Welcome to our growing family of RV owners. Hours of relaxation, adventure and enjoyment
await you in your new Viking. Thousands of Viking owners have been enjoying their units for
many years.
This Owner’s Manual has been prepared to help you and your family enjoy your new Viking
to its fullest by providing basic instructions for the operation and maintenance of its appliances,
accessories and RV systems. Please read it carefully and follow the instructions. Also read and
follow the instructions contained in the appliance and accessory manufacturers’ instruction
booklets provided as part of the “Viking Information Packet.”
If you have any questions regarding operation, maintenance or service, please contact your
Viking dealer so he can assist you. Your satisfaction is of the utmost importance to your dealer
and to Viking Recreational Vehicles.
Operation and maintenance instructions, regarding appliances in this manual were obtained
from manufacturer’s booklets and are used with the permission of those various manufacturers.
Viking Recreational Vehicles reserves the right to present edited portions of these materials.
Viking Recreational Vehicles works year ‘round to improve its products. As a result, all
specifications, equipment and prices quoted in our literature are subject to change without
notice or obligation to the consumer.
Thank you for selecting our product.

3
INTRODUCTION ......................................................4
DEALER /OWNER RESPONSIBILITIES
WARRANTY
Warranty Service..................................................................5
Warranty Period ...................................................................5
Who is Covered....................................................................5
What is Covered................................................................... 5
What is Not Covered ............................................................5
Other Warranties..................................................................5
Owner Relations...................................................................5
Serial #, Decals, Data Plates ................................................ 5
Manufacturer’s Warranties ...................................................6
LP GAS SYSTEM SAFETY REGULATIONS .....7
TOWING HOOK-UP
Coupler................................................................................8
Safety Chains.......................................................................8
Electrical Connection ...........................................................8
Hitch Ball Height ..................................................................8
Federal Sticker.....................................................................8
LOADING
Weight Distribution...............................................................8
Weighing..............................................................................9
TOW VEHICLE SELECTION
Load Carrying Hitch Requirements .......................................9
Brake Control.......................................................................9
Licenses ............................................................................10
Insurance...........................................................................10
DRIVING ...............................................................................10
UNHITCHING & LEVELING...................................10
Bunks ................................................................................10
DOOR INSTALLATION.............................................. 11
OPERATING ROLL-OUT SYSTEM .....................12
BASIC UTILITY SYSTEMS .......................................13
ELECTRICAL
120-Volt System ................................................................13
Shoreline Connection .........................................................13
12-Volt System ..................................................................13
Converter...........................................................................13
FRESH WATER SYSTEM
City Water .......................................................................... 13
Water Tank......................................................................... 13
Sanitizing Water Tank.........................................................13
Water Pump.......................................................................14
Sink................................................................................... 14
Leaks................................................................................. 14
DRAINAGE SYSTEM
Drainage............................................................................14
LP GAS SYSTEM
Climate Differences............................................................15
LP Gas Line Check ............................................................. 15
Filling the LP Gas Bottle ..................................................... 15
LP Bottle Care....................................................................15
Regulator Pressure ............................................................ 15
LP Gas Regulator Freeze-Up...............................................16
APPLIANCES AND ACCESSORIES
Range................................................................................ 16
12V/110V/ Gas Refrigerator................................................17
Furnace .............................................................................17
Water Heater...................................................................... 17
MAINTENANCE
Condensation.....................................................................18
Tent ...................................................................................18
Interior Maintenance ..........................................................18
Roof...................................................................................18
Body ..................................................................................18
Frame ................................................................................18
Electric Brakes................................................................... 18
Wheel Bearings.................................................................. 19
STORAGE
LP Gas System...................................................................19
Water Tank......................................................................... 19
Electric System..................................................................19
Exterior.............................................................................. 19
WINTERIZATION ............................................................19
TROUBLE SHOOTING................................................. 19
MAINTENANCE SCHEDULES.......................... 20-23
PRE-TRAVEL CHECK..................................................24
EMERGENCY CONTACTS........................................26
GENERAL INFORMATION........................................27
OWNER RELATIONS....................................................27
ANNEX A - LP GAS DETECTOR..........................27
LP GAS DETECTOR WARRANTY........................29
CARBON MONOXIDE DETECTOR
WARRANTY........................................................................29
TABLE OF CONTENTS

!A SYMBOL WHICH MEANS BE ALERT!
YOUR SAFETY IS INVOLVED!

4
INTRODUCTION
Congratulations on the purchase of your new RV. We sincerely thank you for choosing our product. To help you enjoy your
new RV, you’ll find in this owner’s manual many useful tips for camping trips as well as basic operation and maintenance
information for your RV’s systems and appliances.
TRY A SHORT TRIP FIRST. The experience you’ll gain from this will help make your future RVing more enjoyable.
To complement the standard and optional equipment you’ve chosen for your unit, there are many other accessories
available. You may wish to use your unit several times before you invest in these accessories. What may be a necessity for one
RVer could prove to be of no value to you. Remember, your dealer is always ready to help and advise you.
We go into great detail in this manual and for good reason. If you are a first-timer, we want you to learn to operate your RV
correctly, to be able to use its components, appliances and any optional equipment in the most efficient manner.
At first glance, you may be overwhelmed by all the detail. But after you’ve used your new RV a couple of times, you’ll be
able to perform all the checks, start-ups and systems in much less time than it takes to read our instructions.
If you’re a veteran RVer, you know that things change and a quick review of this manual will bring you up-to-date on what’s
new.
So read on. Happy camping!
NOTE: Because of the variety of models we offer, your RV may not have all of the components illustrated or described in
this owner’s manual. Ask your dealer for details concerning the specifics of your unit.
Your camping trailer is designed to provide temporary shelter. Its systems and materials are meant to provide reasonable
comforts in reasonable environments. Extremes in usage such as prolonged and continuous exposure to the elements while set
up, overloading, traveling over severe terrain, or other misuses will overtax the camper, its materials and its overall design. The
failure to perform regular maintenance such as gentle cleaning, lubrication, proper tire inflation, and LP systems maintenance
will reduce the proper performance of your camper.

