Colubris Networks CN3200 Service manual

CN3200
Administrator’s Guide
DRAFT
Note: Any references to CN3000 in this draft also apply to the CN3200.

: 2
First Edition (January 2004) 43-10-3200-06
Colubris is a registered trademark of Colubris Networks Inc.
Microsoft, Windows, Windows 2000, Windows NT, Windows 95, Windows 98,
Windows ME, Internet Explorer, and the Windows logo are either registered
trademarks or trademarks of Microsoft Corporation in the United States and/or
other countries.
IBM is a registered trademark of International Business Machines.
All other names mentioned herein are trademarks or registered trademarks of
their respective owners.
Changes are periodically made to the information herein; these changes will be
incorporated into new editions of the document.
Copyright © 2004 Colubris Networks Inc. All rights reserved, including those to
reproduce this document or parts thereof in any form without permission in
writing from Colubris Networks, Inc.
Colubris Networks Inc.
420 Armand-Frappier (suite 200)
Laval (Quebec) Canada H7V 4B4
Telephone: [phone]
Fax: [phone]

: 3
DRAFT
Table of Contents
Chapter 1
Introduction.......................................... 7
Introducing the CN3200..........................................................8
Scalable solution...............................................................8
Secure infrastructure ........................................................8
Enhanced user experience ................................................9
Secure remote management ...........................................10
Wireless bridging............................................................10
Multiple SSID support.....................................................12
Feature summary ..................................................................13
Wireless radio.................................................................13
Hardware ........................................................................16
Networking .....................................................................16
Network management.....................................................17
Access controller functions.............................................17
Security...........................................................................17
RF Tools..........................................................................17
Compatibility...................................................................17
Authentication and accounting........................................18
Management ...................................................................18
Interfaces........................................................................18
Operating Environment ...................................................18
Regulatory Approvals......................................................18
Package contents..................................................................19
Technical support..................................................................19
Syntax conventions...............................................................20
Chapter 2
Important concepts................................21
Networking areas ..................................................................22
Wireless cells..................................................................22
Attaching to a wired LAN ................................................24
Network operating center (NOC)...........................................25
NOC components............................................................25
Sending traffic to the NOC ..............................................26
The public access interface...................................................27
Connecting to and using the wireless network......................28
Broadcast IP address......................................................28
Allow any IP address ......................................................28
WPA/802.1x clients.........................................................28
Proxy server support ......................................................28
The RADIUS server ...............................................................29
Main tasks ......................................................................29
More information ............................................................29
Customer authentication.......................................................30
RADIUS server................................................................30
Local user list .................................................................30
MAC-based authentication ..............................................30
WPA/802.1x....................................................................30
Chapter 3
Planning your installation........................31
Multi-site installation ............................................................32
About this installation .....................................................32
Installation strategy ........................................................33
Multi-area installation ...........................................................34
About this installation .....................................................34
Installation strategy ........................................................35
Chapter 4
Installation ......................................... 37
Anatomy............................................................................... 38
Antenna connectors ....................................................... 38
Ports .............................................................................. 38
Powering the CN3200 .................................................... 39
Status lights ................................................................... 39
Radio.............................................................................. 39
Reset button................................................................... 40
Installing the CN3200........................................................... 41
Mounting the CN3200 .................................................... 41
Configuring the CN3200 ................................................. 41
Chapter 5
The management tool ............................ 43
Overview .............................................................................. 44
Management station....................................................... 44
Management scenarios .................................................. 44
Default settings .............................................................. 44
Starting the management tool .............................................. 46
Menu summary .................................................................... 47
Home.............................................................................. 47
Wireless ......................................................................... 47
Network.......................................................................... 47
Security .......................................................................... 47
Management .................................................................. 48
Status............................................................................. 48
Tools............................................................................... 48
Maintenance ................................................................... 48
Management tool security .................................................... 49
Administrator password ................................................. 49
Connection security........................................................ 49
Security settings............................................................. 50
Firmware management......................................................... 51
Manual update................................................................ 51
Scheduled install ............................................................ 51
Using cURL .................................................................... 52
Configuration management .................................................. 53
Manual management...................................................... 53
Using cURL .................................................................... 54
Chapter 6
WLAN configuration............................... 57
Setting up the wireless LAN ................................................. 58
Configuration procedure................................................. 58
Access point................................................................... 58
Radio.............................................................................. 59
Wireless port.................................................................. 60
Wireless protection ..................................................... 60
....................................................................................... 61
Dynamic keys ................................................................. 61
Addresses ............................................................................ 61
....................................................................................... 62
....................................................................................... 62
Wireless profiles................................................................... 63
Default profile................................................................. 63
Configuration considerations ......................................... 63
To create a wireless profile ............................................. 63
Access point................................................................... 63
RADIUS accounting........................................................ 64
Wireless protection ...................................................... 64
....................................................................................... 65
Configuring overlapping wireless cells ................................. 66
Performance degradation and channel separation.......... 66

