Cockpit 3-IN-1 Sensor Manual

1
Technical specification
3-in-1 Sensor
Type: Ordering code:
3-IN-1 Sensor CKNPED1
Date: 04.03.2018
Document: Cockpit SL_3-in-1_MultiSensor_user manual_eng_V.1B
The purpose of 3-in-1 Sensor is to detect the motion of a person and monitor the current
illumination and temperature. It is for indoor use only.
The 3-in-1 Sensor is a battery powered all-in-one motion sensor, temperature sensor,
and lighting sensor. When the sensor detects motion in front of
its viewing window, it will send wireless signal to the network. The sensor can report
current temperature, and lighting levels in the immediate vicinity.
It is the Z-Wave plus product and it supports the security, OTA. Those are newest
features of the Z-Wave technology.
Add/Remove from Z-WaveTM Network
There are two tamper keys in the device, one is in the back side and another is in the
front side. Both of them can add, remove, reset or association from Z-WaveTM network.
In the first time, add the device into the Z-WaveTM network. First, make sure the
controller is in the add mode. And then power on the device, just take out the insulation
Mylar in the back side of the device. The device will auto start the NWI (Network Wide
Inclusion) mode. It should be included in 5 seconds. You will see the LED light ON one
second.
Notice: Including a node ID allocated by Z-WaveTM controller means “Add” or
“Inclusion”. Excluding a node ID allocated by Z-WaveTM controller, means “Remove”
or “Exclusion”.

2
Function
Description
Add
1. Have Z-WaveTM controller entered inclusion mode.
2. Pressing tamper key three times within 1.5 seconds to enter
the inclusion mode.
3. After add successful, the device will wake up to receive the
setting command from Z-WaveTM controller about 20 seconds.
Remove
1. Have Z-WaveTM controller entered exclusion mode.
2. Pressing tamper key three times within 1.5 seconds to enter
the exclusion mode.
Node ID has been excluded.
Reset
Notice: Use this procedure only in the event that the primary
controller is lost or otherwise inoperable.
1. Pressing tamper key four times within 1.5 seconds and do
not release the tamper key in the 4th pressed and the LED will
light ON.
2. After 3 seconds the LED will turn OFF, after that within 2
seconds, release the tamper key. If successful, the LED will light
ON one second. Otherwise, the LED will flash once.
3. IDs are excluded and all settings will reset to factory default.
Association
1. Have Z-WaveTM controller entered association mode.
2. Pressing tamper key three times within 1.5 seconds to enter
the association mode.
Note: The device supports 2 groups. The group 1 is for receiving
the report message, like triggered event, temperature, illumination
etc. The group 2 is for light control, the device will send the “Basic
Set” command to this group. And each group support 8 nodes
maximum.
•Failed or success in add/remove the node ID can be viewed from Z-WaveTM
controller.
Notice 1: Always RESET a Z-WaveTM device before trying to add it to a Z-WaveTM
network
Notice 2: When the device into NWI mode, the sensor functionality will useless. The
NWI modes will timeout after 30 seconds. You can press the tamper key 3 times to
abort the NWI mode.
Z-WaveTM Notification
After the device adding to the network, it will wake-up once per day in default. When it
wake-up it will broadcast the “Wake Up Notification” message to the network, and wake-
up 10 seconds for receive the setting commands.
The wake-up interval minimum setting is 30 minutes, and maximum setting is 120 hours.
And the interval step is 30 minutes.
If the user wants to wake-up the device immediately, please remove the front cover,
and press the tamper key once. The device will wake-up 10 seconds.
Operation Mode
There are two modes “Test” and “Normal”.
“Test Mode” is for the user to test the sensor function at installation.
“Normal Mode” for the normal operation.
When the event is triggered, normally the LED won't indicate, unless the battery is in
the low level, the LED will flash once. But in the “Test Mode” the LED will also light ON
for one second.
When the event triggered, the device will report the messages to the nodes in the
group 1. The messages also include the battery level, the temperature and the
illumination level. The user can switch the report by setting the configuration NO.5 bit4
(illumination), bit5 (temperature), and the configuration NO.7 bit6 (battery).
When the event is triggered and the environment luminance is less than the setting of
the value of the configuration NO. 4, the device will emit the signal to turn ON the
lighting equipment, those nodes are in the group 2. And delay a while to turn OFF the
lighting equipment. The delay time is setting by the configuration NO. 9.
The PIR motion re-detected interval in the “Test Mode” is fixed to 6 seconds. In the
“Normal Mode” it is according to the setting of the configuration NO. 8.
Notice: When the tamper key of the back side is released, the device is always in the
“Test Mode”, no matter the DIP switch setting.
Battery Installation
When the device reports low battery message, the user should replace the battery with
new one. The battery type is CR123A, 3.0V.
Please, follow below steps to open the front covers.
1. Using a tool press the 1-1 position and release the cover.
2. Hold the front cover and pull back
3. Hold the front cover and pull up

