Colorful GF9800GT-512M DDR3 H10 User manual

COLORFUL Technology&Development LTD. www.colorful.cn
Colorful GF9800GT-512M DDR3 H10 Spec
Model Name:
GF9800GT-512M DDR3 H10
OverView:
Chip: NVIDIA GeForce9800GT GPU (G92)
Core Clock: 600MHZ
Shader Clock: 1500MHZ
Memory Clock: 1800MHZ
Memory Bandwilth: 256BIT
Memory Module: SAMSUNG GDDR3 FBGA 1.0NS
Interface: DVI+DVI+HDMI
ADVANTAGES:
1. With 2 swiches beside the power supply system. The are used for adjusting the voltage of the
core and memory, in order to have a better overclocking ability.
2. With high quality heat-pipe cooling system, start up temperature is only 42 degrees Celsius,
and in the 3D Bench Mark 06 is only 51 degrees Celsius (Ambient temperature is 25 degrees
Celsius).
3. Using high quality inductors and capatitors, ensure the graphics card steadly working.
4. Support for NVIDIA® PureVideo® HD Technology
5. PCI Express 2.0 Support, NVIDIA® PhysX™-Ready
6. Support NVIDIA 2-way SLI® Technology.

COLORFUL Technology&Development LTD. www.colorful.cn
1. Dual-link DVI1 2. Dual-link DVI2
3.HDMIport 4.SPDIFconnector
5. SAMSUNG GDDR3 1.0ns 6. High efficiency cooling system
7. Switch 1 8. 6-pin power connector
9. Switch 2 10. 4-pin fan connector
②
①
③
④⑤⑥
⑦
⑧
⑨
⑩

COLORFUL Technology&Development LTD. www.colorful.cn
Uninstall the cooler
Parts of the graphics card:
Output: DVI+DVI+HDMI
The 2-pin SPDIF-IN pinhead is for the audio output of the HDMI. Please use the SPDIF connecting
cable in the accessories, one end connect to the graphics card, the other end connect to the SPDIF-OUT
pinhead of the motherboard (Please refer to the definition of SPDIF pinhead in the motherboard
manual). The RED cable is data cable, and the WHITE cable is GND.
Data (RED)
GND (White)

COLORFUL Technology&Development LTD. www.colorful.cn
Switch 1
Switch 2
The 2 switches are used for adjusting the memory voltage and core voltage. When switch to
the top, the voltage will be added, and the overclocking ability will be improved.
Caution: The system might come to unstable when overclocking, so normal users please keep the
default clock and voltage.
6-pin power supply connector

COLORFUL Technology&Development LTD. www.colorful.cn
Used 8pcs high quality SAMSUNG 1.0ns GDDR3 memory modules
9800GT GPU

COLORFUL Technology&Development LTD. www.colorful.cn
2-way SLI
High efficiency fan with heat pipe
3+1 phases Power Supply System: Using high quality inductors and capacitors

COLORFUL Technology&Development LTD. www.colorful.cn
Accessories: 1* User’s Guider, 1* Driver CD, 1* 6-pin Power Commutator cable, 1* DVI to VGA
adaptor.
The packing

COLORFUL Technology&Development LTD. www.colorful.cn
GPU-Z reference:
GF9800GT 512M DDR3
42℃when start up

COLORFUL Technology&Development LTD. www.colorful.cn
51℃when run the 3D Bench Mark
