Climate RENTAL SOLUTIONS DBK Drymatic User manual

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
INSTRUCTION MANUAL
DBK HEAT DRYER
MODELS: FGPH061; FGPH062; FGPH063; FGPH064; FGPH065;
FGPH066; FGPH070; FGPH071

INSTRUCTION MANUAL DBK HEAT DRYER
Page 2
• Ensure that you have read and understood this manual before operating the machine.
• Do not overload sockets or extension leads - Check power ratings before use.
• Risk of electric shock - Do not open the unit or try to reach through the grills.
• Hot surfaces - Do not touch heater outlet or grill whilst product is in operation. Once stopped
allow the unit to cool down before touching.
• Do not block or twist ducts. This could cause the unit to overheat or hinder performance.
• Product for indoor commercial use only.
CONGRATULATIONS ON YOUR PURCHASE!
Congratulations and thank you on your purchase of a Drymatic product! In order to get the most out of your Drymatic
please take the time to read this user guide and familiarise yourself with the machines operation and features.
CONTENTS:
Warranty: 1
Safety and Warnings: 2
Introduction: 3
Component Identication: 3
Quick Setup: 5
Advanced Settings: 7
Setup Tips: 9
Storage and Transport: 10
Maintenance: 11
Trouble Shooting: 13
Replacement Parts: 13
Model Identication: 14
Product Specication: 14
WARRANTY INFORMATION:
Please complete and mail, fax or email your warranty registration card complete with bill of sale/receipt to activate
your war-ranty. DBK Technitherm o󰀨ers a standard one year warranty from date of purchase on Drymatic and an
additional four years on the rotomoulded housing. Contact details can be found on the cover of this instruction
manual. Please see the component identication section to locate your model and serial number.
WARNING

INSTRUCTION MANUAL DBK HEAT DRYER
Page 3
IMPORTANT SAFETY INFORMATION:
• Do not alter or modify your Drymatic in any way. Use only replacement parts approved by DBK, modi-cations/repairs not covered in
the maintenance section of this manual and the use of unapproved parts will void any remaining warranty. Contact your local Drymatic
distributor for assistance.
• Check hoses for wear and damage, replace when needed. Heater hose must be rated to 100°C (212°F).
• Product for indoor commercial use only. It must be kept dry at all times away from rain, water or snow.
• Handle the unit carefully. Always operate the unit on a at stable surface. Do not drop, throw or place the unit in area it may fall. Rough
handling may damage the unit, create dangerous operating condi-tions and will void the warranty.
• Lift within your limits. Drymatic weighs 25kg, seek assistance if necessary. Please see transport section.
• Never pull or lift the product via the mains cord.
• Children of less than 12 years should be kept away unless continuously supervised.
• This appliance can be used by children from 16 years and above and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Chil-dren shall not play with the appliance. Cleaning and user maintenance shall not be made without
su-pervision.
• Children aged from 12 years and less than 16 years shall only switch on/o󰀨 the appliance provided that it has been placed or installed in
its intended normal operating position and they have been given su-pervision or instruction.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid
a hazard. Always grasp the plug (not the cord) to unplug.
• To provide a continued protection against electric shock, connect to properly grounded outlets only. Do not use an adaptor, never cut o󰀨
third prong.
• Do not overload sockets or extension leads - Check power ratings and condition before use. The heater shall not be located
immediately below a socket outlet.
• The unit must be operated on a matched voltage circuit protected by a Ground Fault Circuit Interrupter (GFCI) device.
• Always unplug the unit before transporting, servicing and cleaning or whilst the unit is not in use.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 4
IMPORTANT SAFETY INFORMATION:
• WARNING: Do not block heater or twist any ducts. This will cause the unit to overheat and limit airow.
• WARNING: This heater is not equipped with a device to control the room temperature. Do not use this heater in small rooms when they
are occupied y persons not capable of leaving the room on their own, unless constant supervision is provided.
• Do not touch heater outlet, grills or hose whilst product is in operation as surfaces will become hot and cause burns. Once stopped
allow the unit to cool down before touching. Do not open or try to reach through grills. Particular attention has to be given where children
and vulnerable people are present.
• Keep away from open ames and heat sources or where vapours from gasoline, solvents, thinners or any other ammable materials
may be present.
INTRODUCTION:
Drymatic is an intelligent heat drying and air exchange system designed to dry a room as quickly as possi-ble. By
constantly optimising and exchanging moist air with warm dry air in a controlled manner Drymatic greatly speeds up
the drying process whilst making it more e󰀩cient. The addition of heat and controlled air exchanges also increases
the performance of conventional drying equipment.
How it works:
Drymatic has two modes of operation: Recirculation and Exhaust Mode. In recirculation mode air in the room is
continuously heated up until either a temperature or humidity limit is reached. Raising the temper-ature of the air
allows it to hold more water which promotes evaporation. This means that more moisture will be drawn out of the
wet structure/contents of the room and retained in the air. In exhaust mode this now moist and humid air is then
exchanged and replaced with dry air which has been heated before it en-ters the room. By continuously monitoring
the temperature and humidity of the air Drymatic can cycle be-tween these modes to maximise the amount of water
removed from the room.
Features:
• High performance drying with monitoring system to maximise e󰀩ciency.
• Rotomoulded housing that is strong, portable and stackable.
• Quick-x fast and easy ducting system.
• Simple power up and go operation.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 5
Wheels
Side Feet
Hinged Cover and Display
(Open to reveal control panel)
Duct
Stacking Fins
Serial Number on un-
derside of cover
COMPONENT IDENTIFICATION:

INSTRUCTION MANUAL DBK HEAT DRYER
Page 6
Cord Clip Cord Wrap
Main (long)
Handle
Mains Cord Out-
let (cord hidden
for clarity)
Stacking Indents (to line
up with base feet)
6” PVC Hose or Aluminium Hose*
Band
Quick-
Firmware Port
Power Switch
(Illuminates when on)
Fuse Holder
LCD Touchscreen
Control Panel Parts
e.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 7
To quickly set up Drymatic: (Instructions can also be found on the screen cover).
1. Place the unit at on the oor as close to the centre of the Drying area as possible.
2. Connect at least three quick-x ducts, inserting them into the labelled ports (see below) and rotating clockwise
until tight.
3. Plug the power cord into a grounded outlet.
4. Lift the cover and switch on the machine with the red power switch.
5. Press the green play button on the touch screen.
T he display when running
Drymatic will now run on the default settings. The cover can be closed and the machine left to run on it’s own. Try
to keep the area isolated with all doors and windows shut and take note of the initial relative humidity. Continue to
check the room and humidity values until you consider the room ’dry’ and then use the red power switch to turn o󰀨
the machine.
Note that the reset button should be used before the next job is started, see ‘About the Memory’ in the
‘Advanced Settings’ section for more information.
QUICK SET UP:

