CMT IC202 User manual

802.11 b/g Wireless IP Camera
Model : IC202/IC202w
User Manual
Revision: 1.07
Date: 2008/3/5
For firmware version v010612

CMT IP CAM IC202/w
Table of Contents
LIST OF FIGURES AND TABLES......................................................................................................4
1. INTRODUCTION..........................................................................................................................6
2. HARDWARE DESCRIPTION AND QUICK INSTALLATION/USAGE ................................7
2.1. MAJOR HARDWARE COMPONENTS.......................................................................................7
2.2. QUICK INSTALLATION AND USAGE ........................................................................................8
2.3. WIRELESS CONNECTION (FOR IC202W).............................................................................12
3. WEB CONFIGURATIONS........................................................................................................14
3.1. INFORMATION ......................................................................................................................15
3.2. VIDEO DISPLAY ...................................................................................................................16
3.3. NETWORK............................................................................................................................17
3.4. WIFI SECURITY (FOR IC202W)...........................................................................................19
3.5. ADVANCED NETWORK.........................................................................................................21
3.6. VIDEO SETTINGS.................................................................................................................22
3.7. 3GPP/RTSPSETTINGS......................................................................................................24
3.8. MOTION DETECTION............................................................................................................25
3.9. LED DISPLAY CONTROL......................................................................................................27
3.10. DATE/TIME...........................................................................................................................28
3.11. ADMIN..................................................................................................................................29
3.12. UPGRADE ............................................................................................................................30
3.13. REBOOT...............................................................................................................................31
3.14. SAFE MODE.........................................................................................................................32
3.15. SET TO FACTORY DEFAULT..................................................................................................33
4. FEATURES AND SPECIFICATIONS......................................................................................34
4.1. FEATURES ...........................................................................................................................34
4.2. SPECIFICATIONS..................................................................................................................35
5. PACKAGE CONTENTS............................................................................................................37
APPENDIX A. LIST OF TESTED NAT/ROUTER DEVICES........................................................38
APPENDIX B. MAXIMUM ALLOWED VIDEO USERS.................................................................39
APPENDIX C. PERFORMANCE INFORMATION .........................................................................40
APPENDIX D. TROUBLE SHOOTING............................................................................................41
APPENDIX E. 3GPP/ISMA OPERATION........................................................................................43
2

CMT IP CAM IC202/w
APPENDIX F. THIRD PARTY AND EMBEDDED WEB PAGE INTEGRATION........................44
3

CMT IP CAM IC202/w
List of Figures and Tables
Figure 2-1: Major components in the front panel
Figure 2-2: Major components in the back panel
Figure 2-3: IP CAM connection diagram.
Figure 2-4: Connect Ethernet cable to a switch/router.
Figure 2-5: The installation CD disk
Figure 2-6: The ID/Password card
Figure 2-7: Running window of CamView program
Figure 2-8: Pop-up play-video password window
Figure 2-9: Unplug the Ethernet cable to enable the WiFi function
Figure 3-1: Open the web configuration page from CamView software
Figure 3-2: IP CAM Web configuration login page
Figure 3-3: IP CAM Information page
Figure 3-4: Video display page
Figure 3-5: Network settings page for DHCP function
Figure 3-6: Network settings page for fixed IP address
Figure 3-7: WiFi security disabled page
Figure 3-8: WiFi security enabled page
Figure 3-9: WiFi testing page
Figure 3-10: Advanced network settings page
Figure 3-11: Video settings page
Figure 3-12: 3GPP/RTSP enabled page
Figure 3-13: Motion detection enabled page
Figure 3-14: Led Control settings page
Figure 3-15: System date/time settings page
Figure 3-16: Admin settings page
Figure 3-17: Firmware upgrade settings page
Figure 3-18: Firmware upgrade status page
Figure 3-19: System reboot settings page
Figure 3-20: System reboot under-going page
Figure 3-21: Safe mode information page
Figure 3-22: Stick the reset button to set to the factory default
Figure 5-1: IC202/W body
Figure 5-2: Power Adaptor
Figure 5-3: Bracket
Figure 5-4: Antenna
Figure 5-5: Quick installation guide
4

CMT IP CAM IC202/w
Figure 5-6: Ethernet cable
Figure 5-7: Installation CD
Figure 5-8: ID/Password Card
Table A-1: List of tested Wireless AP/router devices
Table A-2: List of tested Wired NAT/router devices
5

