Clint CAD15 User manual

1
www.clintdigital.com
CAD15
USER MANUAL
DAB/DAB+ Digital
Radio Adapter

www.clintdigital.com
CAD15
DAB/DAB+ Digital Radio Adapter
User Manual

www.clintdigital.com
CAD15 User Guide
Table ofContent
INTRODUCTION .................................................................................................................... 1
CONTENTS OF PACKAGE....................................................................................................2
OVERVIEW OF THE CONTROLS AND CONNECTORS.......................................................3
INSTALLATION....................................................................................................................... 4
BASIC LCD DISPLAY AND OPERATION...............................................................................9
STARTING UP THE SYSTEM .............................................................................................. 12
USING DAB ADAPTER ........................................................................................................ 13
To Turn On or Set Standby Mode in CAD15............................................................... 13
To Adjust LCD Brightness ........................................................................................... 13
To Scan for the DAB Stations...................................................................................... 13
To Listen to the DAB Stations...................................................................................... 13
To Change DLS/DL+ Information Display ................................................................... 13
To Save a Memory Preset........................................................................................... 14
To Recall a Memory Preset......................................................................................... 14
To Recall the Last Listened DAB Station..................................................................... 14
USING AUDIO STREAMING................................................................................................ 15
To Set the Auxiliary Input mode................................................................................... 15
To Set the Bluetooth Audio Input mode....................................................................... 15
USING HANDS FREE FUNCTION....................................................................................... 16
FM TRANSMITTING FREQUENCY SETTINGS .................................................................. 17
To Set FM Transmitting Frequency Manually .............................................................. 17
To Save a Desired FM Transmitting Frequency in Memory......................................... 17
To Recall FM Transmitting Frequency Saved in Memory............................................ 18
To Force Immediate FM Transmitting Frequency Change .......................................... 18
MENU SETTINGS ................................................................................................................ 19
To Enable DLS/DL+ Display........................................................................................ 19
To Set DAB Sorting Order........................................................................................... 19
To Perform DAB List Reset ......................................................................................... 19
To Enable Bluetooth.................................................................................................... 19
To Setup Bluetooth Pairing.......................................................................................... 20
To Display Bluetooth Information ................................................................................ 20
To Reset Bluetooth Pairing.......................................................................................... 20
To Change the Link Mode ........................................................................................... 21
To Set Auto Power Down Time.................................................................................... 21
To Set Antenna Power................................................................................................. 21
To Change the Background Display............................................................................ 22
To Upgrade Module Software...................................................................................... 22
To Restore to Factory Settings.................................................................................... 22
TROUBLESHOOTING ......................................................................................................... 23
INFORMATION ON WASTE DISPOSAL.............................................................................. 25

1
www.clintdigital.com
1
CAD15 User Guide
INTRODUCTION
The CAD15 is an in-car digital audio adapter that offers a flexible and cost effective way toapply
modern digital audio technology toyourexisting analogue in-car audio system.
The existing analogue system can be easily upgraded to receive digital signal without replacement of
any component of the car audio system. CAD15 supports the Hands free function and caller ID
display for the incoming call to the Bluetooth connected mobile device, receive the audio streaming
from a mobile device using the Bluetooth technology, receive the DAB digital radio service output
from the DAB antenna, and receive the audio output from an audio device such as MP3 or iPod®etc.
digital music player, then convert all these digital signal to an FM signal. The FM signal is then
transmitted on a FM frequency and listen through the in-car audio system.
The CAD15 is operated on its own with a LCD display and a set of control keys, and all controls and
messages related to the system’s operations, such as station name, memory preset, etc., are
displayed on the CAD15 unit itself.
CAD15 comes with two pre-enabled features for the users. The Traffic Announcement feature
interrupts the DAB service you are currently listening, switches to a station that broadcasts traffic
report and allows you to change routes plan for avoiding traffic congestion. The Service Following
feature provides users with the seamless listening to the same broadcaster as CAD15 switches
ensembles/frequencies automatically while the user travels through different broadcast region
barrier, and the same broadcaster broadcasts its common programming on an ensemble with
multiple frequencies or on more than one ensembles.
Furthermore, CAD15 has an AFC (Automatic Frequency Change) function that allows you to
continuously listen to your favorite DAB programs thru your car radio system without the need to
change the FM frequency manually when you drive into a metropolitan area where FM stations are
highly crowded. Consult your car radio manual or the car dealer if your car radio is RDS compatible,
has the AF (alternative frequency) function, and how to enable AF function before using this AFC
function.
ATTENTION
While working with the AFC function, the possible factors that could affect its normal operation are:
1. The FM sensitivity varies among car radios and the sensitivity can affect AFC’s performance.
2. The algorithm implemented in each car radio’s AF feature varies and this can affect radio’s FM
frequency tuning when triggered by AFC.
3. While the system is in Aux mode and listening to an audio device, if the device’s volume is turned up
too high, it can affect AFC’s performance.
If AFC function is unable to function normally, please disable AFC and use AutoScan mode instead.
Please refer to Menu Settings section, To Change the Link Mode.

