Cocos Smart Sense User manual

Quick Installation Guide
Smart Sense Set
Gateway with sensors
CoCoSo is a part of preussen automation
GmbH.
preussen automation GmbH
Flurweg 11 | 82402 Seeshaupt | Germany
www.cocoso.eu | [email protected]
Smart Sense Set
This is a quick installation guide for you.
Please read this entire guide attentively
before using our products.
The CoCoSo Smart Sense Set centers on
Smart Sensor Gateway which works together
with smoke detector, Smart Button (door
bell), door and motion sensor. After some
Sense Set to remotely monitor indoor tem-
perature, humidity, pressure, ambient light,
motion, noise level, smoke and contact
Smart Sensor Gateway Smoke Detector
Door Sensor Motion Sensor Smart Button
simple configurations you can use Smart
(e.g. open window or door).

Step 3
Add Smart Sensor Gateway
Make sure your smartphone is connected to
the Wi-Fi. Tap “Add new device” and select
Smart Sense Set.
Then follow the prompts to configure your
Add new device
Quick Instruction
Step 1
Download App
Scan QR-Code below with your smartphone
or search for CoCoSo WIFI App in Google
Play Store. Download the CoCoSo App and
install it.
Sign up or log in directly.
Android
CoCoSo App is available for all Android
devices free of charge.
Step 2
Plug into the power outlet
device.

Step 4
Add sensors
Put your finger on the touch button of the
Smart Sensor Gateway or tap “Add new
sensor”in the Smart Sense menu to start
the pairing.
Then use a needle to press the pairing
button on the sensor. If a voice sounds
“The sensor is paired” and the Gateway
indicator stays blue, the pairing was
successful.
Smart Button
Motion Sensor
Door Sensor
Smoke Detector
Specification
Smart Sensor Gateway
Output: DC 5 V | 1 A maximum | Micro USB
Temperature measurement: -10°C to 60°C
Humidity measurement: 5 % to 95 % RH
Tolerance: ± 4 %
Pressure measurement: 300 to 1200 mbar
Tolerance: ± 3 mbar
Light measurement: 0 to 8300 lux
Tolerance: ± 3 %
Noise measurement: 30 to 130 db
Tolerance: ± 3 %
Door and window sensor
Battery type: CR2032 | Weight: 30 g
Dimension: 58 x 29 x 13.3 mm
Motion sensor
Battery type: 2 x AA | Weight: 45 g
Effective detection: 120 degree | 5 m
Dimension: 46.8 x 66.8 x 31.5 mm
Smart Button (door bell)
Battery type: CR2032 | Weight: 27 g
Dimension: 51 x 51 x 19 mm
Smoke detector*
Battery type: 6LR61 | 9 V | Weight: 84 g
Dimension: 103 x 103 x 34 mm
* Attention: Smoke detector has no certification
according to DIN14676.

Motion sensor
The CoCoSo Motion Sensor detects the
movement in the surrounding environment
by infrared detection.
Indicator
Pairing
Button
Smart Button
The CoCoSo Smart Button triggers the Smart
Sensor Gateway to ring door bell by pressing
the button.
Indicator Pairing Button
Product Introduction
Smart Sensor Gateway
The CoCoSo Smart Sensor Gateway features
the control center of Smart Sense Set. The
sensors can be linked with more smart
devices via Smart Gateway.
Loudspeakers
Light
Induction Zone
Indicator
Button
Reset Button
Door and window sensor
The Contact Sensor monitors doors and
windows by sensing opening and closing
between the main part and the magnet.
Magnet
Main
Part
Indicator
Pairing
Button

Indicator
Indicator Description Status
Smart Sensor
Gateway
Quick green
flashing (4 / sec.)
Ready for connect
to network
Green for 5 sec. Router connection
successful
Slow green
flashing (2 / sec.)
Connecting to
network
Quick blue
flashing (4 / sec.)
Ready for pairing
with sensor
Blue for 5 sec. New sensor pairs
successfully
Door Sensor Blue flashing
Smoke
Detector Red flashing Alarm
Smart Button Blue flashing Ring
Motion Sensor Blue flashing Trigger
Button
Button Function
Smart Sensor
Gateway
Touch Button
Slight touch:
De-Alerting
Long touch:
Pairing mode
Reset Button Long press till
green light flashes
Door Sensor Pairing Button Press to pair
Motion
Sensor Pairing Button Press to pair
Smart Button Pairing Button Press to pair
Smoke Pairing Button Press to pair
Reset Button Press to stop alarm
Smoke detector
The CoCoSo Smoke Detector triggers the
Smart Sensor Gateway to alarm when detect
any smoke.
Indicator
Reset Button
Pairing
Button
Open / Close
Detector

Motion sensor
Step 1 Step 2
Load battery with
2 x AA
Mount the bracket
and scew the device
on
Effective detection area
Installation
Smart Button
Step 1Step 2
Load button
battery CR2032
Step 3
Close back cover
Open back cover

Smoke detector
Step 1 Step 2
Load the 6LR61 9V
battery
Step 3 Step 4
Close back cover Mount on ceiling
Please note
All battery need to be prepared by customers.
For technical support please write an email to:
[email protected]
Door and window sensor
Step 1Step 2
Load button
battery CR2032
Step 3 Step 4
Close back cover Less than 22 mm
Open back cover
Open back cover