: 4
DRAFT
Choosing channels..........................................................67
Distance between access points .....................................70
Conducting a site survey and finding rouge access points ...71
Conducting a site survey.................................................71
Identifying unauthorized access points...........................71
Chapter 7
Connecting to a wired LAN .......................73
Overview...............................................................................74
Addressing issues.................................................................75
Using DHCP ....................................................................75
Using static addressing...................................................75
Chapter 8
Connecting to the Internet........................77
Connecting cables.................................................................78
Configuring the Internet connection......................................79
Configuration procedure .................................................79
PPPoE client ...................................................................80
DHCP client.....................................................................81
Static addressing ............................................................82
Firewall .................................................................................83
Firewall presets...............................................................83
Firewall configuration......................................................85
Customizing the firewall..................................................85
Firewall examples............................................................85
Network address translation .................................................89
NAT overview ..................................................................89
NAT security and static mappings...................................89
One-to-one NAT ..............................................................90
NAT IPSec passthrough ..................................................91
NAT example ...................................................................91
Chapter 9
Activating the public access interface..........93
Overview...............................................................................94
Important........................................................................94
Supporting PDAs ............................................................94
Step 1: Setting up the CN3200 RADIUS client 95
Managing shared secrets ................................................95
Configuration procedure .................................................95
Profile name....................................................................96
RADIUS profile settings ..................................................96
Primary RADIUS server ..................................................97
Secondary RADIUS server..............................................97
Step 2: Setting up CN3200 authentication ............................98
Configuration procedure .................................................98
Configuration parameters ...............................................98
Step 3: Setting up customer authentication ........................100
Configuration procedure ...............................................100
Step 4: Setting up the RADIUS server.................................101
Minimum setup.............................................................101
More information ..........................................................101
Step 5: Testing the public access interface .........................102
Chapter 10
Secure remote connectivity .................... 103
Secure remote connectivity using the PPTP client ..............104
Configuration procedure ...............................................105
Connection....................................................................105
Account.........................................................................105
Network Address Translation (NAT) ..............................106
Secure remote connectivity using IPSec.............................107
Preconfigured settings..................................................107
Configuration procedure............................................... 108
General......................................................................... 108
Peer.............................................................................. 109
Authentication method ................................................. 110
Security ........................................................................ 110
Chapter 11
Centralized architecture........................ 113
Scenario #1: Centralized authentication.............................. 114
How it works ................................................................ 114
Configuration roadmap................................................. 115
Scenario #2: Wholesaling with GRE ................................... 117
How it works ................................................................ 117
Configuration roadmap................................................. 118
Scenario #3: Wholesaling with VPNs ................................. 119
How it works ............................................................... 119
Configuration roadmap................................................. 119
Scenario 4: Public/private access with VLANs.................... 122
How it works ............................................................... 122
Configuration roadmap................................................. 123
Chapter 12
Wireless bridging ............................... 125
Overview ............................................................................ 126
Scenarios ..................................................................... 126
Setting up a wireless link.................................................... 128
Wireless link status ...................................................... 128
Chapter 13
SNMP interface .................................. 129
Configuring the SNMP interface ......................................... 130
To configure SNMP options.......................................... 130
Attributes...................................................................... 130
Agent............................................................................ 131
Traps ............................................................................ 131
Security ........................................................................ 131
Standard MIBs ................................................................... 132
Management consoles ................................................. 132
MIB II support details................................................... 132
Colubris Enterprise MIB ..................................................... 134
COLUBRIS-IEEE802DOT11 MIB details.............................. 135
Chapter 14
SSL certificates.................................. 139
Overview of SSL certificates............................................... 140
SSL authentication ....................................................... 140
Eliminating certificate warning messages........................... 142
Creating an SSL certificate ................................................. 143
Certificate tools ............................................................ 143
Obtaining a registered certificate .................................. 143
Becoming a CA............................................................. 145
Creating a self-signed certificate .................................. 149
Converting a certificate to PKCS #12 format ...................... 152
Installing a new SSL certificate .......................................... 153
Manual installation ....................................................... 153
Installing certificates in a browser...................................... 154
Internet Explorer........................................................... 154
Netscape Navigator ...................................................... 157
Chapter 15
Customizing the public access interface .... 159
Overview ............................................................................ 160

