Cobra MARINE MRHH150FLTE User manual

A1 English
Our Thanks to You and
Customer Assistance
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Introduction
Nothing Comes Close to a Cobra® English
Our Thanks to You •
Thank you for purchasing a CobraMarine®VHF radio.
Properly used, this Cobra®product will give you
many years of reliable service.
How Your CobraMarine VHF Radio Works
This radio is a battery-powered portable transceiver for use afloat. It gives you
two-way vessel-to-vessel and vessel-to-shore station communications, primarily
for safety and secondarily for navigation and operational purposes. With it, you
can call for help, get information from other boaters, talk to lock or bridge tenders,
and make radiotelephone calls to anywhere in the world through a marine operator.
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Customer Assistance
FLOATING VHF MARINE RADIO
MRHH150FLTE
Printed in China Part No. 480-1198-P Version B
Owner’s Manual
Customer Assistance •
Should you encounter any problems with this product, or not understand
its many features, please refer to this owner’s manual. If you require further
assistance after reading this manual, please contact your local dealer.
There is no restriction on the EU region for
Transmit Frequency: 156.025 - 157.425 MHz
Receive Frequency: 156.050 - 163.275 MHz
For Warranty, Product Service and Accessory Information
Please contact your local dealer or distributor.
See www.cobra.com for a list of CobraMarine international distributors.
Adapter: ASSA55W-120040
Aquil Star Precision Industrial (Shenzhen) Co., Ltd.
Car Charger: 12V, 1000mA
Shenzhen Nuo Heng Yuan Technology Co., Ltd.
Battery: CEL 523450
Jiangsu CEL Battery Co., Ltd
©2022 Cobra Electronics Europe Ltd
5101 Deansgrange Business Park
Deansgrange
Co. Dublin
Ireland
A94 A4A6www.cobra.com

Memory Channel Icon
FLOATING MARINE HH150
ESC SETUP
PWR MEM H-M-L ENTER
CHANNEL
SC/DW 16+
VOL VOL+
SUBMERSIBLE
FLOATING MARINE HH150
ESC SETUP
PWR MEM H-M-L ENTER
CHANNEL
SC/DW 16+
VOL VOL+
SUBMERSIBLE
A3 English
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Introduction
A2 English
Radio Controls
and Indicators
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Introduction
Backlit LCD (Liquid Crystal Display) Screen •
Instant Channel
16
External Speaker/
Microphone Jack
Antenna
Backlit
LCD
Screen
Battery
Compartment
Backlight/
Key Lock
Memory/
Escape
Push to Talk
UIC Active Channel Map Icons
Dual Watch Icon
Battery Power Icon
Button Lock Icon
Key Tone Icon
Scan Icon
Active Channel Numbers
Speaker
Power Settings
Select 0.5, 1 or 3 watts of output power
for near or distant calling.
International/Canada Channels/USA
Operate on any of the three different channel
maps set up for these areas.
Submersible
Meets JIS7/IPX7 waterproof standards.
Key Lock
Prevents accidental setting changes
when key lock is set.
Channel Scan/Memory Scan
Scan through all or memorized channels to
find conversations in progress.
Instant Channel 16
Provides instant access to priority
Channel 16.
Dual-Watch
Use to monitor two (channels at once – Channel
16 and one user selected channel.
Roger Beep Tone (Selectable)
Confirmation tone indicates the completion of
the user’s transmission and signals to others
it is clear to talk. On or Off selectable.
Rechargeable NiMH (Nickel-Metal Hydride)
Batteries
Five rechargeable NiMH batteries supplied
with the unit provide extended operating
time and have no memory effect. Five AAA
alkaline batteries may also be used for
emergency backup power.
12V Power Cord Included
Charge the NiMH batteries in a car or boat.
Speaker/Mic Jack
Allows connecting optional Cobra Lapel
Speaker/Mic.
Memory Channels
Allows programming of up to ten VHF
memory channels.
Signal Strength Meter
Shows the strength of incoming
or outgoing signals.
Illuminated Buttons
Allows high visibility of all function buttons.
Product Features •
Belt Clip
Engagement
Microphone
Low/Med/High Power Icons
Battery Door Simplex Operation Icon
Backlit LCD Screen
and Product Features
Roger Beep Icon
Power Level
Enter/Setup
Dual Watch/
Scan
Channel Up/Down
Signal Strength Icon
Broadcast Receive Icon
Squelch
Defeat
Charge Jack
Wrist Strap
Connector
Volume Up/ Down
Receive & Transmit Icons

