Emerson SC 820 User manual

1
Section 1 - Introduction
2-PORT SINGLE-HEAD SECURE KVM
Products covered by this manual - secure 2 port KVMs:

SC 820 –DVI-I Video

SC 820D –DisplayPort Video

SC 820H –HDMI Video
Rev: E
Doc No.: HDC10366
Secure KVM Switch 2-Port, Single-Head User Manual

2
2-PORT SINGLE-HEAD SECURE KVM
Table of Contents
Introduction ....................................................................................... 3
Intended Audience............................................................................. 3
Package Contents .......................................................................... 3
Revision.......................................................................................... 3
Overview ............................................................................................ 4
Safety Precautions ......................................................................... 4
Safety Precautions (French)........................................................... 5
User Guidance & Precautions........................................................ 6
Main Features................................................................................ 8
Tamper Evident Labels ................................................................ 10
Active Anti-Tampering System .................................................... 10
Product Enclosure Warning Label ............................................... 10
Equipment Requirements............................................................ 11
Front Panel Features ................................................................... 12
Rear Panel Features –SC 820 ...................................................... 13
Product Specifications ................................................................. 14
Before Installation ....................................................................... 15
Installation ....................................................................................... 16
Typical system installation........................................................... 17
Operation......................................................................................... 18
Operating the Product................................................................. 18
Troubleshooting Guide .................................................................... 19
Copyright and Legal Notice.......................................................... 22

3
2-PORT SINGLE-HEAD SECURE KVM
Section 1 - Introduction
Introduction
Thank you for purchasing this Emerson Secure product designed for
use in secure defense and intelligence installations. The product
provides the highest security safeguards and features that meet
today’s IA (information assurance) computing requirements as
defined in the latest PSS Protection Profile Rev 3.0.
This User Manual provides all the details you’ll need to install and
operate your new product.
Intended Audience
This document is intended for the following professionals:
•System Administrators/IT Managers
•End Users
Package Contents
Inside product packaging you will find the following:
Emerson Secure Product
DC Power Supply
User Guidance Documentation
Revision
A –Initial Release, 24 Feb 2015
B –Corrections, 5 April 2015
C –Product image updates, 25 May 2015
D –User Guidance updates, 21 June 2015
E –Correction to Features section, 13 August 2015
Important Security Note:
If you are aware of potential security vulnerability while
installing or operating this product, we encourage you to
contact us immediately in one of the following ways:
Web form: Emerson Support
Email: [e-mail]
Tel: [phone]
Important: This product is equipped with always-on active anti-
tampering system. Any attempt to open the product enclosure
will activate the anti-tamper triggers and render the unit
inoperable and warranty void.

4
2-PORT SINGLE-HEAD SECURE KVM
Section 2 - Overview
Overview
Safety Precautions
Please read the following safety precautions carefully before using
the product:
• Before cleaning, disconnect the product from any electrical power
supply.
• Do not expose the product to excessive humidity or moisture.
• Do not store or use for extensive period of time in extreme
thermal conditions –it may shorten product lifetime.
• Install the product only on a clean secure surface.
• If the product is not used for a long period of time, disconnect it
from electrical power.
• If any of the following situations occurs, have the product checked
by a qualified service technician:
oLiquid penetrates the product’s case.
oThe product is exposed to excessive moisture,
water or any other liquid.
oThe product is not working well even after carefully
following the instructions in this user’s manual.
oThe product has been dropped or is physically
damaged.
oThe product shows obvious signs of breakage or
loose internal parts.
oIn case of external power supply –If power supply
overheats, is broken or damaged, or has a damaged
cable.
• The product should be stored and used only in temperature and
humidity controlled environments as defined in the product’s
environmental specifications.
• Never attempt to open the product enclosure. Any attempt to
open the enclosure will permanently damage the product.
• The product contains a non-replaceable internal battery. Never
attempt to replace the battery or open the enclosure.
• This product is equipped with always-on active anti-tampering
system. Any attempt to open the product enclosure will activate the
anti-tamper triggers and render the unit inoperable and warranty
void.

