Clipper C13 User manual

OWNERS
MANUAL
Small Concrete Saw
MODEL:
C13
FORM <<7317 3/2005

2
WARRANTY
Norton warrants all products manufactured by it against defects in
workmanship or materials for a period of one (1) year from the date of
shipment to the customer.
The responsibility of Norton under this warranty is limited to
replacement or repair of defective parts at Norton's Gainesville,
Georgia factory, or at a point designated by it, of such part as shall
appear to us upon inspection at such point, to have been defective in
material or workmanship, with expense for transportation borne by
the customer.
In no event shall Norton be liable for consequential or incidental
damages arising out of the failure of any product to operate properly.
Integral units such as gasoline engines, electric motors,batteries,
tires, transmissions, etc., are excluded from this warranty and are
subject to the prime manufacturer's warranty.
This warranty is in lieu of all other warranties, expressed or implied,
and all such other warranties are hereby disclaimed.
Important: Before placing equipment in operation, record the following
information.
MODEL:_________ SERIAL NO.___________
PURCHASE FROM: _____________________
ADDRESS: ____________________________
CITY_______ STATE ______ ZIP ________
TELEPHONE NO. ______________________
Before using this equipment, make sure that person using it
read and understand the instructions in this owner’s manual.

3
Table Of Contents
CONTENTS PAGE
I. Preparation
A. Safety Precautions 4-6
B. Assembly 7
C. C13 Series Concrete Saw Specifications 8
D. Engine Specifications 9
E. Pointer Alignment 9
II. Operation
A. Blade Installation 9-10
B. Starting The Engine 10
C. Water Supply 10-11
D. Operating The Saw 11
E. Cutting Technique 12
III. Maintenance
A. Engine 13-14
B. Bearings 14-15
C. V-Belts 15-16
D. Depth Control 16
IV. Parts List Section
A. Ordering Information 17
B. Parts Drawing 18-19
C. Service Parts List 20
Read Owners Manual Before Use
Safety Alert Symbol: Information Following This Symbol Is Very
Important.
Use Only Clipper Diamond Blades

4
I. PREPARATION
A. Safety Precautions
Important! The following safety precautions must always be observed.
Hazard Symbols
Fuel (gasoline) is extremely flammable and its vapors can explode
if ignited. Store gasoline only in approved containers, in well-
ventilated, unoccupied approved areas, and away from sparks or
flames. Do not fill the fuel tank while the engine is hot or running.
Do not start the engine near spilled fuel. Never use the
fuel as a cleaning agent
Engine components can get extremely hot from operation. To
prevent burns, do not touch the engine or related parts while the
engine is running or immediately after it is turned off. Never
operate the engine with any heat shields or guards removed.
Keep all guards in place when operating any piece of equipment
Keep hands, feet, hair, and clothing away from all rotating parts
Lethal Exhaust Gas use only in well ventilated areas. Engine
exhaust gases contain poisonous carbon monoxide, which is
orderless, colorless, and can cause death if inhaled. Avoid
inhaling exhaust fumes, and never run the engine in a closed
building or confined area
Never tamper with the governor components of settings to
increase the maximum speed. Severe personal injury and damage
to the engine or equipment can result if operated at speed above
maximum. Always obey the maximum speed rating of blade.
DO NOT LIFT THE SAW BY THE HANDLE BARS

5
Dust and Silica Warning
Grinding/cutting/drilling of masonry, concrete, metal and other materials can
generate dust, mists and fumes containing chemicals known to cause serious or
fatal injury or illness, such as respiratory disease, cancer, birth defects or other
reproductive harm. If you are unfamiliar with the risks associated with the
particular process and/or material being cut or the composition of the tool being
used, review the material safety data sheet and/or consult your employer, the
material manufacturer/supplier, governmental agencies such as OSHA and
NIOSH and other sources on hazardous materials and make certain to comply
with all product warnings and instructions for the safe and effective use of the
material being cut. California and some other authorities, for instance, have
published lists of substances known to cause cancer, reproductive toxicity, or
other harmful effects.
Control dust, mist and fumes at the source where possible. In this regard use
good work practices and follow the recommendations of the
manufacturer/supplier, OSHA/NIOSH, and occupational and trade associations.
Water should be used for dust suppression when wet cutting is feasible. When
the hazards from inhalation of dust, mists and fumes cannot be eliminated
through engineering controls such as either vacuum and/or water mist, the
operator and any bystanders should always wear a respirator approved by
NIOSH/MSHA for the material being cut.
Use Approved:
Eye Protection Hearing
Protection Respiratory Protection Head Protection