!WARNING!
READ THIS MANUAL CAREFULLY BEFORE YOU TAKE YOUR FIRST TRIP
READ WARNINGS ON LP GAS SYSTEMS PAGE

5
OUR WARRANTY
GENERAL
Your new recreational vehicle is backed by our position as
an industry leader, achieved through decades of experience in
producing RV’s noted for their quality and dependability. Our one-
year warranty demonstrates our confidence in our products and is a
commitment to customers’ continued satisfaction.
Every effort has been made to provide you with a safe,
dependable recreational vehicle. Your RV complies with applicable
federal and state regulations and the requirements of ANSI A119.2,
the nationally recognized “Standard for Recreational Vehicles -
Installation of Plumbing, Heating and Electrical Systems.” The
Recreation Vehicle Industry Association (RVIA) periodically inspects
our production and assists in maintaining strict compliance with
installation and safety standards for those systems. Similar periodic
inspections of the systems are made by representatives of various
states. You, the owner, must perform periodic inspections of the
systems and provide a program of preventive maintenance as
described in the Owner’s Manual and instruction booklets.
WARRANTY SERVICE
We recommend that warranty service be performed by the
authorized dealer from whom you purchased your RV because of
the dealer’s continued and personal interest in your satisfaction.
But if you are traveling or in the event that you move, service under
the warranty will be performed by any of our authorized dealers.
Whenever possible, make an appointment to avoid unnecessary
delays.
If you cannot locate an authorized dealer, contact our Service
Department at 1-800-239-6157 or 269-467-6321.
WARRANTY PERIOD
The warranty period shall be for 12 months and begin on the
date the new recreational vehicle is delivered to the retail purchaser,
or the first in-service date, whichever is first.
WHO IS COVERED
The first retail purchaser, provided terms of the warranty are
met.
WHAT IS COVERED
The Manufacturer warrants to owners that an authorized dealer
or Service Center will make repairs made necessary by defects in
material or workmanship during the warranty period. Such repairs
will be made without charge for parts and labor to the owner.
WHAT IS NOT COVERED
Our warranty does not cover the tires, tubes, repairs or
adjustments required because of neglect, accident, misuse,
failure to follow service and use instructions, normal wear and/or
exposure, unauthorized repairs or modifications to any part of the
systems or body that might cause defective performance.
Your new recreational vehicle is designed as a temporary living
quarters for recreational camping, travel or seasonal use and not as
a permanent dwelling place. Usage as a permanent accommodation
is breach of warranty and we are not liable for any damage that
results because of such misuse.
The manufacturer does not assume responsibility for loss of use
of the recreational vehicle, loss of time, inconvenience or expenses
due to equipment failures (refer to the warranty statement for other
exclusions and limitations).
OTHER WARRANTIES
Be certain to complete and submit to the appropriate
manufacturers the warranty forms for tires, which are not covered
by our one-year warranty. If service or parts are required for these
products, refer to the furnished list of factory-authorized service
centers. If the list is not available, write or call the manufacturer
concerned to obtain the location of the nearest authorized service
center.
OWNER RELATIONS
Owner satisfaction and good will are of primary concern to us.
We recognize that our continued success as a leading manufacturer
of recreational vehicles depends upon your complete confidence
in our products and service. A pleasant and effective relationship
through our dealers is as important as maintaining the technical
excellence of our product. Your authorized dealer will assist
you in providing service, maintenance, selection of options and
instructions concerning the operation of your recreational vehicle.
Occasionally, a warranty or service matter may not be handled
to your satisfaction. Often it is the result of a misunderstanding and
can be resolved at the dealer level. Discuss the situation with the
dealership management. If you cannot find satisfaction at the dealer
level, we invite you to contact our Service Department, where we
will make every effort possible to provide an agreeable solution. In
most instances, we will eventually refer you back to the local dealer
with our recommendations.
SERIAL NUMBER, DECALS AND DATA
PLATES
The camping trailer serial number label is mounted on the front
road side of the camper and stamped into top of “A-Frame.”
IMPORTANT
Always give model, year and serial number information when
ordering parts. Also VIKING recommends that you keep a copy of
this information separate from the camper in the event theft or
vandalism requires you to supply a copy to the authorities.
Decals and date plates used throughout the camper aid in
its safe and efficient operation; others give service instructions.
Read all decals, data and instruction plates before using your new
camper. When any decal, data or instruction plate is damaged,
painted over, removed, etc.; it should be replaced.

6
MANUFACTURER’S WARRANTIES
The following list of manufacturers has been compiled to help you
know which products on your camping trailer may have their own
warranties. If you have any of these components on your camping
trailer, be sure to check the literature supplied by the manufacturer to
see if they require that you register your purchase with them to validate
their warranty. These warranties usually apply only to the first owner
of the camping trailer. VIKING recommends that you send the various
warranty registration cards immediately before any time constraints on
registration expire. Manufacturer’s literature is contained in a separate
packet furnished with the owner’s manual on newly delivered units.
Only those products and options which are on your camper will be
included in this packet. You should go over this literature with your
dealer during the pre-delivery inspection. Any shortages of literature
should be reported to dealer at that time.

!SAFETY
THE SAFETY ALERT SYMBOL IS USED
THROUGHOUT THIS MANUAL TO CALL
ATTENTION TO WARNINGS WHERE VEHICLE
DAMAGE OR POSSIBLE PERSONAL INJURY
MAY BE INVOLVED.

!WARNING!
SAFETY REGULATIONS REGARDING LP GAS SYSTEMS AND LP GAS APPLIANCES
APPLIANCES
Range..................................................................... Suburban
Refrigerator............................................................... Dometic
ELECTRICAL
110V / 12V Converter.................................................. WFCO
WATER & DRAINAGE
Water Heater......................................................... Suburban
Toilet....................................................................... Thetford
LP GAS
Regulator................................................................ Fairview
Furnace ................................................................ Suburban
MISCELLANEOUS
Axle ........................................................................... AL-KO
Tires / Wheels ............................................... Americana Tire
LIFT SYSTEMS
...................................................................Goshen Stamping

7
The manufacturer of this recreational vehicle is required to
furnish the following consumer information as provided by the
National Fire Prevention Association and the American National
Standards Institute. The information and warnings found here
may also be found in other sections of this Owner’s Manual.
Please see sections titled “Liquid Petroleum Gas System” and
“Appliances” for other safety and operating information.

!WARNING!
LP gas containers shall not be placed or stored
inside the vehicle. LP gas containers are
equipped with safety devices which relieve
excessive pressure by discharging gas to the
atmosphere.

!WARNING!
It is not safe to use cooking appliances for
comfort heating. Cooking appliances need fresh
air for safe operation. Before operation:
1. Open overhead vent or
2. Open window
This Warning Label has been located in the
cooking area to remind you to provide an
adequate supply of fresh air for combustion.
Unlike homes, the amount of oxygen supply is
limited due to the size of the recreational vehicle,
and proper ventilation when using the cooking
appliance(s) will avoid dangers of asphyxiation. It
is especially important that cooking appliances
not be used for comfort heating as the danger
of asphyxiation is greater when the appliance is
used for long periods of time.

!WARNING!
Portable fuel-burning equipment, including wood
and charcoal grills and stoves, shall not be used
inside this recreational vehicle. The use of this
equipment inside the recreational vehicle may
cause fires or asphyxiation.

!WARNING!
Do not bring or store LP gas containers, gasoline,
or other flammable liquids inside the vehicle
because a fire or explosion may result.
A warning label has been located near the LP gas container.
This label reads:
DO NOT FILL CONTAINER(S) TO MORE THAN 80
PERCENT OF CAPACITY.
Overfilling the LP gas container can result in uncontrolled
gas flow which can cause fire or explosion. A properly filled
container will contain approximately 80 percent of its volume
as liquid LP gas.
The following label has been placed in the vehicle near the
range area:
IF YOU SMELL GAS:
1. Extinguish any open flames, pilot lights and all
smoking materials.
2. Do not touch electrical switches.
3. Shut off the gas supply at the tank valve(s) or gas
supply connection.
4. Open doors and other ventilating openings.
5. Leave the area until odor clears.
6. Have the gas system checked and leakage source
corrected before using again.
LP gas regulators must always be installed with the
diaphragm vent facing downward. Regulators that are not in
compartments have been equipped with a protective cover.
Make sure that regulator vent faces downward and the cover is
kept in place to minimize vent blockage which could result in
excessive gas pressure causing fire or explosion.

