Samsung Wisenet SNC-79440BW User manual

SNC-79440BW
1080p Wireless IR Camera
User Manual
CAUTION : Changes or modications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE : This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at their own expense.

Copyright
©2017Hanwha Techwin Co., Ltd. All rights reserved.
Trademark
Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of
their respective company.
Restriction
Copyright of this document is reserved. Under no circumstances, this document shall be reproduced, distributed or changed, partially or wholly,
without formal authorization.
Disclaimer
Hanwha Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be
provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Hanwha Techwin reserves the right
to change the contents of this document without prior notice.
Design and specications are subject to change without prior notice.
1080p Wireless IR Camera
User Manual

part names and functions
Equipped with the IR LED lights and the illumination sensor, the camera enables you to monitor at all times, day and night. The
camera is suitable for both indoor and ourtdoor use.
Do not fully expose the camera to rain. The camera must be installed under a shelter to avoid exposure to excessive rain or moisture.
Name Description
aLens 3.6mm focal length enables you to monitor at a wider field of view
bIR LED Infrared LED lights are controlled by the illumination sensor.
cIllumination Sensor Detects incoming light to control the IR LED.
dPairing Button Click to do pairing manually.
ePower Cable Use to power the camera.
English _3
d e
a
b
c

precautions
Ensure you read out the following instructions before installing the camera:
•
Select an area (ceiling or wall) that can withstand 5 times the camera weight
•
Stuck-in or peeled-off cables can cause damage to the product or a fire.
•
For safety purposes, keep anyone else away from the installation site.
And put aside personal belongings from the site, just in case.
installing the camera
The camera can be installed on the wall, ceiling, shelf or a desired position using the provided mounting bracket.
1. Choose an installation site that can sufficiently support the weight of the camera to be installed.
2. Adhere the installation template onto the ceiling and use it as installation locating tool. "Please refer to Page15 (Quick Guide)"
3. Attach the camera mount to the wall using the supplied screws.
4. Adjust the direction of the camera to the desired direction, and tighten the bracket.
5. Adjust camera angle as needed.
6. Connect the camera cable to the camera.
Take caution when installing the camera outdoors because the cable connectors may be wet with moisture or pile up with
impurities.
Although the camera is IP66 rated, direct exposure to water or moisture may cause problem such as condensation.
English _4
CAMERA FRONT
Screw holes for
the Camera
installation

protection of cable from Water
If this product is mounted outdoor, water leakage may occur at gap between cables. As shown below, butyl rubber (available on the
market) shall be used to protect from water.
1. Connect power supply and BNC power source.
2. Cover black sheath of the cable (Zone A), and ensure half of butyl rubber can cover the cable joint.
J
`Poor water protection at the cable sheath may cause water leakage. Make sure to wrap tightly.
`The water-proof butyl rubber is made of rubber that expands to twice the original length.
`If you do not use cable joint, it must be covered with water-proof tape.
connecting the nVr
Use a 12V 0.5A power adpator to power each wireless camera. There is no need to connect cameras to NVR as it is wireless AIO.
HDMI
VGA 12V
CAUTION
RISKOFELECTRI SHOCK
DONOTOPEN
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK
DONOT OPEN COVERS. NO USER SERVICEABLE
PARTSINSIDE. REFER SERVICING TO QUALIFIED
SERVICEPERSONNEL.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD. DO NOT
EXPOSE UNITS NOT SPECIFICALLYDESIGNED
FOR OUTDOOR USE TO RAIN OR MOISTURE.
WAN
English _5

specifications
camera model: snc-79440bW
Item Details
Video
Imaging Device 2M CMOS (1/2.9")
Effective Pixels 1,920(H)x1,080(v)
Scanning System Progressive
Synchronization Internal
Horizontal Resolution 1080P
Min. Illumination 0 Lux (IR LED ON)
Camera Output RJ45
Lens
Focal Length 3.6mm
Max. Aperture Ratio F2.1
Angular Field of ViewDiagonal : 105°
Operational
Shutter Mode Auto
Gain Control Auto
White Balance Auto
Wide Dynamic Range D-WDR
Contrast Enhancement Auto
Digital Noise Reduction 3DNR
Flickerless Manual(50Hz/60Hz optional)
Day & Night TRUE D/N, Auto
IR Distance 82ft(Total Darkness)/130ft(Ambient Lighting)
Environmental
Operating Temperature / Humidity -30°C ~ +50°C (-22°F ~ +122°F) / Less than 90% RH ※Startup : -10°C ~ +50°C
Ingress Protection IP66
English _6

Item Details
Electrical
Input Voltage 12V/500mA DC Adaptor
Power Consumption 5.4W(IR LEDS ON)
Mechanical / Package information
Color / Material White / Metal
Dimension (Ø x D) Ø69.3 x D147.2mm (2.73" x 5.79")
Weight 0.34kg prox.
Accessory
Printed material Quick guide
Bracket one body (assembled)
Screw 3 EA (per camera)
Anchor 3 EA (per camera)
Hex key 1 EA (per camera)
Power Adaptor 12V 0.5A 1 EA (per camera)
Cable (45ft ) 4EA 45ft power Cable
English _7

dimension
camera
Unit: mm (inch)
English _8
134.5 (5.30")
77.6 (3.06")
147.2 (5.80")
117.3 (4.62") 117.3 (4.62")
Ø69.30 (2.73")
87.47 (3.44")
Ø6 (0.24")
Ø54.2 (2.13")
Ø69.30
(2.73")
3-Ø3.60 (0.12"-0.14")

English _9
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.
Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide
customers with more environmentally friendly products.
The Eco mark represents Hanwha Techwin's devotion to creating environmentally friendly products, and indicates
that the product satisfies the EU RoHS Directive.
Correct disposal of batteries in this product
(Applicable in the European Union and other European countries with separate battery return systems.)
This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other
household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains
mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these
substances can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them
through your local, free battery return system.