INSTRUCTION MANUAL DBK HEAT DRYER
Page 8

INSTRUCTION MANUAL DBK HEAT DRYER
Page 9
**Heater power levels are determined by software and sensors to allow air out to fall between room limits and provide
safe operation. The bars here serve as an indication of how the machine is performing. Conditions such as low room
limits, high ambient temperatures, low fan speed and duct blockage may limit the heaters power level.
EXAMPLE SET UP:
The diagram below shows an example set up for a small room with windows. A wooden panel is used to seal the
window leav-ing the room and all hoses are directed away from one another. Always try to minimise the length of the
heater hose or avoid using it if possible.
ADVANCED SETTINGS:
Drymatic has four control buttons along the bottom of the screen, Play, Stop, Reset and Settings. The top ribbon
shows the machine status, in any situation where the machine is stopped the play button will restart it from where it
previously left o󰀨. Similarly the stop button will put the machine on hold without the need to power it down. In order to
correctly understand how the reset button functions please see ’About the Memory’ below.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 10
Touching the settings button brings you to the advanced menu, here you have complete control of the room conditions,
fan speed, units and language. Once you have nished you will need to press play again to restart the machine
(accessing the settings will cause the machine to stop).
About the Memory - Drymatic has a built in memory allowing it to continue and restart jobs even if power is lost
or re-moved. This ensures that the machine doesn’t forget kWh and hours data and continues on the same point
of it’s drying cy-cle. There are two separate memory banks that can be reset independently.
Job Memory - Keeps track of where the machine is in the drying cycle and all kWh/hours data - This data should
be reset at either the start of the new job or end of the previous job to ensure that the next jobs starts fresh. This
can be reset from the main display, failure to do so will slow the drying time and could cause confusion with data.
Settings Memory - Remembers all of the user settings such as room limits, fan speed, units and language.
These can be reset to the default values via the settings page but will not be reset with the job. If using the
machine after someone else you should always ensure that the appropriate settings have been chosen.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 11
In some situations high temperatures, humidity or even a very low humidity may not be desirable, if this is the case
the room limits can be adjusted manually to suit.
Touching any of the values for the room limits will allow you to change them. An edit box will appear with di󰀨erent
increments that can be pressed to change the value. Once you are happy with the value press the tick button to
conrm, if you wish to cancel the changes press the cross. Remember that the reset button on the settings page will
restore all room limits to the fac-tory defaults. An outline of the variable room limits can be found below.
Cancel changes and
close the window.
The current value for
the selected limit.
Accept the changes
limit by the indicated
amount.
Max Temp - This is the maximum temperature the room can reach, higher temperatures should speed up the drying
process. Please note that by default on some machines this is limited to 40°C (104°F) however can be increased to
up to 50°C (140°F) depending on how the machine is used.
Max RH - This is the maximum relative humidity the room can reach, when in recirculation mode the machine will aim
to in- crease the humidity by extracting water from the room and into the air before exhausting it out of the building.
Reducing this limit will cause the machine to switch mode more frequently however may not be extracting as much
moisture as it possibly could each cycle. Higher values will generally correspond to faster drying.
Min RH - This is the minimum relative humidity the room can reach, e󰀨ectively a limit on how ’dry’ you want the room
to get. Once this target has been reached the machine will mainly run in exhaust mode with the aim to keep this hu-
midity constant.
THE MACHINE STATUS RIBBON:
The machine status ribbon shows the machines current operating state, operating mode and the heater power level.
This table shows most possible situations. (note that fans are always running when machine is running).
CHANGING THE ROOM LIMITS:

INSTRUCTION MANUAL DBK HEAT DRYER
Page 12
Machine Status: Description: Heater Level: Description:
Machine Running Machine running as normal. Full Heater Power
Machine Stopped Machine on hold, press play to
resume.
66% Heater Power (80% for Aus/Scan
models)
33% Heater Power (40% for Aus/Scan
models)
Heater O󰀨
Set Up Tips:
The following guidelines should be followed to get the most out of your Drymatic. Taking the time to set up the unit correctly will give much
better performance and will reduce drying times.
Hoses -
• Keep hoses clear and as straight or smooth as possible - tight bends or blockages will restrict airow and limit heater.
• If there is space to put Drymatic near the target drying it may be possible to run the unit with only three hoses. This will guarantee the
heater is always on the highest possible power. Ensure that no hoses block the open port if they cross.
• Keep the ends of both the Outside hoses and Room hoses separate. If they are too close the unit will just be cycling round the same
air limiting performance.
• Aim to create a ow of air around the room - ideally the warm air should pass all target drying areas to absorb moisture before been
evacuated.
• Hoses can be moved throughout the cycle to target wetter areas, this is especially useful for larger or complex rooms.
• Hoses can be cut down or they can be extended by using cardboard/duct tape sections to join them - bear in mind that elongating the
hoses will reduce the airow. See the maintenance section if you wish to change the hose entirely.
Drying Area -
• Keep the drying area sealed - any loses of heat will slow performance or allow more moisture to enter the area. In larger/open areas
consider using tenting to isolate target zones. - For more info ask your Drymatic representative about Zip Wall.
• If hoses are running through open windows board the area with a wooden or cardboard panel to keep the room sealed. Cut a 6” hole
in the panel to run the hose through.
• Drymatic can be used in a separate room with hoses feeding in to the drying area - this may be the only option for smaller rooms/
cupboards.
• If the oor under Drymatic is wet consider moving it throughout the job. Always stop the unit before doing this.
• If there is nowhere to vent wet air consider directing it to a sealed shower allowing it to condense and leave via the drain.
Measuring, Monitoring and other Equipment -
• Drymatic’s display gives an outline of relative humidity throughout the room. To optimise the drying process we recom-mend using
moisture meters to map the wet areas and then placing/moving the hoses accordingly. Remote monitoring can be achieved through
the Drymatic Hygronet system. For more information please contact a Drymatic Sales Representative.
• When monitoring energy usage remember to reset and log the kWh and Hours run readings at the start and end of the job.
• Strategically using Drymatic with other equipment can increase performance. For example placing the Heater Outlet hose near an air
mover will mean that warm air is pushed over it’s target area increasing the rate of evaporation.
Alternative Uses -
• Running Drymatic with no ducts will make it function like a fan heater, the settings menu can then be used to control the max temp
and fan speed.
• Setting a high RH target and low temperature limit will make Drymatic run solely as an air exchange machine.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 13
STORAGE AND TRANSPORT:
Always use the long handle to pick up the unit using two hands whenever possible. Ensure that safe manual handling
guidelines are followed and request assistance if necessary. The soft handle can be used to pull Dry-matic along with
it’s wheels as you would a suitcase. A case is provided to store four complete hoses
The power cord should always be removed from the electrical outlet when not in use and wrapped anti clock-wise
around the cord wrap as shown. Once fully wrapped the cord can be clipped to the side of the unit. (number of wraps
will vary depending on cord length)
DO NOT PULL ON THE MAINS CORD - this may damage the product and create a risk of electric shock.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 14
Drymatic can be stored in three di󰀨erent orientations as shown. It can also be stacked at up to four units high.
The unit should be kept indoors and dry. Ensure it is not exposed to rain or snow. And protected from freezing.
Drymatic must be secured when in transit to prevent it sliding and potentially causing damage, harm or injury.
Flat (stacked three high)
USER MAINTENANCE:
WARNING: The unit must be unplugged before performing any form of maintenance or cleaning.
Before each use:
Inspect the power cord for any sign of damage. If the cord looks broken, frayed or worn do not use the product and
seek a re-placement.
Cleaning:
The housing can be cleaned with a mild detergent and warm water. Do not use liquids on the grills and metal plates,
these can be cleaned with a soft cloth. Never use a hose to clean the unit and ensure that it is completely dry before
use.
Replacing the Fuse:
The on board fuse can be changed by 1) opening the screen cover. 2) Using a at head screwdriver to open the fuse
holder. 3) Remove the old fuse and replace with new one. 4) Close the fuse holder and shut the cover. Replacement
fuses must be 15A, 250V or 500V fast blow cartridge types.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 15
Replacing the Mains Cord:
The mains cord should only be replaced by a qualied electrician. If you are unsure of any thing contact your Drymatic
repre-sentative. When changing the cord never pull it with much force as a connection may become damaged. Only
use mains cords supplied by DBK or Drymatic with the correct part number (See Table).WARNING: The unit must be
unplugged before performing any form of maintenance or cleaning.
Fuse Holder
Control Panel
Screws
Control Panel Screws
Power Switch
Control Panel Components
Firmware Port
LCD Display
Removing the Mains Cord
1. Unplug the unit and make sure that switch is in the o󰀨 position.
2. Open the cover and remove the four screws from the Control Panel.
3. Gently lift the panel - note that other connections will restrict the plate. Care must be taken to prevent damage to
the com-ponents, the plate only needs to be lifted slightly.
4. Remove the Live and Neutral mains connections from the switch. Wiggling them may help them come o󰀨.
5. Remove the nut from the mains grounding post, remove the mains cord ground terminal and the star washers
either side.
6. Remove the four screws from the mains cord plate.
7. Gently pull the mains cord plate away from the housing, it has other connections and does not need to move far.
8. Squeeze the strain relief grommet at the back with pliers to release it. Slide the old mains cord out through the
hole.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 16
Mains Cord Plate
Strain Relief Grommet
Mains Cord
Mains Cord Plate Screws
Connecting a new Mains Cord
1. Feed the new cord through the mains cord plate and through the housing up to the control panel keeping it slack.
2. Connect the mains cord ground terminal to the mains ground post with star washers either side and a nut on top.
3. Connect the live and neutral connections to the switch.
4. Relocate the control panel and screw it back on the housing.
5. Squeeze strain relief grommet around the mains cord with pliers and push through mains cords plate. The cord
wrap can be used to gage where to place the grommet.
6. Push any slack into the housing and screw mains cord plate in place. (Do not pull tight as some slack is needed
for servicing)

