CLF ARES User manual

CLF ARES LEDWASH
V1.0 December 2015

Dimensions
All dimensions are in millimeters
2

Safety Information
The following symbols are used to identify important safety information on the product and in this manual:
WARNING!
Read the safety precautions in this section before
installing, powering, operating or servicing this
product
DANGER!
Safety hazard.
Risk of severe
injury or death.
DANGER!
Hazardous
voltage. Risk of
lethal or severe
electric shock.
WARNING!
Fire hazard.
WARNING!
LED light
emission. Risk of
eye injury.
WARNING!
Burn hazard. Hot
surface. Do not
touch.
WARNING!
Wear protective
eyewear.
WARNING!
Refer to user
manual.
Warning! Risk Group 3 (high risk) LED product according to EN 62471. Do not look into the beam at a distance
of less than 8.3 meters from the front surface of the product. Do not view the light output with optical
instruments or any device that may concentrate the beam.
l
lAlways ground (earth) the fixture electrically.
lUse only a source of AC power that complies with local building and electrical codes and has both overload and
ground-fault (earth-fault) protection.
lBefore using the fixture, check that all power distribution equipment and cables are in perfect condition and rated for
the current requirements of all connected devices.
lPower input and throughput cables must be rated 20 A minimum, have three conductors 1.5 mm² (16 AWG) minimum
conductor size and an outer cable diameter of 5 - 15 mm. Cables must be hard usage type (SJT or equivalent) and
heat-resistant to 90° C minimum.
lUse only PowerCon true cable connectors to connect to power input sockets. Use only PowerCon true cable
connectors to connect to power throughout sockets.
lIsolate the fixture from power immediately if the power plug or any seal, cover, cable, or other component is
damaged, defective, deformed, wet or showing signs of overheating. Do not reapply power until repairs have been
completed.
This product is for professional use only. It is not for household use.
This product presents risks of severe injury or death due to fire and burn hazards, electric shock and falls.
Read this manual before installing, powering or servicing the fixture, follow the safety precautions listed below and
observe all warnings in this manual and printed on the fixture. If you have questions about how to operate the fixture
safely, please contact your supplier
PROTECTION FROM ELECTRIC SHOCK
Disconnect the fixture from AC power before removing or installing any cover or part and when not in use.
3

lDo not expose the fixture to rain or moisture.
lRefer any service operation not described in this manual to a qualified technician.
lSocket outlets used to supply fixture fixtures with power or external power switches must be located near the fixtures
and easily accessible so that the fixtures can easily be disconnected from power.
lDo not operate the fixture if the ambient temperature (Ta) exceeds 40° C .
lThe exterior of the fixture becomes hot during use. Avoid contact by persons and materials. Allow the fixture to
cool for at least 10 minutes before handling.
lKeep all combustible materials (e.g. fabric, wood, paper) at least 100 mm away from the head.
lKeep flammable materials well away from the fixture.
lEnsure that there is free and unobstructed airflow around the fixture.
lDo not illuminate surfaces within 200 mm of the fixture.
lDo not attempt to bypass thermostatic switches or fuses.
lIf you relay power from one fixture to another using power throughout sockets, do not connect more than five fixtures
in interconnected chain.
lDo not stick filters, masks or other materials onto any optical component.
lDo not modify the fixture in any way not described in this manual
lDo not look continuously at LEDs from a distance of less than 8.3 meters from the front surface of the fixture without
protective eyewear such as shade 4-5 welding goggles. At less than this distance, the LED emission can cause eye
injury or irritation. At distances of 8.3 meters and above, light output is harmless to the naked eye provided that the
eye’s natural aversion response is not overcome.
lDo not look at LEDs with magnifiers, telescopes, binoculars or similar optical instruments that may concentrate the light
output.
lEnsure that persons are not looking at the LEDs from within 8.3 meters when the product lights up suddenly. This can
happen when power is applied, when the product receives a DMX signal, or when SERVICE menu items are selected.
lFasten the fixture securely to a fixed surface or structure when in use. The fixture is not portable when installed.
lEnsure that any supporting structure and/or hardware used can hold at least 10 times the weight of all the devices they
support.
lAllow enough clearance around the head to ensure that it cannot collide with an object or another fixture when
it moves.
lCheck that all external covers and rigging hardware are securely fastened.
lBlock access below the work area and work from a stable platform whenever installing, servicing or moving
the fixture.
lDo not operate the fixture with missing or damaged covers, shields or any optical component.
PROTECTION FROM BURNS AND FIRE
PROTECTION FROM INJURY
4