!WARNING!
SAFETY REGULATIONS REGARDING LP GAS SYSTEMS AND LP GAS APPLIANCES
APPLIANCES
Range..................................................................... Suburban
Refrigerator............................................................... Dometic
ELECTRICAL
110V / 12V Converter.................................................. WFCO
WATER & DRAINAGE
Water Heater......................................................... Suburban
Toilet....................................................................... Thetford
LP GAS
Regulator................................................................ Fairview
Furnace ................................................................ Suburban
MISCELLANEOUS
Axle ........................................................................... AL-KO
Tires / Wheels ............................................... Americana Tire
LIFT SYSTEMS
...................................................................Goshen Stamping

8
TOWING HOOKUP
COUPLER
Release and lift the coupler lever (as shown below). Crank the
jack counter-clockwise to lower the coupler onto the hitch ball.
Be certain that the coupler is fully seated on the hitch ball. Finish
the connection by pushing the coupler lever down until it latches
securely. (Required, an RV safety pin at minimum.)
SAFETY CHAINS
Attach safety chains on unit to tow vehicle by connecting the
driver’s side chain, the passenger’s side chain mount and the
passenger’s side chain to the driver’s side chain mount creating
an “X” shape. Chains should be below “A” frame of camper. Safety
chains shall not be touching the ground. If necessary crossing the
safety chains several times may be necessary.
ELECTRICAL CONNECTION
Plug the tow vehicle’s electrical harness into the camper’s
pigtail connection. Leave enough slack in the chains and pigtail to
permit the unit to turn freely.
HITCH BALL HEIGHT
When the loaded trailer is hitched to the tow vehicle, check the
hitch ball height. It can be determined by measuring from the top
of the curved portion of the coupler to the ground. A high hitch will
transfer the weight behind the axle, causing the unit to fishtail. A
low hitch will transfer additional weight to the hitch.
FEDERAL STICKER
Found on the road side of your camping trailer, the Federal
Sticker lists the Viking Serial Number, the Gross Axle Weight Rating
(GAWR) and the Gross Vehicle Weight Rating (GVWR). Your tow
vehicle also will have a Federal sticker. The ratings are for the
specific rim and tire sizes, which are listed.
TRAILER WEIGHT INFORMATION
Model
Hitch Wt.
Base Wt.
Carrying
Capacity
LOAD LIMITS & WEIGHT
DISTRIBUTION
Your camper has been designed to carry loads within specified
limits. Exceeding these limits will greatly effect handling, safety, and
can cause damage to camper components. Load limit and weight
distribution terminology is as follows:
Gross Vehicle Weight Rating (GVWR) - This is the total
designed weight rating of the camping trailer. It includes everything

9
that combines to give the camper its total weight when traveling.
Included are the weight of the camper, all appliances and
conveniences, water, LP fuel, and all personal belongings and gear
stored both inside and outside. This value must never be exceeded.
Hitch Weight - This is the weight of the tongue as it bears
down on the hitch of the towing vehicle. Hitch weight should
be determined with the camper as it would be fully loaded for
travel. For stable towing at highway speeds, this weight must be
a minimum of 10% and a maximum of 15% of the gross vehicle
weight.
Base Weight (UVW) - This is the weight of the camper as
equipped with options. For our purpose, the unloaded vehicle weight
is the weight of the unit with maximum options.
Carrying Capacity - This is the maximum weight of all personal
belongings, food, fresh water, LP gas, tools, dealer installed
accessories, etc., that can be carried by this trailer. (NCC is equal to
or less than GVWR minus UVW).
This trailer is capable of carrying up to ______ gallons of
fresh water (including water heater) for a total of ______ pounds.
Reference: Weight of fresh water is 8.33 lbs./gal.; Weight of LP gas
is 4.5 lbs./gal. (average).

!WARNING!
Exceeding the weight ratings of the camper can
create a serious safety hazard. Check the weight
of your camper frequently as it would be loaded for
travel. Remember to take the weight of all liquids
into consideration. Also, make sure that the weight is
distributed evenly.
Once you become familiar with loading your camping trailer and
know how to distribute the weight and which items you normally
carry, make a list and diagram you can use for future reference.
Plan your loading and storage so that emergency items are easily
accessed. Place heavier or breakable items on the camper floor for
greater load stability. Make sure these items are well packed and
secured to prevent movement. Take extra care not to overload the
front and rear ends of the camper.
Make sure to use packing material around breakable items such
as plates and glasses in cupboards if you will be towing over rough
roads or terrain. It is a good idea to use non-skid materials under
heavier items to help prevent shifting.
Most new camping trailer owners tend to carry more supplies
than they really need. It is important to remember that each item
added brings with it the extra weight to tow and distribute.

!WARNING!
DO NOT store LP gas containers, gasoline, or other
flammable liquids inside the camper because a fire
or explosion may result.

!WARNING!
CAUTION: Extending the rear bumper or adding rear
supports to carry toolboxes, bikes, motorcycles or
other heavy equipment may seriously overload the
trailer brakes, axle, wheels and tires. In addition,
rear-end load reduces the hitch weight and can
cause severe fishtailing. NEVER EXCEED THE GAWR
FOR YOUR UNIT. NEVER TOW WITH LESS THAN 10%
OF THE TRAILER GROSS WEIGHT ON THE HITCH.
TOW VEHICLE SELECTION
– See your vehicle owner’s manual.
LOAD CARRYING HITCH
REQUIREMENTS
Your camping trailer fits a 2” or 2-5/16” hitch ball. Ask your
Viking dealer about the proper Class of load-carrying hitch to use.
The selection of the hitch is important since it affects towing and
handling characteristics. Read the information supplied by the hitch
manufacturer to achieve best possible performance.
NOTE: Installation of a Weight-Distributing (Load-Equalizing)
Hitch is NOT recommended on any vehicle towing a camping trailer.
Any Class 2 or 3 load equalizing hitch IS NOT approved.
BRAKE CONTROL
The electric brake controller, required on models with electric
brakes only, automatically activates the brakes on your camper
when the tow vehicle’s brakes are applied. It provides braking effort
directly proportional to the braking action of the tow vehicle.
This is an item that must be purchased additionally as it is not
supplied with the camper from the manufacturer or automatically
supplied by your dealer at the time of purchase. There are several
models to choose from including those that install in your towing
vehicle and those that may be installed on the A-frame of the
camper.
If you are not familiar with them, please contact your dealer for
assistance in choosing the correct one to meet your specific needs.
Units equipped with safety break-a-way switch require auxiliary
battery mounted to trailer with wiring to activate upon trailer break-
a-way. Refer to your Tow Vehicle Owner’s Manual for additional
towing/braking instructions.

10
LICENSES
Vehicle licensing laws vary from state-to-state. Check with your
license bureau or nearest branch office for the requirements in your
state.
INSURANCE
Personal liability, property damage, collision and theft of
contents may be features of your automobile policy which apply to
your Viking unit. Contact your insurance agent about details of your
coverage.
DRIVING
– See your vehicle’s owner’s manual.
UNHITCHING AND LEVELING
1. Select a level campsite, preferably one without low hanging
branches that could damage your camping trailer’s top.
2. Position camping trailer for most desirable use of campsite.
3. Unplug car-end wire harness from socket on trailer
A-frame, unhook safety chain from tow vehicle, unlatch
coupler.
4. Rotate tongue jack clockwise to raise tongue just enough to
disengage vehicle hitch ball.
5. Move the tow vehicle or trailer to allow access to the front
of the trailer to complete the setup.
6. Rotate jack handle clockwise until camper is level from
front to rear. *See Annex A for maintenance.
7. Remove crank handle from unit and place socket end on
the end of the jack and extend jack until it firmly contacts
the ground. Several pieces of 6 x 6 x ½ (or thicker) plywood
are recommended as part of your camping gear. In some
cases it may be necessary to place more than one piece of
plywood under jack foot for added stability.
ROOF EXTENSION AND RETRACTION
1. Unlatch roof latches located at each corner of unit (4 total).