CMT IP CAM IC202/w
1. Introduction
The IC202/w IP Camera is designed with the “user-friendly” idea deep in mind.
The user can install the IC202/w easily on his/her home network and then access the
IP Camera anywhere in the world through the accompanied video management
software - CamView program without setting some complicated DNS name or
changing the router’s settings. It’s just a plug & play action.
For indoor surveillance and remote monitoring, the IC202/w provides the best
image quality in its class, and excellent performance. The IC202/w IP Camera also
provides the best bandwidth efficiency, it offers 640x480 resolution, 30 fps frame rate,
real MPEG4 image compression ability. The built-in microphone enables remote
users to not only view, but also listen for additional monitoring options.
Of course, with the built-in Web server, the IC202/w IP Cameras can also be
managed from a standard web browser on a Windows computer.
The IC202/w IP Camera provides both wireless IEEE 802.11 b/g and wired
Ethernet network interfaces for flexible installation. It supports the WEP and WPA
(Wi-Fi Protected Access) security modes to provide the best security for wireless
networks. (IC202 model only support wired Ethernet interface)
The IC202/w IP Camera provides motion detection function. Users can easily
setup this function and receive the notification with the snapshot images through
email and/or ftp when some motion events are detected.
The IC202/w IP camera is ideal for securing small businesses, home offices and
residences over a local area network and/or the Internet.
The differences
It’s very easy to see the video of the IC202/w IP Camera, you only need to key in
the ID/Password of the IP CAM any where in the world, you do not need to remember
the IP address or domain name or DDNS name or port number. And you do not need
to modify the settings(like port mapping, fixed IP, DDNS, virtual server) of the
NAT/router devices, it’s just a plug & play usage.
So, the differences are the followings:
♦Public IP address needed ? No
♦Dynamic DNS needed ? No
♦Port mapping in router? No
♦Virtual server in router ? No
♦UPnP support in router ? No
♦What’s needed ? ID and Password
6

CMT IP CAM IC202/w
2. Hardware description and quick installation/usage
The IP CAM is designed to be very easy to install and use. First, let’s see the
major components of the IP CAM products.
2.1. Major hardware components.
The major components on the front panel of the IP CAM products are the built-in
microphone, lens and LEDs :
1. Microphone – for receiving the audio/voice. Effective distance is about 5 meters.
2. Lens – the focus of the lens is fixed, you do not need to spend time to adjust the
focus, the effective focus range is from 40cm to infinity.
3. Status indication LED (red) – this LED is to indicate the Internet connection status.
When the Internet connection is connected, the LED will be constant red light. If
there is any Internet connection problem, the LED will be blinking red light.
4. Ethernet indication LED (blue) – this LED is to indicate if the Ethernet link is ok
and packet traffic is sending/receiving. When the Ethernet cable is connected, the
LED is constant blue light. When there is packet sending/receiving, the LED is
blinking blue light.
Figure 2-1: Major components in the front panel
The major components on the back panel of the IP CAM products are the bracket
screw jack, power jack, Ethernet jack and reset button:
1. Bracket screw jack – this is the position to screw in the bracket of the IP CAM.
With the bracket, you can put the IP CAM on the desk, on the wall or on the
ceiling.
2. Power jack – this is the place to plug in the power adaptor. The power needed for
this IP CAM is 5V/1.0A, please make sure you are using the correct power
adaptor.
3. Ethernet jack – this is the place to plug in the RJ45 Ethernet cable. When the
7

CMT IP CAM IC202/w
Ethernet link is ok, the Ethernet indication LED on the front side will be blue light.
4. Reset button – this is the button to reset the IP CAM to default factory settings.
You need to use a small stick like pencil or tooth stick to press the reset button for
more than 3 seconds to enable the reset function. Usually when you forgot the
administrator account, you will probably need to do this reset action to reset to the
default factory settings. Please refer to section 3.15 for more details.
5. Antenna jack(for IC202w) – this is the place to hold the wireless antenna. The
antenna must be plugged to let the 802.11 b/g wireless work.
Figure 2-2: Major components in the back panel
2.2. Quick installation and usage
There are only three things that you need to do to see the video from the IP CAM.
1. Connect the IP CAM to the home/office network.
2. Install the CamView software on the notebook/PC.
3. Key in the ID/password of the IP CAM(from the IP/Password card) on the
CamView, and then you can see the video.
First, Connect the IP CAM to the home/office network
Please connect the IP CAM accessaries to the IP CAM body correctly, including
the antenna, bracket, power adapter and Ethernet cable, as shown in Figure 2-3.And
connect the other end of the Ethernet cable to the home network or office network.
Usually, this Ethernet cable is plugged into a home NAT/router device or an Ethernet
switch if in the office, as shown in Figure 2-4. Since the default settings of the IP CAM
use DHCP function and very often there is a DHCP server on most of the Home/office
network, the IP CAM should be connected to the Internet immediately. The Internet
status LED is constant red light to indicate this good connection status. If the LED is
blinking, please refer to section 3.3~3.5 to try other network settings.
8