6
1. Before mounting any blade on the saw, the blade should be inspected for
any damage which might have occurred during shipment, handling or
previous use.
2. The blade collars and arbors should be cleaned and examined for
damage before mounting the blade.
3. The blade must be properly fitted over the arbor with the drive pin on the
outside collar projecting through the drive pin hole on the blade and
inside collar.
4. The blade shaft nut, which is a left-hand thread nut, must be tightened
securely against the outside blade shaft collar.
5. The blade must be operated within the specified maximum operating
speed listed on the blade.
6. Turn water control valve to full to provide adequate coolant (4 to 6
gallons per minute) for diamond blades and wet cutting abrasive blades.
Insufficient coolant could result in severe blade breakage or diamond
segment separation.
7. The blade guard must be in place with the nose guard down and locked
when the saw is running.
8. The operator should wear safety glasses and any other appropriate
safety equipment.
9. When starting the saw, the operator should stand away and to the side of
the blade.
10. If for any reason the saw should stall in the cut, raise the blade out of
the cut. Check the outside blade shaft collar and nut for tightness.
Inspect the blade for damage before restarting the saw. Use caution
when resuming a cut. Be certain that the blade is in alignment with the
previous cut.
11. During cutting operations, do not exert excess side pressure on the
handles as a method of steering. Do not force the blade into the cut by
lowering the blade too fast or by pushing the saw too fast.
You Are Responsible For Your Safety!!!

7
I. PREPARATION
B. Assembly
The compact concrete saws are shipped completely assembled and ready for
use except for diamond blade, gasoline, oil, and handle bar. Inspect the saw
for shipping damage. If any damage is found, contact the shipper
immediately and file a freight claim. The Norton Company is not responsible
for any freight-related damages. Remove the saw from the pallet. Reverse
the position of the handlebars so that the handle bar sticks out towards the
operator. Adjust the handlebars to the desired height. Attach the handlebars
to the saw with the supplied hardware. Read and understand the remaining
sections of this Owners Manual. NOTE: Do not install the blade until it is
time to use the saw. ANSI regulations prohibit the transportation of any
concrete saw with the blade installed.
Part # Description QTY
027021 Screw Din931 M10 x 25 Hex Head Cap 1
028098 Screw Din933 M10 x 65 Hex Head Cap 1
027006 Nut Din934 M10 HFX 2

8
C. C13 Series Concrete Saw Specifications
Dimensions/Weight
Length (Working) 45.66” (1160 mm)
Length (Transport) 33.50” (850 mm)
Width 39.50” (1003 mm)
Height 39” (990 mm)
Weight 220 lbs (100 kg)
Engine
Engine Mfg. Honda
Spec No. GX390K1QXC9
Engine Type Single Cylinder 4 Cycle
Horse Power 13 hp (9.5kW) @ 3,600 rpm
Max Torque 19.5 ft-lbs (26.5 Nm, 2.7 kg-m) @ 2,500 rpm
Model GX390K1QXC9
Model GX390
Cooling System Air
Oil Capacity 1.1 liter (1.16 US qt)
Fuel Capacity 6.5 liter (1.79 US gal)
Fuel Type Unleaded Gasoline (86 pump octane)
Low Oil Sensor Yes
Air Filtration Four Stage Cyclone
Characteristics
Max Blade ∅16” (406 mm)
Depth of Cut 16” (406 mm) 5.75” (146 mm)
14” (356 mm) 4.75” (121 mm)
12” (305 mm) 3.75” (95 mm)
Arbor Bore 1” (25.4 mm)
Blade Shaft Locking Device Machined Into Flats Of Tight Collar
Blade Shaft Speed 2850 rpm
Depth Control Hand Wheel With Screw Feed
Depth Lock Standard
Depth Gauge Customer Installed Accessory
Number Of V-Belts 4
Blade Guard Type Hinged, All Steel Construction
Right or Left Side Cutting Yes
Lifting Bale Built In
Handle Bars Adjustable, Stays Level At All Times
Water Tank Standard
Water Tank Capacity 5.28 US Gallons (20 liter)
Water Hose Connector Standard Garden Hose With Flow Control Valve
Recessed Rear Wheels Standard
Sound pressure188 db(A)
Sound power1105 db(A)
1) the sound measures have been made following pr EN 12638, Annex A; 2)“ Floor sawing, grooving and milling machines – Safety “

