Clifton Range MSH Series User manual

THE CliftonRANGE
MagneticStirrers
MSHSeries
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

Contents
About this Manual 3
GeneralNotes 3
Amendments 3
Symbols 3
Location 4
Unpacking 4
Safety 4
PowerLeadandConnectiontoElectricalSupply 4
First Use 4
Front andRearViews 5
UsingtheMagneticStirrer 6
-Mixing 6
-Heating 6
GeneralCleaning 7
CleaningexternalpaintedsurfaceswithAnti-bacterialfinish 7
Cleaningthestainless steeltank 7
Decontaminationof Equipment 8
VirucidalDisinfectant 8
Disinfectant/Sterilant 8
3YearWarranty 9
Out ofWarranty 9
Endof Life 9
PortableApplianceTesting 9
Accessories 10
Spares/ServiceDiagram 10
Specification 11
Declarationof Conformity 12
Product FinalInspectionandElectricalSafety Report EnclosedRear
TheCliftonRange-3YearWarranty 2HighQualityProductsatAffordablePrices
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

About thisManual
This userManualcontains instructions whichmust befollowedin orderthat theproductis operated
correctly.
General Notes
1. Alwaysfollowgoodlaboratorypracticeby ensuringsubstancesbeingheatedoffernoriskof a
hazard (explosion,implosionorreleaseof toxicorflammablegases)orthat thesehavebeen
addressed. Whenheatingsubstanceswhereliberationof gasesoccurssuitableextractionshould
beused.
2. Ifthis product is not usedin accordancewiththeseinstructions,thenbasicsafety protection
is affected.
3. TheMSrangeis classifiedas Class 0(IEC519)withregardstoovertemperatureprotection.
4. Themains supplycord fittedto this productis aheatresistanttypeandshould bereplacedby
an equivalent type.
5. It is recommendedtheunitsareconnectedtothemains supply withRCDprotection.
6. Beforeusinganycleaningordecontaminationmethodexceptthoserecommended, checkwith
yourdistributorthattheproposedmethodwill not damagetheequipment.
7. Donot movetheunitwhenin useorwhenconnectedto an electricalsupply.Allowto coolfor
at least 30 minutesbeforemovingandwhenREDhot indicatoris extinguished.
8. Donot movewithcontainersonthetopplate.
9. Liquidcan spill ifcontainersareoverfilledandliquidis stirredathighspeed. Alwaysbuild
stirrerspeedslowly andneverstirmorerapidly than neccessary.
10. Neverplaceacold glass vesselonto ahotplatewhichis already hot.
Amendments
Issue1 July 1992 Initialissue
Issue2 January 1992 Revised
Issue3 September 1993 Changes
Issue4 January 1996 RevisedCEapproved
Issue5 May 1996 Address update
Issue6 August 1996 Page2revised
Issue7 September 1999 F toT
Issue8 February 2000 Revisiononratings,updatespec,warranty period
Issue9 September 2001 Layout andwww download
Issue10 January 2004 Newdesign
Issue11 April 2005 Updateto controller
Issue12 November 2006 Deletionof MSU Series,WEEE andAnti-bacterial
paint finish.
Symbols
HOT SURFACES
Paragraphs markedbythis symbolindicatethat apotentialhazard toyour
personalsafety existsfromheatedsurfacesorotherappendagesontheoutside
orinsideof theequipment.
CAUTION
This iconaccompaniestext and/orotherinternationalsymbolsdealingwith
potentialdamagetoequipment.Whenpresent,it indicatesthatthereis a
potentialdangerof equipment damagemay occurifinformationstatedwithin
the"CAUTION"paragraphis not adheredtoorproceduresareexecuted
incorrectly.
PROTECTIVEEARTH OR GROUND TERMINAL
Protectiveearthconductorterminal.
TheCliftonRange-3YearWarranty 3HighQualityProductsatAffordablePrices
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