: 5
DRAFT
Common configuration tasks........................................160
Site map..............................................................................161
Internal pages ...............................................................162
External pages ..............................................................164
How it works.................................................................165
Customizing the internal pages...........................................166
Creating new internal pages..........................................166
Important restrictions ...................................................166
Loading new internal pages ..........................................166
Examples ......................................................................168
Customizing the external pages ..........................................169
Creating new external pages .........................................169
Activating new external pages.......................................169
Examples ......................................................................171
Using a remote login page ..................................................173
Advantages ...................................................................173
Activating a remote login page......................................173
How it works.................................................................174
Location-aware authentication ............................................181
How it works.................................................................181
Security.........................................................................181
Roaming .......................................................................181
Configuration ................................................................181
Parameters ...................................................................182
iPass support......................................................................183
ASP functions .....................................................................184
Errors............................................................................184
RADIUS.........................................................................184
Page URLs ....................................................................185
Session status and properties.......................................185
Session quotas .............................................................188
iPass support................................................................190
Message file........................................................................192
Source code for the internal pages .....................................194
Login page ....................................................................194
Transport page ..............................................................196
Session page ................................................................197
Fail page........................................................................198
Source code for the external pages.....................................200
Welcome page ..............................................................200
Goodbye page ...............................................................201
Login Error page ...........................................................202
Remote login page ........................................................204
Chapter 16
Customizing CN3200 and customer settings 207
Overview.............................................................................208
RADIUS attributes...............................................................209
Standard RADIUS attributes .........................................209
Colubris Networks vendor-specific attributes................210
RADIUS limitations .......................................................211
Terminate-Acct-Cause values........................................212
Creating a RADIUS client entry for the CN3200 ..................213
Configuration settings...................................................213
Managing shared secrets ..............................................213
Creating a profile for the CN3200 on the RADIUS server....214
Supported standard RADIUS attributes ........................214
Colubris-AVPair attribute ..............................................216
Access lists...................................................................216
White list.......................................................................221
Custom SSL certificate .................................................222
Configuration file ..........................................................222
MAC authentication.......................................................223
Default user idle timeout ...............................................223
Default user session timeout ........................................224
Default SMTP server .................................................... 224
Creating customer profiles on the RADIUS server.............. 225
Supported RADIUS attributes....................................... 225
Colubris-AVPair attribute.............................................. 228
Colubris-Intercept attribute .......................................... 228
SMTP redirection ......................................................... 228
Access list .................................................................... 229
One-to-one NAT............................................................ 229
Quotas.......................................................................... 229
Group name ................................................................. 230
SSID............................................................................. 230
VLAN support............................................................... 231
Creating administrator profiles on the RADIUS server ....... 232
Supported RADIUS attributes....................................... 232
Chapter 17
Sample setup - Backend software ............ 233
Overview ............................................................................ 234
CAUTION ...................................................................... 234
Prerequisites ................................................................ 234
Equipment setup ................................................................ 235
Topology....................................................................... 235
About the components ................................................. 236
Step 1: Retrieve software 237
Server 1........................................................................ 237
Server 2........................................................................ 237
Step 2: Install configure software on Server 1.................... 238
Windows 2000 ............................................................. 238
Colubris backend archive ............................................. 238
Steel-Belted Radius ...................................................... 238
Apache ......................................................................... 239
Sample pages............................................................... 240
PHP 4.2.3 ..................................................................... 241
MySQL ......................................................................... 241
Configure the OBDC data source .................................. 241
phpMyAdmin................................................................ 243
Setting the path ............................................................ 243
Start mysql................................................................... 244
Test PHP....................................................................... 244
Create the sample RADIUS database............................ 244
Step 3: Configure Steel-Belted Radius on Server 1 ............ 245
Modify the default configuration files ........................... 245
Start and connect to the server .................................... 245
Define a RAS client for the CN3200.............................. 246
Create RADIUS profiles ................................................ 248
Update the Steel-Belted Radius configuration .............. 249
Step 4: Install web server certificates on Server 1.............. 250
Install the public key certificate .................................... 250
Install the private key certificate ................................... 250
Verify the certificates.................................................... 250
Step 5: Install and configure the CN3200 ........................... 253
Start Apache................................................................. 253
Assign a static address................................................. 253
Configure RADIUS settings .......................................... 254
Certificates ................................................................... 256
Step 6: Install and configure software on Server 2............. 257
Step 7: Test the installation ................................................ 258
Step 8: Test the remote login page feature ......................... 260
Enable the remote login feature.................................... 260
Test the remote login feature........................................ 261
Step 9: Test the NOC authentication feature ....................... 263
Enable NOC authentication ........................................... 263
Test NOC authentication ............................................... 264
Tools................................................................................... 266
Batch files..................................................................... 266
phpMyadmin ................................................................ 266

