Coffee Queen Grinder original User manual

U / ENG
Rev. 090115
Your local Dealer
...............................................................................
...............................................................................
ORIGINAL GRINDER
User Guide

1 Contents 2.
2 Introduction 3.
3. Warnings and regulations 3-4
4. Basic rules 4.
5. Technical data 4.
6. Overview of grinder 5.
7. Installation and start-up 6-7.
8. Adjust coffee amount 8.
9. Grinder care 8.
10. Cleaning with GRINDZ cleansing agent (once a month) 9.
11. Dimension sketch 10.
1. contents. Original Grinder
2.

2. Introduction. Original Grinder
Original Grinder
Congratulations on choosing an Original coffee grinder.
 TheOriginalcoffeegrindertsallCremInternationalAB's1.8litrepotsand2.2-2.5litre
thermos brewers.
Crem International AB is certied in accordance with ISO 9001 and ISO 14001,
ensuring that its products have the lowest possible environmental impact.
3.
3. Warnings and safety regulations. Original Grinder
Warnings and safety regulations:
Readthismanualbeforeusingthecoffeegrinderforthersttime.
 Onlyqualiedpersonnelshouldinstallthemachine.
Check that all parts are free of defects. If they are not, stop installation and contact your
dealer.
Keep this manual in a safe place.
 -Checkthatthevoltageinthepoweroutletmatchestheinformationonthegrinder'slabel.
The grinder is designed exclusively for grinding roasted coffee beans.
The grinder should only be used for its intended use, that is, grinding roasted coffee beans.
All other uses are considered unsuitable and therefore dangerous. The manufacturer
cannot be held liable for any damage caused by unsuitable, improper or unreasonable use.
Nor is the manufacturer liable for personal injuries or damages caused by
the machine when is used in a way other than the manner described in the manual.
Likewise, the manufacturer cannot be held liable if maintenance or safety regulations
are neglected.
The warranty will become void if the machine is used in a way other than the manner
described in the manual.
The machine may only be operated by an adult.
- The user must be an adult. The grinder may not be used by children or other unsuitable
individuals.
- Theusermustobservethesafetyregulationsapplicableintheuser'scountry.He/she
must also use common sense.
- The user, installer or service technician must inform the manufacturer of
 anydefectsorwearthatmayjeopardisethemachine'soriginalsafety.
The installer must check the conditions at the place of use, to ensure
hygienic and safe use for the user and customers.
- The manufacturer is responsible for the machine components, and the buyer for ensuring
that trained personnel use the grinder.

4.
4. Basic rules Original Grinder
- Do not pull on the power cord or machine to pull the plug from the wall outlet.
- Do not allow children or inappropriate individuals to use the grinder.
- Disconnect from power source before cleaning or other maintenance.
- Switch off the grinder in case of error or poor function. Contact an authorised service
technician and ask that only original spare parts be used.
Failure to do so may make the damage worse.
- Do not leave the grinder connected to a power source when it is not necessary.
Unplug the device when it is not in use.
- Make sure that the ventilation slots on the grinder are not blocked and that water or
other liquids cannot get inside.
- If the power cord is damaged, have it replaced immediately.
Warning! - when the machine is operating.
Never put a spoon, fork or other item in the grinder when it is in use.
Never immerse the motor or any other part of the grinder in water.
5. Technical data. Original Grinder
Dimensions:
 Height:     475mm
Width: 209 mm
Depth: 369 mm
Weight: 12 Kg
Bean container capacity: 2.5 Kg. coffee beans
Electrical Specications:  230V/60Hz
Power: 450 W
3. Warnings and safety regulations. Original Grinder
 Themanufacturerhastakeneverypossiblemeasuretoguaranteetheuser'ssafety,
but variable installation or transport conditions may cause
unpredictable and uncontrollable situations. Therefore, it is important to try
to avoid any hidden dangers, in particular the following:
- The packaging material can cause cuts and other injuries if handled
carelessly. Do not allow children or inappropriate individuals to handle the material.
- Any errors or defects must be reported immediately to an authorised installer or
technician.
- Only authorised personnel may repair the grinder.

