Code 3 Pedestal mount bracket User manual

920-0627-00 Rev. A Page 1 of 4

Introduction:

The Code3 Pedestal Mount Bracket provides a system to

mount the SB48 Series Square Beacon to utility truck bodies

for re and ambulance applications.

Contents:

Specications.......................................02

Installation and Mounting.....................02

Notes....................................................03

Warranty...............................................04

IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.

WARNING!

Failure to install or use this product according to manufacturers recommendations may result in property damage, serious injury,

and/or death to those you are seeking to protect!

1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to

ensure the safety of emergency personnel and the public.

2. Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical

connections.

3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,

which can cause personal injury and/or severe vehicle damage, including re.

4. Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of the

system is maximized and the controls are placed within convenient reach of the operator so that s/he can operate the system without losing

eye contact with the roadway.

5. It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator

should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors), people,

vehicles or other obstructions.

6. The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal. Never

take the right-of-way for granted. It is your responsibility to be sure you can proceed safely before entering an intersection, drive against

trafc, respond at a high rate of speed, or walk on or around trafc lanes.

7. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws regarding

emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The manufacturer

assumes no liability for any loss resulting from the use of this warning device.

Do not install and/or operate this safety product unless you have read and understand the safety information con-

tained in this manual.

Installation and Operation Instructions

PEDESTAL MOUNT BRACKET

SB48 SERIES SQUARE BEACON

920-0627-00 Rev. A Page 2 of 4

Specications:

The Code3 Pedestal Mount Bracket is a 6.625 X 6.875 X 4.125 high bracket for mounting the SB48 Series Beacon in re and ambu-

lance applications. For SB48 Series Beacon operations & specications see the Code3 SB48 Series Beacon installation manual.

Installation and Mounting:

Step 1. Using the Pedestal Bracket as a template hold the bracket in position on the vehicle in the desired location. Mark the mount-

ing holes and the cable hole locations on the vehicle’s mounting surface (See Figure 1 below). Drill the mounting holes with a 3/16”

drill and the cable hole with a 5/16” drill. Mount the bracket to the vehicle using the (2) provided #14 X 3/4” long sheet metal screws

(See Figure 2 below).

Step 2. Feed the SB48 Series Beacon’s cable/wires through the center hole in the beacon’s gasket, through the center hole in the

platform surface of the Pedestal Bracket then through the cable hole in the Pedestal Bracket’s mounting ange. Mount the beacon to

the bracket using the (4) provided #6-32 X 3/8” long black machine screws (See Figure 2 below). It is advisable to apply RTV sealant

around the cable where it enters in the vehicle mounting surface.

Step 3. Route the wiring as desired to connect to the beacon to the vehicle wiring.

Figure 1

BRACKET MOUNTING

FLANGE HOLES

MARK THESE LOCATIONS

ON VEHICLE

BRACKET MOUNTING

FLANGE CABLE HOLE

MARK THIS LOCATION

ON VEHICLE

BEACON MOUNTING HOLES

BEACON CABLE HOLE

Figure 2

920-0627-00 Rev. A Page 3 of 4

Notes:

920-0627-00 Rev. A Page 4 of 4

Manufacturer Limited Warranty Policy:

Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specications for this product (which are avail-

able from the Manufacturer upon request). This Limited Warranty extends for Sixty (60) months from the date of purchase.

DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICA-

TIONS, FIRE OR OTHER HAZARD; IMPROPER INSTALLATION OR OPERATION; OR NOT BEING MAINTAINED IN ACCORDANCE WITH THE

MAINTENANCE PROCEDURES SET FORTH IN MANUFACTURER’S INSTALLATION AND OPERATING INSTRUCTIONS VOIDS THIS LIMITED WAR-

RANTY.

Exclusion of Other Warranties:

MANUFACTURER MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED. THE IMPLIED WARRANTIES FOR MERCHANTABILITY, QUALITY

OR FITNESS FOR A PARTICULAR PURPOSE, OR ARISING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE ARE HEREBY EX-

CLUDED AND SHALL NOT APPLY TO THE PRODUCT AND ARE HEREBY DISCLAIMED, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE

LAW. ORAL STATEMENTS OR REPRESENTATIONS ABOUT THE PRODUCT DO NOT CONSTITUTE WARRANTIES.

Remedies and Limitation of Liability:

MANUFACTURER’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDY IN CONTRACT, TORT (INCLUDING NEGLIGENCE), OR UNDER ANY

OTHER THEORY AGAINST MANUFACTURER REGARDING THE PRODUCT AND ITS USE SHALL BE, AT MANUFACTURER’S DISCRETION, THE

REPLACEMENT OR REPAIR OF THE PRODUCT, OR THE REFUND OF THE PURCHASE PRICE PAID BY BUYER FOR NON-CONFORMING PROD-

UCT. IN NO EVENT SHALL MANUFACTURER’S LIABILITY ARISING OUT OF THIS LIMITED WARRANTY OR ANY OTHER CLAIM RELATED TO

THE MANUFACTURER’S PRODUCTS EXCEED THE AMOUNT PAID FOR THE PRODUCT BY BUYER AT THE TIME OF THE ORIGINAL PURCHASE.

IN NO EVENT SHALL MANUFACTURER BE LIABLE FOR LOST PROFITS, THE COST OF SUBSTITUTE EQUIPMENT OR LABOR, PROPERTY

DAMAGE, OR OTHER SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES BASED UPON ANY CLAIM FOR BREACH OF CONTRACT, IM-

PROPER INSTALLATION, NEGLIGENCE, OR OTHER CLAIM, EVEN IF MANUFACTURER OR A MANUFACTURER’S REPRESENTATIVE HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. MANUFACTURER SHALL HAVE NO FURTHER OBLIGATION OR LIABILITY WITH RESPECT

TO THE PRODUCT OR ITS SALE, OPERATION AND USE, AND MANUFACTURER NEITHER ASSUMES NOR AUTHORIZES THE ASSUMPTION OF

ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH SUCH PRODUCT.

This Limited Warranty denes specic legal rights. You may have other legal rights which vary from jurisdiction to jurisdiction. Some jurisdic-

tions do not allow the exclusion or limitation of incidental or consequential damages.

Product Returns:

If a product must be returned for repair or replacement*, please contact our factory to obtain a Return Goods Authorization Number (RGA number)

before you ship the product to Code 3®, Inc. Write the RGA number clearly on the package near the mailing label. Be sure you use sufcient

packing materials to avoid damage to the product being returned while in transit.

*Code 3®, Inc. reserves the right to repair or replace at its discretion. Code 3®, Inc. assumes no responsibility or liability for expenses incurred for the removal and /or reinstallation of products requiring service and/or repair.; nor for the packaging, handling,