5
2-PORT SINGLE-HEAD SECURE KVM
Section 2 - Overview
Safety Precautions (French)
Veuillez lire attentivement les précautions de sécurité suivantes
avant d’utiliser le produit:
Avant nettoyage, débranchez l’appareil de
l’alimentation DC / AC.
Assurez-vous de ne pas exposer l’appareil à une
humidité excessive.
Assurez-vous d’installer l’appareil sur une surface
sécurisée propre.
Ne placez pas le cordon d’alimentation DC en
travers d’un passage.
Si l’appareil n’est pas utilisé de longtemps, retirez
l’alimentation murale de la prise électrique.
L’appareil devra être rangé uniquement dans des
environnements à humidité et température
contrôlées comme défini dans les caractéristiques
environnementales du produit.
L’alimentation murale utilisée avec cet appareil
devra être du modèle fourni par le fabricant ou un
équivalent certifié fourni par le fabricant ou
fournisseur de service autorisé.
Si une des situations suivantes survenait, faites
vérifier l’appareil par un technicien de
maintenance qualifié:
oEn cas d'alimentation externe - L’alimentation
de l’appareil surchauffe, est endommagée,
cassée ou dégage de la fumée
oou provoque des court circuits de la prise du
secteur.
oUn liquide a pénétré dans le boîtier de
l’appareil.
oL’appareil est exposé à de l’humidité excessive
ou à l’eau.
oL’appareil ne fonctionne pas correctement
même après avoir suivi attentivement les
instructions contenues dans ce guide de
l’utilisateur.
oL’appareil est tombé ou est physiquement
endommagé.
oL’appareil présente des signes évidents de
pièce interne cassée ou desserrée
oL’appareil contient une batterie interne. La
batterie n’est pas remplaçable. N’essayez
jamais de remplacer la batterie car toute
tentative d’ouvrir le boîtier de l’appareil
entraînerait des dommages permanents à
l’appareil.
oCe produit est équipé d'toujours-sur le
système anti-sabotage active. Toute tentative
d'ouvrir le boîtier du produit va activer le
déclencheur anti-sabotage et de rendre l'unité
vide inutilisable et garantie.

6
2-PORT SINGLE-HEAD SECURE KVM
Section 2 - Overview
User Guidance & Precautions
Please read the following User Guidance & Precautions carefully
before using the product:
1. As product powers-up it performs a self-test procedure. In
case of self- test failure for any reason, including jammed
buttons, the product will be Inoperable. Self-test failure will
be indicated by the following abnormal LED behavior:
a. All channel-select LEDs will be turned ON and
then OFF;
b. A specific, predefined LED combination will be
turned ON;
c. The predefined LED combination will indicate the
problem type (jammed buttons, firmware integrity).
Try to power cycle product. If problem persists please
contact your system administrator or technical support.
2. Product power-up and RFD behavior:
a. By default, after product power-up, the active
channel will be computer #1, indicated by the
applicable front panel push button LED lit.
b. Product Restore-to-Factory-Default (RFD) function
is available via a physical control button on rear
panel. Use a sharp object or paper clip to hold RFD
button pressed for several seconds to initiate an
RFD action.
c. RFD action will be indicated by front panel LEDs
blinking all together.
d. When product boots after RFD, keyboard and
mouse will be mapped to the active channel #1 and
default settings will be restored, erasing all user-set
definitions.
3. The appropriate usage of peripherals (e.g. keyboard, mouse,
display, authentication device) is described in detail in this
User Manual's appropriate sections. Do not connect any
authentication device with an external power source to
product.
4. For security reasons products do not support wireless
keyboards and mice. In any case do not connect wireless
keyboard/mouse to product.
5. For security reasons products do not support
microphone/line-in audio input. In any case do not connect
a microphone to product audio output port, including
headsets.
6. Product is equipped with always-on active anti-tampering
system. Any attempt to open product enclosure will activate
the anti-tamper system indicated by all channel-select LEDs
flashing continuously. In this case, product will be
inoperable and warranty void. If product enclosure appears
disrupted or if all channel-select LEDs flash continuously,
please remove product from service immediately and
contact technical support.
7. In case a connected device is rejected in the console port
group the user will have the following visual indications:
a. When connecting a non-qualified keyboard, the
keyboard will be non-functional with no visible
keyboard strokes on screen when using the
keyboard.
b. When connecting a non-qualified mouse, the
mouse will be non-functional with mouse cursor
frozen on screen.

