Clevo N850HP6 User manual

Contents
About this Concise User Guide .........................................................1
System Startup ..................................................................................4
System Map: Front View with LCD Panel Open ............................5
LED Indicators ..................................................................................6
Keyboard ...........................................................................................7
Function Keys & Visual Indicators ...................................................8
System Map: Front, Rear & Bottom Views ....................................11
System Map: Left & Right Views .................................................12
Control Center .................................................................................13
Memory Overclocking Support ......................................................15
Flexikey® Application ....................................................................17
Windows 10 Start Menu, Context Menu, Taskbar, Control Panel
and Settings .....................................................................................21
Video Features ................................................................................22
Audio Features ................................................................................24
Power Options .................................................................................25
Driver Installation ...........................................................................26
TPM (Option) ..................................................................................27
3G/4G Module (Option) .................................................................28
Troubleshooting ..............................................................................29
Specifications ..................................................................................30
Inhalt
Über das Ausführliche Benutzerhandbuch ......................................33
Schnellstart ......................................................................................36
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm ..............................................................................37
LED-Anzeigen ................................................................................38
Tastatur ............................................................................................39
Funktionstasten & visuelle Anzeigen ..............................................40
Systemübersicht: Ansicht vorne, hinten & unten ............................43
Systemübersicht: Ansicht von links & rechts .................................44
Control Center .................................................................................45
Unterstützung für Speicher-Übertaktung ........................................47
Flexikey® Anwendung ...................................................................49
Start-Menü, Kontextmenü, Taskleiste, Systemsteuerung und
Einstellungen von Windows 10 .......................................................53
Grafikfunktionen .............................................................................54
Audiofunktionen ..............................................................................56
Energieoptionen ..............................................................................57
Installation der Treiber ....................................................................58
TPM (Option) ..................................................................................59
3G/4G-Modul (Option) ...................................................................60
Fehlerbehebung ...............................................................................61
Technische Daten ............................................................................62

Sommaire
A propos de ce Guide Utilisateur Concis ........................................65
Guide de démarrage rapide .............................................................68
Carte du système: Vue de face avec l’écran LCD ouvert ..............69
Indicateurs LED ..............................................................................70
Clavier .............................................................................................71
Touches de fonctions & indicateurs visuels ....................................72
Carte du système: Vues de face, arrière et dessous ........................75
Carte du système: Vues de gauche et droite .................................76
Control Center .................................................................................77
Prise en charge du surfréquençage de la mémoire ..........................79
Application Flexikey® ....................................................................81
Menu Démarrer, Menu contextuel, Barre des tâches, Panneau de
Configuration et Paramètres de Windows 10 .................................85
Caractéristiques vidéo .....................................................................86
Caractéristiques audio .....................................................................88
Options d’alimentation ....................................................................89
Installation du pilote .......................................................................90
TPM (Option) ..................................................................................91
Module 3G/4G (Option) .................................................................92
Dépannage .......................................................................................93
Spécifications ..................................................................................94
Contenidos
Acerca de esta Guía del Usuario Concisa .......................................97
Guía rápida para empezar ..............................................................100
Mapa del sistema: Vista frontal con panel LCD abierto ...............101
Indicadores LED ...........................................................................102
Teclado ..........................................................................................103
Teclas de función & indicadores visuales .....................................104
Mapa del sistema: Vistas frontal, posterior e inferior ...................107
Mapa del sistema: Vistas izquierda y derecha .............................108
Control Center ...............................................................................109
Soporte de Overclocking de Memoria ..........................................111
Aplicación Flexikey® ...................................................................113
Menú Inicio, Menú contextual, Barra de tareas, Panel de Control
y Configuración de Windows 10 ...................................................117
Parámetros de vídeo ......................................................................118
Opciones de energía ......................................................................120
Características de audio .................................................................121
Instalación de controladores ..........................................................122
TPM (Opción) ...............................................................................123
Módulo 3G/4G (Opción) ...............................................................124
Solución de problemas ..................................................................125
Especificaciones ............................................................................126

III
Sommario
Informazioni su questa guida rapida .............................................129
Guida di avvio rapido ....................................................................132
Descrizione del sistema: Vista anteriore con pannello
LCD aperto .................................................................................133
Indicatori LED ..............................................................................134
Tastiera ..........................................................................................135
Tasti funzione e indicatori visivi ...................................................136
Descrizione del sistema: Vista anteriore, posteriore e inferiore ...139
Descrizione del sistema: Vista sinistra e destra ............................140
Control Center ...............................................................................141
Supporto di overclock di memoria ................................................143
Applicazione Flexikey® ...............................................................145
Menu Start, Menu contestuale, Barra delle applicazioni,
Pannello di controllo e Impostazioni di Windows 10 ...................149
Funzioni video ..............................................................................150
Funzionalità audio .........................................................................152
Opzioni risparmio energia .............................................................153
Installazione driver ........................................................................154
TPM (Opzione) .............................................................................155
Modulo 3G/4G (Opzione) .............................................................156
Risoluzione dei problemi ..............................................................157
Specifiche tecniche .......................................................................158