9
D. Engine
Prior to attempting to operate the engine, read the information
contained in the engine owner's manual. An engine owners manual is
supplied with every gasoline powered concrete saw.
1. Check Oil: Add oil if low. Refer to the engine owner's manual for the
recommended SAE viscosity grades. Capacity of oil is 1.1 liters (1.16 US
qt)
2. Check Fuel: Fill if low. Use only unleaded gasoline with a pump sticker
octane rating of 86 or higher is recommended. Never use an oil and
gasoline mixture!
3. Air Cleaner: Never run the engine without the air cleaner! Rapid engine
wear will result from contaminants being drawn through the carburetor and
into the engine.
4. Engine Starting: Refer to the engine owner's manual for proper engine
starting procedure.
E. Pointer Alignment
1. Use a straight edge, and carefully mark a line 12 feet long on a smooth
level surface.
2. Place the saw blade on the marked line, move the saw to the center of the
marked line and then lower the blade until it is about 1/16” above the
marked line
3. Measure from each end of the saw frame to insure that the frame is
parallel to the marked line. Adjust the saw as needed.
4. With the blade centered on the marked line and the saw frame parallel to
the marked line, lower the front pointer.
5. Adjust the pointer by bending it until is aligned with the marked line.
II. OPERATION
A. Installing the Blade
1. Disconnect the spark plug.

10
2. Remove the blade shaft nut, (Turn clockwise) , and remove the outside
collar.
3. Clean off any foreign particles on the clamping surfaces of both collars
and on the mounting surface of the blade.
4. Place the blade on the blade shaft, lining up the drive pin hole in the
blade with the drive pinhole in the inside collar.
Use only Clipper Diamond Blades. This machine was not
designed for the use with abrasive blades.
5. Slide the outside blade shaft collar onto the blade shaft . The drive pin
on the outside collar must project through the drive pin hole in the
blade and into the inside collar.
6. Tighten the blade shaft nut (counter-clockwise) securely against the
outside collar.
7. Reconnect the spark plug.
Blades Use Only Clipper Diamond Blades
B. Starting the Engine
1. Refer to the engine owner's manual for the proper starting procedures.
2. Always cut with engine rpm in the full throttle setting.
C. Water Supply
Pressurized source: Turn the water control to full "ON" when using wet
cutting blades. The required flow rate is 4-6 gallons per minute.
Water Tank on saw: This supply is designed for use with dry blades to
keep the dust levels down. The tank will not supply the proper water flow
rates when used with wet cut only blades. Do not drink the water from this
tank. Fill the tank with water only. Close the water tank valve. Attach the
saws water supply hose to the tank outlet. Fill the tank with water. The
capacity of the tank is 5 US Gallons. When you are ready to cut, adjust
the water supply rate until a fine mist or a slow trickle is made. The

11
use of water greatly decreases the amount of dust produced during the
cutting process, aids in the cooling of the blade, and provides additional
stability.
•Use Only Water In The Water Tank
•Do Not Drink From The Tank
D. Operating the Saw
1. For blade installation instructions see section II. Operation sub heading A.
Installing the Blade. For the engine starting instructions, see the Engine
manual and follow the instructions located in section II. Operation sub
heading B. Starting the Engine.
2. Check the Engine Oil level.
3. Raise the saw to the full upright position. Do not let the blade come in
contact with the ground.
4. Maneuver the saw to the desired starting point.
5. If wet cutting, connect the water supply to the saw.
6. Follow the instructions for starting the engine found in the Engine manual.
7. If wet cutting, turn on the water supply at the source and then open the
water valves on the saw. Make sure that there is a minimum of 4-6 gallons
per minute of water flow!!
8. Be sure the engine is running at full throttle!!!
9. Slowly lower the blade by rotating the hand wheel clockwise until the
desired depth of cut is reached. Use a reasonable rate of feed. Do not
force the blade into the cut!!
10. When the end of the cut is reached, slowly raise the blade out of the cut
by rotating the Hand Wheel counter-clockwise until the blade is at least
one (1) inch above the ground.
11. Only move the saw in reverse with the blade in the raised position.

