Ikegami HDL-F3000 User manual
3MOS HDTV CAMERA
HDL-F3000
Operation Manual
Products conforming to RoHS directive
1609 1st Edition (U) (E)
3MOS HDTV CAMERA
HDL-F3000
Operation Manual
Products conforming to RoHS directive
Copyright © 2016 Ikegami Tsushinki Co., Ltd.
We reserve the copyright on the software we create.
1R SDUW RI WKLV SXEOLFDWLRQ PD\ EH PRGL¿HG RU UHSURGXFHG LQ DQ\ IRUP RU E\ DQ\ PHDQV ZLWKRXW SULRU ZULWWHQ SHUPLVVLRQ
from Ikegami Tsushinki Co., Ltd.
iPRODUCTS CONFORMING TO RoHS DIRECTIVE
PRODUCTS CONFORMING TO RoHS DIRECTIVE
Following products described in this manual are products conforming to RoHS directive.
・
HDL-F3000 HDTV Camera
3URGXFWVFRQIRUPLQJWR5R+6GLUHFWLYHLQFOXGHSURGXFWVWKDWGRQRWFRQWDLQVSHFL¿HGKD]DUGRXVVXEVWDQFHVVXFKDVOHDGPHUFXU\
cadmium, hexavalent chromium, polybrominated biphenyl (PBB) and polybrominated diphenyl ether (PBDE) in electrical and
electronic equipment excluding following exemption applications based on the EU directive.
* About RoHS Directive
7KH5R+6GLUHFWLYHVWDQGVIRU³WKH5HVWULFWLRQRIWKH8VHRI&HUWDLQ+D]DUGRXV6XEVWDQFHVLQ(OHFWULFDODQG(OHFWURQLF
(TXLSPHQW´DQGLVRQHRIHQYLURQPHQWDOGLUHFWLYHVLQ(XURSH7KLVGLUHFWLYHUHVWULFWVWKHXVHRIVSHFL¿HGKD]DUGRXV
substances in electrical and electronic equipment.
ƔApplications exempted from RoHS directive compliance
Followings applications are permitted as exemptions from RoHS directive compliance.
0HUFXU\LQFRPSDFWÀXRUHVFHQWODPSVQRWH[FHHGLQJPJSHUODPS
0HUFXU\LQVWUDLJKWÀXRUHVFHQWODPSVIRUJHQHUDOSXUSRVHVQRWH[FHHGLQJ
・
halophosphate 10mg
・
WULSKRVSKDWHZLWKDQRUPDOOLIHWLPHPJ
・
triphosphate with a long lifetime 8mg
0HUFXU\LQVWUDLJKWÀXRUHVFHQWODPSVIRUVSHFLDOSXUSRVHV
0HUFXU\LQRWKHUODPSVQRWVSHFL¿FDOO\PHQWLRQHGLQWKLV$QQH[
/HDGLQWKHJODVVRIFDWKRGHUD\WXEHVHOHFWURQLFFRPSRQHQWVDQGÀXRUHVFHQWWXEHV
/HDGDVDQDOOR\LQJHOHPHQWLQVWHHOFRQWDLQLQJXSWROHDGE\ZHLJKWDOXPLQXPFRQWDLQLQJXSWROHDGE\ZHLJKWDQG
DVDFRSSHUDOOR\FRQWDLQLQJXSWROHDGE\ZHLJKW
7. Lead in following items
・
/HDGLQKLJKPHOWLQJWHPSHUDWXUHW\SHVROGHUVLHWLQOHDGVROGHUDOOR\VFRQWDLQLQJPRUHWKDQOHDG
・
Lead in solders for servers, storage and storage array systems
・
Lead in solders for network infrastructure equipment for switching, signaling, transmission as well as network anagement
for telecommunication
・
/HDGLQHOHFWURQLFFHUDPLFSDUWVHJSLH]RHOHFWURQLFGHYLFHV
8. Cadmium plating except for applications banned under Directive amending Directive relating to restrictions on the marketing
and use of certain dangerous substances and preparations
9. Hexavalent chromium as an anti-corrosion of the carbon steel cooling system in absorption refrigerators
10.Lead used in compliant pin connector systems
11.Lead as a coating material for the thermal conduction module C-ring
/HDGDQGFDGPLXPLQRSWLFDODQG¿OWHUJODVV
13.Lead in solders consisting of more than two elements for the connection between the pins and the package of microprocessors
ZLWKDOHDGFRQWHQWRIPRUHWKDQDQGOHVVWKDQE\ZHLJKW
14.Lead in solders to complete a viable electrical connection between semiconductor die and carrier within integrated circuit Flip
Chip packages
'HFDEURPLQDWHGGLSKHQ\OHWKHU'HFD%'(LQSRO\PHULFDSSOLFDWLRQV
ii MAINTENANCE OF PRODUCTS CONFORMING TO RoHS DIRECTIVE
MAINTENANCE OF PRODUCTS CONFORMING TO RoHS DIRECTIVE
Work with care about followings for maintenance of products conforming to RoHS directive.