1
English
About this Concise User Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for the
expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’s Manual
disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper operation of
the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information contained in the expanded User’s Man-
ual on the Device Drivers & Utilities + User’s Manual disc.
© March 2017
Trademarks
Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.

FCC Statement
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2.This device must accept any
interference received, includ-
ing interference that may
cause undesired operation.

2
English
Instructions for Care and Opera-
tion
The computer is quite rugged, but it can be damaged. To
prevent this, follow these suggestions:
•Don’t drop it, or expose it to shock. If the computer falls, the
case and the components could be damaged.
•Keep it dry, and don’t overheat it. Keep the computer and
power supply away from any kind of heating element. This is an
electrical appliance. If water or any other liquid gets into it, the
computer could be badly damaged.
•Avoid interference. Keep the computer away from high capacity
transformers, electric motors, and other strong magnetic fields.
These can hinder proper performance and damage your data.
•Follow the proper working procedures for the computer. Shut
the computer down properly and don’t forget to save your work.
Remember to periodically save your data as data may be lost.
• Note that in computer’s featuring a raised LCD electro-plated
logo, the logo is covered by a protective adhesive. Due to general
wear and tear, this adhesive may deteriorate over time and the
exposed logo may develop sharp edges. Be careful when handling
the computer in this case, and avoid touching the raised LCD
electro-plated logo. Avoid placing any other items in the carrying
bag which may rub against the top of the computer during trans-
port. If any such wear and tear develops contact your service cen-
ter.
Power & Battery Safety
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual.
• Your AC/DC adapter may be designed for international travel but
it still requires a steady, uninterrupted power supply. If you are
unsure of your local power specifications, consult your service
representative or local power company.
• The AC/DC adapter may have either a 2-prong or a 3-prong
grounded plug. The third prong is an important safety feature; do
not defeat its purpose. If you do not have access to a compatible
outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it
by the plug head, not by its wire.
• Make sure the socket and any extension cord(s) you use can sup-
port the total current load of all the connected devices.
• Make sure that your computer is completely powered off before
putting it into a travel bag (or any such container).
• Only use batteries designed for this computer. The wrong battery
type may explode, leak or damage the computer.
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in fire.
• Recharge the batteries using the computer’s system. Incorrect
recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair
or replacement to your service representative or qualified service
personnel.
• Keep children away from, and promptly dispose of a damaged
battery. Always dispose of batteries carefully. Batteries may
explode or leak if exposed to fire, or improperly handled or dis-
carded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not dispose of batteries in a fire. They may explode. Check
with local codes for possible special disposal instructions.
• Do not touch the battery contacts with your hands or metal
objects.

3
English
Polymer Battery Precautions
Note the following information which is specific to poly-
mer batteries only, and where applicable, this overrides
the general battery precaution information.
• Polymer batteries may experience a slight expansion or swelling,
however this is part of the battery’s safety mechanism and is not a
cause for concern.
• Use proper handling procedures when using polymer batteries.
Do not use polymer batteries in high ambient temperature envi-
ronments, and do not store unused batteries for extended periods.
Cleaning
• Use a soft clean cloth to clean the computer, but do not apply
cleaner directly to the computer.
• Do not use volatile (petroleum distillates) or abrasive cleaners on
any part of the computer.
•(For Computer Models Supplied with Light Blue Cleaning
Cloth) Some computer models in this series come supplied with a
light blue cleaning cloth. To clean the computer case with this
cloth follow the instructions below.
• Power off the computer and peripherals.
• Disconnect the AC/DC adapter from the computer.
• Use a little water to dampen the cloth slightly.
• Clean the computer case with the cloth.
• Dry the computer with a dry cloth, or allow it time to dry
before turning on.
• Reconnect the AC/DC adapter and turn the computer on.
Servicing
Attempting to service the computer yourself may violate
your warranty and expose you and the computer to electric
shock. Refer all servicing to qualified service personnel,
particularly under any of the following conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the
operating instructions.
• If the computer has been dropped or damaged (do not touch the
poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your com-
puter.