Location
Theproduct mustbeplacedonasmooth,levelandsturdy worksurfacein aventilatedroom.
Suitableforusein aventilatedroomwithambienttemperaturerange5to 40°C.Maximumhumidity
80%fortemperature31°Cdecreasingto50%at 40°C.Theproduct is designedforlaboratory use.
Theunit mustbesitedaway fromdraughtsanddirectsunlight asboth
affecttemperaturecontrol.
Unpacking
Removethemagneticstirrerfromitspackaging.Anydamagepleasenotifyyourdealerandretain the
packagingoverthewarranty period. Fitthemains lead. Suppliedwitharetortpointassemblywhich
can befittedtotherearof theunit ifrequired.
Safety
Donottouchanyelectrical contactsoropenanyclosurepanels.
RISKOF ELECTRICALSHOCK!
TheMSHrange areClass 0 (IEC519 -Part 2)-withreferencetoover
temperaturecondition.These magnetic stirrersaredesignedthatif the
temperaturecontrolsystemfailsinuse theheatingplatewill notexceed
itsmaximumtemperature.
TheMSHrange arefittedwithHOTindicatorwarningwhenthehob
temperatureexceeds60°C.
Themotorisfittedwithoneshot overtemperaturesafetycut out.
TheMSHrange uses superbrightindicatorsforeasyviewingthestatus
equipment:stirring,heating,mainsandwarningHOT condition.
Arange ofaccessoryspillage potsalsoavailable.
PowerLead andConnection Electrical Supply
Beforeconnectingtheproduct to theelectricalsupply,checktheinformationontheratinglabelis
compatible.
IFINDOUBTCONSULTAN ELECTRICIAN.THEPRODUCTMUSTBEEARTHED!
Wherethemains supplyorplugconnectiondiffersreferto localregulations orqualifiedelectrician.
First Use
Theunit may producean odourwhenfirst switchedon.This is normalandwill diminsh withuse.
TheCliftonRange-3YearWarranty 4HighQualityProductsatAffordablePrices
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

MSHSeries
Front View
SpeedControl
TemperatureControl
StirringIndicator
HeatingIndicator
PowerIndicator
WarningIndicator-HOTCONDITION(hotplate)
RearView
Mains powerswitch“I”ON,“O”OFF.
Serialnumberandelectricalsupply
details.
IECconnector,forpowersupply lead
andplug.Fusedrawfittedunderneath.
Retort point
TheCliftonRange-3YearWarranty 5HighQualityProductsatAffordablePrices
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

UsingtheMagnetic Stirrer-Mixing
1.TurntheCliftonMagneticStirrerON"I".
2.Turnthespeeddialtolowest setting.
3.Placeafollowerinto aflaskrequiringmixing.Placeflaskin middleof
thehotplate.
Notes:
a.Different lengths of followersgivedifferent stirringcharacteristics-
try severalsizesforbest mixingcontrol.
b. Ensurethefollowercoatingdoesnot react withliquidbeingstirred.
4.Turnthedialof thespeedcontrolslowly tothedesiredamount of
stirring.
UsingtheMaginetic Stirrer-Heating
1.Adjustthetemperaturedialforthedesiredheating.
Notes:
a.Theunit can beusedas aheatinghotplateonly withnostirring.
Many solutions heatedonthehotplatewill fume andtherefore
appropriatesafety precautions should befollowed. Some solutions may
explode,implodeorreleasetoxicorflammablegases-ensure
appropriatesafety precautions arefollowed.
ENSUREALLPERSONNELINTHEVACINITYOFTHEHOTPLATEAREAWARE-
ITSHOT!
DONOTLEAVETHEHOTPLATEONWHENNOTINUSE!
TheCliftonRange-3YearWarranty 6HighQualityProductsatAffordablePrices
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