1. Identification
・
For products conforming to RoHS directive, the letter “E” is appended at the end of the serial number on the label. For
models that the letter cannot be appended to the serial number, the letter “E” will be described in a distinguishable position
RQWKHODEHO$GHVFULSWLRQH[DPSOHRQDPDLQODEHOLVVKRZQEHORZ
MODEL HDL-F3000
SERIALNo. AA123456 E
Label
Product conforming to RoHS directive
・
Print-circuit board of the products conforming to RoHS directive is manufactured by following methods.
[1] Blue resist ink is used for the print-circuit board. (The color of conventional print-circuit board is green.)
[2] Either one of the following marks is indicated by a serigraph or label.
Phase 3A Phase 3
2. Soldering
6LQFHWKHPHOWLQJSRLQWRIOHDGIUHHVROGHUXVHGIRUWKHSURGXFWVFRQIRUPLQJWR5R+6GLUHFWLYHLVWRGHJUHHV&HOVLXV
higher than that of conventional solder with lead (Sn-Pb eutectic solder), a high temperature needs to be set to a soldering
iron. Taking allowable temperature limit of the parts and stable work into consideration, use a soldering iron with excellent
thermal recovery characteristics.
・
5HFRPPHQGHGVROGHUFRPSRVLWLRQLV³6Q$J&X´RUHTXLYDOHQW
・
Separate the soldering iron exclusively for RoHS products and the soldering iron for conventional use.
・
6HWWKHWHPSHUDWXUHRIWKHVROGHULQJELWWRWRGHJUHHV&HOVLXV
・
7KHWHPSHUDWXUHPD\QHHGWREHDGMXVWHGDFFRUGLQJWRWKHVL]HRIWKHFRSSHUIRLOODQGRQWKHSULQWFLUFXLWERDUGDQGWKHWLS
width of the soldering bit.
・
Finish by a lead-free solder looks dull or whitish compared to conventional solder with lead.
・
If the customer mixed the lead-solder with the main body wiring or the circuit board, it becomes guarantee off the subject.
Ikegami doesn’t guarantee to do the repair work. Because the solder polluted with lead cannot be removed.
3. Parts
Be sure to use parts conforming to RoHS directive.
iiiINFORMATION TO THE USER
INFORMATION TO THE USER
7KLVHTXLSPHQWKDVEHHQWHVWHGDQGIRXQGWRFRPSO\ZLWKWKHOLPLWVIRUD&ODVV$GLJLWDOGHYLFHSXUVXDQWWR3DUWRIWKH)&&
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
&KDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHSDUW\UHVSRQVLEOHIRUFRPSOLDQFHFRXOGYRLGWKHXVHU¶VDXWKRULW\WRRSHUDWH
the equipment.
The mark means
The CE mark means that the following products will meet the Directives 89/336/EEC, 92/31/EEC, 93/68/EEC and standards
(1(1$(1$(1$
・
+'/)+'79&$0(5$
8VHVKLHOGHGFDEOHH[FHSW$&FDEOH
This equipment is not intended for use in residential areas, so that use in residential areas may cause interference.
iv SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
This manual describes the precautions for you to use the product safely. Please read these precautions thoroughly before use.
1. Notes on this manual
(1) This manual is written for readers with a basic knowledge of handling this product.
Therefore, the explanation of technical terms is omitted in this manual.
(2) The content of this manual are subject to change without notice in the future.
2. Hazard Alert Symbol and Signal Term Regarding the Safety of This Manual
³+D]DUG$OHUW6\PERO´WKDWURXVHVWKHIROORZLQJDWWHQWLRQWRWKHFRQWHQWRIWKHVDIHW\UHODWHGH[SODQDWLRQ³6LJQDO7HUP´WKDW
shows the level of danger, “Notice” and “Reference” are used.