: 6
DRAFT
Troubleshooting ..................................................................268
Chapter 18
Sample setup - Steel-Belted Radius.......... 271
Overview.............................................................................272
Prerequisites.................................................................272
Equipment setup .................................................................273
Topology .......................................................................273
About the components..................................................273
Step 1: Install software on Server 1 274
Windows 2000..............................................................274
Steel-Belted Radius.......................................................274
Internet Explorer ...........................................................274
Step 1: Add support for Colubris Networks attributes 275
Step 2: Connect to the Steel-Belted Radius server..............276
Step 3: Create a RADIUS client profile for the CN3200 .......278
Step 4: Define RADIUS profiles...........................................280
Defining a CN3200 profile .............................................280
Defining a Customer profile ..........................................282
Defining an CN3200 administrator profile....................284
Step 5: Define user accounts ..............................................286
Defining user accounts .................................................286
Step 6: Install and configure the CN3200............................288
Assign a static address .................................................288
Configure RADIUS settings...........................................288
Step 7: Install Server 2........................................................291
Step 8: Test the installation .................................................292
Testing administrator logins..........................................293
Chapter 19
Sample setup - Microsoft RADIUS ............ 295
Overview.............................................................................296
Prerequisites.................................................................296
Equipment setup .................................................................297
Topology .......................................................................297
About the components..................................................297
Step 1: Install software on Server 1 298
Windows 2000..............................................................298
Internet Explorer ...........................................................298
Step 2: Define user accounts ..............................................299
Step 3: Define groups and add users to them.....................300
Step 4: Start the RADIUS server .........................................302
Step 5: Create a RADIUS client account..............................303
Step 6: Create an access policy for the CN3200..................305
Step 7: Create an access policy for customers ...................314
Step 8: Create an access policy for CN3200 admins...........324
Step 9: Install and configure the CN3200............................330
Assign a static address .................................................330
Configure RADIUS settings...........................................330
Step 10: Install Server 2......................................................332
Step 11: Test the installation ...............................................333
Testing administrator logins..........................................334
Chapter 20
Experimenting with NOC authentication ..... 335
Overview.............................................................................336
About the certificates ....................................................336
Requirements ...............................................................336
Equipment setup .................................................................337
Topology .......................................................................337
Step 1: Configure the CN3000 338
Step 2: Configure the RADIUS profile for the CN3200 ........339
Define the profile...........................................................339
Force authentication ..................................................... 339
Step 3: Configure Server 1 ................................................. 340
Install certificates ......................................................... 340
Verifying that winhttpcertcfg.exe is installed ................ 343
Granting access to the private key for noc-client.......... 344
Configuring the hosts file on Server 1 .......................... 345
Experimenting with noc-authenticate.vbs........................... 346
Retrieve noc-authenticate.vbs ...................................... 346
Running the program ................................................... 346
Examples...................................................................... 346
Authentication results........................................................ 348
noc.h contents ........................................................ 348
Returned values ........................................................... 349
Examples...................................................................... 351
Chapter 21
The configuration file ........................... 353
Manually editing the config file........................................... 354
Retrieving/restoring the configuration file .................... 354
Configuration file structure................................................. 355
Chapter 22
Building a cross-over cable.................... 357
Wiring details ..................................................................... 358
Chapter 23
Troubleshooting ................................. 359
CN3200 issues ................................................................... 360
Client station issues ........................................................... 361
Management issues ........................................................... 365
Chapter 24
Regulatory, wireless interoperability,
and health information ......................... 367
Regulatory information....................................................... 368
Health Information ............................................................. 370
Important ........................................................................... 371
Ports ............................................................................ 371
Installation.................................................................... 371