Contents
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Fixture overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
AC power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Power voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Power cables and power plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Data link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting the data link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Tips for reliable data transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
DMX protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Onboard control menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Control panel and menu navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
DMX address setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
WDMX control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Control mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Dimming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Enable passwork lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Restoring factory default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5
5

Fixture overview
6
Safety cable
attachment point
Display
DMX input
AC mains power
input
G Clamp with
Quicklock # 875760
(Optional)
AC mains power
through
DMX output
Antenna Wireless
Solutions

Introduction
Warning! Read “Safety Information” on page 3 before installing, powering, operating or servicing the
fixture. Before applying power to the fixture:.
lCarefully review “Safety Information” starting on page 3.
lCheck that the local AC mains power source is within the fixture’s power voltage and frequency ranges.
lSee “Power cables and power plug” on page 8. Install a PowerCon input connector on a suitable power
cable. If drawing power from a mains power outlet, install a suitable power plug on the power cable.
Using for the first time
7
lThis CLF Ares fixture features:
l RGBW color control with color temperature control
l‘Color wheel’ color
lOnboard control panel and backlit LCD graphic display
lSmooth electronic dimming
lElectronic shutter with strobe and pulse effects
lCalibrated and raw modes
lEach line can be control independently
=Refresh frequency 600/1200/2400/4800 adjustable
lWireless DMX multimode(2.4GHz) by Wireless Solution Sweden
=Master, Slave Function
=XLR 3-pole DMX standard sockets

AC power
Warning Read “Safety Information” starting on page 3 before connecting the fixrures to AC mains power.
Warning! For protection from electric shock, the fixture must be grounded (earthed). The powerdistribution
circuit must be equipped with a fuse or circuit breaker and ground-fault (earth-fault)protection.
Warning! Socket outlets or external power switches used to supply the fixture with power must be located
near the fixture and easily accessible so that the fixtures can easily be disconnected from power.
Important! Do not insert or remove live PowerCon connectors to apply or cut power, as this may cause arcing at
the terminals that will damage the connectors.
Important! Do not use an external dimming system to supply power to the fixture, as this may cause damage to
the fixture that is not covered by the product warranty.
The can be hard-wired to a building electrical installation if you want to install it permanently, or a power plug that is
suitable for the local power outlets can be installed on the power cable.
,
Warning! Check that the voltage range specified on the fixture s serial number label matches the local AC mains
power voltage before applying power to the fixture.
The fixtures accept AC mains power at 100-240 V nominal, 50/60 Hz. Do not apply AC mains power to the fixture at any
other voltage than that specified on the fixture’s serial number label.
Power input and throughput cables must be rated 20 A minimum, have three conductors 1.5 mm² (16 AWG) minimum
conductor size and an outer cable diameter of 5 - 15 mm. Cables must be hard usage type (SJT or equivalent) and heat-
resistant to 90° C minimum. In the EU the cable must be HAR approved or equivalent.
If you install a power plug on the power cable, install a grounding-type (earthed) plug that is rated 20 A minimum. Follow
the plug manufacturer’s instructions. Table 1 shows standard wire color-coding schemes and some possible pin
identification schemes; if pins are not clearly identified, or if you have any doubts
!
fixture
Power voltage
8
Wire Color
(EU models)
Wire Color
(US models)Conductor Symbol Screw (US)
brown black live L yellow or brass
blue white neutral N silver
yellow/green green ground (earth) or green
Table 1: Wire color-codig and power connections
Power cables and power plug

Data link
A DMX 512 data link is required in order to control a fixture via DMX.
The fixture has 3-pin XLR connectors for DMX data input and output. The pin-out on all connectors is pin 1 = shield,
pin 2 = cold (-), and pin 3 = hot (+).
Or the fixture has 5-pin XLR connectors for DMX data input and output. The pin-out on all connectors is
pin 1 = shield, pin 2 = cold (-), and pin 3 = hot (+). Pins 4 and 5 in the 5-pin XLR connectors are not used
Use shielded twisted-pair cable designed for RS-485 devices: standard microphone cable cannot transmit control data
reliably over long runs. 24 AWG cable is suitable for runs up to 300 meters. Heavier gauge cable and/or an amplifier is
recommended for longer runs.
To connect the fixture to data:
1. Connect the DMX data output from the controller to the closest fixture’s male 3-pin XLR DMX input connector.
2. Connect the DMX output of the fixture closest to the controller to the DMX input of the next fixture and continue
connecting fixtures output to input.
Tips for reliable data transmission
Connecting the data link
9

