Clevo M740TUN User manual

Preface
I
Preface
Notebook Computer
M740TUN/ M760TUN
Service Manual

Preface
II
Preface
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information contained
herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven-
dor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are
they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or
reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publica-
tion, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of
their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement
of that product or its manufacturer.
Version 1.0
March 2009
Trademarks
Intel and Intel Core are trademarks of Intel Corporation.
Windows®is a registered trademark of Microsoft Corporation.
Other brand and product names are trademarks and /or registered trademarks of their respective companies.

Preface
III
Preface
About this Manual
This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and
inspection of personal computers.
It is organized to allow you to look up basic information for servicing and/or upgrading components of the M740TUN/
M760TUN series notebook PC.
The following information is included:
Chapter 1, Introduction, provides general information about the location of system elements and their specifications.
Chapter 2, Disassembly, provides step-by-step instructions for disassembling parts and subsystems and how to upgrade
elements of the system.
Appendix A, Part Lists
Appendix B, Schematic Diagrams
Appendix C, Updating the FLASH ROM BIOS

Preface
IV
Preface
IMPORTANT SAFETY INSTRUCTIONS
Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per-
sons when using any electrical equipment:
1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of elec-
trical shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.
5. This product is intended to be supplied by a Listed Power Unit with an AC Input of 100 - 240V, 50 - 60Hz, DC Output
of 19V, 4.74A (90 Watts) minimum AC/DC Adapter.
CAUTION
Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment.
TO REDUCE THE RISK OF FIRE, USE ONLY NO. 26 AWG OR LARGER,
TELECOMMUNICATION LINE CORD
This Computer’s Optical Device is a Laser Class 1 Product

Preface
V
Preface
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating element. This
is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
3. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save
your work. Remember to periodically save your data as data may be lost if the battery is depleted.
Do not expose the computer
to any shock or vibration. Do not place it on an unstable surface. Do not place anything heavy on the computer.
Do not expose it to excessive
heat or direct sunlight. Do not leave it in a place where foreign matter or mois-
ture may affect the system.
Don’t use or store the com-
puter in a humid environment. Do not place the computer on any surface which will block
the vents.
Do not turn off the power
until you properly shut down
all programs.
Do not turn off any peripheral
devices when the computer is
on.
Do not disassemble the com-
puter by yourself. Perform routine maintenance on your computer.

Preface
VI
Preface
4. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag-
netic fields. These can hinder proper performance and damage your data.
5. Take care when using peripheral devices.
Power Safety
The computer has specific power requirements:
• Only use a power adapter approved for use with this computer.
• Your AC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are
unsure of your local power specifications, consult your service representative or local power company.
• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third prong is an important safety feature; do
not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it by the plug head, not by its wire.
• Make sure the socket and any extension cord(s) you use can support the total current load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external power supplies.
Use only approved brands of
peripherals. Unplug the power cord before attaching peripheral devices.
Do not plug in the power
cord if you are wet. Do not use the power cord if it is broken. Do not place heavy objects on the power cord.

Power Safety
Warning
Before you undertake
any upgrade proce-
dures, make sure that
you have turned off the
power, and discon-
nected all peripherals
and cables (including
telephone lines). It is
advisable to also re-
move your battery in
order to prevent acci-
dentally turning the
machine on.

Preface
VII
Preface
Battery Precautions
• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
• Do not remove any batteries from the computer while it is powered on.
• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service
personnel.
• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries may explode
or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not touch the battery contacts with your hands or metal objects.

Battery Disposal
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of
its useful life, under various state and local laws, it may be illegal to dispose of this battery into the municipal
waste stream. Check with your local solid waste officials for details in your area for recycling options or proper
disposal.
Caution
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommend-
ed by the manufacturer. Discard used battery according to the manufacturer’s instructions.

Preface
VIII
Preface
Related Documents
You may also need to consult the following manual for additional information:
User’s Manual on CD
This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro-
gram. It also describes the installation and operation of the utility programs provided with the notebook PC.