7
2-PORT SINGLE-HEAD SECURE KVM
Section 2 - Overview
c. When connecting a non-qualified display, the video
diagnostic LED will flash green and video will not
work.
d. When connecting a non-qualified USB device, fUSB
LED will flash green and USB device will be
inoperable.
8. Do not connect product to computing devices:
a. That are TEMPEST computers;
b. That include telecommunication equipment;
c. That include frame grabber video cards;
d. That include special audio processing cards.
9. Product has a remote control port in the back panel labeled
RCU. Do not use this port - it is inoperable and for future
use.
10. Important! Before re-allocating computers to channels, it is
mandatory to power cycle product, keeping it powered OFF
for more than 1 minute.
11. Product log access and administrator configuration options
are described in product Administrator Guide.
12. Authentication session will be terminated once product
power is down or user intentionally terminates session.
13. If you are aware of any potential security vulnerability while
installing or operating product, please remove product from
service immediately and contact us in one of the ways listed
in this manual.

8
2-PORT SINGLE-HEAD SECURE KVM
Section 2 - Overview
Main Features
Product is designed, manufactured and delivered in security-
controlled environments. Below is a summary of the main advanced
features incorporated in product:
Advanced isolation between computers and shared peripherals
The emulations of keyboard, mouse and display EDID, prevent
direct contact between computers and shared peripherals. Product
design achieves maximal security by keeping the video path
separate with keyboard and mouse switched together, purging
keyboard buffer when switching channels. All these features
contribute to strong isolation between computer interfaces,
maintained even when product is powered off.
Unidirectional data flow: USB, audio and video
Unique hardware architecture components prevent unauthorized
data flow, including:
Optical unidirectional data flow diodes in the USB data path
that filtrate and reject unqualified USB devices;
Secure analog audio diodes that prevent audio
eavesdropping with no support for microphone or any other
audio-input device;
Video path is kept separate from all other traffic, enforcing
unidirectional native video flow. EDID emulation is done at
power up and blocks all EDID/MCCS writes. For DisplayPort
video, filtration of AUX channel exists to reject unauthorized
transactions.
Isolation of power domains
Complete isolation of power domains prevents signaling attacks.
Secure administrator access & log functions
Product incorporates secure administrator access and log functions
to provide auditable trail for all product security events, including
battery backup life for anti-tampering and log functions. Non-
reprogrammable firmware prevents the ability to tamper with
product logic.
Always-on, active anti-tamper system
Active anti-tampering system prevents malicious insertion of
hardware implant such as wireless key-logger inside product
enclosure. Any anti-tampering attempt causes isolation of all
computers and peripheral devices rendering product inoperable and
showing clear indications of tampering event to user.
Holographic security tamper-evident labels are placed on the
enclosure to provide a clear visual indication if product has been
opened or compromised.
Metal enclosure is designed to resist mechanical tampering with all
microcontrollers protected against firmware-read, modification and
rewrite.

9
2-PORT SINGLE-HEAD SECURE KVM
Section 2 - Overview
Main Features (Cont.)
Small form factor:
Small form factor product occupying minimum desktop space.
Video Support
SC820 supports DVI-I displays as well as VGA and HDMI via
compatible cables.
SC820D supports DisplayPort1.1 & 1.2 displays.
SC820H supports HDMI displays.
Resolutions Supported
Products support video resolutions of up to 4K-2K Ultra HD (3840 X
2160 pixels).

10
2-PORT SINGLE-HEAD SECURE KVM
Section 2 - Overview
Tamper Evident Labels
Product uses holographic tamper evident labels to provide visual
indications in case of an enclosure intrusion attempt. When opening
product packaging inspect the tampering evident labels.
If for any reason one or more tamper-evident label is missing,
appears disrupted, or looks different than the example shown
here, please call Technical Support and avoid using that product.
Active Anti-Tampering System
Product is equipped with always-on active anti-tampering system. If
mechanical intrusion is detected by this system, the Product will be
permanently disabled and all LEDs will blink continuously.
If product indicates "tampered state" (all LEDs blinking) - please
call Technical Support and avoid using that product.
Product Enclosure Warning Label
Product has the following warning sticker on a prominent location
on the product enclosure:
Emerson Tamper Evident Label
