1
Remote Vehicle Control System
IMPORTANT NOTE: The operation of the IV-F65 as described in this manual is applicable
to most vehicles. However, due to the engine type and configuration of some vehicles (i.e.
diesel engines), some functions AND/OR SAFETY PRECAUTIONS may not apply. Please
see your installing dealer for more information.
Car Start, Security and
Convenience System
CA-630TM
Owner's Manual
CA630owners.p65 10/17/03, 4:30 PM1

2
Features and Benefits of the CODE ALARM CA-630 .............4
UsingYourRemoteTransmitter ....................................................5
Arming the Security System
Pre-arm Mode
Disarming the Security System
Attempted Intrusion Identification
Disabling the IT-sTM Interior Theft Sensor ...................................6
Two-Stage Door Unlock
Activating the Trunk Release Feature
Turning on the Vehicle Headlights
Using the Car Finder Feature
Personal Protection Alarm (Panic)
Remote Start / Stop Feature
UsingValet Mode
Using Your Remote Starter.............................................................7
StartingYourVehicle
If your vehicle stalls or does not start
Remote Start Safety Features
Entering the Vehicle While it is Running via Remote Start
Pre-Heating or Pre-Cooling the Interior of the Vehicle
Using the “Quick-stop” Feature
Automatic Convenience Options..................................................8
When Your Security System is Triggered ...................................8
The Interior Status Indicator ..........................................................8
System Maintenance .......................................................................9
Changing the Remote Control Battery
Adding Remote Controls to Your System
Deleting Lost or Stolen Remote Controls from Your System
Basic Troubleshooting ...................................................................10
Emergency Disarm Procedure ...............................................11
Emergency Disarm Button Location
Code Alarm WarrantyPlan ............................................................12
Code Alarm Theft Protection Plan ..............................................13
Table of Contents
CA630owners.p65 10/17/03, 4:30 PM2

3
Features and Benefits of the Code Alarm CA-630
Two Easy-to-Use Weather-Resistant Remote Controls
The remote controls included with the Code Alarm CA-630 utilize
durable, moisture resistant cases and sealed rubber buttons for
reliability and long life. Rolling code technology prevents the
transmitter signals from being duplicated. The button functions are
clearly labeled to make the CA-630 simple to operate.
All Entrances Protected
Opening any door or entrance protected by the security system
triggers the vehicle’s horn and flashes the vehicle parking lights.
Starter Disable
The Code Alarm CA-630 protects your vehicle from theft by
disabling the starter when the system is armed.
IT-sTM Interior Theft Sensor
This patented sensor uses infra-red technology to reliably detect
vehicle impact associated with attempted intrusion. The IT-sTM
sensor guards against vehicle body damage, and theft of the
vehicle’s equipment (such as airbags) and personal belongings.
Remote Keyless Entry
The Code Alarm CA-630 conveniently locks and unlocks vehicle
doors and opens the trunk or hatch by remote control.*
Personal Protection Features
Remote Panic Alarm, Illuminated Entry, and Car Finder are among
an array of features that enhance personal safety.**
Interior Status Indicator
The bright-blue warning light is an effective visual deterrent to a
would-be thief.
Remote Start
The Code Alarm CA-630 allows you to warm up your vehicle
and preheat or pre-cool the interior with the press of a button on
the remote control.
PowerRangeTM Antenna
This long-range antenna allows you to operate the Code Alarm CA-
630from distances of up to1/8mile. Remote-start your vehicle from
the safety of your home, apartment or office building.
*If vehicle is equipped with power door locks and they are connected to the alarm system by your installer.
** May require additional connections, components, and/or charges. See your installer for details.
CA630owners.p65 10/17/03, 4:30 PM3