Preface
IX
Preface
Contents
Introduction ..............................................1-1
Overview .........................................................................................1-1
System Specifications .....................................................................1-2
External Locator - Top View with LCD Panel Open ......................1-5
External Locator - Front & Right side Views .................................1-6
External Locator - Left Side & Rear View .....................................1-7
External Locator - Bottom View .....................................................1-8
Mainboard Overview - Top (Key Parts) .........................................1-9
Mainboard Overview - Bottom (Key Parts) ..................................1-10
Mainboard Overview - Top (Connectors) .....................................1-11
Mainboard Overview - Bottom (Connectors) ...............................1-12
Disassembly ...............................................2-1
Overview .........................................................................................2-1
Maintenance Tools ..........................................................................2-2
Connections .....................................................................................2-2
Maintenance Precautions .................................................................2-3
Disassembly Steps ...........................................................................2-4
Removing the Battery ......................................................................2-5
Removing the Hard Disk Drive .......................................................2-6
Removing the Optical (CD/DVD) Device ......................................2-9
Removing the System Memory (RAM) ........................................2-11
Removing the Inverter Board ........................................................2-13
Removing and Installing the Processor .........................................2-14
Removing the Wireless LAN Module ...........................................2-17
Removing the Bluetooth Module ..................................................2-18
Removing the Keyboard ................................................................2-19
Removing the Modem ...................................................................2-20
Part Lists ..................................................A-1
Part List Illustration Location ........................................................A-2
Top with Fingerprint (M740TUN) ................................................ A-3
Top with Fingerprint (M760TUN) ................................................ A-4
Top without Fingerprint (M740TUN) ........................................... A-5
Top without Fingerprint (M760TUN) ........................................... A-6
Bottom (M740TUN) ...................................................................... A-7
Bottom (M760TUN) ...................................................................... A-8
LCD (M740TUN) .......................................................................... A-9
LCD (M760TUN) ........................................................................ A-10
DVD DUAL DRIVE (M760TUN) .............................................. A-11
DVD SUPER-MULTI (M740TUN) ............................................ A-12
Schematic Diagrams.................................B-1
System Block Diagram ...................................................................B-2
Clock Generator ..............................................................................B-3
Penryn (Socket-P) CPU 1/2 ............................................................B-4
Penryn (Socket-P) CPU 2/2 ............................................................B-5
CANTIGA 1/7, Host .......................................................................B-6
CANTIGA 2/7, Graphics ................................................................B-7
CANTIGA 3/7 ................................................................................B-8
CANTIGA 4/7 ................................................................................B-9
CANTIGA 5/7 ..............................................................................B-10
CANTIGA 6/7 ..............................................................................B-11
CANTIGA 7/7 ..............................................................................B-12
DDRII SO-DIMM - 0 ...................................................................B-13
DDRII SO-DIMM - 1 ...................................................................B-14
Panel, Inverter, CRT .....................................................................B-15
VGA N10M-1 ...............................................................................B-16
VGA N10M-2 ...............................................................................B-17
VGA N10M-3 ...............................................................................B-18
VGA N10M-4 ...............................................................................B-19
VGA N10M-5 ...............................................................................B-20

Preface
X
Preface
VGA N10M-6 ..............................................................................B-21
VGA N10M-7 ..............................................................................B-22
ICH9M 1/4, SATA .......................................................................B-23
ICH9M 2/4, PCI, USB .................................................................B-24
ICH9M 3/4 ................................................................................... B-25
ICH9M 4/4 ................................................................................... B-26
New Card, Mini PCIE ..................................................................B-27
3G, Powergood .............................................................................B-28
USB, Fan, TP, FP, Multi CON ..................................................... B-29
Card Reader ..................................................................................B-30
SATA ODD, LED, Hotkey, LID SW ...........................................B-31
PCI-E LAN RTL8111C ...............................................................B-32
Audio Codec ALC662 .................................................................. B-33
Audio AMP ..................................................................................B-34
KBC-ITE IT8512E .......................................................................B-35
5VS, 3VS, 3.3VM, 1.05VS, VIN1 ...............................................B-36
Power 3.3V/5V .............................................................................B-37
Power 1.5VS/1.05VS ...................................................................B-38
Power 1.8V/0.9V ..........................................................................B-39
Power GPU/NVVDD ...................................................................B-40
AC-IN, Charger ............................................................................B-41
VCORE ........................................................................................B-42
NVVDD .......................................................................................B-43
HDMI ...........................................................................................B-44
External ODD Board for M76 ......................................................B-45
Click & Finger Board for M76 ..................................................... B-46
Multi Function Board ...................................................................B-47
Audio Board .................................................................................B-48
Finger Sensor Board for M76 .......................................................B-49
Power Switch Board for M74 .......................................................B-50
FingerPrint Board for M74 ........................................................... B-51
Power Switch Board for M76 .......................................................B-52
Updating the FLASH ROM BIOS......... C-1
Download the BIOS ........................................................................ 2-1
Unzip the downloaded files to a bootable CD/DVD/ or USB Flash
drive ................................................................................................ 2-1
Set the computer to boot from the external drive ........................... 2-1
Use the flash tools to update the BIOS ........................................... 2-2
Restart the computer (booting from the HDD) ............................... 2-2

Introduction
Overview 1 - 1
1.Introduction
Chapter 1: Introduction
Overview
This manual covers the information you need to service or upgrade the M740TUN/ M760TUN series notebook computer.
Information about operating the computer (e.g. getting started, and the Setup utility) isin the User’s Manual. Information
about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.
Operating systems (e.g. Windows XP, Windows Vista, etc.) have their own manuals as do application software (e.g. word
processing and database programs). If you have questions about those programs, you should consult those manuals.
The M740TUN/ M760TUN series notebook is designed to be upgradeable. See “Disassembly” on page 2 - 1 for a de-
tailed description of the upgrade procedures for each specific component. Please note the warning and safety information
indicated by the “” symbol.
The balance of this chapter reviews the computer’s technical specifications and features.