HAZARD ALERT SYMBOL
SIGNAL WORDSDANGER WARNING CAUTION
7KHV\PEROVXVHGLQWKLVPDQXDODUHDVIROORZV
,QGLFDWHVWKDWPLVKDQGOLQJRIWKHSURGXFWE\LJQRULQJWKLVODEHOPD\OHDGWRDGDQJHUUHVXOWLQJLQ
an injury or property damage.
6XSSOHPHQWDU\LQIRUPDWLRQRUJXLGDQFH
6HFWLRQVZKHUHUHODWHGLQIRUPDWLRQLVDYDLODEOH
3. Attention on handling of the equipment
7KLVSURGXFWLVGHVLJQHGZLWKVDIHW\LQPLQGVXI¿FLHQWO\+RZHYHUHOHFWURQLFSURGXFWVPD\FDXVHWKHHOHFWULFVKRFNDFFLGHQW
and the product damage by incorrect use or under the bad environment.
Therefore, please observe the following items for handling the product.
(1) Do not remove the cover or disjoint the product unless necessary to avoid the breakdown or the electric shock accident.
Doing so may cause not only the breakdown but also electric shock accident.
(2) $IWHUXVLQJWKHSURGXFWDOZD\VWXUQRIIWKH32:(5VZLWFK
Turning on the POWER switch though it is not used may cause the breakdown of the product or the accident when the
$&SDFNLVXVHG
(3) $YRLGWKHVWURQJYLEUDWLRQRUVKRFN)DLOXUHWRGRVRPD\FDXVHWKHGDPDJHDQGEUHDNGRZQRIWKHSURGXFW
(4) Do not lift or hold the product by the projection parts.
If you lift or hold the camera by the lens, you are prone to dropping it. Moreover, the connection parts between the
camera and the lens may be exposed to unnecessary pressure, which may cause equipment damage.
$OZD\VLQVWDOOWKHDFFHVVRULHVDIWHUSODFLQJWKHFDPHUDRQD¿[HGSRVLWLRQ
:KHQLQVWDOOLQJVXFKDFFHVVRULHV¿[WKHFDPHUDRQDVWDEOHSODFHHJRQDWDEOHDWULSRGHWF
(6) $YRLGXVHRUVWRUDJHLQWKHIROORZLQJFRQGLWLRQV
Failure to do so may cause the damage of parts.
・
Extremely high/low temperature
・
In direct sunlight for a long time, or near a heater
・
High humidity or dusty
・
Exposed to water or other liquid
・
Strong vibration or shock
・
6WURQJPDJQHWLF¿HOGRUUDGLRZDYHV
・
lightning
・
In rain without the rain cover
(7) Do not spread or spill water or other liquid on the equipment.
(8) $YRLGPRYLQJWKHHTXLSPHQWVXGGHQO\IURPDQH[WUHPHO\FROGSODFHWRDZDUPSODFH
Condensation may occur in the Image sensor.
(9) %HVXUHWRKROGWKHSOXJDQGSXOOZKHQ\RXGLVFRQQHFWWKHFDEOH)DLOXUHWRGRVRPD\FDXVHD¿UHRUHOHFWULFVKRFNGXH
to a broken cable.
vSAFETY PRECAUTIONS
(10) Regarding the Lithium Battery
・
Do not change the lithium battery inside the camera by yourself.
・
'RLQJVRPD\FDXVHH[SORVLRQOLTXLGOHDNDQGDWZRUVW¿UHRULQMXU\
When changing or discarding a battery, please contact Ikegami’s sales and service centers.
(11) Clean the product using a dry and soft cloth.
If the stain is hard, soak the cloth with water or detergent, wring well and wipe. If you use detergent, wipe off the
detergent with a cloth that is soaked in just water and wrung well.
When cleaning the product, be sure to turn off the power and do not spill water in the product.
(12) Laser beams may damage the Image sensor. If you shoot a scene that includes a laser beam, be careful not to let a laser
EHDPEHFRPHGLUHFWHGLQWRWKH,PDJHVHQVRU$ODVHUEHDPLQMHFWLRQLQWRWKH,PDJHVHQVRUPD\FDXVHWKHGDPDJH
4. Environmental Cautions
(1) When continuously operating the product in a rainy, cold or hot conditions, use a rain cover, cold-weather cover, and
shade cover respectively.