!WARNING!
Lift system damage will result if operation of lift
system occurs without total release of all latches.
2. Remove the crank handle from storage position and insert
crank into the winch located on the front A-frame of the
unit.
3. Turn the crank clockwise to raise the roof and counter-
clockwise to lower.
4. Raise roof until GREEN gauge cable located near front door
side lifter arm is taut. (Do not over crank roof lift system
as damage to system may result.)
5. Install Safety Channels (2) one per side of camper locating
them diagonally.
NOTE: BE SURE TO REMOVE THE SAFETY CHANNELS PRIOR
TO LOWERING THE ROOF ASSEMBLY!
6. To retract roof reverse steps 1-5 above.
BED PLATFORM SET-UP “GLIDE-N-
LOCK BED SYSTEM” (All Models Except
806)
1. Pull out beds using strap located at the center of each bed
platform until both sides of bed lock in place. At near full
extension pull upward as well as outward.
2. Zip tent sides closed at all four zippers located behind lifter
arms.
3. Install inner bed flaps starting from the camper body
and working outward to bottom of bunk platforms using
attached Velcro fastener.
4. Raise bed platform rain flap and wrap inner flap around
bed corners and lower rain flap over inner flaps at corners.
5. Install shock cord by hooking detached end to eyelet
opposite fixed end. Repeat for opposite end.
6. Locate bed tension rafter poles (usually stored under
respective mattresses).
7. Insert tension rafter into bed bow extension (red cap
located on end).
8. Push tension rafter and bed bow upward and outward and
lock inner end of tension rafter into roof bracket when tent
top is taut. Repeat for other bed.
9. Install lifter arm covers by attaching Velcro located on
opposite side lifter arm.
10. For bed platform disassembly reverse steps 1-9 above.

11
BED PLATFORM SET-UP 806 MODELS
1. Remove the four bed support poles from inside unit and
place near the front and rear of unit.
2. Pull out bed using strap located at the center of each bed
platform.
3. Insert flat end of support poles into unit frame first then
swing upward and install on support plates located on
the underside of bed platform. Slight lifting on bunk end
will be required to complete install. (Repeat steps 1-3 for
remaining bed platform.)
4. Zip tent sides closed at all four zippers located behind lifter
arms.
5. Install inner bed flaps starting from the camper body
and working outward to bottom of bunk platforms using
attached Velcro fastener.
6. Raise bed platform rain flap and wrap inner flap around
bed corners and lower rain flap over inner flaps at corners.
7. Install shock cord by hooking detached end to eyelet
opposite fixed end. Repeat for opposite end.
8. Locate bed tension rafter poles (usually stored under
respective mattresses).
9. Insert tension rafter into bed bow extension (red cap
located on end).
10. Push tension rafter and bed bow upward and outward and
lock inner end of tension rafter into roof bracket when tent
top is taut. Repeat for other bed.
11. Install lifter arm covers by attaching Velcro located on
opposite side lifter arm.
12. For bed platform disassembly reverse steps 1-3 above.

!WARNING!
CAUTION: NEVER PULL BUNKS OUT OR PUSH
BUNKS IN, UNLESS ROOF IS EXTENDED TO ITS FULL
HEIGHT. THIS IS A MUST!

!WARNING!
CAUTION: NEVER ALLOW BUNKS TO HANG
UNSUPPORTED, AS THIS WILL CAUSE DAMAGE TO
SLIDE ASSEMBLIES.

!WARNING!
AS THE CANVAS IS PERMANENTLY ATTACHED TO
THE BUNK AT THE END ONLY, DO NOT PLACE SMALL
CHILDREN OR INFANTS IN BUNK AREA WITHOUT
PROVIDING ADEQUATE PROTECTION AROUND OPEN
EDGES.
DOOR INSTALLATION 806 MODELS
1. Close lower door.
2. Release upper door storage straps (4) while supporting
gently in center.
3. Gently swing door downward to vertical position.
4. Position the bottom of the upper door directly over the
lower door and insert the black plastic guide pins into
corresponding channels in the lower door frame. Securely
latch upper to lower door using latch provided.
5. Push outward on top of upper door and secure top plate to
roof sideboard using (2) turn buttons provided.
6. Attach front and rear tent sections to door frame using
Velcro provided.
7. Check door for smooth operation. Adjustments at top or
re-leveling the unit may be necessary.
8. Reverse steps 1-7 to uninstall.
HELPFUL HINTS:
If door will not open and close properly from outside of the unit,
check to see if upper door is square in frame. If not, this may be
adjusted by adding or subtracting tension on bunk bows.
DOOR INSTALLATION STEPPER DOOR
AND V-TREC MODELS
1. Release upper door storage straps (4) while supporting
gently in center.
2. Gently swing door downward to vertical position.
3. Place door bottom against lower door frame into channel
provided.
4. Push outward on top of screen door. When door is in
vertical position, push downward on door making sure door

12
top mounting plate is secure in opposing channel located
on roof sideboard.
5. Attach front and rear tent sections to door frame using
Velcro provided.
6. Check door for smooth operation. Adjustments at top or
re-leveling the unit may be necessary.
7. Reverse steps 1-6 to uninstall.
ROLL OUT ASSEMBLY OPERATION
(ROLL OUT MODELS ONLY)
1. From exterior of camper release roll out latch by turning
handle and pulling outward on roll out.
2. Pull outward on roll out until it stops.
3. Check to make sure roll out latches located inside at floor
level are engaged in the locked position. (Pushing outward
from inside the unit at floor level may be necessary to fully
engage latches).
4. Locate roll out tension rafter and install in the same
manner as bed end installation.
5. Secure roll out tent side by attaching Velcro at all points
inside and outside.
Reverse steps 1-5 for unit take down.

!WARNING!
During set-up and take down procedure make sure
all tent materials are clear of any moving parts to
prevent tent damage. I.E. (Lifter arms, bed platform
slides and roll out box).