2
www.clintdigital.com
2
CAD15 User Guide
CONTENTS OF PACKAGE
CAD15 unit
Power cable
with cigarette lighter
Cradle
DAB Antenna User Guide
ATTENTION
You must use the supplied power cable with cigarette lighter only, and not any other power cables,
to work with CAD15; and you must not use the supplied power cable to work with any other devices. If
you do not follow this instruction, damage may occur which is not covered by the warranty.
CAD15
User Guide

3
www.clintdigital.com
CAD15 User Guide
3
OVERVIEW OF THE CONTROLS AND CONNECTORS
Front Panel
❶LCD
❷Control keys and rotary knob
➌Main microphone
Back Panel
❶Snap-in, for cradle
❷Gaps, for securing antenna cable and power cable
➌SW update cable connector
Side Panel
❶SMB Connector, for DAB antenna
❷3.5mm stereo audio jack, for aux in/out
➌Power jack, for supplied power cable
➍Auxiliary microphone
❶
❷
❷
➌
➍
❶➌
➌
❶
❷

4
www.clintdigital.com
4
CAD15 User Guide
INSTALLATION
Please read the installation procedure carefully prior to the actual installation. Consult a professional
installer if you have any issues or concerns with the installation.
1. From the backof CAD15 unit, snap the cradle into the unit.
2. Mount the cradle.



Peel off the backing ofthe 3M tape on the bottom ofthe cradle.
Attach the cradle to a desiredlocation, and then press the bottom ofthe cradle to
permanently secure the cradle and CAD15 unit.
Alter the CAD15’s orientation as necessary by using the adjustable knob of the cradle.
3. Install the supplied DAB antenna; please refer to the section on Antenna Installation.
ATTENTION
We have fully tested the DAB Antenna,ifsupplied, to work with CAD15. If you use a third
party’s DAB antenna, the performance may suffer.
For CAD15 to work with the active antenna, the antenna power must beset to ON.
CAD15 can also work with a passive antenna; you must set the antenna power to OFF.
Anytime you need todisconnect/connect the antenna from CAD15,please unplug
CAD15 from the cigarette lighter first to avoid possible damage to the antenna.
Damage resulted from incorrect installation of the antenna is not covered by the warranty.
4. Secure the antenna cable on the back ofthe CAD15 unit, so that it won’t fall off, and then
plug the antenna cable to CAD15.
Fit the antenna cable tightly into the gap on the back ofthe CAD15 unit leaving about

10cm ofslack tothe end of the antenna cable.
Plug the end connector ofthe antenna cable into the antenna connector located on the
side panel of CAD15.
5. Secure by fitting the supplied cigarette-lighter power cable into the gap on the back ofthe
CAD15 unit, and then plug the cable connector into the power jack located at the side panel
of CAD15.
6. Plug the cigarette-lighter power plug into the cigarette lighter,this will also power on CAD15.