(2) $YRLGVWRULQJWKHSURGXFWLQDGXVW\SODFHIRUDORQJWLPH,IXQDYRLGDEOHXVHDGXVWSURRIFRYHU
(3) :KHQVKRRWLQJLQSODFHVVXFKDVDLUSRUWVPLOLWDU\EDVHVRUWUDQVPLWWLQJVWDWLRQVZKHUHPDJQHWLFDQGUDGLR¿HOGVDUH
excessively strong, completely shield the camera by covering it with aluminum foil.
5. Notice for Use
(1) When carrying or storing the product, always use a carrying case.
(2) Before shooting important subjects, take test shots to obtain the desired effect.
(3) $IWHUXVLQJWKHSURGXFWDOZD\VWXUQRIIWKHSRZHU
6. Regular maintenance is recommended
This product includes parts that wear out and have a limited life even in proper use or storage. Therefore, regular
maintenance is recommended to extend the life and safe use of this product for a long time. Please contact Ikegami's sales
and service centers for the regular maintenance and repair of our products.
7. The CE mark (Declaration of conformity)
7KH&(PDUNPHDQVWKDWWKHIROORZLQJSURGXFWVZLOOPHHWWKH6WDQGDUGV(1(1
8. FCC
7KLVHTXLSPHQWKDVEHHQWHVWHGDQGIRXQGWRFRPSO\ZLWKWKHOLPLWVIRUD&ODVV$GLJLWDOGHYLFHSXUVXDQWWR3DUWRIWKH
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
&KDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHSDUW\UHVSRQVLEOHIRUFRPSOLDQFHFRXOGYRLGWKHXVHUVDXWKRULW\WR
operate the equipment. This equipment doesn't intend to use at residential areas, so that use in residential areas may cause
interference.
9. Cable
8VHVKLHOGHGFDEOHH[FHSW$&FDEOH
CONTENTS - 1
HDL-F3000
OPERATION MANUAL
(TABLE OF CONTENTS)
PRODUCTS CONFORMING TO RoHS DIRECTIVE.........................................................................i
MAINTENANCE OF PRODUCTS CONFORMING TO RoHS DIRECTIVE .......................................ii
INFORMATION TO THE USER ..........................................................................................................iii
SAFETY PRECAUTIONS ..................................................................................................................iv
1. OUTLINE.......................................................................................................................................1-1
2. FEATURES ...................................................................................................................................2-1
3. NAME and FUNCTION of EACH PART.......................................................................................3-1
3.1 Camera Head......................................................................................................................3-1
3.2 Rear of the CCU..................................................................................................................3-2
4. INSTALLATION and CONNECTIONS..........................................................................................4-1
4.1 System Setup Diagram .......................................................................................................4-1
4.2 Lens Mounting.....................................................................................................................4-2
4.3 Connection of Power Supply ...............................................................................................4-3
4.4 Connection of Monitor.........................................................................................................4-4
4.5 Connection of Remote Control Panel..................................................................................4-5
4.6 Connection of Camera Cable..............................................................................................4-6
4.7 Connection of External SYNC Signal for Genlock ..............................................................4-6
5. OPERATION .................................................................................................................................5-1
5.1 Turning On Power................................................................................................................5-1
5.2 Auto Black Balance (ABB)...................................................................................................5-1
5.3 Auto White Balance (AWB) .................................................................................................5-2
5.4 Camera Menu .....................................................................................................................5-3
