USER GUIDE
10.0 ELLIPSE BOLLARD SUBWOOFER™
EB10SW710BN
Keep this manual
for future reference
© 2022 Coastal Source
Data is subject to change without notice.
For the latest update, please refer to the online
version available on www.coastalsource.com.
coastalsource.com 1
SPEAKER INSTALLATION OPTIONS
Features & Benets
• Sleek design that can be easily hidden within a landscape yet looks great when installed out in the open.
• Large driver area compared to conventional outdoor speakers offering higher performance,
higher efciency, higher delity & less compromise.
• Installation exibility in many forms for above-ground or in-ground applications.
• High quality materials and construction built to Defy the Elements™.
• Built to be part of a complete patented Coastal Source Plug+Play system
or can be easily integrated into existing systems.
10.0 ELLIPSE BOLLARD SUBWOOFER™
Landscape
Stake
Drain Hole
at least 1”
above grade Landscape
Stake &
Theft Guard
IN THE LANDSCAPE
DIRECT BURIAL
45˚ ANGLE BURIAL
SURFACE/PARTIAL BURIAL
W/STAKE
SURFACE/PARTIAL BURIAL
W/STAKE & THEFT GUARD
Stabilizer &
Isolation Spikes** Isolation Spikes***
Hardscape
Mount*
ON HARDSCAPE
HARDSCAPE MOUNT
STABILIZER & ISOLATION SPIKES
STABILIZER & ISOLATION SPIKES
2coastalsource.com
Direct Burial Installation
Dig a hole 12” in diameter and 14” deep. Level the
speaker in the hole then backll with clean sand or soil
being sure that the grill drain hole remains at least 1”
above grade. Compact the sand/soil to make sure the
speaker will not shift or settle over time.
Note: Hard to dig areas may benet from a gas-powered
handheld 12” auger (may be rented locally).
Note: Avoid installing in locations that are prone to
ooding.
Hardscape Mount Installation
Once the appropriate location is selected, secure the
recess mount to the surface with fasteners appropriate
for the surface material. Slide the bollard over the recess
mount and orient the speaker in the appropriate direction.
Insert the supplied set screws and tighten in a uniform
fashion so they all make contact with the recess mount
before nal tightening.
WIRING INSTALLATION
All Coastal Source speakers feature our patented Coastal
Connector™ for a waterproof direct burial connection.
For connecting to a Coastal Source amplier just select
the appropriate cable lengths and y-cables and Plug+Play
the speakers to the amplier. For connection to 3rd
party (non-CS) ampliers, Coastal Source pigtail cables
are available to convert the Coastal Connector™ on the
speaker to a typical 2 conductor bare wire that can be
spliced in to a conventionally wired system.
Cabling Rules
Coastal Connector™ 12AWG cables can be run up to
300’ total per channel without any signicant degradation
of performance. Coastal Source systems ship preset for
typical applications. Adjustments should only by made my
Certied Dealers.
Coastal Source speakers operate at 8 ohms. When using
Coastal Source ampliers (check amp specications for
details) up to (4) 10.0 Ellipse Bollard Subwoofers may be
daisy chained by using a Parallel Audio Y-Divider at each
subwoofer
Two speakers can be paralleled per channel with amps
that are stable to 4 ohms and four can be paralleled per
channel with amps that are stable to 2 ohms. Carefully
consult the amplier manual for low impedance drive
ability and stability. All Coastal Source ampliers are stable
to 2 ohms.
SOUND TUNING
Note that optimal sound tuning is subjective and
specic to each listener so there are no hard and fast
rules for optimizing the sound of a Coastal Source system.
We have designed with exibility to allow you to shape
the sound to your personal preferences. The following
information is offered as a brief guide. It is highly
recommended to take the time to experiment and tune
the system to achieve your desired sound.
SUBWOOFER PLACEMENT
Above Ground - Open area
Less bass response.
Above Ground - Near a rear wall surface
Heavy bass response. Low frequencies gather in corners
and travel better though surfaces like the ground or walls
than the air.
Buried Vertical
Slightly heavier bass response than above ground.
