveland Standard Features :
Kleensteam II:
nRecommended water filter system for all Cleveland Combi
models, delivering high quality filtered water with scale inhibition
nSystem includes: one prefilter, two carbon-block cartridges and
one scale stick cartridge.
nDual cartridge design provides enhanced performance for low or
high flow capacity steamers
n2 five micron carbon block filters improve performance, maximize
energy efficiency and increase the life of combi oven steamers
nReduces chlorine-induced corrosion
nLong lasting SS-10 cartridge is more effective in higher
alkalinity/hardness/TDS/temperature installations.
nSophisticated Hydroblend compound prevents limescale
formation in high temperature steam applications
nSystem is simple to install, operate and maintain
Prefilter:
nFilters out larger dirt and rust particles
nExtends the life of primary filter cartridges
nTightly spun EC210 sediment cartridge delivers 10 micron
nominal filtration
nDurable slim bowl design makes cartridge change outs easy to
handle
nClear housing allows for visually inspection of trapped particles
and makes determining when to change the cartridge easy
Short Form Specifications
Shall be Cleveland Model C9797-K2PF Kleensteam II with one prefilter, two
carbon-block cartridges and one scale stick cartridge, dual cartridge design
for low or high flow capacity steamers, 2 five micron carbon block filters and
SS-10 cartridge for higher alkalinity/hardness/TDS/temperature installations.
Kleensteam II
Prefilter
MODEL:cC9797-K2PF

NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers.
SECT.IIB PAGE 13
0707
20.50”
521mm
5.16”
131mm
25.50”
521mm
22.44”
570mm
Outlet to
Combi
Oven-Steamer
Inlet
3/4” FNPT
Kleensteam IIPrefilter
Technical Data
Overall Dimensions: 25.5”H x 20.5”W x 7”D
Inlet Connection: 3/4” FNPT
Outlet Connection: 3/4” FNPT
Service Flow Rate: Maximum 3.5 gpm (13.2 Lpm) - twin cartridges
Pressure Requirements: 10 - 125 psi (0.7 – 8.6 bar), non-shock
Maximum Water Temperature at Inlet: 100°F (38°C)
Alkalinity Range: 2 to 12 grains per gallon
Electrical: No electrical connection required
Shipping Weight: 34 lbs.
Operating Weight: 42 lbs.
The contaminants or other substances removed or reduced by this
drinking water system are not necessarily in your water. Do not
use with water that is microbiologically unsafe or of unknown
quality without adequate disinfection before or after the system.
Systems certified for cyst reduction may be used with disinfected
water that may contain filterable cysts.
NSF Certified under NSF/ANSI Standard 42 for materials
