Cloud CXA21K User manual

Carton Contents
• Amplier unit • Output connector x 1 or 2
• Rack mount ears (tted) x 2 • Adhesive rubber feet x 4
• Mains power cable • Document pack
• Input connector x 2 • GPIO socket connector
Support
• A full user manual that includes information on installation,
mounting accessories and amplier operation is available online.
Go too: www.cloud.co.uk
Wireless Network Control Connection
Connection Sockets
Wired Network Control Connection
• The amplier must be switched on before use via its front panel
Standby button. Do not switch on until all required signal and
control connections are made.
• High or low impedance speaker connection options can be selected
independently for each output channel via the conguration web
app
• Analogue input sensitivity can be adjusted independently for each
channel via the conguration web app.
Installation Notes
Network
Control
Congurable
GPIO
S/PDIF Audio I/O Audio Inputs
Balanced: Euroblock
Unbalanced: RCA Phono.
Congurable Speaker
Outputs
Mains
Power Input
• Audio I/O routing can be congured via the conguration web app.
• GPIO (General Purpose Input/Output) options can be congured via
the conguration web app.
• Ensure that rack or other conned installation does not restrict
the front to rear airow required for safe and reliable operation of
the amplier. It is important that the 40°C maximum operating
temperature for the amplier is not exceeded.
A mobile, laptop or desktop device with WiFi functionality and a
web browser is required.
Follow the steps below.
1. Connect the [Amp Name] amplier to mains power using the
supplied mains cable and switch it on via the front panel Standby
switch. Wait for the front panel WiFi indicator to illuminate green.
2. Use a mobile, laptop or desktop device to search for available WiFi
networks. Connect to, ‘[Amp Name] (product serial number)’ using the
password, ‘password’. The amplier serial number can be found on its
rear panel.
3. Open a mobile, laptop or desktop device web browser and enter
the following IP address: 192.168.4.1. The amplier conguration
web interface page will open in the browser app to enable amplier
conguration as required.
It is strongly recommended that the amplier WiFi password is
changed following initial wireless connection.
A laptop or desktop device with Ethernet functionality, a web
browser and a network scanning app is required.
Follow the steps below.
1. Connect the [Amp Name] amplier Network Control socket directly
to a laptop or desktop device - or through a switch.
2. Connect the [Amp Name] amplier to mains power using the
supplied mains cable and and switch it on via the front panel Standby
switch. Wait for the front panel Network indicator to illuminate green
to indicate that the amplier has network connectivity.
3. The default LAN IP address of the amplier is 192.168.64.100.
Congure your laptop or desktop device to a xed IP address in the
same IP range, ex. 192.168.64.10, with Subnet mask 255.255.255.0 (or
prex 24) and set Gateway to 192.168.64.1.
4. Open a laptop or desktop device web browser and enter the
address http://192.168.64.100/ - The amplier conguration web page
interface will open to enable amplier conguration as required.
QUICK START GUIDE
CXA SERIES DIGITAL AMPLIFIERS
MODELS: CXA21K & CXA215K

This symbol is intended to alert
the user to the presence of
uninsulated “dangerous voltage”
within the product’s enclosure
that may be of sufcient
magnitude to constitute a risk
of electric shock to persons.
Ce symbole a pour but d’attirer l’attention de l’utilisateur sur la présence, à
l’intérieur du boîtier de l’appareil, d’une « tension dangereuse » non isolée, qui
pourrait être sufsamment puissante pour représenter un risque d’électrocution
pour les personnes.
This symbol is intended to
alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
Ce symbole a pour but d’attirer l’attention de l’utilisateur sur la présence, dans la
documentation qui accompagne l’appareil, d’instructions importantes relatives à son
utilisation et sa maintenance (entretien).
Consignes de sécurité importantes
1. Veuillez lire ces instructions.
2. Conservez ces instructions.
3. Respectez tous les avertissements.
4. Suivez toutes les instructions.
5. N’utilisez pas cet appareil près de l’eau.
6. Nettoyez uniquement avec un chiffon sec.
7. N’obstruez pas les ouïes de ventilation. Installez l’appareil en respectant les
instructions du fabricant.
8. Éloignez l’appareil des sources de chaleur : radiateurs, bouches de soufage,
fours et autres (y compris les amplicateurs).
9. Pour réduire le risque d’électrocution, le cordon d’alimentation doit être
connecté à une prise de courant avec une mise à la terre de protection.
10. Respectez le dispositif de protection de mise à la terre de la prise secteur. Une
prise polarisée est équipée de deux ches, l’une plus large que l’autre. Une
prise avec borne de terre est équipée de deux ches et d’une borne de terre.
La che large, ou la borne de terre, est garante de votre sécurité. Si la che
secteur fournie avec l’appareil ne correspond pas à la prise secteur de votre
installation, faites remplacer cette dernière par un électricien.
11. Disposez les câbles de sorte qu’ils ne puissent pas être piétinés, coincés ou
pincés ; une attention toute particulière doit être accordée au niveau des prises
secteur et de l’embase secteur de l’appareil.
12. Ne débranchez pas l’appareil en tirant sur le cordon. Utilisez la che.
13. Débranchez cet appareil du secteur lors des orages ou des longues périodes
d’inutilisation.
14. Conez toute réparation à un technicien qualié. L’intervention d’un
technicien est nécessaire dans les cas suivants : le cordon d’alimentation ou
la prise secteur sont endommagés, des corps étrangers ou du liquide se sont
introduits dans l’appareil, l’appareil a été exposé à la pluie ou à l’humidité,
l’appareil montre des signes de dysfonctionnement ou est tombé.
15. Le coupleur de l’appareil, ou la che secteur, est le dispositif de déconnexion
du secteur et doit rester facilement accessible après l’installation.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation opening. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
9. To reduce the risk of electrical shock, the power cord shall be connected to a
mains socket outlet with a protective earthing connection.
10. Do not defeat the safety purpose of the polarized or grounding type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
11. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
12. Do not unplug the unit by pulling on the cord, use the plug.
13. Unplug this apparatus during lightning storms or when unused for long periods
of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
15. The appliance coupler, or the AC Mains plug, is the AC mains disconnect device
and shall remain readily accessible after installation.
This equipment must be earthed.
AVIS
RISQUE DE CHOC
ELECTRIQUE.
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
QUICK START GUIDE
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Class 2 Wiring
Exposed high voltage on the speaker terminals. Touching the
uninsulated terminals or wiring may result in an unpleasant sensation
Class 2 Câblage
Haute tension exposeé sur les bornes des haut-parleurs.Toucher
les bornes ou le câblage non isolés peuvent entraîner une sensation
désagréable
CXA SERIES DIGITAL AMPLIFIERS
MODELS: CXA21K & CXA215K
Cloud Electronics Limited 140 Staniforth Road, Shefeld S9 3HF UK [email protected] / www.cloud.co.uk
Issue_V1.1 E&EO