Chapter 1: Introduction 7
DRAFT
Chapter 1: Introduction
Chapter 1
Introduction
This chapter presents an overview of the CN3200 and illustrates how it
can be used to deploy a public access network.

Chapter 1: Introduction 8
DRAFT
Introducing the CN3200
The CN3200 simplifies the process of installing a public access network by
integrating all the key components you need into a single, easy-to-install device.
It features an access controller with robust firewall and full-featured router, and a
high-speed wireless access point.
Scalable solution To service large locations or areas with many customers, you can deploy multiple
CN3200s or use CN300 satellite stations to extend the reach of the wireless
network.
Secure
infrastructure
The CN3200 and the CN300s provide the wireless cells which customers use to
connect their mobile computers. Intelligent bridging software on the CN300s
restricts customer traffic so that it can only flow to and from the CN3200.
Generally, the CN3200 is configured to provide a ‘public’ area on the network that
is freely available to customers without logging in. However, to gain access to the
Internet (or restricted resources on the local network) customers are usually
required to login. This secures the network and enables billing to take place.
P
U
B
L
I
C
W
L
A
N
P
U
B
L
I
C
W
L
A
N
P
U
B
L
I
C
W
L
A
N
P
U
B
L
I
C
W
L
A
N
P
U
B
L
I
C
W
L
A
N
CN3200
CN300CN300CN300 CN300
P
U
B
L
I
C
W
L
A
N
CN3200
P
U
B
L
I
C
W
L
A
N
Hacker
Unauthenticated
customer
Authenticated
customer
CN300

Chapter 1: Introduction 9
DRAFT
For added security, the CN3200 is protected from malicious Internet traffic by its
integrated firewall.
Enhanced user
experience
The CN3200 makes it easy to deliver a completely customized experience for
your customers.
At login time, customers are authenticated and their location within the network is
identified. This information is forwarded to an external web server, enabling it to
generate a custom experience for each location or even every customer.
Authenticated
Customer
Unauthenticated
Customer
syn attack
telnet
Integrated
Firewall
Hacker
Network
Operating Center
RADIUS
server
Stations cannot
exchange data
Customized
Web Page Custom page
is built based
on Customer ID
and location
Customer location and login
name are forwarded to web server Web server

Chapter 1: Introduction 10
DRAFT
Secure remote
management
Integrated VPN client software (PPTP and IPSec) enables the CN3200 to
establish a secure connection with a remote network operating center. This
provides a secure encrypted tunnel for management and accounting traffic,
enabling you to establish a centralized location from which to manage one or
more CN3200s.
Wireless bridging The CN3200s wireless bridging feature enables you to use the wireless radio to
create point-to-point wireless links to other access points. This feature can be
used locally to extend the reach of a network without laying cable. For example:
Site #1 Site #2 Site #3
Secure tunnels protected
by IPSec or PPTP.
RADIUS
server
VPN
server
Management
station
Network
Operating
Center
CN3200
P
U
B
L
I
C
W
L
A
N
P
U
B
L
I
C
W
L
A
N
P
U
B
L
I
C
W
L
A
N
CN3200 CN3200
P
U
B
L
I
C
W
L
A
N
P
U
B
L
I
C
W
L
A
N
P
U
B
L
I
C
W
L
A
N
CN3200
Backbone LAN
CN300 CN300
wireless bridge