12
13. When moving the saw to a new location, be sure the blade is not
touching the ground. Always pay close attention to where you are
moving and where the blade is at all times.
E. Cutting Technique
Lower the blade into the concrete to the required depth by turning the hand
wheel clockwise.
Reduce the forward pressure if the saw begins to stall.
Note: For deeper cuts (4 inches or more), several cuts should be made in
incremental steps of 1-1/2 to 2 inches until the desired depth of cut is
reached.
Push the saw steadily forward using the front pointer as a guide. Exert
enough forward pressure so that the engine begins to labor, but does not
slow down. If the saw begins to stall, reduce the forward movement until full
rpm is restored to the blade. If the saw stalls, raise the blade out of the cut
before restarting. Avoid excessive side pressure or twisting of the blade in
the cut.
Additional Guide Lines For Sawing:
•Understand and follow all of the instructions in this owner’s manual.
•If wet cutting, turn on the water supply so that there is a minimum of 4-6
gallons per minute of water flow!!
•In critically hard aggregate, more than a single pass may be needed to cut
the desired depth.
•If the saw stalls in the cut, immediately stop the forward speed and raise
the blade out of the cut. If this is not done the belts can fail or the blade
may be damaged.
•Go slowly with a new blade until it opens up, that is, until the diamonds
can be seen and felt.

13
III. MAINTENANCE
A. Engine
Follow the below schedule for engine maintenance. NOTE: Check the Honda
Engine manual that came with the engine for any changes to the
maintenance schedule. If the charts have any differences, follow the chart in
the Honda Engine Manual. The Norton Company does not warranty the
engine. If any warranty or service of the engine is required contact your
nearest Honda service center, or from the Internet: http://www.honda-
engines.com/home.htm
Honda engine ( refer to owner's manual for complete maintenance.)
Check the engine oil level before each use when the engine is cool and the
engine is level. Add oil if the level is low. The oil level should be within the
operating range (see the eninge owner’s manual for details).
Only use a high-detergent, premium quality motor oil certified to meet or
exceed U.S. automobile manufacturer’s requirements for Service
Classification SG, SF/CC, CD. Motor oils will show the classification on the
container. A SAE viscosity of 10W-30 is recommend by Honda for general,
all temperature use. Please consult the below chart or contact your local
Honda service center for the proper viscosity for your temperature range.

14
Always refer to the engine manual for more detailed information on checking
the oil, changing oil, and oil capacity, air filter changes, and fuel type to use.
Use only Honda air filters. Do not clean the air filter with gasoline or other
flammable solvents. A fire or explosion could result. To clean, follow the
instructions found in the Honda engine manual.
Dry Cutting Engine Maintenance
9When operating the engine in dry cutting or dusty environments the following
is required:
9Engine oil changed more often.
9Every 50 hours (or more often if conditions require) clean all of the engine
cooling fins.
9Every 25 hours (or more often if conditions require) clean the engine
precleaner.
9Every 100 hours (or more often if conditions require) replace the air filter. If
the engine is equipped with a reusable air cleaner, clean and re-oil it.
9Check and clean the air filter after each use. Replace as needed.
B. Bearings
Re lubrication type bearings must be relubricated daily to assure long life.
The grease used should conform to the NLGI grade two and be free of
any chemical impurities such as free acid or free alkali, dust, rust, metal
particles or abrasives.

15
For best results, bearings should be relubricated while in operation. Note:
Due caution for personal safety must be observed when servicing
rotating equipment. The grease should be pumped in slowly until a
slight bead forms around the seals. This bead, in addition to acting as an
indicator of adequate relubrication, provides additional protection against
the entry of foreign matter. If necessary to relubricate while the bearing is
idle refer to relubrication table for maximum grease capacity for the
various size bearings.
Shaft Size Maximum Grease Capacity of
Bearing Chamber in Ounces
1/2"' to 3/4" 1/8
7/8" to 1-3/16" 3/8
1-1/4" to 1-1/2" 5/8
C. V-Belts
Warning: Never make adjustments to belts or pulleys while
engine is running!
1. The best tension for a belt drive is the lowest tension at
which the belts will not slip under full load.
2. Simply take up the drive until the belts are snug in the
grooves. Run the drive for about 15 minutes to "seat" the
belts. Then impose the peak load. If the belts slip, tighten
them until they no longer slip at peak load.
3. Remember, too much tension shortens belt and
bearing life!
4. Check the belt tension frequently during the first day of operation. Check
the belt tension periodically thereafter and make any necessary
adjustments.
5. The two most common causes of misalignment are shown in the drawing.
a). The engine drive shaft and the blade shaft are not parallel.
b). The pulleys are not located properly on the shafts.
6. To check alignment, all you need is a steel straight edge.
FIGURE 1 FIGURE 2

16
7. Line up the straight edge along the outside face of both pulleys as shown
in the drawing.
8. Misalignment will show up as a gap between the pulley face and the
straight edge.
9. Make sure that the width of the outside land (area between the belt and
the edge of the pulley) is equal on both pulleys.
D. Depth Control
The depth control (raising screw) consists of a threaded rod, which feeds into
a brass nut. In order to keep the two parts working smoothly it is necessary
to keep the rod free from dirt and sludge as much as possible. Cleaning the
threaded rod with a rag after each use will prevent sludge from collecting in
the tube assembly and protect the threads. It is a good practice to keep the
raising screw threads lubricated, as the slurry generated during cutting will
cause premature thread wear.
The bearing used to support the raising screw should be checked after each
use to make sure it is turning freely and lubricated. If the bearing requires re
lubrication lithium base grease is recommended.

