INSTALLATION GUIDE FOR:
TKRSl
TRUNK RELEASE
Component Parts
SOLENOID WIR~ . ~
SOLENOID ACTUATOfi SWITCH ASSV.
RED WIRE
>==
SOLENOID MTG. BRACKET HOOK ASSV.
FUSE10A
~~----
~ ........_..._ ______
AUXILIARY BRACKET
INSTALLATION
1. Open trunk lid and find lock. Confirm ·oPEN"
direction
of lock lever by moving the lever.
2.
AffiX hook assembly on the lock lever In ·oPEN"
direction as shown
In FIGURE A.
FIG. A
OPEN DIRECTION
LOCK LEVER
3. Select location to mount solenoid. Mount the
solenoid using solenoid mounting bracket alone
(FIGURE B) or in combination with auxiliary bracket
(FIGURE C).
GROUND WIRE (BLACK)
FIG.C

4. Connect hook assembly to solenoidwire by using
lock bolt. Adjustment
of lenght of solenoid wire
is made by pulling the wire as tight as possible
and then returning it by 1/2" (2-3 mm.). If sole-
noid wire is longer than necessary, cut it off.
If solenoid wire is
too long, the trunk release
will
not operate properly. If ·the wire Is too short
the
lock lever will remain in the "OPEN" position
and trunk lid can not be shut.Readjust the length
of the solenoid wire.
5. The actuator assembly switch can be mounted
on the dash board or on the center or overhead
FIG.O
console as desired, although it is suggested that
it be mounted in the glove compartment, this
would preclude others from access
to the trunk;
also, this will prevent accidental opening
of the
trunk while traveling at high speeds.
6. Extend' wiring as shown In FIGURE D .Affix ground
wire (BLACK)
to one of the bolts on the trunk
lock . Connect green wire between the solenoid
and one
of the terminals on the actuator. The
red wire should be connected between the sec-
ond terminal on the actuator and the fuse - box
or battery.
~TOR SWITCH ASSY.
~~
~~RED WIRE
--
FUSE BOX
Wiring Diagram
ACTUATOR SWITCH
FUSE BOX
SOLENOID RED WIRE
FUSE10A
GROUND WIRE (BLACK)
GROUND
BATIERY
I
I
I
,--_J
I
.J.,.
-:•
GROUND