Cleaning
General
TheHotplatetopshould bewipedclean withdampclothsoakedin anon-abrasivecleanser/clean-
ingsolutiontoremovedebris andcontamination.TheHotplatewill operatebetterifclean andlast
considerably longer.
Important -please followthese instructionstoavoidpossibledamage
totheunit,otherwise affectingitsperformanceandwarranty.
Alwaysdisconnect theproduct fromtheelectrical supply before
cleaningandallowtheunit tocooldowntoambient room
temperature.
Theproduct MUSTNOT bedecontaminatedby steamsterlization.
CleaningExternalPaintedSurfacesfeaturing“Anti-bacterialPaint Finish”
Themagneticstirrershould becleanedatregularintervalswipingexternalsurfaceswithaclothor
spongesoakedin warmsoapywaterwithamild detergent.All surfacesshould becleanedusingasoft
clothorsponge.
Donotunderanycircumstances use strongsolventsorsolutionscontaini
ngChlorinatedHydocarbons,Esters,Ketonesorabrasivecleanersorpolish
on thepaint finishotherwise itdamages thebuilt
inanti-bacterial properties.
AllpaintedsurfacesonCliftonrangeproductsfeaturesan “Anti-bacterial
paint finish”identifiedwiththis authenticatinglogoontheunit.
This“Anti-bacterialpaintfinish” inhibitsthegrowthofbacteria.It has
beentestedbyindependentspecialisttest housessuchastheLawLabora-
tories(in theUK)usinginternationallyrecognizedtestmethodsand
proventobeeffectiveversus awiderangeofbacteria speciesincluding
Escherichia coliandStaphylococcus aureus(MRSA).
Werecognisehygieniccoatingsarepartof acontrolledapproachto acleaner
workingenvironment.Withinitsformulationanactiveingredientwithprovenanti-bacterialproper-
tiesis boundintothepaintfinish.Theefficacyofthepaintfinish appliedtotheCliftonrangeis
maintainedoveritslifetime,astheanti-bacterialagent isintegralwithinthepaint.
Inalaboratory environmentitmakesthisonelesssourceofcontamination,contributingto
essentialclean workingpractices.Abenefitof suchapaint finish can leadto areductionin
cleaningschedulesbecausesurfacesaremoreprotectedandimprovesprotectionbetweenclean-
ing.Unlikedetergents“Anti-bacterialpaintfinish” doesnot offeran instantaneous action,butis
intendedforlong-termgeneralprotectionagainst bacterialgrowth.
Moistureonthepaintedsurfaceis necessary forthebacteriumtoabsorbtheagentandbeaf-
fectedby it.Thecoatingisthereforelessactivein very dryconditions,but dependent upon
relativehumidity,moisturein theatmospheremaintains activity.Areaswheremoistureistrapped
arealsoareasthat normally aredifficulttocleanandwherebacteria proliferatebut theseareas
aremost activefortheanti-bacterialcoatingimprovingthedefenceagainstbacterialgrowth.
TheCliftonRange-3YearWarranty 7HighQualityProductsatAffordablePrices
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