5.4.1 MENU PAGE 1........................................................................................................5-4
5.4.2 MENU PAGE 2........................................................................................................5-6
5.4.3 MENU PAGE 3........................................................................................................5-9
5.4.4 MENU PAGE 4........................................................................................................5-15
5.4.5 MENU PAGE 5........................................................................................................5-17
5.4.6 MENU PAGE 6........................................................................................................5-18
5.5 Engineer Menu....................................................................................................................5-24
5.5.1 Hierarchical Structure of the Engineer Menus ........................................................5-25
5.5.2 How to Change the Scanning Format.....................................................................5-27
6. SPECIFICATIONS ........................................................................................................................6-1
6.1 Rating..................................................................................................................................6-1
6.2 Performance........................................................................................................................6-1
6.3 Output Signal ......................................................................................................................6-2
6.4 Input Signal .........................................................................................................................6-2
6.5 External Appearance ..........................................................................................................6-3
6.6 External Connectors ...........................................................................................................6-4
7. CHANGING INFORMATION.........................................................................................................7-1
OCP-100 OCP-100 1209 VOL1 (J)
1. OUTLINE
7KH+'/)DUH³026+'79FDPHUDVIRUXVHZLWKDJ\URVWDELOL]HU´LQZKLFKRXUFXWWLQJHGJHFDPHUDWHFKQRORJLHVDQG
GLJLWDOWHFKQRORJLHVDUHXVHGWRLPSOHPHQWKLJKGH¿QLWLRQKLJKVWDELOLW\DQGKLJKUHOLDELOLW\
'HVLJQHGVSHFL¿FDOO\IRUXVHZLWKDJ\URVWDELOL]HUWKHRSWLFDOEORFNLQWKHFDPHUDKHDGLVPLQLPL]HGLQSK\VLFDOGHSWKWRIDFLOLWDWH
PRXQWLQJRQDVPDOOJLPEDO7KHFDPHUDFRQWUROXQLW&&8LVDOVRVXEVWDQWLDOO\UHGXFHGLQVL]HDQGZHLJKWWRIDFLOLWDWHLQVWDOODWLRQ
in helicopters where available space is a key consideration.
7KLVFDPHUDXVHVWKUHH0SL[HO&026VVXSSRUWLQJIXOO+'79îSL[HOVDQGGLJLWDOSURFHVV/6,$6,&XVHGIRU
broadcasting studio HDTV cameras to get resolution and color reproducibility comparable to broadcasting studio HDTV cameras.
1HZO\GHYHORSHG0SL[HO&026VDQGRXURZQFLUFXLWWHFKQRORJLHVUHDOL]HKLJKSLFWXUHTXDOLW\ZLWKDKLJKVHQVLWLYLW\RI)
and a high S/N ratio of 64dB.
1-11. OUTLINE
2. FEATURES
■Camera Head of 80mm Depth
The camera head is thinned to 80mm in physical depth to ensure adequate space for a long lens even when mounted on a
small gimbal. The camera head has no projecting parts as connector plugs on the rear side, making cable handling in the
JLPEDOHDV\,WQHHGQRWEHGLVDVVHPEOHGRUUHWUR¿WWHGIRUPRXQWLQJRQDJLPEDOHQVXULQJKLJKPDLQWDLQDELOLW\DQGQRLVH
performance.
■Small and Lightweight CCU
7KHUHGXFWLRQLQVL]HDQGZHLJKWRIWKH&&8IDFLOLWDWHVLQVWDOODWLRQLQKHOLFRSWHUVZKHUHPRXQWLQJVSDFHDQGDOORZDEOH
ZHLJKWDUHOLPLWHG9DULRXVFRQQHFWRUVDQGRSHUDWLRQSDQHOVDUHDOOODLGRXWRQWKHUHDUVLGHRIWKH&&8WRPLQLPL]HWKH
SK\VLFDOGHSWKZKHQPRXQWHGLQDKHOLFRSWHU7KH&&8KDVDÀDWERWWRPVRLWFDQEHVHFXUHO\LQVWDOOHGDQ\ZKHUHLQD
helicopter.
■2.6M-pixel 3MOS Camera
The HDL-F3000 use 2/3-inch 2.6M-pixel CMOS sensor supporting full HDTV (1920×1080 pixels) to implement a high
GH¿QLWLRQRIKRUL]RQWDOYHUWLFDOUHVROXWLRQ79OLQHVDQG61UDWLR G%6HQVLWLYLW\)LQ+'79V\VWHP
■Built-In Filter Servo
7KHFDPHUDLQFRUSRUDWHV¿OWHUVHUYR)LOWHUSRVLWLRQFDQEHUHPRWHO\FRQWUROOHGIURPYDULRXVFRQWUROSDQHOV,QDGGLWLRQ
¿OWHUSRVLWLRQFDQDOVREHFRQWUROOHGGLUHFWO\IURPWKHFRQWUROSDQHORIWKHJLPEDOWKURXJKH[WHUQDO¿OWHUFRQWUROLQSXW&75/
connector) which is newly provided on the CCU.