Buried at 45° Angle - Speaker grill
perpendicular to the ground surface
Heaviest bass response. The driver being close to the
ground allows for those low frequencies to travel through
and be reected by the ground.
Subwoofers
Since very low frequencies are omni-directional placement
is less critical, but experimenting with placement is still
recommended since proximity to walls and corners will
have a signicant effect on the bass output.
Streaming Quality
Today most people stream music from a mobile device
to listen to music. This makes the quality of the streaming
source paramount to the overall quality of the sound of
an audio system. Whether demoing a system for a client,
showing off to your friends, or just listening by yourself,
streaming quality can make a huge difference. Below are
the maximum streaming quality rates available for the most
45˚ ANGLE BURIAL
coastalsource.com 3
popular music streaming services (when streaming from
a mobile device). They are listed in ascending order of
maximum quality.
• Pandora: Up to 64kbps
• Rdio: Up to 192kbps
• iTunes: Up to 256kbps
• Beats Music: Up to 320kbps
• Google Play: Up to 320kbps
• Spotify: Up to 320kbps
• Deezer: Up to 14410kbps (lossless)
• Tidal: Up to 14410kbps (lossless)
Keep in mind that all of these services are set by default to
lower quality streaming rates. Higher rates consume much
more mobile data/bandwidth, so the default is always a
lower quality stream. Change these rates in settings to
obtain the best quality possible.
Equalization
If equalization is available from your streaming device it
can aid in further ne tuning of the system’s sound. Note
that equalization is not a substitute for proper speaker
placement and orientation. Equalization should be used
in moderation to make the ne tuning adjustments as
needed.
Speaker Coverage Guidelines
Each bollard subwoofer can cover 100-400 sqft of
listening space.
SPECIFICATIONS
Physical Specications
Size: 29.125in x 10in
Weight: 15.5lbs
Finish: Brown
Woofer: 7X10” Composite Cone w/ Santoprene Surround
Construction: Rotomold Enclosure w/Aluminum Grill
U.S. Design Patent D725,552
Performance Specications
Power Handling: 100W Max Power
Minimum Recommended Amplier Power (per sub):
50 Watts
Frequency Response: 50Hz – 300Hz
Impedance: 8 ohms
Input: Male Coastal Connector™
Efciency: 90dB 1w/M
Dispersion: 360°
OPTIONAL ACCESSORIES
Large Tri-Stabilizer
Isolation Spikes
Hardscape Mount
8” Removable Tip Stake
Theft Guard
10”
*hardscape mount
**tri-stabilizer
***isolation spikes
29.125”
4coastalsource.com
WARRANTY INFORMATION
COASTAL SOURCE warrants its goods against defects in
material and functionality. At COASTAL SOURCE’s sole
discretion, COASTAL SOURCE will either repair or replace
(at no charge) any properly installed and maintained
COASTAL SOURCE goods that fail under normal
operating conditions within the specied warranty period
noted below. All goods are warranted from the date of
invoice, provided they are returned to the corporate ofce
for inspection (transportation prepaid) and determined
defective under the terms of the warranty. This warranty
covers only equipment manufactured by COASTAL
SOURCE and does not extend to transportation,
installation, labor compensation, or replacement
charges, nor does it apply to any equipment of another
manufacturer used in conjunction with COASTAL SOURCE
equipment. Our warranty becomes null and void in
the event of damage to the product resulting from
breakage due to abuse or misuse; repairs, alterations
or modications of the product by anyone other than
authorized representatives thereof; damage resulting from
accidents, vandalism, acts of nature, and improper use.
See Lifetime Care Program for additional options.
This product bears a ve (5) year limited warranty.*
* All Coastal Source products bear a 2-year limited warranty for
commercial/non-residential installations.
Filing a Claim
To le a warranty claim, please contact us to receive a
Return Materials Authorization number (RMA)
and a return shipping label:
COASTAL SOURCE
WARRANTY CLAIMS DEPARTMENT
1.800.719.1996
Please include your contact information, a copy of your receipt
and reason for the return.
Coastal Source
1270 Glen Avenue
Moorestown, NJ 08057
Tel: 1-800-719-1996
www.coastalsource.com