TheCliftonRange-3YearWarranty 8HighQualityProductsatAffordablePrices
Decontamination ofEquipment
Cliftonlaboratory equipmentcan bedecontaminatedafterspillageorcontact withpotentially HIV
andHepatitis infectedbloodsamplesduringanalysis usingfollowingrecommendedrapiddisinfect-
ants.
Virucidal Disinfectant
WerecommendVirkontabletsforthesafeandrapiddisinfectionof equipmentin awidevariety of
situations availablefromyourdistributororcontactDay-ImpexLtd. formoredetails.Telephone:
44+(0)1787 223232 or http://www.day-impex.co.uk
Theultimatehighlevelsurfacedisinfectant,dissolveVIRKONin water,providing
asafeworkingsolutionwithafaintlemonodor.It has provenefficacyagainst
bacteria (includingmycobacteria), viruses,sporesandfungiin avariety of inde-
pendenttestsusingdifferentprotocols.Presentsnoserious longtermhealth
risksto staff –obviatingtheneedforcostlyventilationequipmentandhealth
monitoring.Alsoprovideshighleveldisinfectionof laboratoryequipmentand
instrumentswhereautoclavingis neitherpracticalnornecessary.Formorede-
tailedinformationrelatingto howVirkonshould beusedwithaccess to test
reports www.relyon.dupont.com
IsVirkonsolutioncorrosive?Virkonsolutionrequiresonly10 minutescontact timetobeeffec-
tivesolong-termexposureisnotnecessary andtherefore will notcorrodemostmaterials.Care
should betakenwithStainless steelwaterbathtanks,thesesurfacesshouldnotbeaffected
however,itisimportantthat generallyyoudonot leaveVirkonsolutionincontactwithmetal
surfaces“FORLONGERTHANISNECESSARY”.
Virkonis Registeredin accordancewiththerequirementsof theMedicalDevicesDirective,(93/42/
EEC)as aMedicalDevice.
Disinfectant/Sterilant
WerecommendPeraSafeapowderproductforthesafeandrapidchemi-
calsterilantof equipmentin awidevariety of situations availablefrom
yourdistributororcontactDay-ImpexLtdformoredetails.Telephone:
44+(0)1787 223232 or http://www.day-impex.co.uk
PeraSafehas aprovensafety profileforend-userswithnoneof the
undesirablepropertiesof skin sensitisation,toxicfumesorunpleasant
odoursthat areassociatedwithaldehydesolutions.
LeadingUK andUSAmicrobologistshaveprovenPeraSafetobeactive
against viruses,mycobacteria andfungi.It is microbiologically superior
to glutaraldehyde,destroyingsporingbacteria in oneminute.It has alsobeenindependently
proventhat PeraSafesterilisesin just 10 minutes.
Formoredetailedinformationrelatingto howPeraSafeshouldbeusedwithaccessto test reports
www.relyon.dupont.com
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

3YearWarranty
Ourserviceengineersarefullytrainedin theassembly,calibrationandservicingof all Cliftoninstru-
mentation.Productscan bereturnedto ourcomprehensivelyequippedservicecentrewhereafast
andefficientturnaroundis guaranteed:
ServiceDepartment,NickelElectroLimited, OldmixonCrescent,Weston-super-Mare,NorthSomerset
BS24 9BL,UK.Tel[phone] Fax [phone].
Out ofWarranty
OurServiceDepartmenthas comprehensivestockof charegeablesparepartsmaintainingworkinglife
of equipmentorunitscan bereturnedforquotationbeforerepairsareundertaken.
EndofLife
Thissymbolindicatesthat thisproductshouldnot bedisposedofwithyourwaste.
Instead,disposewasteelectricalequipmentbyhandingitovertoadesignated
collectionpointfortherecyclingof wasteelectricalandelectronicequipment.
Theseparatecollectionandrecyclingofyourwasteequipmentatthetimeof
disposalwillhelpto conservenaturalresourcesandensurethat itis recycledina
mannerthatprotectshumanhealthandtheenvironment.Formoreinformation
aboutwhereyoucan dropoffyourwasteequipmentforrecycling,in UKplease
contactServiceDepartment,restEuropecontactyourDistributor.
Health&Safety,unlessinreceipt ofaDecontaminationNoticeorReportthe
unit cannot bereturnedoracceptedfordisposal.
Cliftonelectricalandelectronicequipment hasbeendesignedforrecyclingand
takesinto accountthedismantlingandrecovery itscomponentsandmaterials.
Cliftonproductsareeasily recycledwithmajorityof theproduct constructed
fromstainless ormildsteels,whichcan readily bere-usedorrecycled.
Inexcessof52%ofthisproduct range canbeeasily re-cycledeconomically.
PortableApplianceTesting
Whenconductingtestingensureit is completedbyaqualifiedperson.
TheproductMUST NOTbeFlashtested!
TheCliftonRange-3YearWarranty 9HighQualityProductsatAffordablePrices
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