■ND Filter and Electric Color Temperature (ECC) Filter
7KH+'/)LQFRUSRUDWHIRXUSRVLWLRQRSWLFDO1'¿OWHU,5,6YDOXHFDQEHFRQWUROOHGGHOLFDWHO\LQDFFRUGDQFHZLWKWKH
VXEMHFWHYHQDWDSODFHZKHUHLOOXPLQDWLRQLVH[WUHPHO\GLIIHUHQWVXFKDVRXWGRRU7KHFDPHUDSURYLGHVWKH1'¿OWHUFRQWURO
PRGHZKLFKDXWRPDWLFDOO\FKDQJHVWKH1'¿OWHURQHSRVLWLRQDFFRUGLQJWRZKHWKHUWKHOHQVH[WHQGHULVXVHGRUQRWWR
suppress lens IRIS change.
8VHFDPHUDPHQX³0(183$*(´!³(;7(1'(51'),/(´WRVHWWKLVPRGH
(OHFWULFFRORUWHPSHUDWXUH(&&¿OWHUV....DUHXVHGDV&&¿OWHU
■Super-high sensitivity mode
The newly-developed image sensor and the noise reduction function provide the minimum subject illumination of 0.0068
lux, and the addition of long exposure mode enables shooting even under the moonlight of 0.00011 lux.
■Image sharpening function
7KHQHZO\GHYHORSHGLPDJHVKDUSHQLQJWHFKQRORJ\HQDEOHVVKRRWLQJLQKLJKGH¿QLWLRQXQGHUDQ\VHYHUHFRQGLWLRQVXFKDV
KD]H
■1080psF format
When capturing a still image, you can select a high-resolution 1080psF format with a single motion. The 1080psF format
eliminates line displacements due to the time lag of interlacing, providing a high-resolution still image. In both 1080psF
and 1080i formats, the same equipment can be used for transmission and recording.
■Digital zoom
7KHGLJLWDOIXQFWLRQZKLFKHQDEOHV]RRPLQJLQRQWKHVFUHHQFHQWHUXSWRWLPHVLQWLPHLQFUHPHQWVLVORDGHG
CAUTION : $FWLYDWLQJWKHGLJLWDO]RRPZLOOGHWHULRUDWH
■AVC (Auto Video Level Control) function
7KH$9&$XWR9LGHR/HYHO&RQWUROOHWVWKHFDPHUDSHUIRUPVZLWFKLQJWKH1'¿OWHUSRVLWLRQ,5,6FRQWUROJDLQFRQWURO
and shutter speed control automatically and continuously. When a camera operator cannot concentrate on camera operation
or when doing rescue or other operations, turning it ON will let the camera keep the video level proper automatically.
■ATW (Auto Tracking White balance) function
,QDGGLWLRQWRWKHVLQJOHSXVK$:%WKH$7:$XWR7UDFNLQJ:KLWHEDODQFHZKLFKWUDFNVDZKLWHEDODQFHDXWRPDWLFDOO\
is loaded.
2-12. FEATURES
■Color Temperature tracking function
The Color Temperature function, which can track a white balance according to color temperature changes during the day
with a single knob, is loaded. It is not necessary to readjust a white balance according to sunlight changes.
■Multi Format
Correspondingtomultiscanningmethod.
[Correspondingscanningmethod]
LLSV)SV)SS
2. FEATURES2-2
①Camera connector
Used to connect the camera cable to the CCU.
②Mounting holes
8VHGWR¿[WKHFDPHUDKHDGWRWKHLQVLGHRIWKHJLPEDO
6FUHZKROH0PPGHSWK
③Lens connector
Used to connect the 12-pin lens cable.
④Cooling fan
Cooling fan for the camera head.
Take care so that the fan opening will not be clogged with
dirt. Replace the fan at periodic overhaul.
3. NAME and FUNCTION of EACH PART
This section explains the name and function of each part.
3.1 Camera Head
①Camera connector
②Mounting holes
③Lens connector
④Cooling fan
Rear View
Bottom View
Front View
Top View
3-13. NAME and FUNCTION of EACH PART
①CTRL connector
8VHGWRH[WHUQDOO\FRQWUROWKH1'(&&¿OWHUVDQG,5,6
②Cooling fan
Cooling fan for the CCU.
Take care so that the fan opening will not be clogged with
dirt. Replace the fan at periodic overhaul.