Chapter 1: Introduction 11
DRAFT
Or, it can be used to create point-to-point links over longer distances, such as
between two buildings (as illustrated below). This requires that the appropriate
external antenna be installed on each unit (not included).
P
U
B
L
I
C
W
L
A
N
CN3200
P
U
B
L
I
C
W
L
A
N
CN300
wireless bridge
P
U
B
L
I
C
W
L
A
N
CN300
P
U
B
L
I
C
W
L
A
N
CN300
antenna antenna
Building A Building B
RADIUS
server

Chapter 1: Introduction 12
DRAFT
Multiple SSID
support
The CN3200 provides support for multiple SSIDs. This permits the wireless
network to be split into multiple distinct entities, each with its own SSID and
configuration settings.
By combining multiple SSIDs and IPSec VPNs, several WISPs (wireless Internet
service providers) can effectively share wireless access points in one or more
locations.
In this scenario, the CN3200 controls access to the Internet. However, it validates
customer logins and records accounting information using the RADIUS server in
each NOC. The CN3200 knows which RADIUS server to communicate with for a
particular customer based on the SSID the customer is associated with. IPSec
VPN tunnels provide full protection for all data transfers with the NOC.
Custom login pages can be hosted by each WISP, enabling the shared access
point to provide a distinct online experience for each WISP’s customers.
P
U
B
L
I
C
W
L
A
N
SSID #1
SSID #2
IPSec VPN #2
IPSec VPN #1
WISP #1
NOC
Internet
WISP #2
NOC
IPSec VPN #1 IPSec VPN #2

Chapter 1: Introduction 13
DRAFT
Feature summary
Wireless radio The CN3200’s dual-band mini-PCI radio module is software configurable to
operate either in the 2.4GHz band (802.11b and 802.11g) or the 5GHz band
(802.11a).
Note: Customers are responsible for verifying approval and to identify the
regulatory domain that corresponds to a particular country. Not all regulatory
domains have been approved. Please consult the Colubris Networks web site
(www.colubris.com/certifications) for an up-to-date list.
802.11a
The following features apply when the radio is operating as IEEE 802.11a (5 Ghz
Unlicensed ISM radio band).
Data rates
• 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Frequency band
• North America: 5.150-5.350 GHz and 5.725 -5.825 GHz
• Europe: 5.150-5.350 GHz and 5.470-5.725 GHz and 5.725-5.825 GHz
• Japan: 5.150-5.250 GHz
Operating channels (non-overlapping)
• North America: 12
• Europe: 19
• Japan: 4
Modulation technique
Orthogonal Frequency Division Multiplexing (OFDM)
• BPSK @ 6 and 9 Mbps
• QPSK @ 12 and 18 Mbps
• 16-QAM @ 24 and 36 Mbps
• 64-QAM @ 48 and 54 Mbps
Media Access Protocol
• Carrier Sense Multiple Access with Collision Avoidance (CSMA/CA)
Receive sensitivity
• 6 Mbps: -85 dBm
• 54 Mbps: -65 dBm
Available Transmit Power Settings
• 6-24 Mbps: 17.5dBm +/- 2
• 54 Mbps: 12 dBm +/- 2
Note: Maximum power setting varies according to individual country regulations.
Standards compliance
Safety
• IEC 60950
• EN 60950