17
IV. PARTS LIST SECTION
A. Ordering Information
1. List model number and serial number of machine.
2. List part number and serial number of part not the item number.
3. Wherever alternate parts are shown due to product improvement, inspect the part
you have and provide additional description as necessary.
4. Specify mode of shipping desired, such as, parcel post, truck, U.P.S., best way,
etc.
For the nearest Clipper distributor call 1-800-554-8003
Common Replacement Parts
Description Part Number
Belts V-belts XPZ 780 LW (set of 4) 80519
Blade Shaft Nut ¾-16 Left Hand Thread
(Operators Right Side Of Saw) 227156
Blade Shaft Nut ¾-16 Right Hand Thread
(Operators Left Side Of Saw) 227191
Collar Tight (Operators Right Side) 227159
Collar Tight (Operators Left Side) 227190
Collar Loose Assembly (With Pin) 227247
Drive Pin ∅3/8 x 1 227154
Bearing Blade Shaft (1) 72474
Front Wheel Complete (1) 82786
Rear Wheel (1) 80991
Wrench 1-1/2” 105377
Wrench 32mm 82910
Wrench 17mm 72279
NOTE: All Parts Are Sold As Individual (each) Unless Noted Otherwise
Blades Use Only Clipper Diamond Blades. Contact your local Clipper
Distributor or Clipper at 1-800-554-8003 for the best blade for the application.

18

19

20
Item DESCRIPTION Qty Part No
1 Basic Frame 1 83352
2 Rear axle assy. 1 82784
3 Rear Wheel 2 80991
4 Rear axle 1 82785
5 Front wheel complete 2 82786
6 Bushing Iglidur 20/23/11 4 80999
7 Bushing Iglidur (set of 2) 2 80297
8 Screw Feed.Spindle 1 82787
9 Raise-lower screw + key 1 83353
10 Bearing + Screw 1 76670
11 Stop ring A20 1 82789
12 Depth screw locking 1 83354
13 Handwheel + nut 1 76357
14 Handle 1 73428
15 Handwheel + Handle 1 76465
16 Handle Grip 1/2" 2 213633
17 Maneuvering bar cpl. 1 83355
18 Wrench 1"1/2 1 105377
19 Wrench 32mm 1 82910
20 Wrench 17mm 1 72279
21 Water Tank support 1 82792
22 Connector for Hose 1 9600017
23 Water cock 1 72357
24 Water tank complete 1 83357
25 Stopper for Water tank 1 82794
26 Blade shaft assy. 1 83358
27 Nut blade shaft right side
(left threaded) 1 227156
28 Loose collar 2 227247
29 Nut blade shaft left side
(right threaded) 1 227191
30 Inside collar right side
(left threaded) 1 227159
31 Bearing for blade shaft 2 72474
32 Inside collar left side
(right threaded) 1 227190
33 Blade shaft 1 83421
34 Blade shaft pulley 1 76347
35 Pointer Complete 1 80448
36 Blade guard assy 1 83365
37 Blade guard nut 1 83366
38 Blade guard axle 1 83367
39 Waterdistributor-Y 1 72286
40 Water supply tape 1/2" 1 107859
Item DESCRIPTION Qty Part No
41 Hose coupling 1 227116
42 Blade splash guard 1 82800
43 Motor frame 1 83369
44 Axle motor frame cpl 1 82802
45 Axle motor frame 1 82803
46 Brake complete 1 82804
47 Motor Honda 1 123327
48 Motor pulley compl. 1 81012
49 V-belts XPZ 780 LW
(set of 4) 1 80519
50 Belt guard compl. 1 83371
51 Screws for motor
(Set complete) 1 82814
58 Motor stop switch 1 227115
59 Water hose (set of 2) 1 82998
60 Reduction 1 83218
61 Blade shaft guard 1 83363
-NA- Pointer Bracket 1 99612-2