③SDI OUT 1 connector
2XWSXWVWKH+'6',VLJQDOFRQIRUPLQJWR%7$6%
Character signals and VF marker signals can be
superimposed on this signal independently of ④SDI
287FRQQHFWRU8VHFDPHUDPHQX³0(183$*(´!
³6',0(180,;´
④SDI OUT 2 connector
2XWSXWVWKH+'6',VLJQDOFRQIRUPLQJWR%7$6%
Character signals and VF marker signals can be
superimposed on this signal independently of ③SDI
287FRQQHFWRU8VHFDPHUDPHQX³0(183$*(´!
³6',0(180,;´
⑤REMOTE connector
Used to connect a remote controller (optional) for the
camera.
⑥GL indicator
Lights in green while the camera is genlocked with the
SYNC signal of an external system.
3.2 Rear of the CCU
CTRL
DC IN
CAMERA
SDI OUT
12
REM
WARNING
POWER
CAM
BAR
GAIN AWB
ABB
H
M
L
G.L IN
G.L
MENU
GAIN select switch CAMERA connector
3. NAME and FUNCTION of EACH PART3-2
⑦GL IN connector
Inputs the SYNC signal when the camera is to be
genlocked with an external system (internal termination
ȍ,QSXWRI+'79YDOXH6\QFRU6'79%%6LV
possible.
,QSXWOHYHOLV+'799SSG%ȍRU6'79
9SSG%ȍ
⑧DC IN connector
Used to supply DC power. Input voltage range is shown
below.
When a lens requiring high power consumption is mounted
on the camera head, the camera may not normally operate
if the minimum voltage shown below is underrun. Input a
higher voltage in such a case (+16V or lower).
■
'&9WR9ZKHQWKHFDPHUDFDEOHLVPRU
shorter)
■
DC +12V to +16V (when the camera cable is 30m or
shorter)
No. Function
①GND
②NC
③NC
④DC+
5HFHSWDFOH+$5$3
⑨AWB/ABB indicator
/LJKWVLQJUHHQGXULQJH[HFXWLRQRI$:%$XWR:KLWH
%DODQFHRUOLJKWVLQRUDQJHGXULQJH[HFXWLRQRI$%%
$XWR%ODFN%DODQFH*RHVRXWXSRQFRPSOHWLRQRI$:%
$%%H[HFXWLRQ
%OLQNVZKHQ$:%RU$%%LVLQFRPSOHWH,IEOLQNLQJ
RSHUDWHWKH$:%$%%VHOHFWVZLWFKDJDLQWRFDQFHOWKH
EOLQNLQJVWDWH5HPRYHWKHFRQGLWLRQIRULQFRPSOHWH$:%
$%%DQGUHH[HFXWH$:%$%%
⑩AWB/ABB select switch
([HFXWHV$:%$XWR:KLWH%DODQFHRU$%%$XWR%ODFN
Balance).
This is a momentary switch, which returns to the midpoint
when released.
When a remote controller is connected to the REMOTE
connector, the operation right goes to the remote controller
and this switch is not operable.
⑪GAIN select switch
Changes the camera gain. Desired gain values can be set
through camera menus to satisfy L < M < H.
When a remote controller is connected to the REMOTE
connector, the operation right goes to the remote controller
and this switch is not operable.
Set arbitrary gain values in camera menu “MENU
3$*(´!³/2:0,'+,*+*$,102'(´
⑫MENU switch
When this switch is held down for one second or more, the
menu screen is superimposed on the video signal output
from the MONITOR OUT connector. Turn this rotary
encoder to select a menu, and press it to determine the
menu.
⑬CAM/BAR select switch
Switches between the video taken with the camera and the
color bar signal.
&$09LGHRWDNHQZLWKWKHFDPHUD
%$5 &RORUEDU
When a remote controller is connected to the REMOTE
connector, the operation right goes to the remote controller
and this switch is not operable.
⑭POWER switch
Turns ON/OFF the power of the camera.
When turning on the power immediately after
power-off, do so after two seconds or more to
completely discharge the internal electric charge.
⑮POWER indicator
Lights in green while the power of the camera is ON.
⑯WARNING indicator
Lights when the input voltage is low. Blinks in red when
an error occurs in the camera or the cooling fan of the
CCU stops. For further details of errors, refer to “MENU
3$*(´!³:$51,1*´
⑰CAMERA connector
Used to connect the camera cable to the camera head.
3-33. NAME and FUNCTION of EACH PART