DMX protocols
21CH
1
2
3
16CH 27CH
1
2
3
30CH
1
2
3
11CH
1
2
3
4CH 9CH
1
2
3
10
DMX Value
0 - 19
20 - 24
25 - 64
65 - 69
70 - 84
85 - 89
90 - 104
105 - 109
110 - 124
125 - 129
130 - 144
145 - 149
150 - 164
165 - 169
170 - 184
185 - 189
190 - 204
205 - 209
210 - 224
225 - 229
230 - 244
245 - 255
0 - 255
0 - 39
40-44
45-49
50-54
55-59
60-64
65-69
70-74
75-89
90 - 94
95 - 99
100 - 104
105 - 109
110 - 114
115 - 119
120 - 124
125 - 129
130 - 134
135 - 139
140 - 144
145 - 149
150 - 154
155 - 159
160 - 164
165 - 169
170 - 174
175 - 179
180 - 239
240 - 244
245 - 249
250 - 255
Function
Electronic shutter effect
Shutter closed
Shutter open
Strobe 1 (fast → slow)
Shutter open
Strobe 2: opening pulse fast → slow
Shutter open
Strobe 3: closing pulse (fast → slow)
Shutter open
Strobe 4: random strobe (fast → slow)
Shutter open
Strobe 5: random opening pulse (fast → slow)
Shutter open
Strobe 6:random closing pulse (fast → slow)
Shutter open
Strobe 7: burst pulse (fast → slow)
Shutter open
Strobe 8: random burst pulse (fast → slow)
Shutter open
Strobe 9:sine wave (fast → slow)
Shutter open
Strobe 10: burst (fast → slow)
Shutter open
Dimmer 0-100% intensity
Fixture control settings
No function
1
SILENT MODE (level 1)-70% fan speed
1
SILENT MODE (level 2)-40% fan speed
1
SILENT MODE (level 3)-20% fan speed
No function
1
Fan mode FULL
1
Fan mode REGULATED
1
Fan mode SILENT
No function
1
Calibrated color output mode- COLOR CALIB = ON
1
output mode - = ON
1
Raw color output mode- COLOR CALIB = OFF
No function
1
Normal dimming, speed of changes unrestricted
No function
1
Smooth dimming, speed of changes restricted slightly
No function
600 Hz Refresh rate
1200Hz Refresh rate
2400Hz Refresh rate
4800Hz Refresh rate
No Function
1
WDMX - ON
No Function
1
WDMX - OFF
No Function
1
WDMX - RESET
No Function
2
DMX
No Function
illuminate display
1 Value must be held for 3 seconds to activate.
2Please refer the page of 15.(calibrate by DMX control)
Value must be held for 3 seconds to activate.
( )
Manual calibration Manual calibration
Manual calibration mode

11
21CH
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
16CH
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
27CH
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
30CH
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
11CH
4
5
6
7
8
9
10
11
4CH
1
2
3
4
9CH
4
5
6
7
8
9
DMX Value
000 - 009
010 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 009
010 - 255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
000-255
0-9
10-19
20-29
......
180-189
190-199
200-255
Function
No Function
Color wheel rotation effect
Red(0-100%)
Green(0-100%)
Blue(0-100%)
White(0-100%)
No Function
Color temperature(2500K-10000K)
LED block 1 dimmer
LED block 1 -Red 1(0-100%)
LED block 1 -Green 1(0-100%)
LED block 1 -Blue 1(0-100%)
LED block 1 -White 1(0-100%)
LED block 1 -Fade(dimmer speed)
LED block 2 dimmer
LED block 2 -Red 2(0-100%)
LED block 2 -Green 2(0-100%)
LED block 2 -Blue 2(0-100%)
LED block 2 -White 2(0-100%)
LED block 2 -Fade(dimmer speed)
LED block 3 dimmer
LED block 3 -Red 3(0-100%)
LED block 3 -Green 3(0-100%)
LED block 3 -Blue 3(0-100%)
LED block 3 -White 3(0-100%)
LED block 3 -Fade(dimmer speed)
LED block 4 dimmer
LED block 4 -Red 4(0-100%)
LED block 4 -Green 4(0-100%)
LED block 4 -Blue 4(0-100%)
LED block 4 -White 4(0-100%)
LED block 4 -Fade(dimmer speed)
NO Function
AUTO 1
AUTO 2
......
AUTO 18
AUTO 19
NO Function
AUTO Speed or Dimmer Speed
AUTO cycle
AUTO speed