Introduction
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
1
Nothing Comes Close to a Cobra®
Table of Contents
Introduction
Our Thanks to You......................................................................................... A1
Customer Assistance..................................................................................... A1
Radio Controls and Indicators ....................................................................... A2
Backlit LCD (Liquid Crystal Display) Screen.................................................. A3
Product Features ........................................................................................... A3
Important Safety Information ............................................................................ 2
Marine Communication and Radio Procedures................................................. 4
Licensing Information & Electrical Equipment Disposal.................................... 5
Installation
Included in this Package ................................................................................... 6
Wrist Strap, Belt Clip and External Speaker/Mic............................................... 7
Installing, Charging and Maintaining Batteries ................................................. 8
Operating Your Radio
Getting Started ................................................................................................ 10
Setup Mode Programming............................................................................... 14
Standby, Receive and Transmit....................................................................... 18
Advanced Operation ........................................................................................ 21
Maintenance.................................................................................................... 27
Troubleshooting............................................................................................... 27
VHF Marine Radio Protocols
VHF Marine Radio Procedures......................................................................... 28
Voice Calling.................................................................................................... 30
Radiotelephone Calls....................................................................................... 31
Emergency Messages and Distress Procedure............................................... 32
Warranty and Trademark
Limited 1-Year Warranty ................................................................................. 35
Trademark Acknowledgement ........................................................................ 35
Customer Service
Product Service ............................................................................................... 36
Specifications.................................................................................................. 37
Appendix – English/Español
VHF Marine Channel Assignments .................................................................. 38
Accessories ..................................................................................................... 56
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance

3
Nothing Comes Close to a Cobra®
2English
Important Safety Information
Introduction
Important Safety Information
Industry Canada Antenna Notice
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by
Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.
Avis d’antenne du Canada d’industrie
En vertu de la réglementation de l’industrie du Canada, cet émetteur de radio ne peut
fonctionner à l’aide d’une antenne d’un type et un maximum (ou moins) Gain approuvé
pour l’émetteur par Industrie Canada. Pour réduire le risque d’interférence aux autres
utilisateurs, le type d’antenne et son gain doivent être choisis afin que la puissance
isotrope rayonnée équivalente (PIRE) ne dépasse pas ce qui est nécessaire pour une
communication réussie.
Important Safety Information •
Before using your CobraMarine®VHF radio, please read these general precautions
and warnings.
Warning and Notice Statements
To make the most of this radio, it must be used properly. Please read the operating
instructions carefully before using the radio. Special attention must be paid to the
WARNING and NOTICE statements in this manual.
WARNING
Statements identify conditions that could result in personal injury or loss of life.
NOTICE
Statements identify conditions that could cause damage to the radio
or other equipment.
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Introduction
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Introduction
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
General Precautions •
The following WARNINGS and NOTICE information on the following page will make you
aware of RF exposure hazards and how to assure you operate the radio within the CE
RF exposure limits established for the radio.
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
WARNINGS
Your radio generates electromagnetic RF (radio frequency) energy when it is
transmitting. To ensure that you and those around you are not exposed to excessive
amounts of that energy, DO NOT touch the antenna when transmitting. KEEP the radio
at least two inches (5 cm) away from yourself and others when transmitting. DO NOT
transmit more than 50% of the time the radio is in use — 40% duty cycle. The radio is
transmitting when the Talk button is pressed and the transmit information shows on the
LCD screen.
ALWAYS use only Cobra authorized accessories.
NEVER connect the transceiver to AC power. It can be a fire hazard, may cause an
electric shock, and may damage the transceiver.
NEVER mount the transceiver or microphone where they might interfere with operation
of your vessel or cause injury.
DO NOT allow children or anyone unfamiliar with proper procedures to operate the radio
without supervision.
Failure to observe any of these warnings may cause you to exceed
FCC, Industry Canada or EU RF exposure limits or create other dangerous conditions.
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
WARNING
The device complies with RF specifications when the device is used at 25mm from
your front face and 0mm from your body.
Maximum SAR Value:
0.452 W/Kg (50% duty to face 10g)
0.795 Ww/Kg (50% duty to body 10g)
0.413 W/Kg (50% duty to face 1g)
0.975 W/Kg (50% duty to body 1g)

