Cognex In-Sight I/O Expansion Module Installation and operating manual

I/O Expansion Module
Installation & Reference
Overview
The In-Sight™vision sensor supports up to
ten discrete inputs and ten discrete outputs.
Two inputs and two outputs are built-in to
the In-Sight processor. The remaining eight
inputs and outputs require the optional I/O
Expansion Module.
This document describes the I/O Expansion
Module, including the following topics:
Installation..................................... p. 2
Connector Pin Assignments ........... p. 5
Terminal Block Pin Assignments... p. 6
Schematics ..................................... p. 7
Specifications ................................. p. 8
Product Contents:
The I/O Expansion Module kit (Cognex
P/N CIO-2350-00) includes the following
components:
• I/O Expansion Module
(P/N 800-5712-2)
• 2.1 m (7.0 ft) I/O Expansion Module
Cable (P/N 300-0274-7)
NOTE: The In-Sight processor supplies power
to the I/O Expansion Module; no external power
supply is necessary.
➊
➋
➌
➍
➎
➏
1 26-pin D-sub connector to In-Sight processor
2 LEDs
3 Output terminals
4 Ground screw
5 Input terminals
6 DIN rail mount
➊
➋
➌
➍
➎
➏
1 26-pin D-sub connector to In-Sight processor
2 LEDs
3 Output terminals
4 Ground screw
5 Input terminals
6 #3 DIN rail mount
Figure 1
–
I/O Expansion Module Overview

I/O Expansion Module
Installation & Reference
2
Installation
This section describes how to connect the I/O Expansion Module to the In-Sight processor and
how to connect input and output lines to the I/O Expansion Module.
Step 1 – Connect the Cables
1. Remove power from the In-Sight processor.
2. Plug one end of the provided cable into the I/O Expansion Module’s 26-pin
connector, and the other into the 26-pin connector on the In-Sight processor
labeled EXTERNAL I/O.
CAUTION! The I/O Expansion Module must have the same ground potential as the In-Sight
processor’s chassis. Any difference in potential can damage the equipment. If you connect
a ground wire to the I/O module’s ground screw, then that ground must have the same
potential as that of the In-Sight processor.
3. On the I/O Expansion Module, connect input lines to the input terminals and
output lines to the output terminals. For both input and output signals, connect the
“source” side of the signal to a positive number terminal and the “sink” side to a
negative-numbered terminal. Tighten the set screws.
Figure 2
–
Wi
r
ing Diagram
5 – 24 Vdc
Supplied by
In-Sight

I/O Expansion Module
Installation & Reference
3
Step 2 – Configure the Input Lines in the User Interface
1. Power up the In-Sight processor.
2. Using the control pad, highlight any empty cell in the spreadsheet and press
the A3 button to open the System menu.
3. Highlight Settings and press the A1 button to open the Settings menu.
4. To configure a discrete input line, highlight Discrete Input and press A1 to
open the Discrete Input dialog. Configure the selected input lines as needed
and press OK to close the Discrete Input dialog.
You read a discrete input values in the spreadsheet using the Read Discrete function.
Figure 3 – Discrete Input Dialog

I/O Expansion Module
Installation & Reference
4
Step 3 – Configure the Output Lines
1. Open the Settings menu as in Step 5, but this time highlight Discrete Output
to open the Discrete Output dialog.
2. Configure the selected output line as needed and press OK to close the
Discrete Output dialog.
You write values from the worksheet to the discrete output through the WriteDiscrete
function.
NOTE: In-Sight retains the settings in the Discrete Input and Discrete Output dialogs until you
change them. These settings are system-wide, and apply to all saved jobs.
Figure 4
–
Discrete Output Dialog

I/O Expansion Module
Installation & Reference
5
Connector Pin Assignments
The following table lists the signal assignments for each pin on the I/O Expansion
Module’s connector:
Pin # Assignment Pin # Assignment
1 Input 0 14 Output 5
2 Input 1 15 Output 6
3 Input 2 16 Output 7
4 Input 3 17 Power, +5v DC, fused at 0.5 A
5 Input 4 18 Power, +5v DC, fused at 0.5 A
6 Input 5 19 Ground
7 Input 6 20 Ground
8 Input 7 21 Ground
9 Output 0 22 Ground
10 Output 1 23 Ground
11 Output 2 24 Ground
12 Output 3 25 Not connected
13 Output 4 26 Not connected
123456789
101112131415161718
1920212223242526
Figure 5
–
Connector Pin Numbering

I/O Expansion Module
Installation & Reference
6
Terminal Block Pin Assignments
The table below lists the signal assignments for both the Input and Output terminal blocks on
the I/O Expansion Module.
Assignment AssignmentPin #
INPUTS
(LED Anode)
OUTPUTS
(Collector)
Pin #
INPUTS
(LED Cathode)
OUTPUTS
(Emitter)
1 IN 0+ OUT 0+ 9 IN 0 - OUT 0-
2 IN 1+ OUT 1+ 10 IN 1- OUT 1-
3 IN 2+ OUT 2+ 11 IN 2- OUT 2-
4 IN 3+ OUT 3+ 12 IN 3- OUT 3-
5 IN 4+ OUT 4+ 13 IN 4- OUT 4-
6 IN 5+ OUT 5+ 14 IN 5- OUT 5-
7 IN 6+ OUT 6+ 15 IN 6- OUT 6-
8 IN 7+ OUT 7+ 16 IN 7- OUT 7-
NOTE: The pin numbering for both input and output terminal blocks is identical.
1
8
16
9
Figure 6
–
Terminal Block Pin Numbering

I/O Expansion Module
Installation & Reference
7
Schematics
The following schematics apply only to the external discrete inputs and outputs on the I/O
Expansion Module. For information on the built in discrete inputs and outputs on the In-Sight
processor, see the Installing In-Sight guide.
Figure 7
–
I/O Expansion Module Schematics

I/O Expansion Module
Installation & Reference
Specifications
Feature Description
Inputs and Outputs • Eight independent discrete inputs, optically isolated.
• Eight independent discrete outputs, optically isolated.
Operating Voltage
(Field Side)
• 5v to 24v DC.
Power • +5v DC, supplied from the In-Sight processor.
Maximum Output Current • 15 mA (sink or source).
ON State Voltage Drop • 0.8v DC @ 10 mA, 2.6v DC @ 15 mA.
OFF State Leakage Current • 100 µA; maximum @ 15v DC.
Output Delay • ON: 6 µSec.
• OFF: 130 µSec @ 5 mA; 95 µSec @ 10 mA; 85 µSec @ 15 mA.
Input Resistance • ~ 1000 Ohms.
Input State Current • ON: 3.5 to 15 mA.
• OFF: 500 µA.
Input Delay • ON: 30 µSec @ 3.5 mA; 8 µSec @ 15 mA.
• OFF: 45 µSec @ 3.5mA; 80 µSec @15 mA.
Field Wiring Size • 26 to 12 AWG
Terminal Block Torque • Maximum 7 in-lb (0.8 N-M).
Cable • 2.13 m (7 ft), supplied
Mechanical • Dimensions: 120 mm (4.75 in) wide x 60 mm (2.35 in) high x 83 mm (3.25 in) deep.
• #3 DIN Rail mountable.
Environmental • Operating Temperature: 0 to 50°C (32 to 122°F).
• Operating/Storage Humidity: 5 to 95% non-condensing.
• Storage Temperature: -20 to 85°C (-4 to 185°F).
60.0 mm
(2.35 in)
120 mm
(4.75 in)
83 mm
(3.25 in)
Figure 8
–
Dimensions
P/N 597-0015-01
