Cobra 148 GTL ST Reference manual

Consumer Response Group
6500 W. Cortland Street *Chicago, IL 60707 *Phone: [phone] * FAX: [phone]
-------------------------------------------------------------------------------------------------------------------
June 3, 2003 Page 1 of 2
TECHNICAL SERVICE BULLETIN
10020
MODEL(S): 148GTL, 148NWST
DESCRIPTION: Squealing on transmit. Possible causes:
• High SWR
• Inadequate ground
• Microphone sensitivity of radio is too high. Specification:
− From 1 to 2mV for 50% modulation with Soundtracker off
− From 0.5 to 1mV for 50% modulation with Soundtracker on
ACTION: One of the following suggestions should solve the problem:
1. Check the SWR of the antenna, make sure it is below 3.
2. Connect a ground wire to a screw on the side of the radio, to ground the
chassis of the radio.
3. Remove the top cover plate and tighten all the screws around the edge of the
circuit board.
4. If the radio still squeals, the microphone sensitivity of the radio is too high.
Change R126 to a 12Kresistor.
ADJUSTMENTS: If R126 was changed, check maximum modulation.
NOTES: Page 2 contains a procedure for checking microphone sensitivity.

Technical Bulletin 10020 Page 2 of 2
Checking Microphone Sensitivity
1. Connect an audio source to the microphone input.
2. Connect a modulation meter to the antenna connector.
3. Turn Soundtracker off.
4. Adjust the audio source for 50% modulation.
5. The audio level should be between 1mV to 2mV. If the audio level is below 1mV, increase R126.