4
Arming the Security System
To arm the system, exit the vehicle, close all doors, then press* the
LOCK button. The horn will “chirp” twice†and the parking lights will
flash twice, indicating the system is armed. The doors will also lock at
this time (if equipped and connected). The status indicator (blue
warning light on the dash) will blink steadily, once per second.
Pre-arm Mode
If the horn chirps and the parking lights flash only once, this indicates
that the vehicle courtesy light is on, or that an entrance is not closed
securely. Check to see that doors, hood, and trunk are properly
closed. Once all entrances are secured (and the courtesy light is off),
the system will chirp / flash again. The system is now fully armed.
(If the entrance is not secured within 4 minutes, the system will arm
and ignore the unsecured entrance until it is closed.)
Disarming the Security System
To disarm the system, press the UNLOCK button. The horn will chirp
and the parking lights will flash once, and the doors will unlock.
The courtesy light will turn on for 1 minute, or until the vehicle is started.
Attempted Intrusion Identification
If the horn chirps four times when disarming, this indicates that the
system was triggered in your absence. The status indicator will also
flash rapidly. Perform the following operation to determine the protected
zone that triggered the system:
After disarming, press the
emergency override button.
The horn will chirp to indicate
the cause of the alarm trigger:
1 chirp IT-sTM InteriorTheftSensor
2 chirps Door
3 chirps Hood
4 chirps Trunk/Optional Sensors
5 chirps Ignition was turned on
Using Your Remote Transmitter
*Throughout this manual, ‘press’ refers to pressing
for less than 1 second; ‘press and hold’ refers to pressing for more than 1 second.
†If you have chosen the Silent Arming Option, the horn will not sound when arming or disarming until the
appropriate button is pressed a second time.
LOCK Button
Press to Arm Security
System and Lock
Doors
FIND/PANIC Button
Press for Car Finder
Press and Hold for
Panic Alarm
UNLOCK Button
Press to Disarm Security
System and Unlock
Doors
PressTwicefor Two-
Stage Door Unlock*
Press and Hold to Open
Trunk
START Button
Press and Hold for
Remote Start / Stop
Press to Activate
Rear Defroster
CA630owners.p65 10/17/03, 4:30 PM4

5
Using Your Remote Transmitter (cont.)
Disabling the IT-sTM Interior Theft Sensor
It may be necessary at times to disable the IT-sTM Interior Theft Sensor,
especially when parking in areas (like parking garages) where
extreme vibration may cause false alarms. Press the LOCK buttonand
then press the FIND/PANIC button within two seconds of pressing
LOCK to disable the interior theft sensor.The horn will chirp two times
to indicate that the sensor is disabled. The sensor will become
enabled again the next time the system is armed normally.
Two-Stage Door Unlock
If this feature is enabled on your system, pressing UNLOCK one time
will unlock only the driver’s door. Press UNLOCK again within 1
minute to unlock all doors.
Activating the Trunk Release Feature
Press and hold UNLOCK to open the vehicle trunk or hatch (if
equipped and connected). If this button is used to operate another
accessory, the accessory will stay active for as long as the button is
held.
Using the Progressive Car Finder Feature
Press FIND/PANIC on the remote control to locate your vehicle. The
horn will emit five short chirps at low volume, increasing in volume
each of three times the button is pressed.
Personal Protection Alarm (Panic)
Press and hold the FIND/PANIC button to activate the vehicle horn
and parking lights for 30 seconds. (If the vehicle horn is connected,
the horn will “pulse” for 30 seconds.) Press any remote control button
to turn off the Panic alarm.
Remote Start / Stop Feature
Press and hold START on the remote control. If all safety parameters
are correct, the engine will start within 5 seconds (diesel engines will
take longer.) Press and hold START again to turn off the vehicle. (Turn
to page 6 for more on remote start features.)
CA630owners.p65 10/17/03, 4:30 PM5

