Club 3D CSV-1430 User manual

CSV-1430 MANUAL
USB 3.0 3-Port Hub with Gigabit Ethernet
www.club-3d.com
SenseVision USB 3.0 Hub 3 Ports with Gigabit Ethernet
Support IEEE 802.3az (Energy Ecient Ethernet)
Support IPV4/IPV6 pack Checksum Ooad Engine
(COE) to reduce CPU loading
Slim design makes it easy to hand carry.
Support wake-on-LAN function
Support Green Ethernet
USB bus powered 3.3V/500mA
It works with Windows XP, Vista, 7, 8, 8.1, 10, Mac OS X
APPLE
OS X
APPLE
OS X
Microsoft
WINDOWS
Microsoft
WINDOWS
3x
USB
3.0
3x
USB
3.0
NO
NEED
POWER
SUPPLY
NO
NEED
POWER
SUPPLY
GB
ETHERNET
GB
ETHERNET
ULTRA
SLIM
SIZE
ULTRA
SLIM
SIZE

CSV-1430 MANUAL
Introduction
Features
Package Contents
System Requirements
www.club-3d.com
USB 3.0 3-Port Hub with Gigabit Ethernet
3x USB 3.0 Female
Gigabit Ethernet Female
1x USB 3.0 Male
USB 3.0 3-Port hub with Gigabit Ethernet adapter is compliant with USB 2.0
specification. It is two applications in the product. With USB interface, you can
access USB 3.0 Hub and Giga Ethernet at the same time. Stylish design and slim
type make it easy to carry.
USB 3.0 Giga LAN with 3 ports USB 3.0 HUB
Small design make users easy hand carry.
Support wake-on-LAN function
Support Green Ethernet
Support IEEE 802.3az(Energy Efficient Ethernet)
Support IPV4/IPV6 pack Checksum Offload Engine(COE) to reduce CPU loading
It works with Windows® and Mac OS®
Bus-powered
USB 3.0 3-port Hub with Gigabit Ethernet Adapter
CD (Driver & User’s Manual)
Quick Installation Guide
PC with USB port.
Laptop with USB port.
One of the following operation systems: Windows®& Mac OS®

www.club-3d.com
CSV-1430 MANUAL
USB 3.0 3-Port Hub with Gigabit Ethernet
Driver Installation on Windows™ and Mac OSX®
1. Insert the provided CD into your disc drive. Then locate and double-click the
setup.exe file under x:\Driver\Windows where x is your disc drive letter.
2. When you click setup.exe, you could see the screen as below
Caution: DO NOTconnect the USB HUb with Ethernet adapter to your
computer before you install the provided driver.You will be instructed
to do so later.
3. Click Finish to complete Ethernet Driver.
Now the installation is completed. You can connect the adapter to a network device by an
Ethernet cable:
1. Connect an Ethernet cable to the Ethernet port on the adapter.
2. Connect the other end of the Ethernet cable to your network hub, switch or router.
The Link LED should light up green to indicate a proper physical connection between the
adapter and the network. If the Link LED doesn’t light up, please verify the cable
connections between all the network devices.
*Actual strings depend on your operation system. These screen shots are from Windows®
8.1 and might vary slightly for each operation system.

www.club-3d.com
CSV-1430 MANUAL
USB 3.0 3-Port Hub with Gigabit Ethernet
On Mac OS®
1. Insert the provided driver CD into your CD-ROM drive. Double-click <AX88179
.pkg> to launch the setup procedure.
2. When the Install AX88179/178A Ethernet Adapter Driver screen appears, please
select Continue.
3. When the screen below appears, please click Install to install
4. Please enter your password as prompted, and click Install Software to start the ..
installation.

www.club-3d.com
CSV-1430 MANUAL
USB 3.0 3-Port Hub with Gigabit Ethernet
5. When the screen below appears, please click Continue Installation. 7. When the driver is successfully installed, click Restart to restart your computer
*Actual strings depend on your operation system. These screen shots are from Mac
OS® v10.9 and might vary slightly for each operation system.
6. It will take a while to install the driver.
