Cololight PLUS User instructions

Setting up your Cololight PLUS
User Guide V1.0

LifeSmart Cololight PLUS is an ambient light
supporting split joint and color changing. It can be
placed on the table or installed as background
wall, suspended ceiling.
Cololight PLUS is HomeKit-enabled, you can use
Siri and Home app on iOS devices to control it.
Its unique functions like changing color with music,
voice control bring intelligent playing into lighting
system, providing dining, living and so many other
scenes with various experiences.
PRODUCT INTRODUCTION

Reset method: Press and hold the reset hole until
the green indicator light on the controller flashes.
Release the button and the device will reboot. Wait
about 10 seconds for the device to reboot success-
fully and complete the reset.
INSTALLATION INSTRUCTION
Mic
Control button
Reset

Creative Shape
Hexagon design, seamless connection and no
dark area on the surface.
FUN of DIY
various shapes with gorgeous effects to
creates joyful atmosphere.
16 Million Colors
3 color selection modes (Selected, Dynamic &
Customized).
Color Changing with Music
Dynamic effects & Sound activated.
FEATURES

Voice Control
support Siri & Amazon Alexa & Google Assistant.
App Control
Various playing methods, Dimmable function,
Auto ON/OFF.
Intelligent Scene Linkage
Auto lighting up when opening door (Should
be used with sensor).
No Hub Required
Directly controlled through App on mobile
device.
FEATURES

Light size
Light weight
Controller Size
Controller weight
Power cable length
Communication protocol
Operating frequency
Input
Operating temperature
Operating humidity
Material
Power consumption
Control mode
86x74.5x30.5mm
52.5g
46.5x30.5x28mm
54g
1m
Wi-Fi
2.4GHz (5GHz not supported)
5V DC, 2A
-5~45°C
5~90%
ABS/ABS+PC
Static 0.3W Maximal 5W
App/Voice/Control button
SPECIFICATIONS

Scan QR code or input following URL in your mobile
browser to download App.
http://www.ilifesmart.com/getapp_qlgp.html
Visit the iOS App Store or Google Play and search
for Cololight.
Pair up COLOLIGHT with your mobile device
according to the instruction on App.
Please check the FAQ in the
Cololight App if you have any
problems.
APP INSTRUCTION
NOTE

Use the CONNECTOR to fix the Controller unit PLUS
and the Cololight
INSTALLATION INSTRUCTION
Cololight
Controller unit PLUS CONNECTOR
The first Jack
The second Jack

Use the CONNECTOR to connect the COLOLIGHTs
together. One end of the CONNECTOR must
connect to the outer slot while other end must
connect to the inner slot.
CONNECTOR
Inner slot
INSTALLATION INSTRUCTION
FIXATOR
CONNECTOR

INSTALLATION INSTRUCTION
Use FIXATORs to strengthen stability. Notice that
FIXATOR must connect to single hole slots
between two COLOLIGHTs. It only strengthens the
structure without communication function.
FIXATOR

1. Controlling this HomeKit-enabled accessoryautomatically
and away from home requiresa HomePod, an Apple TV with
tvOS 10.x orlater, or an iPad with iOS 10.x or later set up as
a home hub.
2. Use of the Works with Apple HomeKit badge means that
an electronic accessory has been designed to connect
specifically to iPod touch, iPhone, or iPad, respectively, and
has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and
regulatory standards.
3. Home app does not support functions such as single LED
edit, playing method create, please turn to Cololight App if
required.
NOTICE

This product contains small parts that can cause
danger if swallowed by children.
This product is not suitable for children
under the age of 3.
Children under the age of 14 must use this
product under parental supervision.
WARNING

Hazardous Substance Table
Part Name
Harmful
Substance
Grey plastic
shell
（Cd）
（Pb）
（Hg）
（Cr）
（Br）
This table is made according to IEC 62321 test standard.
Expresses that this hazardous substance in all
homogeneous materials of this part is within limit range.
Expresses that this hazardous substance in at least one
homogeneous material of this part is above limit.
Code Label IC Body
X

WARRANTY DESCRIPTION
Thank you for purchasing this LifeSmart product. In order to
protect your rights, please read the following content
carefully: The warranty period of our company's products is
one year from the date of purchase or longer if local laws
impose a longer minimum term, in which case the minimum
term is the warranty period. During the warranty period, any
faults caused by the product itself or for quality problems
that arise under normal usage, LifeSmart will provide a free
replacement.

ATTENTION
The following conditions are not covered by the warranty:
Product failure or damage caused by installation, use,
and maintenance that is not in accordance with the
product instructions;
Products beyond the warranty period;
Products that have the barcode tampered with or
removed;
Devices that have been tampered with or customized
outside of LifeSmart Terms of Service as on the LifeSmart
App and website;

ATTENTION
User-caused damage, such as inappropriate voltage
input, high temperature, accidental spillage, physical
damage, etc;
Product failure or damage caused by force majeure such
as earthquakes, fires, or floods;
Product failure or damage caused by other problems
except the product itself.
CERTIFICATION
Quality inspector
QC
PASS
User support e-mail address
[email protected]
Website
www.ilifesmart.com

DECLARATION
LifeSmart is a trademark of Hangzhou LifeSmart Technology
Co., Ltd. As for the trademarks, product logos and product
names from other companies presented within this manual,
they are possessed by their own right holders. Without our
written permission, no entity or individual shall extract, copy
or disseminate in part or the whole of the manual contents in
any form. Due to product version upgrades or other reasons,
content of this manual may change. Our company reserves
the right to change the contents of this manual without any
notice.

DECLARATION
This manual is used only for instructional purposes. We strive
to provide accurate information in this manual, but we are not
able to ensure that the content of this manual is current.
Statements, information and advice in this manual do not
constitute any expressed or implied assurance. Updated
manuals are available on our website at www.ilifesmart.com or
by contacting our team.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference
that may cause undesired operation.

DECLARATION
NOTE: The grantee is not responsible for any changes or modifications not
expressly approved by the party responsible for compliance. Such
modifications could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.

DECLARATION
3) Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
RF EXPOSURE STATEMENT
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance of 20 cm between the radiator and your body.
DECLARATION OF CONFORMITY
Hereby, LifeSmart declares that the radio equipment type Cololight is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet address:
http://global.ilifesmart.com/ce/docs/
Notice: This device may be used in each member state in EU.