Spares andServiceDiagrams
MSHSeries
TheCliftonRange-3YearWarranty 10 HighQualityProductsatAffordablePrices
Accessories forMSHSeries
Cat No Description
SP-1 ContainerforCapturingSpills
Retort Rods
8634 10 x500mm Mild SteelRetort Rod
8631 12.5x600mm Mild SteelRetort Rod
8614 10 x500mm AluminiumRetort Rod
8611 12.5x600mm AlumiumRetort Rod
SpillageContainer
Toavoiddamagingthemagneticstirrerifaliquidis likely toboilover,werecommendtheuseof an
spillagecontainer(SP-1). This is an aluminiumpotwhichwhenplacedonthehobunderneaththeflask
will captureany spillageof liquid.
Retort Point
Aretortpointbracketis supplied. Theunitfeaturestwothreadedholesontherearof theunitto
accept thepoint.This can thenbeusedtosupport aretort rod-see accessories.
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

HOTPLATES
MSSeries, Magneticstirrers
ThisCliftonrangeofmagnetic stirrersare
robustlyconstructedforalonganddurablelife.
Unit consistsof alowprofilecasewithchemical
resistant wipeclean slopingcontrolpanelwhich
featurestatusindicators.
STIRRERS
FeaturesInclude:
MSH
•Indicators
-stirring,heating,powerand
warningHOTcondition
•Easy touse
•Electronicspeedand
temperaturecontrol
•Corrosionresistant stainless
steelcase
•Rapidwarmup
•Chemicalresistant controlpanel
-splashproof,wipeclean
CatNo. MSH-1/MSH-1S MSH-3
Temperature
Display/resolution analoguedial analoguedial
Range 400°Cmaximum 400°Cmaximum
Control electronic electronic
Sensitivity@60°C - -
probe@60°C,water - -
Overtemp. alarm - -
Stirring
Speed 100-1500rpm 100-1500rpm
Timer
Display/resolution - -
Settings - -
Timecycle - -
Cycleend - -
General
Heater,Watts 400W 3 x400W
Hotplatematerial aluminium/stainless aluminium
Hotplate,dims 140mm diameter 140mm diameter
Overall,dims 200wx295dx135hmm 600wx295dx135hmm
Retortpoints 1 3
Voltage 230V 230V
*All modelssuppliedcompletewithPTFEstirringrods(1x20mmand1x40mm)perstirring
position.
TheCliftonRange-3YearWarranty 11 HighQualityProductsatAffordablePrices
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

ECDeclarationofConformity
Weherewithconfirmthe followingproduct
MSH MagneticStirrersRange
Conformswiththerequirementsoutlinedby followingEuropean Directives.
LowVoltage Directive (73/23/EEC)
EMCDirective (89/336/EEC)
Weconfirmthedeclaration
NICKEL-ELECTRO LIMITED
Manufacturersoflaboratory, medicalandclinicalequipment.
OldmixonCrescent,Weston-super-Mare,
NorthSomerset, BS24 9BL, UnitedKingdom.
Tel:[phone]
Fax:[phone]
Email: [e-mail]
www.nickel-electro.co.uk
Nickel-ElectroLtdisalsoregistered ISO9001
referenceNo. Q09820
Conformswiththerequirementsof followingStandards
BSEN61010:1
BSEN61010:2.010
Safety requirementsforelectricalequipment formeasurement,controlandlaboratory use.
BSEN61326
Electricalequipment formeasurement controlandlaboratory use-EMCrequirements.
Nickel-ElectroLtdis alsoregisteredISO9001
referenceNo. Q09820
TheCliftonRange-3YearWarranty 12 HighQualityProductsatAffordablePrices
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk

FinalInspectionandElectricalSafetyTestReport
BX0811 www.nickel-electro.co.uk
PDFcreated withpdfFactoryProtrialversion www.software-partners.co.uk
