Clustrix CLX-IB-MQ08 User manual
Doc #: 770-0047-01, Rev1.0 Page 1
CLX-IB-MQ08
Quick Start Guide
Unpacking the InfiniBand Switch
1
Attaching the Rack Mount Bracket
2
Rack Mounting the InfiniBand Switch
3
Connecting the InfiniBand Switch
4
3. Attach the Right Mounting Bracket to the side of the IB
switch using the four 4-40 x ¼in Phillips Flat Head screws.
4. Repeat step 3 on the other side of the IB switch.
1. Open the box and set the rack mount kit aside.
2. Carefully lift the chassis out of the box and place it on a flat
clean surface. Reserve the shipping carton and packaging
materials for future use.
Rack Mount Kit parts
A.Left/Right Mounting Bracket.
B.bag of fasteners.
5. From the REAR of the rack, place the IB switch at the desired
height and attach to the REAR rack mounting rails. The IB switch
ports should face the rear of the CLX database appliance.
6. Connect the IB Switch PSU to power via supplied AC Power cord.
7. Connect the QDR IB port 1 from each CLX Database Appliance to IB
Switch via the supplied QDR IB cable, before powering up the
appliance. Once connected, power on the appliance and follow the
appliance quick start guide to form a cluster.
8. Repeat for Second IB Switch for a HA deployment.
CLX-IB-MQxx Quick Start Guide
Doc #: 770-0047-01, Rev01
2
Online Documents
As part of Clustrix’s green initiatives, we are moving to e-documents to reduce waste and redundancy. The
product documentation is available online or can be downloaded. Clustrix is committed to a future where
environmental values are key to the way we do business. We will continue to find solutions to reduce our
company impacts and help build safer and greener communities.
The following product documents are available on the Clustrix Support website (URL:
http://docs.clustrix.com/display/CLXDOC/Appliance+Documentation);
•CLX-IB-MQ08 Quick Start Guide
•CLX 4200 Series Quick Start Guide
•CLX 4200 Series Hardware Installation Guide
•CLX 4200 Series Regulatory Compliance and Safety Information
•CLX 4200 Series System Administration Guide
•Clustrix End Users License Agreement
Contacting Support
Use our support team! Contact us with any issues; we’re here to help with any problem you have using
Clustrix.
•Phone: +1 866-558-1309
•Support URL: https://support.clustrix.com