Chapter 1: Introduction 14
DRAFT
Radio Approvals
•Wi-Fi
• FCC Part 15.401-15.407
• RSS-210 (Canada)
• EN 300 440 (Europe)
• ARIB STD-T71 (Japan)
EMI and Susceptibility (Class B)
• FCC Part 15.107 and 15.109
• ICES-003 (Canada)
• VCCI (Japan)
• EN 301.489-1 and -17 (Europe)
Other
• IEEE 802.11a
• FCC Bulletin OET-65C
• RSS-102
IEEE 802.11h Support
• Dynamic Frequency Selection (DFS) and Transmit Power Control (TPC) are
supported as per the current draft of the IEEE 802.11h specification
Antenna
Two SMA (Female) connectors for use with external antenna (sold separately).
Security architecture client authentication
• SSL protected WEB-based Authentication
• 802.1X support including: PEAP, EAP-TLS, EAP-TTLS, and EAP-SIM to yield
mutual authentication
• Wi-Fi Protected Access (WPA) with AES support in HW (ready for WPA-2)·
Support for static and dynamic IEEE 802.11 WEP keys of 40 bits and 128 bits
802.11b/g
The following features apply when the radio is operating as IEEE 802.11b and
802.11g (2.4 Ghz Unlicensed ISM radio band).
Data rates
• IEEE 802.11b: 1, 2, 5.5, and 11 Mbps
• IEEE 802.11g (OFDM only): 6, 9, 12, 18, 24, 36, 48, 54Mbps
Frequency band
• North America: 2.412 to 2.462 GHz
• Europe: 2.412 to 2.472 GHz
• Japan: 2.412 to 2.484 GHz
Operating channels
• North America/China: 1
• Europe: 13
• Japan: 14
Non-overlapping operating channels
• Worldwide: 3

Chapter 1: Introduction 15
DRAFT
Modulation technique
IEEE 802.11b: Direct sequence spread spectrum (DSSS)
• DBPSK @ 1 Mbps
• DQPSK @ 2 Mbps
• CCK @ 5.5 and 11 Mbps
IEEE 802.11g: Orthogonal Frequency Division Multiplexing (OFDM)
• BPSK @ 6 and 9 Mbps
• QPSK @ 12 and 18 Mbps
• 16-QAM @ 24 and 36 Mbps
• 64-QAM @ 48 and 54 Mbps
Media Access Protocol
• Carrier Sense Multiple Access with Collision Avoidance (CSMA/CA)
Receive sensitivity
IEEE 802.11b
• 11 Mbps: -86 dBm
IEEE 802.11g:
• 6 Mbps: -85 dBm
• 54 Mbps: -65 dBm
Available Transmit Power Settings
IEEE 802.11b
• 1-11 Mbps: 18 dBm +/- 2
IEEE 802.11g:
• 6-24 Mbps: 17 dBm +/- 2
• 54 Mbps: 11.5 dBm +/- 2
Note: Maximum power setting varies according to individual country regulations.
Standards compliance
Safety
• IEC 60950
• EN 60950
Radio Approvals
•Wi-Fi
• FCC Part 15.247
• RSS-139-1, RSS-210 (Canada)
• EN 300.328 (Europe)
• TELEC 33B (Japan)
EMI and Susceptibility (Class B)
• FCC Part 15.107 and 15.109
• ICES-003 (Canada)
• VCCI (Japan)
• EN 301.489-1 and -17 (Europe)
Other
• IEEE 802.11a
• FCC Bulletin OET-65C
• RSS-102

Chapter 1: Introduction 16
DRAFT
Antenna
Two SMA (Female) connectors for use with external antenna (sold separately).
Security architecture client authentication
• SSL protected WEB-based Authentication
• 802.1x support including: PEAP, EAP-TLS, EAP-TTLS, and EAP-SIM to yield
mutual authentication
• Wi-Fi Protected Access (WPA) with AES support in HW (ready for WPA-2)·
Support for static and dynamic IEEE 802.11 WEP keys of 40 bits and 128 bits
Hardware Status LEDs
Provide status of wireless port, LAN ports, and power
Uplink ports
Two auto-sensing 802.3 10/100BASE-T Ethernet ports
Memory
• 32 Mbytes RAM
• 16 Mbytes FLASH
Input power requirements
• 90 to 240 VAC +/- 10% (power supply)
• IEEE 802.3af 48 VDC +/- 10%(device)
Power draw
8 watts
Dimensions
• Length: 165.7 mm
• Width: 162.5 mm
• Height: 48 mm
Temperature range
• Operating: 0°C to 60°C
• Storage: -40°C to 70°C
Humidity
5% to 95% typical (non-condensing)
Warranty
One year
Networking • IEEE 802.1d compliant bridging
• GRE (RFC 2784)
• DHCP Server (RFC 2131)
• DHCP Client
• DHCP Relay
• DHCP Option 82 (RFC 3046)
• PPPoE Client (RFC 2516)
• DNS Relay
• Static IP Routing
• Network Address Translation (RFC 1631)
• One-to-one NAT for VPN support