6. Overview of grinder. Original Grinder
Bean container
lid
Bean container
Dispenser
Display
Increase portion
Decrease portion
STARTS GRINDING
Adjustment of
coarseness
5.
Filter holder
90-110 mm
ON/OFF switch

7. Installation and start-up. Original Grinder
7.1. Installation of grinder.
 Placethegrinderonaat,waterproofsurface.
7.2. Electrical connection of grinder.
Connect the grinder to an earthed 230V10A wall outlet.
Warning! The machine must be connected to an earthed power outlet.
 Alwaysobservetherulesineffectintheuser'scountry.
- Use of extension cord or other forms of loose connections is not advisable.
The grinder is often used in rooms where there is water and humidity, and therefore it
must be properly insulated.
6.
7.3. Fill the grinder with coffee beans.
7.3.1.Liftthebeancontainer'slid(A),andllwithfreshlyroastedcoffeebeans.  
7.3.2. Use only coffee beans without additives like fragrance oils and sugar.
A

7.5. Coffee portions: (Default settings)
Recommended portions for Crem International AB
coffee machines, Original and Cater.
The display shows: 4 = 35 grams
6 = 55 grams
8 = 75 grams
10 = 95 grams
12 = 115 grams
14 = 130 grams
Note: Coffee portions 4 - 12 are recommended for 1.8 litre pots/thermoses.
Coffee portions 12 - 14 are recommended for 2.2 litre and 2.5 litre thermoses.
Important! To prevent brewing problems, never exceed 150 grams.
D
E
G
7.
7.4. Start the grinder.
7.4.1. Turn on the grinder by pressing the ON/OFF button (B).
7.4.2. The display (C) shows the current coffee portion setting.
7.4.3. You can select preset coffee portions by pressing on
the buttons (D) or (E).
(See the recommendations in chap. 7.5. Coffee portions).
7.4.4. Insertalterinthelterholder(F)andplacethelterholder
under the coffee dispenser. Use only Crem International AB-
 recommendedpaperlters.For90mmlterholders,
lter110100 whenordering,and110mmlterholders,lter
110110 when ordering.
7.4.5. BEGIN the grinding by pressing button (G).
B
C
7. Installation and start-up. Original Grinder
D
E
G

8.
8. Adjust coffee amount.
8.1. Press buttons (D) and (E) simultaneously for 6 seconds.
8.2. The display (C) shows the current time setting for grinding.
8.3. You can now choose to increase or decrease the time
15 = 1.5 seconds for grinding, by pressing the buttons (D) or (E).
This means that you increase or decrease the amount of
coffee grounds,
(Adjust the coarseness, see the service manual, and this
should only be done by a service technician authorised
by Crem International).
C
8. Adjust coffee amount. Original Grinder
D
E
9. Grinder care. Original Grinder
9.1. External cleaning of grinder.
To clean the exterior of the machine,
use a soft rag and liquid
detergent that is non-abrasive.
9.2. Cleaning the bean container.
Make sure that the bean container is
completely empty.
Clean with a dry non-abrasive cloth.

10. Cleaning with GRINDZ cleansing agent. Original Grinder
9.
G
Cleaning with GRINDZ™ cleansing agent
We recommend that you clean your espresso grinder once a month using our
GRINDZ™ cleansing agent.
10. Cleaning with GRINDZ cleansing agent Ordering: Item number E1001001
10.1. Run the grinder empty of beans.
10.2. Pour the recommended dose of GRINDZ (35-40g) into the cap and pour it in the
empty bean container.
10.3. Start cleaning by pressing button (G) (see photo).
10.4. Whenthecleaningprocesshasnished,werecommendrunningthemachinewith
a dose of coffee beans, to clean the coffee dispenser until there is no longer any trace
of cleansing agent.
Cleansing agent for grinder.

11. Dimension sketch Original Grinder
10.

Item no. 1730063
FOR SERVICE
Your local Dealer
...............................................................................
...............................................................................
...............................................................................
CREM International AB, Box 960, 671 29 ARVIKA, visiting address: Korpralsv 1B,
Tel: [phone] (switchboard), Fax: [phone]
E-mail: [email protected] www.coffeequeen.se
Original Grinder