CMT IP CAM IC202/w
Figure 2-3: IP CAM connection diagram.
Figure 2-4: Connect Ethernet cable to a switch/router.
Second, Install the CamView software on the notebook/PC
Please insert the installation CD into the CD-ROM drive in your notebook or
personal computer (must be running Microsoft Windows OS). Execute the program
CamViewInstaller-xxx.exe on the disk. The program will pop-up some windows about
the installation options, please press the “next” button to proceed with the installation.
After the installation is complete, there will be a CamView icon on the desktop of your
computer screen, please execute this icon. The CamView program will run
immediately.
9

CMT IP CAM IC202/w
Figure 2-5: The installation CD disk
Third, Use CamView program to see the video
Figure 2-5 is the running window of the CamView program. If the computer and
IP CAM is connected to the same network, the IP CAM ID will be displayed in the
“Auto Search” list. You can double click the “Auto Search” to search all the connected
IP CAMs any time. The only thing left right now for seeing the video is to double click
the IP CAM ID item in the “Auto Search” list. For example, if the IP CAM ID is
001-001-029, you can then double click the 001001029 item in the “Auto Search” list
to view the video. A window asking for password input will pop up. Please key-in the
password in your ID/Password card into this field and click “ok”. The video will then be
displayed on the window.
Figure 2-6: The ID/Password card
Notice :
1. You can modify this play-video password by entering into the web configuration
pages. Please refer to section 3.6 for more information.
2. You can also add the IP CAM into the CameraList or GroupList in the CamView
software to have more convenient video display, please refer to the user manual
of the CamView software for more functions.
Seeing the video in a remote location
After the IP CAM is installed and you can see the video from the CamView
software in the local network, it’s very easy to see the video in a remote location.All
you need to do is add a camera item in the “CameraList” folder of the CamView
10

CMT IP CAM IC202/w
software, key in the IP CAM ID and Password(from the ID/Password card).And then
double click this camera item. You will then see the Camera video immediately. No
further NAT/router setting modifications are needed.
Figure 2-7: Running window of CamView program
Figure 2-8: Pop-up play-video password window
11

CMT IP CAM IC202/w
2.3. Wireless connection (for IC202w)
The IP CAM can also be connected to the home/office network through the
802.11 b/g wireless connection. There are only three things that you need to do to
have the wireless connection:
1. Set the WiFi security settings on the web configuration page.
2. Test if the WiFi settings are correct.
3. Unplug the Ethernet cable.
First, set the WiFi security settings on the web configuration page.
Make sure there is a WiFi router or AP on your home or office network. Write
down the WiFi security parameters used in this WiFiAP/router, including the SSID ,
security mode, encryption protocols and the “key” values. The supported WiFi security
mode of the IP CAM is WEP(64 bits and 128 bits) and WPA-PSK(TKIP and AES). In
most of the home/office WiFi environment, this is quite enough.
The easiest way to set the WiFi settings on the IP CAM is through CamView
software. Right-click the searched IP CAM in the “Auto Search” list and click the “Web
Configure” to open the login window of the IP CAM. Fill in all the WiFi security
parameters you have written down. The WiFi configuration is complete now.
Please refer to section 3.4 for more detailed description if needed
.
Second, test if the WiFi settings are correct
You can now test if the above WiFi settings are correct. Click the “WiFi test” on
the “WiFi Security” settings web page. The testing result will be displayed in less than
60 seconds. If the test is failed, please check the WiFi security parameters and test
again.
Third, unplug the Ethernet cable
If the WiFi test is successful, you can then enable the WiFi connection by
unplugging the Ethernet cable from the IP CAM. The IP CAM will detect the Ethernet
cable unplugged condition and start the WiFi connection. After the WiFi is connected,
the IP CAM will connect to the Internet immediately.
Notice :
1. Please remember that the WiFi connection will use a different IP address, you will
need to do the “Auto Search” function in the CamView again to find the IP CAM
again after the WiFi is connected.
2. If you want to switch back to the wired Ethernet connection, just plug in the
Ethernet cable into the IP CAM again. Do not need to disable the WiFi function on
the web pages.
12