Introduction
1 - 2 System Specifications
1.Introduction
System Specifications
Feature Specification
Processor Intel® Core™2 Duo Processor
(478-pin) Micro-FC-PGA Package, Socket P
TDP: 35W
T9400/ T9600
45nm (45 Nanometer) Process Technology
6MB On-die L2 Cache & 1066MHz FSB
2.53/ 2.8 GHz
Intel® Core™2 Duo Processor
(478-pin) Micro-FC-PGA Package, Socket P
TDP: 25W
P9500
45nm (45 Nanometer) Process Technology
6MB On-die L2 Cache & 1066MHz FSB
2.53 GHz
Intel® Core™2 Duo Processor
(478-pin) Micro-FC-PGA Package, Socket P
TDP: 25W
P8400/ P8600
45nm (45 Nanometer) Process Technology
3MB On-die L2 Cache & 1066MHz FSB
2.26/ 2.40 GHz
Intel® Celeron® Processor
(478-pin) Micro-FC-PGA Package, Socket P
T1600/ T1700
65nm (65 Nanometer) Process Technology
1MB On-die L2 Cache & 667MHz FSB - TDP 35W
1.66/ 1.86 GHz
Intel® Celeron® M Processor
(478-pin) Micro-FC-PGA Package, Socket P
575/ 585
65nm (65 Nanometer) Process Technology
1MB On-die L2 Cache & 667MHz FSB - TDP 31W
2.0/ 2.16 GHz
Core Logic Intel(R) PM45 + ICH9M Chipset
LCD M740TUN:
14.1" WXGA (1280*800)/ WXGA+ (1440*900) Glare Type
TFT LCD
M760TUN:
15.4" WXGA (1280*800)/ WXGA+ (1440*900)/ WSXGA+
(1680*1050) Glare Type TFT LCD
Video Adapter nVIDIA GeForce G105M Discrete Graphics On-Board
512MB of GDDR2 Video Memory On-Board
Supports DirectX 10.0
Supports HDCP
Memory 64-bit Wide DDRII (DDR2) Data Channel
Supports Dual Channel DDR2 SDRAM
Two 200 Pin SO-DIMM Sockets Supporting DDRII (DDR2) 667MHz/ 800MHz
Memory Expandable up to 4GB (1024MB/ 2048MB DDRII Modules)

Introduction
System Specifications 1 - 3
1.Introduction
Security Security (Kensington® Type) Lock Slot
Fingerprint ID Reader Module (Factory Option)BIOS Password
BIOS One 32Mb SPI Flash ROM Phoenix™ BIOS
Storage
One Changeable 12.7mm(h) SATA Optical Device (CD/DVD) Type Drive (see “Optional” on page 1 - 4 )
Easy Changeable 2.5" 9.5 mm (h) SATA (Serial) HDD
Audio Intel® High Definition Audio (HDA) Interface
3D Enhanced Sound System S/PDIF Digital Output 2 * Built-In Speakers (1W, 8Ω)
Built-In Microphone
Keyboard &
Pointing Device Winkey Keyboard Built-In TouchPad with Scrolling Function
Interface Three USB 2.0 Ports
One HDMI-Out Port (High-Definition Multimedia Interface)
One Headphone-Out Jack
One Microphone-In Jack
One S/PDIF-Out Jack
One eSATA Port (supported in Windows Vista only):
AHCI mode supports hot swapping
IDE mode does not support hot swapping
One RJ-11 Modem Jack
One RJ-45 LAN Jack
One DC-In Jack
One External Monitor Port
Card Reader Embedded 7-in-1 Card Reader (MS/ MS Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Duo)
Note: MS Duo/ Mini SD/ RS MMC Cards require a PC adapter
Communication Built-In 56K MDC Modem, V.90 & V.92 Compliant
Built-In Gigabit Ethernet LAN
Bluetooth 2.1 + EDR (Enhanced Data Rate) Module (Factory Option)
1.3M or 2.0M Pixel USB PC Camera Module (Factory Option)
Wireless LAN Module:
Intel® WiFi Link 5300 Series (3*3 - 802.11a/g/n) Wireless LAN Mini-Card Module (Option)
Intel® WiFi Link 5100 Series (1*2 - 802.11a/g/n) Wireless LAN Mini-Card Module (Option)
802.11b/g Wireless LAN Mini-Card Module (Option)
3.5G Module:
UMTS/HSPDA-based 3.75G Module with Mini-Card Interface (Factory Option)
Feature Specification

UMTS Modes
Note that UMTS
modes CAN
NOT be used in
North America.