13
Tent damage created by not heeding this warning will not
be covered by warranty.
NOTE: Be sure tent is dry before lowering unit. If tent is damp
when unit is stored, mildew will form causing damage to the
canvas.
BASIC UTILITY SYSTEM
The basic utility systems in your camping trailer can be
classified under four titles - Electrical, Fresh Water, Drainage and LP
Gas. This section outlines these systems, describing their operation,
function and simple maintenance. It is not intended as a service
guide. Your RV has been engineered and built to provide trouble
free operation, but should a problem arise, we recommend that you
contact your authorized Viking dealer.
ELECTRICAL GENERAL
Your camping trailer contains two separate electrical systems,
providing you with power while you are camped or traveling.
There is a 12-volt direct current system, similar to the one in
automobiles, and a 120-volt alternating current system, similar to
one in homes. Your 120-volt system requires an external source of
120-volt electricity. This is provided by a connection to a campsite
receptacle. The 120-volt system should be used whenever a 120-
volt hook-up is available to reduce the 12-volt load on your tow
vehicle’s battery. Power is supplied by the Shoreline connection to
the 120-volt receptacles. The 12-volt system is supplied by your
automotive battery or the frame mounted or recessed battery pack
which may be purchased from your Viking dealer and is used when
you are on the road or in campsites which do not provide 120-
volt hook-ups. The interior lights in your camping trailer operate
only from a 12-volt source. Energy is supplied by the automotive
battery through the camper’s electrical connection, or by the power
converter, which changes 120-volt AC into 12-volt DC. Without the
converter, the only 12-volt power source to your camper is from the
tow vehicle’s automotive battery, through the electrical connection.
120-VOLT SYSTEM
The 120-volt system supplies power for the power converter
for the 12-volt system and the 120-volt receptacles located in
the camping trailer, which are used to operate regular household
appliances. (It also provides 120-volt power for an optional three-
way refrigerator in certain models.)
When you use the external 120-volt hook-up, the electrical
power source is connected directly into the main electrical service
panel and is distributed through a circuit breaker.
SHORELINE CONNECTION
The Shoreline is a heavy-duty cable with a three-prong ground
plug on one end, permanently attached at the other end to the
service panel. It can be pulled from its storage compartment
through a hatch in the sidewall of your vehicle and connected to
an external receptacle. Some campsites and trailer parks still have
two-slot outlets. If it is necessary to use a three-to-two adapter, be
certain its grounding wire is fastened securely to the outlet
grounding screw. If in doubt, you may attach a No. 6-AWG copper
wire to the frame of the vehicle and fasten it to an 8-inch copper or
brass stake driven into the ground.
12 VOLT SYSTEM
12-Volt energy is supplied by the automotive battery (through
the pigtail connection) or the power converter.
The automotive battery and alternator supply 12-volt power
to the taillights, brake lights (brakes if so equipped), clearance
lights, turn signals, warning flasher lights and 12-volt side of 2-way
refrigerator or 3-way refrigerator, if so equipped.
CONVERTER
The power converter transforms 120-volt AC to 12-volt DC. The
converter supplies power to all the 12-volt systems, except the
refrigerator and vehicular lights. The 12-volt circuit is protected
by a fuse in the converter. If the fuse breaks, turn off or unplug all
appliances. Replace the broken fuse with one of the same ampere
rating. If the fuse continues to break, contact your Viking dealer.
FRESH WATER SYSTEM
GENERAL
Fresh water for your unit is supplied either to the vehicle’s fresh
water tank or an external pressurized source. Both supply water to
the sink.
CITY WATER
Connect a hose to a “city” pressurized water faucet and to the
vehicle’s water inlet. When using the city water hook-up, the water
tank is by-passed. You cannot fill the water tank through the city
water inlet. When city water is not being used, tighten cap on city
water fill.

!WARNING!
CAUTION: In areas where city water pressure
exceeds 60 psi, you should use a pressure regulator.
Excessive water pressure may damage lines and
connections. See your Viking dealer for further
details.
FILLING WATER TANK
Open the gravity water fill by turning cap. Insert a hose to fit the
fill spout. Water will flow out the water fill vent when the tank is full.
SANITIZING WATER TANK
Sanitize your unit’s water tank before initial use, after a
period of non-use and whenever the tank is suspected of being
contaminated. Open the drain cock (located either directly on
bottom edge of tank or in some instances on a short piece of clear
hose for easier access) and drain the water out. When the tank is

14
empty, close the drain cock. Mix three gallons of water with 1/4 cup
of liquid household bleach. Pour solution into tank through gravity
water fill. Wait three hours. Flush the tank with fresh, potable
water. If a chlorine taste lingers, pour one quart of vinegar and five
gallons of water into the tank. Wait several days before draining
tank. Flush tank with fresh, potable water.
WATER PUMP
The water pump is a 12-volt DC appliance that is activated by a
switch mounted in the kitchen area. The switch may be left on while
camping. When you want water, simply open a faucet. The pump,
which applies water from the fresh water tank, will run only as long
as is needed. If the pump fails to start when the switch is on, check
the fuse located in the converter. If the pump continues to operate
whether the faucets are opened or closed, check the water tank.
It might be empty, or there may be a leak in the system. If the city
water hose is connected, the pump is not required.
SINK
Clean the sink with non-abrasive cleanser only.
LEAKS
Traveling over bumpy or rough roads can cause pipe fittings to
loosen. Check pipe fittings regularly for signs of leakage.
DRAINAGE SYSTEM
GENERAL
The drainage system of your camping trailer consists of a
sink drain and a drain trap. The latter maintains a water barrier to
prevent odors (caused by drain water) from entering the RV.
DRAINAGE
Remove protective cap from drain fixture and attach a garden
hose to the outlet. Some campsites will have septic service for the
disposal of sink water at each site. If the site is not so equipped,
collect water in a bucket or container and dispose of as required
by the park rules. To avoid contaminating your water system, use
different hoses for fresh and drain water. Hoses of different colors
will help you avoid interchanging. The same is true for buckets or
vessels used for fresh water and drainage; paint or mark them to
prevent contamination.

!WARNING!
CAUTION: Do not pour boiling water down the drain
as it will damage your flexible drain hose.

!WARNING!
Read the following chapter and safety warnings on
Page 5 CAREFULLY.
LP GAS SYSTEM
* See Annex A for LP Detector information
GENERAL
The Liquefied Petroleum (LP) Gas system in your unit, furnishes
fuel for heating and cooking. LP gas is stored in a bottle or bottles
on the “A” frame of your unit. Under pressure in the bottle, the LP
gas turns to vapor; it is the latter which burns. Each bottle has a
20% vapor level gauge which allows space in the bottle for vapor
expansion. The high pressure vapor in the bottle is reduced in
two stages through a regulator. The tank pressure will vary with
temperature and altitude, but may be 100 pounds per square inch
or more. It is reduced to about 12 pounds psi in the first stage,
then to about 6-1/4 ounces psi in the second stage. The LP gas is
propane or a blend of propane and butane, depending upon your
locale.
The LP gas system is designed and built to rigid standards and
tested before leaving the factory. Your Viking dealer also tests the
system prior to delivery to you. Except for simple maintenance and
occasionally tightening a connection, you should take your unit
to an authorized Viking dealer for repairs or adjustments. The LP
bottle(s) should always be filled by an authorized dealer.
NOTE: Viking Recreational Vehicles is not responsible for
personal injury or property damage resulting from improperly
maintained LP gas appliances and systems. LP gas burns readily
and with intense heat.
With proper care and maintenance, it is safe and efficient.
However, there are certain characteristics of LP gas of which you
should be aware. In its natural state, LP gas is odorless but an
additive gives it a distinctive odor so that most leaks may be readily
detected.
LP gas is heavier than air and tends to collect in low pockets.
As LP gas settles into any closed area, it displaces air and thus
could cause suffocation if not detected. It could also create a
fire or explosion hazard.
The following label has been placed in the vehicle near the
range area:

!WARNING!
For your safety, if you smell gas:
1. Extinguish any open flames, pilot lights and all smoking
materials.
2. Do not touch electrical switches.
3. Shut off the gas supply at the tank valve(s).
4. Open doors and other ventilating openings.
5. Leave the area until odor clears.
6. Have the gas system checked and leakage source
corrected before using again.