6
Using Valet Mode
If the Passive Arming feature is enabled on your system, Valet mode
temporarily prevents the alarm system from arming automatically.
This is useful when fueling or servicing your vehicle.
To enter Valet Mode:
With the vehicle ignition on, press the LOCK button. The blue
dashboard warning light (status indicator) will turn on for one second,
then turn off. This indicates that the system is in Valet mode. Once the
ignition is turned off, the status indicator will emit a quick double-flash
pattern.
Note: In Valet mode, all keyless entry, convenience and remote start
features operate normally.
To exit Valet Mode:
With the vehicle ignition on, press the UNLOCK button. The blue
dashboard warning light (status indicator) will turn on for one second,
then turn off. This indicates that the system has exited Valet mode.
Hint: To prevent your security system from automatically arming while
unloading or refueling your vehicle, without placing the system in
Valet mode, simply press the disarm button on your remote control
transmitter after turning the ignition key off. Doing so places your
system into a temporary or one time Valet mode. Next time you exit
your vehicle the system will arm in the normal manner.
Using Your Remote Starter
StartingYour Vehicle
The remote start function is activated by pressing and holding the
STARTbutton for 2 seconds on the remote control. The system will
check the vehicle to ensure that it is safe to start, and if all safety
parameters are correct, the engine will start within 5 seconds (diesel
engines will take longer.) Press and hold START again to turn off the
vehicle.
If your vehicle stalls or does not start...
If the vehicle stalls or does not start, the CA-630 will pause 5 seconds,
then try 3 more times to start the vehicle (a total of four attempts). The
system pauses 5 seconds between each start attempt. If the vehicle
does not start after the fourth attempt, the CA-630 will abort the start
process.
Your vehicle can be started by remote control whether the alarm is
armed or disarmed. When the alarm is armed, the impact sensor turns
off when the vehicle is started to prevent the engine vibration from
Using Your Remote Transmitter (cont.)
CA630owners.p65 10/17/03, 4:30 PM6

7
Using Your Remote Starter (cont’d)
setting off the alarm.
Remote Start Safety Features
For safety and security reasons, the CA-630 will shut off the vehicle
during remote start if any of the following occur:
•The vehicle hood is opened
•The brake is pressed before the vehicle ignition is turned on
with the key
•The engine reaches 3 times its normal idle*
•The alarm is triggered
As a safety precaution, the vehicle will shut off if left unattended for 12
or 25 minutes, depending on the time preset by your installer.
Entering the Vehicle While It is Running via Remote Start
1.Press UNLOCK to unlock the door(s) and turn off the alarm
system (if it is not already off).
2.Enter the vehicle. Do not press the brake pedal.
3.Insert the key into the ignition and turn to the ON position.
4.Press the brake pedal. The remote starter disengages and the
vehicle will operate normally.
Pre-Heating or Pre-Cooling the Interior of the Vehicle
Before exiting the vehicle, set the temperature controls to the desired
setting and operation. After the CA-630 starts the vehicle, the heater
or air-conditioning will activate and heat or cool the interior to your
setting.
Using the “Quick-stop” Feature
If you want to make a short stop and leave your vehicle running (to keep
the interior warm or cool, for instance), the quick stop feature allows
you to do this while keeping your vehicle secure and your keys with you.
To engage quick stop:
1.Stop the vehicle and place the transmission in PARK.
2.With your foot off the brake pedal, press the STARTbutton on
the remote control, the parking lights will turn on, indicating that
the vehicle is now running via remote start.
3.Remove the keys from the ignition and exit the vehicle. Press
LOCK to arm the alarm system if desired.
Note: Do not leave children or animals unattended in the vehicle
when using the quick stop feature.
CA630owners.p65 10/17/03, 4:30 PM7

8Automatic Convenience Options
The CA-630 performs a variety of automatic functions to enhance
security and comfort. Some of these features are programmable at the
time of installation. Please see your installer for further details.
Illuminated Entry
When the alarm system is disarmed, the vehicle courtesy lights will turn
on for 1 minute, or until the vehicle is started or the system is re-armed.
Illuminated Exit
When removing the key from the ignition, the vehicle courtesy lights
will turn on for 1 minute, or until the CA-630 is armed.
Automatic Arming
The CA-630 will arm automatically 1 minute after the key is removed
from the ignition. This feature can be temporarily disabled by placing
the system into Valet mode.
Ignition Lock
If all doors are closed and the vehicle is started with the key, the doors
will automatically lock.
Ignition Unlock
When removing the key from the ignition, the doors will automatically unlock.
When Your Security System is Triggered
The CA-630 will trigger if one of the following events occurs while the
system is armed:
• Any protected entrance is opened
• The vehicle ignition is turned on
• The vehicle is jolted hard enough to signal the impact detector
Once the alarm is triggered, the horn (or horn) sounds and the vehicle
parkinglights flash for 30 seconds.Thesystemwillthenre-arm,awaiting the
next intrusion attempt. To stop the horn while keeping the alarm armed
and doors locked, press the ARM button while the system is triggered.
The Interior Status Indicator
The Status Indicator is a high-intensity red light mounted in a visible
location on the vehicle dashboard. This red light gives a visual indication
of the alarm system’s state of operation. Note the chart below:
If the Status Indicator is... ....then the Security System
Off is disarmed
Flashing Slowly is armed
FlashingVery Quickly was triggered in your absence
(see Attempted Intrusion ID - page 4)
Flashing Intermittently is in Valet mode
(2 flashes, off, 2 flashes)
On (not flashing) is in Pre-arm mode
CA630owners.p65 10/17/03, 4:30 PM8