CMT IP CAM IC202/w
Figure 2-9: Unplug the Ethernet cable to enable the WiFi function
13

CMT IP CAM IC202/w
3. Web configurations
You can login into the web configuration page by directly key-in the IP address of
the IP CAM or right-click the searched IP CAM in the “Auto Search” list of the
CamView software and click the “Web Configure” to open the login window of the IP
CAM.
Figure 3-1: Open the web configuration page from CamView software
The default login account is “admin”, leave the Password field empty.
Figure 3-2: IP CAM Web configuration login page
14

CMT IP CAM IC202/w
3.1. Information
The first page of the web configuration of the IP CAM IC202(w) is the information
page. You can see the model name/firmware version, IP CAM ID, registration status,
network type and current video settings( bandwidth, resolution) in this page.
The IP CAM can be viewed remotely by the CamView software only when the IP
CAM is registered. If this IP CAM is not registered, please check the Ethernet wiring of
your network environment. The “Network type” field displays the network
connection(wired or wireless) and method(DHCP, PPPoE or static ip) the IP CAM is
running. The “Video users” field displays the number of connected video viewing
users.
Figure 3-3: IP CAM Information page
15

CMT IP CAM IC202/w
3.2. Video Display
This display page allows you to view the video display of the IP camera. For the
first time use of this display on a computer, an activeX component will be
automatically downloaded into the browser. This could take some time, depends on
the internet speed. The component is downloaded from a public domain, so that the
computer must be connected to the Internet.
If you want to modify the video display screen size, please refer to section 3.6
for more details.
Figure 3-4: Video display page
16

CMT IP CAM IC202/w
3.3. Network
The Network page allows you to modify the network settings of the wired
Ethernet. The default settings use DHCP to obtain an IP address automatically. In
most of the home and office network environment, there is a DHCP server running. In
this situation, by using this default settings, the IP CAM can work immediately in most
of the time.
If the Ethernet cable is unplugged, the IP CAM will lose connection. But as soon
as the Ethernet cable is plugged in again, the IP CAM will obtain a new IP address
immediately.
Figure 3-5: Network settings page for DHCP function
If the network environment does not support DHCP function, you will need to set
the network settings of the IP CAM manually. Please fill all the fields including “IP
address”, “Subnet mask”, “Default gateway” and “DNS server” to let the network work.
All these settings must be correct for your network environment, otherwise the IP
CAM can not work.
The default setting is “Obtain an IP address automatically”.
17

CMT IP CAM IC202/w
Figure 3-6: Network settings page for fixed IP address
18

CMT IP CAM IC202/w
3.4. WiFi security (For IC202w)
You can use the wireless to connect the IP CAM to the network. If your network
environment has a 802.11 b/g router or AP running, you can check the “Enable WiFi
function” button to use the wireless.
Figure 3-7: WiFi security disabled page
In order to use the wireless network, you need to fill the following fields:
1. SSID – this is the ID of the wireless router or AP of your wireless network
environment, must be set correctly.
2. Security mode – this is the security mode used in the wireless router or AP. Need
to choose one of the three modes – None, WEP and WPA-PSK.
WEP : Wireless Encryption Protocol.
WPA : WiFi Protected Access.
PSK : Pre-Shared Key.
TKIP : Temporal Key Integrity Protocol.
AES : Advanced Encryption Standard.
3. WEP mode – when the WEP mode is chosen, you need also choose between
64-bit(5 char), 64-bit(10 hex), 128-bit(13 char) and 128-bit(26 hex) encryption
mode, and then fill the WEP key correctly.
4. WPA-PSK mode - when the WPA-PSK mode is chosen, you need also choose
between TKIP andAES encryption mode, and then fill the WPA-PSK key
correctly.
All the fields in this page must be filled correctly with the same settings the
wireless router or AP using.
19

CMT IP CAM IC202/w
Figure 3-8: WiFi security enabled page
You can also click the “WiFi test” button to check if the IP CAM can connect to
the wireless network for these settings. You will need to unplug the Ethernet cable to
enable the wireless connection after the “WiFi test” is successful.
After the setting and “Save&Apply”, do not need to restart the IP CAM to let the
WiFi work, only need to unplug the Ethernet cable.
The default setting is “Disable WiFi Function”.
Figure 3-9: WiFi testing page
20