5
www.clintdigital.com
5
CAD15 User Guide
Antenna Installation
Overview
Caution:
1. Please read the detail section of the installation procedure carefully prior to the actual
installation.
2. This glass-mount DAB antenna is exclusively for use inside the vehicle.
3. It is not suitable for use on reflective-coated glass.
4. Do not bend or damage the antenna.
5. The antenna should be installed on the passenger side of the front windshield, or the rear
windshield for safety.
6. The car’s DAB receiver must provide a 12V phantom power to the SMB connector for the DAB
antenna.
Warning: Once the antenna is adhered to the windshield it cannot be relocated. Please test the
antenna in its location before removing the adhesive separator and permanently fixing it to the
windshield. The antennas that have been adhered in location are not valid for return and
warranty claims.
Procedure
1Front windshield installation
1.1 For the best performance in the digital reception, the glass-mount antenna must be
placed on the top right corner and on the inside of the front windshield. If there is a
UV protection layer across the top of the windshield then you must place the DAB
antenna with Antenna 1 at least 5cm below the layer.
❶
➌
❷
❶
Antenna 1
❷Antenna 2
➌Signal Booster
➍Antenna Cable
➎SMB Connector
➎
➍

6
www.clintdigital.com
CAD15 User Guide
6
1.2 The glass-mount antenna must be placed outside of the swept area of the windshield
w i p e r.
1.3 The windshield usually has a black enamel band around the edges that contains a
border of dots and a black-shade area. Please attach Antenna 2 over at least part of
the black-shade area and not just over the dotted area only, and as close to but not
inside the A pillar cover (shown below) to get a better performance.
2Rear windshield installation
2.1 If the antenna cable length can reach to the rear windshield, the glass-mount antenna
can be placed on the top right corner and on the inside of the rear windshield that is
not reflective-coated. Same as the front windshield installation, attach the Antenna 2
over the black band, and as close to the edge of the windshield as possible.
2.2 For windshields with the electric defroster, there are tiny electric lines across the glass.
For best performance to receive the digital reception, the Antenna 1 must not be
aligned with the defroster’s electric lines as illustrated below:

7
www.clintdigital.com
CAD15 User Guide
7
Fig 1: This is the recommended antenna installation for the best performance.
Fig 2: Top of the Antenna 1 is aligned with an electric line, this will hinder the reception
quality and it is not recommended.
Fig 1 Fig 2
3Clean the windshield.
Ensure the antenna location on the windshield is clean and free of dirt, water, and other
substance which will help the antenna adhere to your car windshield properly. Clean the glass
with alcohol prep pad, and wait until the surface is completely dry before attaching the
glass-mount DAB antenna.
Do not use a cleaner with surfactant to clean the windshield because Antennas 1 & 2
and the Signal Booster may not stick to the glass.
4Attach the glass-mount antenna to the windshield.
4.1 As it is designed to be attached once only, if the antenna is removed, it will not adhere
again; therefore, it is recommended that you try fitting the antenna on the chosen
location first before attaching the antenna permanently.
4.2 Gently peel off the adhesive separator of Antenna 2 and paste it on the inside of the
windshield on the chosen location, press and rub to bond it to the glass.
4.3 Repeat step 4.2 for the Signal Booster.
4.4 Repeat step 4.2 for the Antenna 1, allow for a small slack of Antenna 1 before attaching
it to the glass (see below). This is to prevent over pressed the joint, between the
Antenna 1 and the Signal Booster, and breaks the Antenna 1.
Signal
Booster
Signal
Booster
Antenna 1

8
www.clintdigital.com
CAD15 User Guide
8
4.5 Secure the antenna cable along the edge of the side windshield.
a) Clip the supplied 3 mini-clips on the antenna cable just below the antenna.
b) Gently peel off the clips’ adhesive separator.
c) Paste the clips along with the antenna cable on the edge of the windshield.
5Route the antenna cable within the car interior.
Route the antenna cable along the left side edge of the windshield and then route the antenna
cable within the car interior to the DAB receiver, make sure the antenna cable does not
interfere with the safe operation of steering wheel, air bags, and seatbelts or other equipment.
6Connect to the DAB receiver.
6.1 Power off the DAB receiver.
6.2 Plug the SMB connector at the end of the antenna cable into the DAB receiver’s DAB
antenna input connector.
6.3 Power on the DAB receiver and start using your DAB receiver with the DAB antenna.
NOTE: To achieve best performance, Antenna 1 must not be placed over a UV protection layer, while
there is no such restriction to Antenna 2.
DAB Receiver
DAB Antenna
Mini Clip