9
System Maintenance
Changing the Remote Control Battery
The12-volt alkaline batterysuppliedinyourremote
transmitter should last approximately one year,
depending on usage. When the battery begins to
weaken, you will notice a decrease in range, or
the distance from your vehicle that your remote
transmitter will operate. Follow the instructions
below to change the remote transmitter battery.
1. Using a coin pry off the back of the transmitter (the
transmitter snaps together) and expose the battery.
2. Remove the old battery and replace with GP-23A or
equivalent. Be sure to observe the (+) and (-) signs in the battery
compartment.
3. Replace the case backing, then test the remote transmitter.
It is not necessary to re-program the remote transmitter after
changing the battery.
Adding Remote Controls to Your System
The CA-630 has the ability to operate from up to eight (8) remote
controls. Follow these instructions to add a remote control to your
system.
1. Make sure the system is disarmed and the ignition is off.
2. Open the driver’s door.
3. Turn vehicle ignition on.
4. Press and hold emergency override button.
After 15 seconds, the horn will sound three (3) times. This
indicates that the unit has entered the remote control
programmingmode.
5. Release the button.
6. Press the LOCK button (button 1) on the remote control to be
programmed.
The horn will sound once, indicating that the system has
“learned” that remote control.
7. Repeat step 6 for any additional remote controls.
8. Turn the vehicle ignition off to exit the programming mode.
Test all remote controls to ensure that they work properly.
Open Back of
Remote Transmitter
CA630owners.p65 10/17/03, 4:30 PM9

10
Basic Troubleshooting
This section outlines some of the basic issues you may experience
while becoming used to the IV-F65. If you have a problem that is not
covered by this section, please consult your installer.
Symptom Problem Solution
Remote control does
not work
Weak or dead battery
Remote control not
programmed
Change battery
Program remote
control (page 9)
System will not arm
Door or other
entrance is open
Courtesy light is on
System is in Valet
mode
Close entrance
Turn courtesy light off
Turn off Valet mode
(page 6)
System will not start Hood is open
Brake is pressed
Close hood
Release brake
System Maintenance (cont.)
Deleting Lost or Stolen Remote Controls from Your System
If one of your remote controls is lost or stolen, follow these instructions
IMMEDIATELYto remove the control code from your system.
1. Have all remaining remote controls available.
2. Enter the control programming mode by following steps 1 - 5
of Adding Remote Controls to Your System (page 8).
3a. If you have only one remaining remote control, press the
LOCK button on that remote control eight (8) times, pausing
at least 1 second between each press. Make sure that the
horn chirps each time you press the LOCK button.
3b. If you have two remaining remote controls, press the LOCK
button on each remote control four (4) times, pausing at
least 1 second in between each press. Make sure that the
horn chirps each time you press the LOCK button.
3c. If you have three remaining remote controls, press the
LOCK button on the two remote controls three (3) times,
thenpress the LOCK button on the remaining remote control
twice. Pause at least 1 seconds in between each press.
Make sure that the horn chirps each time you press the
LOCK button.
4. Turn the vehicle ignition off to exit the programming mode.
When you are finished, the lost or stolen remote control will
no longer operate your system.
CA630owners.p65 10/17/03, 4:30 PM10