15
CLIMATE DIFFERENCES
The appliances will not function if the LP gas does not vaporize.
Butane will not vaporize below 32°F (the freezing point of water),
but propane will continue to vaporize down to -44°F. Propane has
become the main type of LP gas used in RV’s in recent years. Your
LP supplier will have the correct type or blend for your locale. If your
travels will take you into an area where climate differs, ask your LP
dealer for his recommendations. The names of LP suppliers can be
found in the yellow pages of your telephone directory under “Gas-
Liquefied Petroleum - Bottled and Bulk.” Many campgrounds now
have LP gas fill facilities as do some service stations.

!WARNING!
LP GAS LINE CHECK
Always check the gas line connection after each refill and
inspect other connections regularly, at least every 30 days or 5,000
miles of travel. To check, turn off all burners and pilot lights. Open
all doors and windows. Open the LP gas bottle service valve and
use soapy water, a bubble solution or approved leak detector to test
all line connections. Do not use products that contain ammonia or
chlorine. Bubbles indicate a leak. Tighten the connections with two
open-end wrenches until bubbles stop. If leak persists, contact your
Viking dealer.
FILLING THE LP GAS BOTTLE
Before removing an LP gas bottle, be certain ALL burners and
pilot lights are off. Close the service valve and turn the green
knob on gas hose counter-clockwise to disconnect the hose from
the tank valve. NOTE: NO TOOLS REQUIRED TO DISCONNECT THE
NEW ACME PIGTAIL FROM THE VALVE. To remove empty LP gas
bottles, loosen the bottle clamp and slide the bottle up and out of
the bracket. TRANSPORT EMPTY LP GAS BOTTLES IN AN UPRIGHT
POSITION!
Take your bottles to an authorized LP supplier for filling. He will
connect the fill nozzle to the gas line connector. The Service valve
and the 20% vapor level gauge must be open. Filling should be
stopped as soon as liquid appears at the liquid level gauge. Close
the Service valve or the 20% gauge; they are designed to be closed
leak-tight by hand. If you cannot hand-tighten properly, the valve
may need repair or replacement.
A warning label has been located near the LP gas container. This
label reads:
DO NOT FILL CONTAINER(S) TO MORE THAN 80
PERCENT OF CAPACITY.
Overfilling the LP gas container can result in uncontrolled gas
flow which can cause fire or explosion. A properly filled container
will contain approximately 80% of its volume as liquid LP gas.
Avoid overfilling by insisting that the LP gas bottle is never filled
beyond 80% of capacity. If the bottle is over-filled, have the LP gas
dealer bleed out the excess. Over-filling does not allow sufficient
space for the liquid to expand. This can produce excessive pressure
which can cause LP gas leaks, creating potential fire or explosion.
hazard. DO NOT smoke, strike a match or ignite a lighter when
the LP gas bottle is being filled. A spark or flame could ignite
fumes. Be certain all burner and pilot flames are out and the
Service valve is closed when filling your tow vehicle’s gasoline tank.
Reinstall a single bottle by placing it in the support brackets,
insert the bolt through the bracket. One nut should be tightened
until the ring is tight around the gas bottle, then a second nut
should be tightened against the first to prevent them from vibrating
loose. Reinstall a double bottle on the bottom support plate. Tighten
the spinner nut so the “T” bar holds both bottles in place. Reconnect
the gas line and check for leaks.
LP BOTTLE CARE
After each trip, inspect the LP gas bottle. Sand off traces of rust
and apply a rust preventative paint. When the LP gas system is not
in use, the Service valve should be closed.

!WARNING!
LP Gas containers shall not be placed or stored
inside the vehicle. LP Gas containers are equipped
with safety devices which relieve excessive pressure
by discharging gas to the atmosphere.
REGULATOR PRESSURE
Each LP gas bottle, or pair of gas bottles, will have a regulator. If
you have double 20 lb. bottles, open only one bottle’s Service valve.
When the bottle is empty, close the Service valve and open the
other bottle. You can check the volume of LP gas by weighing the
bottle, comparing the known weight of an empty and filled bottle.
The Tare (empty) Weight is stamped on the LP gas bottle handle.
Also stamped on the bottle is its water capacity in pounds.
Multiply the Water Capacity by .42. The result will be the LP
capacity in pounds (allowing for the 20% vapor space). Add the LP
weight to the Tare Weight to get the total weight of filled bottle.
EXAMPLE:
If a 20 lb. bottle lists Tare Weight (TW) at 18 lbs. and Water
Capacity (WC) at 48 lbs., the weight of the bottle when filled with LP
to 80% of its capacity will be 38 lbs. (48 x 42 - 20.16 or 20 lbs. or
LP 18 lbs. plus 20 lbs. = 38 lbs.).
LP Gas regulators must always be installed with the diaphragm
vent facing downward. Regulators that are not in compartments
have been equipped with a protective cover. Make sure that
regulator vent faces downward and that cover is kept in place
to minimize vent blockage which could result in excessive gas
pressure causing fire or explosion.
Check the LP gas regulator at the beginning of each season, or
whenever a problem is indicated. Correct line pressure is 11 inches
of water column. Your Viking Dealer or LP gas supplier can perform
this check.

16
LP GAS REGULATOR FREEZE-UPS
LP Gas regulator freeze-up is a problem RV owners can prevent
if they are aware of its cause. Freeze-up is usually caused by one of
three things: moisture in the bottle, an overfilled bottle, or a greater
vapor withdrawal demand than the bottle can deliver at a particular
temperature. Freeze-ups occur more frequently in cold weather
when equipment can freeze and there is a lower rate of vaporization
and a higher rate of demand.
Moisture can enter the bottle in the LP gas or through
condensation if air is allowed into the bottle through an open valve.
Avoid these conditions by using moisture-free LP gas and keeping
all bottle valves closed during storage. If moisture is present,
have the bottle purged by an authorized dealer and have him add
anhydrous methanol; he will know the correct amount for the size
of your bottle.
An overfilled bottle can allow liquid gas, instead of vapor, to
flow through the regulator. This can result in erratic regulator
delivery pressure, improper appliance operation or burner outage,
and possible frosting of the regulator and LP gas lines. This can
be avoided by following the previously cited precaution about
overfilling.
Liquid gas does not vaporize as rapidly in cold weather, so
you may place too great a demand on your bottle’s capabilities in
certain conditions. This can cause a refrigeration effect resulting in
frosting of the bottle and regulator. Check with your Viking dealer or
LP supplier about the appliance demand which can be met by your
bottle at various temperatures. Always have your LP supplier add
anhydrous methanol before filling the bottle in cold weather.

!WARNING!
Do not bring or store LP gas containers, gasoline or
other flammable liquids inside the vehicle, a fire or
explosion may result.
APPLIANCES AND
ACCESSORIES
RANGE
– See manufacturer’s owner’s manual
GENERAL
Your Viking camping trailer will have a two or three burner
range, which is a LP gas appliance.
LIGHTING THE RANGE
Be certain the LP gas bottle service valve is OPEN. Light a
match and hold it close to the range burner, then turn the burner’s
control knob to full ON.
Air in the line may cause a blowing sound and may extinguish
the match. When the line is free of air, the burner should light
readily. Adjust the burner flame with the control knob.

!WARNING!
It is not safe to use cooking appliances for comfort
heating.