INSTRUCTION MANUAL DBK HEAT DRYER
Page 17
Replacing a Hose:
Through misuse or just general wear and tear hoses may become frayed or damaged. Hoses can be replaced by
unscrewing the green tab on the band clamp and pulling the hose o󰀨. To attach a new hose simply slide the hose over
the attachment as far as possible then tighten the band clamp. 6m standard 6” grey PVC ducting is used however
di󰀨erent lengths or colours may be used providing they don’t restrict airow. WARNING: The heater outlet hose must
be rated for at least 100°C/212°F on 230V models and at least 70°C/158°F on 120V models. Hoses are available
through DBK.
TROUBLE SHOOTING:
In the event of a fault the rst thing to try is powering down the machine, turning o󰀨 the power at the mains and then
waiting ten seconds. You can then power it up again and see if there are any improvements. If not please refer to this
troubleshooting table for causes and solutions.
FAULT CAUSE SOLUTION
No power, red power switch is not
illu-minated when in on position. Plug fuse blown. Check plug fuse, if plug type doesn’t have a fuse contact service.
No display, red power switch
illuminates when in on position.
1) Internal fuse blown.
Check Internal fuse, it is located on the display
panel next to the red power switch. Replace if
necessary.
2) Thermal cut out activated
The safety cut has activated, contact service.
The machine will require in-spection as cut out
will only activate if additional faults are present.
Old temperature/humidity readings. Not running long enough.
Drymatic hasn’t updated these values from
a previous job. Wait a minute and see if they
update. if problem persists reset the machine
and repeat.
Frozen Display Software error/crash Restart and reset machine, if problem persists
software may need updating. Contact service.
Vane out of alignment Something has blocked the vane and caused it
to come out of alignment.
Vane may of become damaged or forced loose.
Contact service centre.
Machine resets on start-up Too little power to start fans.
Check correct power supply is being used for
your machine. If problem per-sists contact
service.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 18
REPLACEMENT PARTS:
Replacement parts can be ordered through your local Drymatic representative or DBK directly. Available parts include:
Hose Kits (4 Hoses with adaptors in a carry case) - FGPH072
Additional Plastic Hose Adaptors (with band clamp) - FGPH082
High Temperature PVC Hoses - DT0048, High Temperature Aluminium Hoses - DT0021
230V Mains Cords - UK - HA5343, Europe - HA5344, Australia - HA5202, USA - HA5347, CAN - HA5375
120V Mains Cords - USA - HA5346, CAN - HA5374
Fuse (15A, 500V Fast Blow Cartridge) - EC308
Additional parts available on request. Please check your correct mains cord against your model number in the
maintenance section.
MODEL IDENTIFICATION:
Your model number can be found on the side of the power rating sticker (see component identication page). Here
you will nd your model number and power requirements as shown below: - Please note model number, approvals
and symbols may be di󰀨erent for your machine.

INSTRUCTION MANUAL DBK HEAT DRYER
Page 19
PRODUCT SPECIFICATION:
Model FGPH061 FGPH062 FGPH063 FGPH064 FGPH065 FGPH066 FGPH070 FGPH071
Country for use UK Europe Australia/
NZ
USA
Standard
USA High
Power Scandanavia Canada
Standard
Canada
High
Power
Power/kW 2.5 2.5 2.05 1.4 2.5 2.05 1.4 2.5
Voltage/V 230 230 230 120 230 230 120 230
Max Current/A 10.9 10.9 8.9 11.6 10.9 8.9 11.6 10.9
Frequency/Hz 50 50 50 60 60 50 60 60
Air Movement 650m³/hr (380cfm) Recirculation Mode, 595m³/hr (350cfm) Exhaust Mode,
Weight 25kg (55lbs) excluding removable attachments and hoses.
Dimensions 35 x 64 x 93 cm (13.9 x 25.3 x 36.6 in)
Max Air O󰀨 100°C (212°F)
Operating
Range -20°C to 50°C (-4°F to 122°F)
Construction Rotomoulded double skinned housing
Safety CE CE CE UL UL CE UL UL