9
www.clintdigital.com
CAD15 User Guide
9
BASIC LCD DISPLAY AND OPERATION
Basic LCD Display – DAB Mode
1. DAB signal strength for the selected DAB station
2. Bluetooth indicator
3. Bit rate for the selected DAB station
4. DAB/DAB+ indicator for the selected DAB station
5. Channel frequency for the selected DAB station
6. DAB station name for the selected DAB station
7. DLS/DL+ information and ensemble name display for
the selected DAB station, or Hands Free information
(Bluetooth device name, Caller ID, Active Line)
8. System’s FM transmitting frequency to car radio
9. Link mode indicator - AFC_H, AFC_L, or AUTOSCAN
Basic LCD Display – Audio Steaming
1. System’s FM transmitting frequency to car radio
2. Link mode indicator - AFC_H, AFC_L, or AUTOSCAN
3. Audio streaming indicator
4. Bluetooth indicator
No icon – disabled
– enabled but not connected
– enabled and connected
5. Auxiliary input /Bluetooth audio input, icon display, or
Hands Free information (Bluetooth device name,
Caller ID, Active Line)

10
www.clintdigital.com
CAD15 User Guide
10
Basic operation
There are 6 control keys and a rotary knob in the CAD15 unit:
Control
key
General operation
1
Press to enter Preset List in group 1.
Keep pressing key 1 to move among the 4 memory presets locations.
Press the rotary knob to recall the desired memory preset, or press and hold key 1 to program
the desired memory preset with the listening DAB station.
Press and Hold to toggle LCD backlight brightness level between high and low.
3
MODE
Press to enter Preset List in group 3
Keep pressing key 3 to move among the 4 memory presets locations.
Press the rotary knob to recall the desired memory preset, or press and hold key 3 to program
the desired memory preset with the listening DAB station.
Press and Hold to toggle CAD15 audio input between DAB or AUX mode.
2
Press to enter Preset List in group 2
Keep pressing key 2 to move among the 4 memory presets locations.
Press the rotary knob to recall the desired memory preset, or press and hold key 2 to program
the desired memory preset with the listening DAB station.
Press and Hold to enter Menu Function
DAB R adioTex t – enable/disable display of DLS/DL+ information from the station,
DAB List Order – change DAB station list sequence by alphabet or ensemble.
DAB List Reset – erase the DAB station list and perform a full scan of DAB stations
Bluetooth – enable/disable Bluetooth function.
Bluetooth Pair – enter Bluetooth device pairing mode.
Bluetooth Info – display the connected device information.
Bluetooth Reset – perform reset to erase all existing paired devices setup.
Link Mode – select operating mode (AFC_H/AFC_L/AutoScan).
AutoPowerDown – select inactive timeout (no key pressed) to standby mode
Antenna Power – set ON for active DAB antenna, set OFF for passive antenna.
Set Background – change the LED background display.
Module Upgrade – upgrade the module software to a new version.

Factory Reset– return all system settings to factory defaults.
4
SCAN
Press to enter Preset List in group 4.
Keep pressing key 4 to move among the 4 memory presets locations.
Press the rotary knob to recall the desired memory preset, or press and hold key 4 to program
the desired memory preset with the listening DAB station.
Press and Hold to Perform a full scan for DAB stations.

11
www.clintdigital.com
CAD15 User Guide
11
Rotary
Knob
Press
Turn on CAD15 while itis in standby mode
Confirm a selection, from the station list, presets, menu item, or frequency change
Change DLS/DL+ information, ensemble name while listening toa DAB station.
Toggle the control ofplay/pause while in the Bluetooth audio streaming mode.
Toggle to mute or un-mute the active phone call
Press and Hold to set CAD15 to standby mode, while it is on.
Rotate [◄][►]
Step tune to select a DAB station.
Navigate toitems, sub items, and settings after entering the MENU function
Adjust FMtransmitting frequency by 100 KHz after LINK is pressed
Control of previous/next song while in the Bluetooth audio streaming mode.
Switch between two active phone calls
Accelerate Rotation [◄][►] to do a quick tune oradjust FMfrequency by 2 MHz.
LINK
Press
Display adaptor’s current FM transmitting frequency.
Select and set the FM transmitting frequency manually or from memory presets.
Save the FM transmitting frequency setting to one of the four memory presets.
Answer the incoming phone call.
Press and Hold to perform an immediate FM transmitting frequency change.
BACK
Press
Recall the last listened DAB station.
Cancel an operation, or return to home screen display from the menu selection.
Reject the incoming phone call or hang up the active call.
Press and Hold to reset FM transmitting frequency to 87.6MHz.