Battery Disposal & Caution
The product that you have purchased contains a recharge-
able battery. The battery is recyclable. At the end of its use-
ful life, under various state and local laws, it may be illegal
to dispose of this battery into the municipal waste stream.
Check with your local solid waste officials for details in your
area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Re-
place only with the same or equivalent type recommended
by the manufacturer. Discardused battery according to the
manufacturer’s instructions.

4
English
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and make sure it is locked in
position.
4. Securely attach any peripherals you want to use
with the computer (e.g. keyboard and mouse) to
their ports.
5. Attach the AC/DC adapter to the DC-In jack on the
left of the computer, then plug the AC power cord
into an outlet, and connect the AC power cord to
the AC/DC adapter (make sure you use the
adapter when first setting up the computer, as
to safeguard the computer during shipping the
battery will be locked to not power the system until
first connected to the AC/DC adapter).
6. Use one hand to raise the
lid/LCD to a comfortable
viewing angle
(do not exceed 130 degrees) ; use
the other hand (as illustrated in Figure 1) to
support the base of the computer (Note: Never lift
the computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
System Software
Your computer may already come with system
software pre-installed. Where this is not the
case, or where you are re-configuring your
computer for a different system, you will find
this manual refers to Microsoft Windows 10.
Figure 1
Opening the Lid/LCD/
Computer with AC/DC
Adapter Plugged-In

Shut Down
Note that you should always shut
your computer down by choosing the
Shut down command in Windows
(see below). This will help prevent
hard disk or system problems.
1. Click the Start
Menu icon .
2. Click the Power
item .
3. Choose Shut
Down from the
menu.
130°

5
English
System Map: Front View with LCD Panel Open
Figure 2
Front View with LCD Panel
Open
1. PC Camera
2. *PC Camera LED
*When the PC camera is in
use, the LED will be
illuminated.
3. Built-In Array Microphone
4. LCD
5. Power Button
6. Keyboard
7. Touchpad & Buttons
5
7
6
2 13
4

Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft
is usually prohibited.
Make sure the WLAN,
Bluetooth & 3G/4G
module(s) are OFF if
you are using the com-
puter aboard aircraft by
putting the system in to
Airplane Mode.
3
Note that the Touchpad and
Buttons valid operational
area is that indicated within
the red dotted lines.
7

6
English
LED Indicators
The LED indicators on the computer display helpful information about the current status of the computer.
Table 1 - LED Indicators
Icon Color Description
Orange The AC/DC Adapter is Plugged In
Green The Computer is On
Blinking Green The Computer is in Sleep Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking Orange The Battery Has Reached Critically Low Power Status
Green Airplane Mode is ON (the WLAN, Bluetooth & 3G/4G Modules are OFF)
Green The Hard Diske is in use

7
English
Keyboard
The keyboard, white-LED illuminated keyboard or full color illuminated keyboard (Factory Option), includes a nu-
meric keypad (on the right side of the keyboard) for easy numeric data input. Pressing Num Lk turns on/off the numeric
keypad. It also features function keys to allow you to change operational features instantly.
White-LED Illuminated Keyboard
The keyboard illumination level may be adjusted, or turned off/on, by using the Fn + F4 keys.
(Factory Option) Full Color Illuminated Keyboard
Refer to Colored Keyboard Backlight LED on page 9.
Figure 3 - Keyboard
Function Keys Num Lk &
Scr Lk
Numeric
Keypad
Fn Key
Windows Logo Key
Menu/Application Key
Function Keys Num Lk &
Scr Lk
Numeric
Keypad
Fn Key
Windows Logo Key
Menu/Application Key

8
English
Function Keys & Visual Indicators
The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the
basic function key combinations, some visual indicators are available when the Control Center driver is installed.
Keys Function/Visual Indicators Keys Function/Visual Indicators
Fn + Play/Pause (in Audio/Video Programs) Fn + Airplane Mode Tog-
gle
Fn + Touchpad Toggle Fn + Sleep Toggle
Fn + Turn LCD Backlight Off
(Press a key to or use Touchpad to turn on) Number Lock Toggle
Fn + Mute Toggle Fn + Scroll Lock Toggle
Fn + Toggle Keyboard Illumi- nation/Adjust Bright-
ness Level (for White LED Key-
boards)
Caps Lock Toggle
Fn + Volume Decrease/
Increase Fn + Control Center Toggle (see page 13)
Fn + Change Display Configuration (see page 23)Fn + Fan Automatic Con-
trol/ Full Power
Fn + Brightness Decrease/
Increase Fn + Disable/Enable
Flexikey® (see page
17)
Fn + PC Camera Power
Toggle Table 2 - Function Keys & Visual Indicators