12
Onboard control menus
Menu Item Options Notes (Default settings in bold print)
DMX ADDRESS
CONTROL MODE
1-XXX
21CH
4CH
9CH
11CH
16CH
27CH
30CH
0-255
0-255
0-255
0-255
0-255
(0-20)
REGULATED
SILENT Level(1-3)
FULL
High
Normal
NORMAL
SMOOTH
ON/OFF
ON
OFF
RESET
NO CALIBRATION
MANUAL
FACTORYON
600/1200/2400/4800
Level(1-10)
DMX HOLD
NO DMX HOLD
VXXX
TOTAL XXXX
RESET Reset OK
XXX℃
0-255
0-255
0-255
Set DMX start address
Select 21/04/09/11/16/27/30 channel setting
(0~20Hz)Select strobe frequency
Enables or Disables password
Color calibration mode off.
Manual calibration mode, RGBW to white is custom calibration
Factory calibration mode,RGBW to white is Factory calibration
Select the refresh frequency
Set the LCD display brightness
The fixture will stay the last values when you disconnect DMX
The fixture has no output when you disconnect DMX
Auto programs
Auto speed
Manual calibration mode, RGB to white is custom
calibration,(require password)
0~100%
0~100%
0~100%
0~100%
0~100%
single leds or two color mixing in full power with 120% output
protection
Turn on the Wireless Board
Turn off the Wireless Board
Reset the Wireless Board
CPU firmware version
USE of time
Use time reset(password)
LED board current temperature
Return all settings to factory defaults
Cooling fan speed regulated
three level of silent mode to control the output
Max. cooling fan speed
Normal mode output
Normal dimming with normal speed
Smooth dimming with slow speed
STATIC COLOR
Dimmer
FANS
LED POWER
Dimmer speed
KEY-Lock
W-DMX
CALIBRATION
Refresh rate
LCD brightness
DMX HOLD
AUTO(1-20)
Speed(0-20)
Software type
Usage time
Temperature
LOAD
Red
Green
Blue
Red
Green
Blue
White
Strobe
PERSONALITY
INFO
MANUAL CALIB
FACTORY SET
AUTO

13
Setup
The onboard control panel and backlit graphic display are used to set the 's DMX address,
configure individual fixture settings (personality), read out data and execute service utilities. See “Onboard
control menus” on page 12 for a complete list of menus and commands.
Using the control buttons
lTo enter a menu, select a function or apply a selection, press (Enter).
lPress (Up) and (Down) to scroll within a menu or adjust values.
lTo escape a function or move back one level in the menu structure, press (MODE).
l
The DMX address is configured using the DMX ADDRESS menu in the control panel.
Press the button “UP” to switch off Wireless DMX or disconnect with all connected Transmitters.
Press the button “DOWN' to set the unit in the ”ready to connect with all not connected transmitters'
mode. If you press the mode button on the Wireless solution transmitter all the ready to connect units
will be connected.
If the unit is successfully connected in the home display the sign“ ”. Appears. If the unit is not
connected to a transmitter in the home display the sign “ ”. If the unit switched off in the home
display the sign “ ”.
The Wireless Board will reset.
fixture
►
▲ ▼
◄
Holding down the "UP" and "DOWN" button for more than 3 seconds, the MENU display rotated 180°
lIn order to facilitate for inspection the signal, If the display to flicker when it's not receiving any DMX signal
lHolding the MENU and ENTER button for more than 3 seconds,
Control panel and menu navigation
DMX address setting
WDMX control
: V
:OFF
: X