12
www.clintdigital.com
12
CAD15 User Guide
STARTING UPTHE SYSTEM
1. Plug the cigarette-lighter power plug into the cigarette lighter, this will also power on CAD15.
2. CAD15 will perform a Scan ofDAB stations automatically.
3. Turn on your in-car audio system.
4. Enable the AF function on your car radio if it isequipped (Consult your car radio manual or the
car dealer if your car radio has AFfeature, and how toenable AF feature).
5. Tune the car radio’s FM frequency to match to CAD15 FM TXfrequency as shown on the screen.
Default is 87.6
6. If FM 87.6MHz isalready used by a FMbroadcaster orthe station is noisy, change the initialFM
TX frequency as below:
a) Operating on CAD15
Press and hold LINK for 3 seconds, CAD15 will seta new and clear frequency to transmit
the FM signal.
b) Operating on Car Radio
Tune the car radio’s FMfrequency tomatch to CAD15 FM TXfrequency shown on the
LCD display screen; the CAD15 and the car radio are now synchronized.
7. If your car radio does not have AF feature, do the following to change CAD15’s LINKMODE to
AutoScan instead of the default AFC.
a) Press and hold MENU to enter the menu function.
b) Rotate the Rotary Knob [◄] [►] until the selection is《Link Mode 》.
c) Press the Rotary Knob, and then rotate theRotary Knob [◄] [►] until the selection is
《AUTOSCAN 》.
d) Press the Rotary Knob,the function of AutoScan is nowenabled and the CAD15 is
operating in the AutoScan mode.
8. Now you can listen to the DABstations. For the system operation, please refer to USING DAB
ADAPTER section.
9. While you are using AutoScan function and you are experiencing noise on the listening DAB
station, please refer to To Force Immediate FM Frequency Change or To Set FM Transmitting
Frequency Manually to force or manually switch to another FM frequency.

13
www.clintdigital.com
CAD15 User Guide
13
USING DAB ADAPTER
To Turn On or Set Standby Mode in CAD15
1. Press and hold the Rotary Knob to set tostandby mode, while CAD15 is in the operating mode.
2. Press the Rotary Knob to return it tothe operating mode,while CAD15 is in standby mode.
To Adjust LCD Brightness
1. Press and hold DIMMER to toggle the two LCD backlight brightness levels.
To Scan for the DAB Stations
This function searches and adds all DAB stations in Band III from channel frequency 5A to 13F that
are available in the area where your car is presently located.
1. Press and hold SCAN to do a full scan of DAB stations, the screen will show《SCANNING 》.
To Listen to the DAB Stations
There are two options available for you to select and listen to a DAB station: Quick Tune and Step
Tune. Step Tune is used when you want to step through the station list one by one. Quick Tune
allows you to move more quickly through the station list.
Step Tune
1. Rotate the Rotary Knob [◄] [►],the screen will show the station list and the current selection.
Continue the rotation to step through the station list, one by one, and stop at the desired
station in the station list: 《station name 》
2. Press the Rotary Knob to tune to the desired station.
Quick Tune
1. Accelerate rotating the Rotary Knob [◄] [►], the screen will show the station list and the
current selection. Each accelerated rotation will move through the alphabet sequence to the
first or last station of the next or previous initial letter in the alphabet from the current
selection, if the station list is sorted alphabetically; or move through the ensemble sequence if
the station is sorted by ensemble. Repeat the accelerated rotation, one alphabet at a time, or
one ensemble at a time, until the screen shows the DAB station with desired initial alphabet or
the desired ensemble.
2. Do the Step Tune to tune to the desired station.
To Change DLS/DL+ Information Display
The CAD15 provides certain information, in one or three lines on screen when enabled, about the
current listening station.
1. While the station information is being displayed, each time you press the Rotary Knob, the
screen will cycle through the four station’s information below