9
English
Colored Keyboard Backlight LED
(For Illuminated Colored Keyboards Only)
Press Fn plus the key to toggle the keyboard LED on/
off. The keyboard LED may be configured using the Fn +
key combination outlined in the table below. In addition
press Fnplus the key to launch the keyboard backlight
application to configure the settings.
Table 3 - Keyboard LEDs
Keyboard Backlight Application
The Keyboard Backlight application can be accessed by
pressing the Fn plus key.
Modes
The buttons surrounding the swatch allow you to alter the
effects of the keyboard backlight. Click on any of the but-
tons to view the effects on the keyboard. Click Save when
exiting the application to retain the setting.
Table 4 - Mode Buttons
Keyboard LED Function key Combinations
Fn + Launch the Keyboard Backlight Application
Fn + Toggle the Keyboard LED On/Off
Fn + Keyboard LED Illumination Decrease
Fn + Keyboard LED Illumination Increase
Fn + Toggle the Left keyboard LED On/Off
Fn + Toggle the Middle keyboard LED On/Off
Fn + Toggle the Right keyboard LED On/Off
1
2
3
13
2
Mode Buttons
Random Color Wave Up/Down
Custom - Display & Configure
Keyboard Sections & Colors Dancing Effect
Breathe (All Colors) Tempo Beat
Cycle Colors Flashing
Figure 4
Keyboard
Backlight
Application

10
English
Brightness
Click on any of the numbers (0 - 3) on the brightness bar
to set the brightness level of the keyboard backlight.
Color Swatch
The color swatch in the top right of the screen allows you
to select a range of colors for your keyboard backlight by
clicking on the color required. You can choose to display
the swatch either in Full Color or as an 256 Color
Scheme. Click the Custom mode button to select any col-
ors from the swatch and to apply your chosen colors to
parts of the keyboard.
Figure 5 - Color Swatch
Preview
The bottom left section of the application allows you to
preview setting changes made to colors on the keyboard.
Keyboard Sections
The bottom right section of the application allows you to
select partial areas, or all, of the keyboard on which to ap-
ply the color changes and effects.
Sets
The application allows you to save up to 3 sets of color
and effect combinations. Click Save when exiting the ap-
plication to retain the settings.
Save & Exit
Click Exit to quit the application without saving, or Save
to exit and retain the settings.
Figure 6
Preview
Figure 7
Keyboard
Sections

11
English
System Map: Front, Rear & Bottom Views
Figure 8
Front, Rear & Bottom Views
1. LED Indicator
2. Vent
3. Battery
4. Speakers
1
44
3
Overheating
To prevent your computer from
overheating make sure nothing
blocks any vent while the com-
puter is in use.
Bottom Cover Removal
Warning
Do not remove any cover(s) and/
or screw(s) for the purposes of
device upgrade as this may vio-
late the terms of your warranty.
If you need to replace/remove
the hard disk/RAM etc., for any
reason, please contact your dis-
tributor/supplier for further infor-
mation.
2
Front
Rear
2
2
2
2

12
English
System Map: Left & Right Views
1
Left
13
28
46
3
Right
5
11
7
12 14
10
9
Figure 9
Left & Right Views
1. DC-In Jack
2. RJ-45 LAN Jack
3. Mini DisplayPort 1.2
4. Mini DisplayPort 1.3
5. HDMI-Out Port
6. USB 3.0 (USB 3.1 Gen 1)
Type-C Port
Or
(Factory Option) USB 3.1
Gen 2 Type-C Port
7. USB 3.0 (USB 3.1 Gen 1)
Type-A Port
Or
(Factory Option) USB 3.1
Gen 2 Type-A Port
8. Multi-in-1 Card Reader
9. Headphone-Out Jack
10. Microphone-In Jack
11. USB 2.0 Port
12. USB 3.0 (USB 3.1 Gen 1)
Type-A Port
13. Vent
14. Security Lock Slot

Mini DisplayPorts / HDMI-Out Port
All external and internal displays (up to 4 active displays) can be configured from Windows
by using the Display or System control panels, or the + Por Fn + F7 key combina-
tion. In addition to the Windows controls, you can use any of the following to configure ex-
ternal displays attached to a particular port.
Mini DisplayPort 1.2 : If you wish to configure an external display connected to Mini
DisplayPort 1.2 use the Intel HD Graphics control panel to configure the display.
Mini DisplayPort 1.3 : If you wish to configure an external display connected to Mini
DisplayPort 1.3 use the NVIDIA Control Panel to configure the display.
HDMI-Out Port : If you wish to configure an external display connected to the HDMI-
Out port use the NVIDIA Control Panel to configure the display.
Note that this computer supports virtual reality (VR) headsets, however VR headsets
must be connected to Mini DisplayPort 1.3 or HDMI-Out port .
3
4
5
4
5