Introduction
1 - 4 System Specifications
1.Introduction
ExpressCard Slot One ExpressCard/34(54) Slot
Mini-Card Slots
One Mini-Card Slot for Wireless LAN Module
One Mini-Card Slot for 3.5G Module
Power
Management Supports ACPI 3.0 Supports Wake on LAN Supports Resume from Modem Ring
Power Full Range AC/DC Adapter AC input 100 - 240V, 50 - 60Hz, DC Output 19V, 4.74A (90 Watts)
Battery 6 Cell Smart Lithium-Ion Battery Pack, 4000mAH OR 4400mAH
9 Cell Smart Lithium-Ion Battery Pack, 7200mAH (Option)
Environmental
Spec Temperature Operating: 5°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions
& Weight M740TUN:
336mm (w) * 250mm (d) * 24.8-35.7mm (h)
Around 2.3 kg With 6 Cell Battery
M760TUN:
359mm (w) * 268mm (d) * 24.8-37mm (h)
2.6 kg With 6 Cell Battery
Optional Optical Drive Module Options:
Combo/ DVD-Dual (Super Multi) Device Module
Wireless LAN Module:
Intel® WiFi Link 5300/5100 Series (3*3/1*2 -
802.11a/g/n) Wireless LAN Mini-Card Module
802.11b/g Wireless LAN Mini-Card Module
9 Cell Smart Lithium-Ion Battery Pack
1.3M or 2.0M Pixel USB PC Camera Module (Factory
Option)
Fingerprint ID Reader Module (Factory Option)
Intel Turbo Memory (Robson) NAND Flash 2G/4G
Memory Card Module (Factory Option)
Bluetooth 2.1 + EDR (Enhanced Data Rate) Module
(Factory Option)
UMTS/HSPDA-based 3.75G Module with Mini-Card
Interface (Factory Option)
Feature Specification

UMTS Modes
Note that UMTS modes CAN NOT be used in
North America.

Introduction
External Locator - Top View with LCD Panel Open 1 - 5
1.Introduction
External Locator - Top View with LCD Panel Open Figure 1
Top View
1. Optional Built-In
PC Camera
2. LCD
3. Speakers
4. Power Button
5. Hot Key Buttons
6. Keyboard
7. Built-In
Microphone
8. Touchpad &
Buttons
9. Fingerprint
Module (Optional)
10.LED Indicators
M740TUN M760TUN
2
5
1
7
9
4
6
33
10
10 10
2
5
1
7
9
4
6
33
10
88

Introduction
1 - 6 External Locator - Front & Right side Views
1.Introduction
External Locator - Front & Right side Views
Figure 2
Front Views
1. LED Power &
Communication
Indicators
Figure 3
Right Side Views
1. S/PDIF-Out Jack
2. Microphone-In
Jack
3. Headphone-Out
Jack
4. USB 2.0 Port
5. Optical Device
Drive Bay
6. RJ-11 Phone
Jack
7. Security Lock
Slot
1
15 24 367

Introduction
External Locator - Left Side & Rear View 1 - 7
1.Introduction
External Locator - Left Side & Rear View Figure 4
Left Side View
1. DC-In Jack
2. External Monitor
Port
3. RJ-45 LAN Jack
4. e-SATA Port
5. HDMI-Out Port
6. Vent/Fan Intake/
Outlet
7. 2 * USB 2.0 Ports
8. ExpressCard Slot
9. 7-in-1 Card
Reader
135
28
79 467
Figure 5
Rear View
1. Battery
1

Introduction
1 - 8 External Locator - Bottom View
1.Introduction
External Locator - Bottom View
Figure 6
Bottom View
1. Battery
2. Bluetooth
Module Cover
3. RAM & CPU Bay
Cover
4. Vent/Fan Intake/
Outlet
5. Hard Disk Bay
Cover
6. 3.75G USIM
Card Location

Overheating
To prevent your com-
puter from overheating
make sure nothing
blocks the vent/fan in-
takes while the com-
puter is in use.
M740TUN M760TUN
2
3
1
4
4
56
2
3
1
4
4
56