14
www.clintdigital.com
14
CAD15 User Guide
《DLS》it displays real time Dynamic Label Segment (DLS) station information
such as song titles, music type and news or traffic updates.
《DL+ track info 》it displays the Dynamic Label Plus (DL+) extended information for the
song track.
《DL+ artist info 》it displays Dynamic Label Plus (DL+) extended information for the
song artist.
《Ensemble name 》it displays the ensemble name for the listening station.
To Save a Memory Preset
You can save your favorite stations in the memory preset List. There are 4 groups (1to 4) of memory
presets, and each group has 4 sets of memory location (A, B, C, D). While listening to a DAB station Z,
do the following to save the station:
1. Press the preset control key X(Xfrom 1 to 4) that corresponds to the preset group you would
like to save to. The screen will display the list of 4 memory preset XY (Y from A to D).
2. Keep pressing the preset key Xuntil the desired preset XY (where Yis from A to D, in the
memory preset list for X group) is selected, then press and hold the preset key Xto save the
DAB station Z into memory preset XY. The screen will show 《XY station Z》.
To Recall a Memory Preset
This function allows you to recall a preset favorite DAB station from the memory preset.
1. Press the preset control key X for preset group X that the desired DABstation is stored under;
the screen will present a list of4 memory presets XY (Y from A to D), while CAD15 is tuning to
the last listened memory preset station XY immediately.
2. Keep pressing the preset key X until the desired DAB station XY (where Yis from A to D in the
memory preset list for X group) is selected.
3. Press the Rotary Knob to tune to the selected preset station.
To Recall the Last Listened DAB Station
The CAD15 automatically remembers the station that is last listened to. This allows you to go back
to last listened DAB station quickly; even it is not in the memory Preset List.
1. Press BACK to recall the station that was most recently listened to.

15
www.clintdigital.com
CAD15 User Guide
15
USING AUDIO STREAMING
The CAD15 is capable of receiving audio streaming and play the audio through your car radio.
There are two input sources, the auxiliary input and Bluetooth audio input, see below for the setup.
While in the audio streaming you can return to the DAB mode and listen to the DAB station by one of
the following:
To listen tothe last listened DAB station, you must press and hold MODE to return to DAB
mode and then CAD15 will tune to thelast listened DAB station.
To recall a preset DAB station, you must press a Xcontrol key directly (where Xis from 1 to 4)
to return to the DABmode and tune to the last listened memory preset in preset group X. If
the preset is empty then CAD15 will tune to the last listened DAB station instead.
To Set the Auxiliary Input mode
The auxiliary input mode is setup to play audio device such as MP3 or iPod® etc.
1. Press and hold MODE to switch to audio streaming screen and start listening to the audio when
an audio device is connected to the input audio jack.
2. The play control is operated from your audio device.
To Set the Bluetooth Audio Input mode
The Bluetooth audio input mode is setup to play audio from your mobile device (Smartphone or
Tablets) using the Bluetooth technology, you must enable CAD15’s Bluetooth function,
and then perform the Bluetooth device paring between CAD15 and your mobile device, if they
are not already paired, before the connection is made. For detail, please refer to the menu
setting sections for To Turn Bluetooth On/Off, To Start Bluetooth Paring,and To Reset
Bluetooth Pairing.
1. Press and hold MODE to switch to audio streaming screen and start listening tothe audio if a
mobile device is connected to CAD15 using Bluetooth.
2. Rotate the Rotary Knob clockwise to advance the play tothe next song in the list.
3. Rotate the Rotary Knob counterclockwise to return the play to the previous song in the list.
4. Press the Rotary Knob to toggle the play/pause control.
5. The play control can also be operated from your mobile device.
The auxiliary Input mode takes precedence over the Bluetooth audio input mode if both are
setup for audio streaming. Therefore, once the auxiliary cable has been plugged into the aux in jack,
you can only listen to audio from the auxiliary input even if the Bluetooth audio input is also setup.