Introduction
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
5
Nothing Comes Close to a Cobra®
4English
Marine Communication,
Procedures & LicensingMarine Communication
Introduction
Introduction
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Recommendations for Marine Communication •
The frequencies your radio uses are set aside to enhance safety afloat and for
vessel navigation and operational messages over a range suitable for nearshore
voyages. If the 3 watt maximum output of your radio isn’t sufficient for the
distances you travel from the coast, consider installing more powerful radio
equipment such as HF single side band or satellite radio for your vessel.
The coastguard does not endorse mobile phones as substitutes for
marine radios. They generally cannot communicate with rescue vessels and,
if you make a distress call on a mobile phone, only the party you call will
be able to hear you. Additionally, mobile phones may have limited coverage
over water and can be hard to locate. If you don’t know where you are, the
coastguard will have difficulty finding you if you’re using a mobile phone.
However, mobile phones can have a place on board where mobile coverage
is available — to allow social conversations and keep the marine frequencies
uncluttered and available for their intended uses.
Licensing Information
This CobraMarine radio incorporates a VHF FM transceiver designed for use in the
frequency range of 156.025 to 163.275 MHz. It requires 6 volts DC and has a
switchable RF output power of 0.5, 1 or 3 watts.
The radio operates on all currently allocated marine channels and is switchable for
use according to International, Canadian, or U.S.A. regulations. It features instant
access to emergency Channel 16 by pressing one key.
CobraMarine®VHF radios comply with the U.S. FCC (Federal Communications
Commission) requirements that regulate the Maritime Radio Service.
Station License
The UK requires a ships radio license and a marine radio operators certificate before
transmitting equipment can be used aboard a vessel. Other European countries have
specific requirements of their own.
For detailed information and applications, contact the Royal Mail Licensing Centre
in the UK. In other countries contact the local equivalent of the UK Royal Mail or
the national telecommunications authority.
Canadian or U.S.A. Station License
If your vessel will be entering the sovereign waters of Canada or the U.S.A., you
should contact Industry of Canada, Radio Regulatory Branch or the U.S. Federal
Communications Commission for licensing and operating information.
Radio Call Sign
A radio call sign is included as part of the ships radio license in the UK.
Other countries may have different practices; contact your local regulatory
authority for information.
User Responsibility And Operating Locations
All users are responsible for observing domestic and foreign government regulations
and are subject to severe penalties for violations. The VHF frequencies on your radio
are reserved for marine use and require a special license to operate from land,
including when your boat is on its trailer.
NOTICE
Your radio is waterproof only when the batteries are properly installed.
AVOID using or storing the radio at temperatures below -4° F (-20° C) or above
140° F (60° C).
KEEP your radio at least 3 ft (0.9 m) away from the vessel’s magnetic navigation
compass.
DO NOT attempt to service any internal parts yourself. Have any necessary service
performed by a qualified technician.
This radio is supplied with NiMH (Nickel-Metal Hydride) rechargeable batteries.
• Use only the Cobra power cord to recharge NiMH batteries in the radio.
• Do not short circuit the batteries.
• When replacing the batteries, dispose of the old batteries properly. The NiMH
batteries may explode if disposed of in a fire.
• Do not attempt to operate your radio while recharging the batteries.
•
Do not use batteries other than Cobra NiMH or Alkaline batteries of the correct type.
There is a risk of explosion if the batteries are replaced by an incorrect type.
Compatible replacement NiMH batteries are available from Cobra.
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Changes or modifications to your radio MAY VOID its compliance with FCC (Federal
Communications Commission) rules and make it illegal to use.
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Disposal of Old Electrical or Electronics Equipment
This product may contain hazardous substances that could impact health and the
environment if not disposed of properly.
The crossed out wheeled bin symbol indicates that the product should not
be disposed of along with household waste. It should be handed over to
an applicable collection point for the recycling of electrical equipment. By
ensuring that this product is disposed of correctly you will help/prevent
potential negative impact on the environment.
If you need more information on the collection, reuse and recycling systems, please
contact your local civic office or the shop where it was originally purchased.