3
Replace the new battery and install the cover back.
1. Put the front cover bottom to 1-1 and press down.
2. Push the front cover top to 2-1.
Choosing a Suitable Location
1. The recommended mounting height is 160cm
2. Don't let the device facing the window or the sunlight.
3. Don't let the device facing the source of heat (e.g. heater or air-conditioner).
Installation
1. In the first time, add the device into the Z-WaveTM network. First, make sure the
controller is in the inclusion mode. Then power on the device, just take out the insulation
Mylar in the back side of the device. The device will auto start the NWI (Network Wide
Inclusion) mode. It should be included in 5 seconds. LED light goes ON for one second.
2. Let the controller associate with the device into the first group, any light switch that
intend to be turned on when the device trig please associate with the device into the
second group.
3. In the accessory pack. There are two types of double coated tape, one is thicker
(hereinafter referred to as A tape) and another is thinner (hereinafter referred to as B
tape), you can use A tape for the test at the beginning. The right way for A tape
installation is stick it to the position below tamper key. The thicker tape won't let the
tamper key pressed, so the sensor will enter the test mode. You may test if installed
position is good or not by this way.

4
After the test is finished and you decide to fix sensor, you can remove tape A, and mount
the sensor by using tape B. The tamper key will be pressed and let the sensor enter
normal mode.
Z-Wave Supported Command Class
COMMAND_CLASS_ZWAVEPLUS_INFO_V2
COMMAND_CLASS_BATTERY
COMMAND_CLASS_NOTIFICATION_V4
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_CONFIGURATION
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_SENSOR_BINARY_V2
COMMAND_CLASS_SENSOR_MULTILEVEL_V5
COMMAND_CLASS_WAKE_UP_V2
COMMAND_CLASS_ASSOCIATION_GRP_INFO
COMMAND_CLASS_POWERLEVEL
COMMAND_CLASS_DEVICE_RESET_LOCALLY
COMMAND_CLASS_MULTI_CMD
COMMAND_CLASS_SECURITY
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2
Technical Specifications
Power supply
CR123A lithium battery
Frequency Range
868.42 MHz
Operation temperature
-10 ~ 40°C
Operation humidity
85%RH max
Distance
App. 30m indoor
Dimensions (WxHxD)
28mm x 96mm x 23mm
Weight
39g
*Specifications are subject to change without notice due to continuing product improvement.
FCC ID: RHHPST02
WARNING:
Do not dispose of electrical appliances as unsorted municipal waste, use separate
collection facilities.
Contact your local government for information regarding the collection systems
available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can
leak into the groundwater and get into the food chain, damaging your health and well-
being.
When replacing old appliances with new once, the retailer is legally obligated to take
back your old appliance for disposal at least for free of charge.
Cockpit Smart Home d.o.o.
Ulica Klementa Juga 007, 5250 Solkan, Slovenia
E-mail: [email protected]
Tel: [phone]
