Code Alarm PROFESSIONAL SERIES User manual

1CA1BTW5 / AS9234E 4280848 Owners rev A.
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
PROFESSIONAL
SERIES
Owner’s Guide
For Model:
CA1BTW5
AS9234E
RF Upgrade Kit

22017 Voxx Electronics Corporation. All rights reserved.
Table of Contents
Using Your Remote Control .......................................................3
 2WayRemoteControlNotications.........................................6
Transmitter Programming..........................................................6
 ReplacingRemoteControlBatteries ........................................7

3CA1BTW5 / AS9234E 4280848 Owners rev A.
Flashlogic Functionality
Entering the Vehicle while it is Running via Remote Vehicle Start
1. Unlock the vehicle’s doors. (If equipped, press and release the button
2 times within 2 seconds while the vehicle is remote started)
2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!
3. Insert the key into the ignition switch and turn to the ON or RUN
position.
4. Press the brake pedal. The remote vehicle starter will disengage and
the vehicle will operate normally.
Preheating or Precooling the Vehicle’s interior
Before exiting the vehicle, set the temperature controls to the desired setting and
operation. After the system starts the vehicle, the heater or air conditioner will
activate and heat or cool the vehicle’s interior to your setting.
Using Your Remote Control
Remote Starting Your Vehicle
To activate the remote start, press and release the button 2 times within 2
seconds. The vehicle will start and run the predetermined time set up during
installation (5 to 60 minutes selectable).
Remote Start Shutdown
To cancel the remote vehicle start function, press and release the button 2 times
within 2 seconds.
Unlocking the Vehicle (optional)
During the run cycle, enter the vehicle using your door key or, if the unlock option is
installed, once you are within range of the vehicle, press and hold the transmitter
button for 3 seconds to unlock the vehicle doors.

42017 Voxx Electronics Corporation. All rights reserved.
Using the “Quick-stop” Feature
With vehicle running, if you wish to make a quick stop and leave the vehicle running,
once you arrive at your destination:
a) place the gear selector in Park,
b) set the parking brake,
c) with your foot off the brake, press the transmitter button two times
in succession.
The vehicle will now be under control of the remote start system. Turn your
ignition switch off, WITHOUT stepping on the brake, and exit the vehicle. Lock
the doors with the key to insure security.
Timed Start Program:
The Remote Start unit has the ability to start the vehicle automatically at timed
intervals. This feature is useful in extremely cold climates where starting the engine
is the only means to keep the battery charged and uids warm. The operator has the
option to have the unit start every 2 or 4 hours for a maximum of 48 hours. Factory
preset is to start at 4 hour intervals. To select 2 or 4 hour automatic start timer:
1. Start By Holding the Push Button Switch found on the windshield mount
receiver on.
2. While Holding the Push Button Switch Turn The Ignition Switch On Then
Off
3a) Within 10 seconds of turning the ignition switch off, Release and then
Push On and release the Push Button Switch 2 times holding it on the
second time until the siren and or lights ash and chirp 2 times indicating
that the 2 Hour Start Interval has successfully been set.
- OR -
3b) Within 10 seconds of turning the ignition switch off, (Step 2) Release
and then Push On and release the Push Button Switch 4 times holding
it on the fourth time until the siren and or lights ash and chirp 4 times
indicating that the 4 Hour Start Interval has successfully been set.
NOTE: Once selected, 2 or 4, this timer interval will remain in memory until it is
manually changed. To change, the above sequence will have to be followed.

5CA1BTW5 / AS9234E 4280848 Owners rev A.
Timed Start Operation:
To begin the start timer, within 10 seconds of turning off the ignition switch, activate
the RF command to start 2 times. (Press the start button four times). The lights
will ash and the siren will chirp 4 times. Indicating timed interval mode has been
initiated. The vehicle will automatically start every 2 or 4 hours as programmed. To
cancel the timed start mode start the vehicle either by RF or by the ignition key.
Remote Start Override Mode (Valet Mode) - AS9234E
The intent of the remote start override / manual shut down circuit is to allow the
vehicle operator to prevent operation of the Remote Start Unit regardless of the RF
transmitter operation.
Enter Remote Start Override:
1. With the system disarmed/unlocked, and the ignition switch off Press and
Hold the PBLED push button switch (dash mounted).
2. Turn the ignition switch on, off, on, off, on, off.
3. The LED begins to ash two short ashes followed by one long ashes
and continues this pattern until returned to normal mode of operation.
The action above puts the unit into the Remote Start Override mode or vehicle service
mode and will not start from the RF transmitter or any other input.
Exit Remote Start Override:
1. With the system disarmed, Press and Hold the PBLED push button
switch (dash mounted) on.
2. Turn the ignition switch on, off, on, off, on, off.
3. The LED turns off indicating that the R/S unit is fully functional one again.

62017 Voxx Electronics Corporation. All rights reserved.
Transmitter Programming
1. Turn the ignition ON.
2. Press and hold the valet/override button located on the antenna.
3. Within 10 seconds the LED’s will begin to ash.
4. Press 1 button of each transmitter you wish to program, the LED’s will
ash to conrm each transmitter.
5. Turn the ignition OFF
NOTE: This system has 1 button programming which programs all channels of the
system.
NOTE: The system will hold up to 4 transmitters in memory, programming a 5th
transmitter will erase the oldest transmitter in memory.
2 Way Remote Control Notications
FUNCTION BEEPS / LED FLASHES
Activation 1 Beep / Flash
Conrm Remote Start 4 Beeps / Flashes (repeats 3 times)
Remote Start Running 1 Flash per 3 seconds for duration run time
Remote Start Shutdown 3 Long Beep / Long Flashes (repeats 3 times)
Low Battery 2 Beeps / Flashes when button is pressed

7CA1BTW5 / AS9234E 4280848 Owners rev A.
1 Way Remote Control, CAT1:
The battery (model CR2032) inside each remote control should last approximately 1
year under normal use. When the battery becomes weak you will notice the remote
control range (the distance from the vehicle the remote control will work) deteriorate
and the small LED on the remote control will dim. To replace the battery in the remote
control:
1. Unsnap and disassemble the halves of the remote control.
2. Remove the old battery, observing the +/- symbols on the battery
and replace with new CR2032 battery.
3. Reassemble the halves of the remote control.
4. Test operation of the remote control.
 ReplacingRemoteControlBatteries
2 Way Remote Control, CAT1MTW:
The battery (model CR2032) inside each remote control should last approximately 10
months under normal use. When the battery become weak you will notice the remote
control range (the distance from the vehicle the remote control will work) deteriorate
and the small LED on the remote control will dim. To replace the battery in the remote
control:
1. Remove 1 screw and disassemble the halves of the remote control.
2. Remove the old battery, observing the +/- symbols on the battery
and replace with a new CR2032 battery.
3. Reassemble the halves of the remote control and reinstall the screw.
4. Test operation of the remote control.

82017 Voxx Electronics Corporation. All rights reserved.
Voxx Electronics Corporation.
Customer Service 1-800-421-3209
WWW.CODE-ALARM.COM
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that
may cause undesired operation.
Warning!
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