16
www.clintdigital.com
CAD15 User Guide
16
USING HANDS FREE FUNCTION
The CAD15 is capable of providing the Hands Free function for incoming and outgoing phone calls
from your mobile device using Bluetooth technology and listen to the audio through your car radio.
To use this function, you must enable Bluetooth and do the Bluetooth pairing first, please refer to
the menu setting sections for To Turn Bluetooth On/Off, To Start Bluetooth Paring. CAD15
can support up to two phone calls at the same time to a Bluetooth connected phone while the
system is operating in either DAB mode or Audio Streaming mode.
1. Incoming call indication
While a call, either the first or the second call, is ringing, there will be a warning tone from the
car radio, and the screen will show《Bluetooth Device Name; Caller ID 》.
2. Answer an incoming call
Press (LINK) to answer the first or the second incoming call, the screen will show
《Bluetooth Device Name; Line - X 》where X = 1 or 2 of the call sequence.When you
answer the second call, the first call is put on hold automatically.
3. Reject an incoming call
Press (BACK) to reject the first or the second incoming call.
4. Make an outgoing call
You must make outgoing calls from your Smartphone and while the destination is ringing, the
screen will display 《Connecting; Outgoing call 》until the destination answers.
5. Switch between two active calls
Rotate the Rotary Knob [◄] [►]to switch between the two active calls.
6. Hang up a call
Press (BACK) to hang up the active call.
7. Mute/Un-Mute the active call
Press Rotary Knob to mute/un-mute the active call with a warning tone from the car radio
every 3 seconds when the call is muted.
ATTENTION
The destination party may experience echo on a hands free call, when this happens, please try the
following steps, in sequence, to lessen the echo effect:
1. Adjust your car radio’s volume
As car radio’s volume range varies among different models, adjust the volume to comfortable
but not a loud level while listening to the far end on a call.
2. Adjust your Smartphone’s volume
Use your phone’s volume button and lower the Bluetooth connection’s volume setting to
decrease the echo effect. As there are many different made of Smartphone, the setting can
dif fer. For example, the suggested setting for iPhone users is 5 notches below the maximum
setting.

17
www.clintdigital.com
CAD15 User Guide
17
FM TRANSMITTING FREQUENCY SETTINGS
The FM transmitting frequency isused by CAD15 to transmit the audio and for car radio to
receive the audio. The FM transmitting frequency can be changed by the following:
1. Set FM transmitting frequency manually
2. Recall FM transmitting frequency saved in the memory
3. Force immediate FM transmitting frequency change
To Set FM Transmitting Frequency Manually
If you wish to change the setting and use your own selected FM transmitting frequency manually, do
the following:
1. Press LINK, and the screen will show the current FM Transmitting Frequency《Frequency 》.
2. You can accelerate rotating the Rotary Knob [◄] [►]tostep up or down FMfrequency by 2MHz,
or just rotate the Rotary Knob [◄] [►]tostep up or down FM frequency by 100KHz, to choose a
frequency until the desired FM frequency is displayed (e.g. 106.7MHz).
3. Then press the Rotary Knob, the CAD15 will setand transmit FMsignal atthis new frequency.
The screen will display the new frequency asthe current frequency.
4. Press FM preset of your car radio corresponding to the same frequency from step 2 if you have
previously saved for DAB reception. Otherwise, tune the car radio tothe same FM frequency.
5. Now you can listen to DAB stations via this new FM Frequency.
It is recommended to setthe selected FMfrequency as one ofthe memory presets ofyour car
radio, selecting this particular preset FMfrequency and together with setting the CAD15’s FM
transmitting frequency will quickly enable you to start listening to DAB stations.
To Save a Desired FM Transmitting Frequency in Memory
It is suggested to save a few frequencies (up to 4 frequencies) in CAD15 so that you can switch to a
new FM transmitting frequency instantly when you drive into an area where the original FM
frequency for DAB is no longer available.
1. Press LINK, and the screen will show the current FM Transmitting Frequency《Frequency
MHz 》.
2. You can accelerate rotating the Rotary Knob [◄] [►] to step up or down FM frequency by
2MHz, or just rotate the Rotary Knob [◄] [►] to step up or down FM frequency by 100KHz, to
choose a frequency, until the desired FM frequency is displayed (e.g. 106.7MHz).
3. Then press and hold a Xcontrol key (where Xis from 1 to 4) to save the current selected FM
frequency into the corresponding preset memory FX.
4. The screen will display a short message of 《FX SAVED 》.
The default FM frequencies saved in presets F1 to F4 are 87.6MHz, 92.5MHz, 102.5MHz and
107.9MHz, respectively.