!WARNING!
Use of cooking pans larger than burner diameter
could cause damage to stove box by trapping heat in
the stove top.
Cooking appliances need fresh air for safe operation. Do not use
large pans which could restrict the burner efficiency and spread the
flame away from the burner and cook top.
BEFORE OPERATION:
1. Open overhead vent and,
2. Open window.
This warning label has been located in the cooking area
to remind you to provide an adequate supply of fresh air for
combustion. Unlike homes, the amount of oxygen supply is limited
due to the size of the recreational vehicle, and proper ventilation
when using the cooking appliance(s) will avoid dangers of
asphyxiation. It is especially important that cooking appliances not
be used for comfort heating as the danger of asphyxiation is greater
when the appliance is used for long periods of time.
CARE OF RANGE
– See manufacturer’s owner’s manual
Allow the range top to cool, then clean it with hot, soapy water.
Use a damp cloth to clean surfaces. Grease spatters, which may
bake onto the surfaces, should be wiped off before they have time
to harden. Use a toothpick to clean clogged burner orifices. DO NOT
use metal objects, such as an ice pick or wire to unclog burners.
They may distort the opening and adversely affect burner operation.
Read the manufacturer’s manual for details on the operation and
care of the range.
NOTE: Prolonged use of the range may cause moisture to
form on the inside of the canvas and vinyl walls. Condensation may
also form on the inside of the camper during heavy rain or when
the outside temperature drops. This condition can be controlled by
opening a window on the down-wind side of the camper or opening
the roof vent.
CARE OF THE REFRIGERATOR
Remove food and ice after each trip. Clean interior with warm
water and liquid dish soap. Wipe dry with soft, dry cloth. DO NOT
use abrasive cleaning material; it will scratch interior surfaces. Prop
the door open during periods of non-use.
To defrost refrigerator, remove frozen food and ice. Turn off the
thermostat. Place a pan of hot water inside the compartment to
speed up the defrosting process. Dry the interior with a clean cloth.

17
12V / 110 / GAS REFRIGERATOR
The gas and electric controls are located in the rear of the
refrigerator and are accessible through the doors in the outside wall
of the vehicle. To remove the doors, turn the black buttons on the
lower corners 90° counter-clockwise to release.
Refer to manufacturer’s operation manual supplied with
appliance.
NOTE: Keep items to be stored in your RV refrigerator or ice
box in your home refrigerator or freezer until you are ready to leave.
This will reduce the cooling load on your RV refrigerator or ice box
and help keep perishable foods fresh longer. Always store food in
sealed containers or suitable wrapping. During travel, use the door
latch.
• The refrigerator requires 24 hours running time to cool
down.
• If the refrigerator has been out of use for an extended
period, make sure all air vents are free from obstruction
and check for gas leaks using soapy water.
• Never cover or partially cover the air vents with cardboard
or anything else.
• Remember to level the vehicle when stopping for more
than about an hour, otherwise the cooling unit could be
permanently damaged due to overheating if it is left on.
For recommended maintenance, refer to appliance instruction
booklet.

!WARNING!
Turn on only one energy source at a time.
FURNACE
– See manufacturer’s owner’s manual
The RV furnace is an LP gas appliance. Heat is discharged into
the unit directly through the furnace grill. To operate the furnace,
first remove cabinet front. Turn main gas valve control knob to the
OFF position. Move OFF lever, located at the bottom of thermostat
to the right if set on OFF position. Set the thermostat above room
temperature. A slight delay will occur before the blower starts. Allow
the blower to run for five minutes for combustion chamber purge
cycle. After five minutes, set thermostat below room temperature.
Turn main gas valve control knob to ON position. Set thermostat
above room temperature. Allow 30 seconds for ignition to occur
after the blower comes on. If burner does not ignite, return main
gas valve control knob to OFF. Set thermostat on OFF.
NOTE: If after three attempts with no ignition, go to shut-down
and contact a qualified service agency. Do not continue to cycle
furnace through thermostat in an attempt to get ignition.
CARE OF FURNACE
Your furnace should be inspected before use at least annually
by a qualified service agency. Particular attention should be given
to the combustion chamber gaskets, soot in vent and main burner.
Check your furnace owner’s manual (supplied with furnace) for
more information and before operation of furnace.

!WARNING!
DO NOT use catalytic or open flame heaters in
your Viking unit. This includes wood and charcoal
grills and stoves. The use of this equipment inside
the vehicle may cause fires. These devices, either
portable or permanently installed, consume oxygen
from the interior space and may contaminate the air
with toxic fumes. These fumes may cause nausea,
dizziness or death.
WATER HEATER (Limited Application)
– See manufacturer’s owner’s manual
The water heater is an LP gas appliance capable of heating
water to a preset temperature. The water heater features an electric
ignition. When the system is connected to city water, fill the water
heater by opening a hot water faucet. When filling the fresh water
tank, turn the water pump ON and open a hot water faucet. In either
case, when water flows steadily, turn the faucet OFF. Any air still in
the tank can be removed by opening the relief valve in the outside
access compartment.

!WARNING!
Do not turn on water heater switch until heater tank
is full. Damage will occur to water heater if turned on
when empty!
See manufacturer’s directions for use
and care of water heater.
MAINTENANCE
GENERAL
Recreational vehicle owners are noted for the pride they take
in the appearance of their units. Proper maintenance will do more
than keep your Viking unit looking nice. It can help insure trouble-
free operation and maximum efficiency of the various appliances
and components. Failure to properly maintain the vehicle or
its components also may constitute a breach in your warranty
obligations. Negligence, misuse or installation of unauthorized
equipment could affect the operation of your unit and may void
your warranty. See the various manufacturer’s manuals for specific
maintenance instructions.

18
After each trip, set up your camper in your driveway and clean
thoroughly. Discard all unused food items, especially those items
stored in the ice box or refrigerator to avoid attracting insects or
animals.
CONDENSATION
Condensation can be a natural occurrence in modern, tightly
constructed, recreational vehicles. When the unit is tightly closed,
especially in cold weather, the relatively small air volume in
the RV can absorb only a certain amount of moisture. When the
saturation point is reached, the moisture is released in the form
of condensation. (Certain amounts of condensation should be
expected, especially on cool surfaces such as windows and metal
door frames.) However, excess condensation can damage walls
and ceilings. Bathing, dishwashing, appliances and unvented
gas burners, all add moisture to the air. You can control this by
allowing the moisture to escape to the outside. Use your roof vent
when cooking; don’t hang wet clothes in your unit to dry. Opening
a window slightly and the use of fans to circulate air will reduce
condensation.
TENT
To condition the tent prior to your first trip, set up the camper
and spray with water. Allow the tent to dry and then spray again.
This will expand the thread inside the stitch holes. Always ventilate
and dry the tent with bows and braces in place, as soon as possible
after each exposure to moisture. After every trip, wash dust and
dirt, bird and tree droppings, insects and other foreign material from
the exterior tent surfaces. These substances can damage the vinyl
in your tent. Use warm water and a soft bristle brush to remove
stubborn stains. Rinse tent with cool water. Allow the tent to dry
completely before lowering. Mend tears and holes with patching
material or cement. Leaks in tent seams can be repaired by using a
good commercial seam sealer.