l is the default setting. It gives a virtually instantaneous reaction when you dim from one intensity to another,
but dimming slowly from one intensity to another may appear slightly uneven.
lThe SMOOTH setting gives smoother dimming during slow changes in intensity, but it limits the speed of dimming
changes slightly. This makes it ideal for slow, smooth dimming, but a short time-lag may be noticeable if you try to dim
quickly from one intensity to another.
NORMAL
The fixture factory default settings can be restored by applying a FACTORY SETTING → LOAD command.
Restoring factory default settings
Standard Manual
DMX control mode is selected in the CONTROL MODE menu. The fixture has five DMX control
modes:
lEach line
lRGBW
lRGBW+CT
lRGBW+CT
lEach line(RGBW)
lRGBW+CT Each line(RGBW)
lEach line(dimmer+RGBW+fade)
and modes
(RGBW)21 channels :Strobe+Dimmer+Setting+
4 channels :
9 channels :Strobe+Dimmer+Setting+Macro color +
11 channels :Strobe+Dimmer+Setting+Macro color + + AUTO + AUTO/dimmer speed
16 channels:
27 channels:Strobe+Dimmer+Setting+Macro color + +
30 channels:Strobe+Dimmer+Setting+Macro color +
CONTROL MODE
14
Dimming
【 】 【KEY-Lock】 【ON】/【OFF】{ENTER}
【ON】enable lock，【OFF】disable lock
when you enable password lock and the fixture was in standby mode ,it need password { MODE、UP、MODE、
DOWN、MODE、UP、MODE、DOWN }.then press the enter button to active.
PERSON ALITY [ [ [
Enable password lock

15
CALIBRATION
1,NO CALIBRATION
MANUAL
Color calibration mode is off.
2,
Manual calibration mode, RGBW to white is according your custom calibration.
Manual calibration can calibrate by control panel and DMX channel.
calibrate by control panel
1、Press MODE button until【MANUAL】is displayed, press ENTER
3、Enter the password
3、Set【Red,Green,Blue】to white by custom calibration
Three mode of color calibration
calibrate by DMX control
to enter dmx controller calibrationchannel 4 is set to 245-249
Percent
0-100
0-100
0-100
0-100
0-89
90-95
96-97
98-10
0-99
100
0-100
0-100
0-100
0-100
DMX Value
0 - 255
0 - 255
0 - 255
0 - 229
230 - 234
240-244
245-249
250-255
0 - 254
255
0 - 255
0-255
0-255
0-255
channel
1
2
3
4
5
6
7
8
9
Function
No function
No function
No function
No function
3
come back to DMX mode
No function
3
turn on manual calibration mode by dmx control
Illuminate display
3Value must be held for 3 seconds to activate.
No function
Save Correction, Value must be held for 3 seconds to activate.
RED(0-255)
GREEN(0-255)
BLUE(0-255)
WHITE(0-255)
3,FACTORY calibration mode
Fixture is calibrated in the factory by radiant machine.

Specifications
Physical
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .495 mm
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .233 mm
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .387 mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 kg without accessories
Dynamic Effects
Color mixing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RGBW
Color temperature control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CTO, variable 10 000 - 2500 K
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 PCS 4 in 1 LED
Sh ut te r ef f ec ts . . . . . . . . . . . . . . . . . . . E le c t r o n ic , w i t h re gu l a r an d r a nd om
pulse, burst and strobe effects
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21°
Control and Programming
Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .DMX/Wireless DMX
DMX channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. .
Setting and addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Control panel with backlit graphic display
Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . USITT DMX512-A
Construction
Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Black
Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . High strength die-casting aluminum
Protection rating. . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . .IP 65 when DMX output and input is covered
Installation
Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Any
Minimum distance to combustible materials . . . . . . . . . . . . . . . . . . . . . . . . . . 100 mm. from fixture
Minimum distance to illuminated surfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 mm. from fixture
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . must be fastened to structure or surface
Connections
AC power input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PowerCon input socket (Ip65 when covered)
AC power throughput. . . . . . . . . . . . . . . . . . . . . . . . . . .PowerCon output socket (Ip65 when covered)
DMX data in/out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 pin locking XLR (Ip65 only when covered)
Electrical
AC power . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . .100-240 V nominal, 50/60 Hz
Maximum total power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .360 W
Power supply unit . . . . . . . . . . . . . . . . . . . . . . . . . . . .Auto-ranging electronic switch mode
Power consumption, all effects static, zero light output . . . . . . . . . . . . . . . . . . . . . . . . <10 W
Thermal
Cooling . . . . . . . . . . .. . . . Forced air (temperature-regulated, low noise, user-definable FAN levels)
Maximum ambient temperature (Ta max.). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40° C
Minimum ambient temperature (Ta min.). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5° C
LED Quantity:
Beam Angle:
21/04/09/11/16/27/30 CHs
only
only
only
16