13
English
Control Center
Press the Fn + Esc key combination,
or double-click the icon in the no-
tification area of the taskbar to tog-
gle the Control Center on/off. The
Control Center gives quick access to
frequently used controls and enables
you to quickly turn the camera/Touch-
pad on/off.
Power Modes
You can set a Power Mode by click-
ing the appropriate icon at the top of
the Control Center. Each power
mode will affect the Power Conserva-
tion Mode, Airplane Mode, Power
Plan and PC camera power etc.
Control Center Menus
The Control Center contains 3 menu
headings (System Program, Device
and Gaming) under the Power Modes.
Click the Control Center icons to
toggle the appropriate function, or
hold the mouse button down and move
the dial control where applicable. Cer-
tain functions will automatically be
adjusted when a power mode is select-
ed. Click the menu headings and then
click any of the buttons.
Power Status
The Power Status icon will show
whether you are currently powered by
the battery, or by the AC/DC adapter
plugged in to a working power outlet.
The power status bar will show the
current battery charge state.
Brightness
The Brightness icon will show the
current screen brightness level. You
can use the slider to adjust the screen
brightness or the Fn+ F8/F9key com-
binations, or use the Fn + F2 key com-
bination to turn off the LED backlight
(press any key to turn it on again).
Note that screen brightness is also ef-
fected by the Power Mode selected.
Volume
The Volume icon will show the cur-
rent volume level. You can use the
slider to adjust the volume or the Fn +
F5/F6 key combinations, or use the
Fn + F3 key combination to mute the
volume.
Power Conservation
This system supports Energy Star
power management features that place
computers (CPU, hard drive, etc.) into
a low-power sleep mode after a desig-
nated period of inactivity. Click either
the Performance, Balanced or Pow-
er Saving button.
Figure 10 - Control Center

14
English
Fan Speed
The fan speed will adjust itself auto-
matically to control the heat of the
CPU. However you can adjust the set-
ting to maximum if you prefer. Select
Custom and click on the sliders to ad-
just the settings to your preference,
however these settings can be overid-
den by the system, as a safety precau-
tion, if it requires heavier use of the fan.
Sleep Button
Click either the Hibernate or Sleep
button to have the computer enter the
selected power-saving mode.
Display Switch
Click the Display Switch button to ac-
cess the menu (or use the + P key
combination) and select the appropri-
ate display mode.
Time Zone
Clicking the Time Zone button will
access the Date and Time Windows
control panel.
Desktop Background
Clicking the Desktop Background
button will allow you to change the
desktop background picture.
Touchpad/PC Camera
Click either of these buttons to toggle
the Touchpad or camera module’s
power status. Note that the power sta-
tus of the camera module is also ef-
fected by the Power Mode selected.
Left Windows Key
Click Disable to disable the Windows
Key on the left side of the keyboard.
This may be useful if you are using the
gaming keys (W, A, S & D) and wish
to avoid accidentally triggering menus
with the Windows Key.
Backlight Keyboard (For White-
LED Keyboards)
Click the numbers under
the Backlight Keyboard icon
to adjust the brightness of the
keyboard backlight LED.
Flexikey®
Click the button to access
the Flexikey® application.

15
English
Memory Overclocking Support
You can enable overclocking support for systems with a compatible CPU (contact your distributor/supplier for details)
and memory (note that your system must have 2 DIMMs installed to support memory overclocking). This can be
done in the BIOS or by using the Control Center utility (make sure you have installed the Control Center AP).
You can access the CPU Memory Overclocking utility from the Control Center or taskbar notification area.

Overclocking Issues
If you get any system errors, e.g. a
black screen, to reset the com-
puter press and hold the power
button to force the system to
shutdown. To restart press and
hold the power button while
holding down the Fn + D keys.
This will change the overclocking
settings back to the disabled
state.
Note overclocking the system may
cause hardware damage and is
enabled at the user’s own risk,
and is not covered in the warran-
ty terms.Figure 11 - Access the Memory Overclocking Utility

16
English
Memory Overclocking
1. Click the Memory tab at the bottom right of the screen and the Memory overclocking tab will pop out to allow adjustments to be made.
2. Click Custom to adjust any settings from the drop-down menus.
3. Click Save to retain the settings.
4. A warning will pop-up to remind that you will need to restart the system (make sure you save any open files).
5. Click Restart Now to restart the system or Cancel to return to the utility.
6. You can click Default to go back to the standard default settings.
Figure 12 - Memory Overclocking