!WARNING!
CAUTION: Use of sprays (hair, insect, deodorant, etc.)
near fabric can destroy fabric finish. NEVER allow
spray to come in contact with tent fabric.
INTERIOR MAINTENANCE
FOLDING TABLE LEGS
Fold table legs and secure with straps. Lower table onto seat
braces. Arrange cushions on top for additional sleeping capacity.
VINYL WINDOW & SCREENS
Unzip vinyl windows to permit ventilation. Roll vinyl and secure
in place with straps.
CARE OF PRIVACY CURTAINS AND
DRAPES
Curtains are to be dry cleaned only. Curtains and drapes slide
along tracks.
CARE OF WOODWORK
Clean woodwork with regular household furniture polish. DO
NOT use water to clean wooden surfaces. Scuffs may be covered
with furniture wax and stain mixture. Scratches may be covered
with putty stick.
CARE OF DRAWERS
Clean wooden surfaces with household furniture polish. Wash
plastic surfaces with warm water and liquid soap. DO NOT use
abrasive cleansers.
CARE OF FLOORING
Sweep and damp mop vinyl floors.
ROOF
Frequently check the seals around all extrusions, handles, lights,
roof center seam, etc. Reseal as necessary with silicone sealer.
With expansion and contraction from weather and use, these seals
need to be maintained or damage to your roof from water will
result.
BODY
Wash dust and dirt, road tar, bird and tree droppings, insects
and other foreign material from exterior surfaces. Use a mild soap
in cold or lukewarm water. Apply a good quality auto wax at least
once a year.

!WARNING!
CAUTION: To avoid marring body surfaces, DO NOT
use abrasive cleaning compound or cloth. DO NOT
wipe the surface with a dry cloth; DO NOT wash or
wax your unit in the hot sun, wait until the surfaces
have cooled.
FRAME
Inspect the frame periodically. Remove dirt and rust and apply
rust preventative paint as required routine maintenance.
ELECTRIC BRAKES
After a break-in period of 200 miles, brakes should be adjusted.
Inspect and adjust brake drums, lining and shoes at the beginning
of each camping season or before an extended trip.

19
WHEEL BEARINGS
Check wheel bearing lubrication at the beginning of each
camping season or before an extended trip. Follow directions for
E-Z lube in manual provided with your warranty packet.

!WARNING!
CAUTION: Do not get lubrication on tent material.
STORAGE
GENERAL
You should perform the following procedures if you will not be
using your unit for an extended period.
LP GAS SYSTEM
Close the LP gas service valve. Extinguish all pilots and close all
LP gas valves. Light a range burner to consume any gas remaining
in the lines. When the flame burns out, turn the range burner OFF.
For winter storage, the regulator also should be covered to keep
moisture out of the vent. LP gas bottles should have anhydrous
methanol added by an LP gas supplier.
WATER TANK
Open the water tank drain cock and empty tank. Close the drain
cock when the tank is empty. If unit is equipped with a water heater
and pump, it will require a more detailed service, see dealer.
ELECTRICAL SYSTEM
Turn off the circuit breaker at the service box.
EXTERIOR
Store your unit in a garage or other shelter, if possible, or cover
with tarpaulin or plastic. Do not allow snow to collect on the roof. If
you will not be using your trailer for an extended period, block it up
to prevent tire damage.
NOTE: Do not cover with black or dark colored plastic or seal
airtight.
WINTERIZATION
(Also see Maintenance Schedule pages 20 to 23.)
GENERAL
You should make special preparations for storing your unit in
winter. Contact you dealer to schedule yearly winterization.

!WARNING!
CAUTION: DO NOT use automotive antifreeze in the
fresh water system; it is poisonous.
ELECTRICAL SPECIFICATIONS
LIGHT BULBS
Interior 12 VDC ........................................ #1003 or #1141
Turn, Tail and Stop ................................. #1157 or #2057
License Plate............................................................ #168
Clearance................................................................ #194
FUSE / CIRCUIT BREAKER SIZES
12 VDC Appliances .......................................15 Amp Fuse
120 VAC Circuits............................... 15 / 20 Amp Breaker
WIRE HARNESS COLOR CODES
White..................................................................... Ground
Brown ............................................... Right Stop and Turn
Red ...................................................... Left Stop and Turn
Blue .......................................................................Brakes
Pink................................................................... Converter
Green ............................................................... Clearance
ADDITIONAL OR OPTIONAL EQUIPMENT
WEIGHING OVER 20 LBS. WHEN
INSTALLED
20,000 BTU Furnace............................................. 23 lbs.
Water Heater ..........................................................69 lbs.
2nd LP Gas Bottle with Gas................................... 38 lbs.
1.9 Cu. Ft. Refrigerator ......................................... 44 lbs.
2.5 Cu. Ft. Refrigerator ......................................... 54 lbs.
Awning Wts. 7/9/10/11......................... 18//24/25/29 lbs.
13.5M Air Conditioner.......................................... 104 lbs.
Screen Rooms 7/9/10/11....................... 10/38/39/40 lbs.

!WARNING!
All assembled roof accessories should not exceed
120 lbs. during operation of lift system.
TROUBLE SHOOTING
NOTE: Use the manufacturer’s owner’s manuals for all
appliance trouble shooting.

20
MAINTENANCE
COMPONENT IDENTIFICATION STANDARD CARE FREQUENCY AVOID
Awning Self-storing Household vinyl cleaner As needed Storing wet for extended
periods
Axle Spring
Torflex
Maintenance free
Maintenance free
Road hazards and
overloading
Bearings Tapered roller Lubrication - refer to Al-Ko Axle
book provided in warranty packet
Every 2,000 mi. and
before each session
Road hazards, overloading,
over/under tightening
Bed slides Aluminum / Steel Use silicone lubricant sparingly As needed Unsupported beds,
over-lubrication
Beds Plywood Laminated Use all support poles Model 806 Always Not using proper support
Brakes Al-Ko 7”
10” certain models
Linings and adjustment
see brake manual
Before each season
and as needed
Over-adjustment,
under-adjustment
Ceiling lights 1.5 amps Replace bulb - use only the style
provided as original equipment As needed
Lights on when unit is
closed and connected to
tow vehicle
City water fill Ft. Recovery Cover when not in use Always Over-tightening,
under-tightening
Converter 12-25 amp Use proper size fuses as noted on
the converter
Over-loading, attempting
repairs
Coupler 2” or 2 5/16” Lightly grease ball and oil release
lever rivet Once per year Improper connection to ball
Decorator side drapes
and privacy curtains Woven fabric Dry clean only As needed Machine washing and storing wet
Drain (sink) Winterize with non-toxic
anti-freeze
When storing for the
winter Storing without winterizing
Drain (shower) Winterize with non-toxic
anti-freeze
When storing for the
winter Storing without winterizing
Entrance door Aluminum / Fiberglass
Wash with water and apply quality
auto wax, lubricate channels and
latches with silicone
As needed Abrasive cleaners
Exterior body panels Aluminum / ABS Wash with mild detergent amd
water and apply quality auto wax As needed High pressure spray on graphic labeling areas
Fire extinguisher Located near cabinet
near door on a bracket
Check for charge prior to each
camping trip; note directions on
extinguisher
Floor covering Seamless vinyl, no-
wax
Clean with mild soap and water
as needed As needed Abrasive cleaners
Frame Powdercoat
Rinse with water as needed after
salt or chemical contact; sand
and touch-up bare or rusty spots
with good quality black paint
As needed Chemicals or road salt,
road hazards
Furnace 20,000 BTU See furnace manual
Gas bottle On A-frame See “Gas System” - Be certain
that clamp is secure Every trip Loose clamp
Gas hose Rubber See “Gas System”
Gas line Copper See “Gas System”