Chapter 1: Introduction 17
DRAFT
• RIP v1 (RFC 1058) and v2 (RFC 1723)
• SMTP (e-mail) redirection
• ICMP (RFC 792)
• ARP (RFC 826)
• CIDR (RFC 1519)
Network
management
• SNMP v1 and v2
• MIB-II with TRAPS
• Colubris Hot Spot MIB for user session control and downstream AP
management
• RADIUS Authentication MIB (RFC 2618)
• RIP v2 extension MIB (RFC 1724)
• Secure access (SSL and VPN) to embedded HTML Management Tool
• Scheduled configuration and firmware upgrades from central server
• Real-time status, information and protocol traces (layer 2 and 3)
Access controller
functions
• Secure HTML login page
• Support for centralized WEB Portal
• WEB-Proxy server
• Fixed-IP address spoofing
• Location-aware user authentication
• Support for 802.1x using EAP-SIM, EAP-TLS, EAP-TTLS and PEAP
• MAC-level authentication for non-HTTP or 802.1x devices
• RADIUS AAA using EAP-MD5, PAP, CHAP, MSCHAP v2
• Provides detailed accounting based on session duration and/or volume of data
• Flexible support for pre-paid subscription
• Support up to 100 concurrent users at location
Security • RADIUS Client (RFC 2865 and 2866)
• Layer-2 Wireless Isolation
• Integrated VPN client (IPSec or PPTP) for secure connection to central
RADIUS Server
• Per-user customizable firewall
RF Tools • Rogue AP detection
• Embedded Site Survey tools
Compatibility • Communicates with all Wi-Fi certified wireless adapters
• Supports all operating systems

Chapter 1: Introduction 18
DRAFT
Authentication and
accounting
• Secure HTML login page
• Support for 802.1x using EAP-MD5, EAP-TLS, EAP-TTLS, PEAP
• RADIUS AAA supporting EAP-MD5, PAP, CHAP, MSCHAP v2, MSCHAP v1
• MAC-level authentication for non-HTTP devices
• Supports up to 100 concurrent users
• Provides accounting by time used or data transferred/received by customers
• Traffic quotas
Management • Web-based management tool
• Secure local and remote management via HTTPS and VPN
• Scheduled configuration upgrades from a central server
• Remote Syslog
• Web-based firmware upgrades
• Real-time status and information protocol traces
• Site survey and monitoring tool
• SNMP V1, V2 MIB-II with traps and Colubris MIB
• RADIUS Authentication Client MIB (RFC 2618)
Interfaces • IEEE 802.11b wireless port
• 10/100BaseTX Ethernet port
• 10BaseT Ethernet port
Operating
Environment
• Temperature: 0ºC to 55ºC
• Humidity: 15% to 95% non-condensing
Regulatory
Approvals
• FCC Part 15, CSA NRTL (C22.2 No 950, UL 1950)
• CE Mark (EN55022, EN55024, IEC 60950)
• Wi-Fi Certified

Chapter 1: Introduction 19
DRAFT
Package contents
Make sure that your package contains the following items. If an item is missing,
contact your reseller.
Technical support
To obtain technical support, contact your reseller.
Information about Colubris Networks products and services, including
documentation and software updates, is available on our web site at
www.colubris.com.
CN3200 Wireless Access Controller
Power supply (optional)
Power cord (optional)
CD-ROM
Cross-over Ethernet cable (yellow)
CN3200 warranty, license, and registration cards
Contains the CN3200 Administrator’s Guide, Colubris
Backend Archive, and the Colubris Enterprise MIB.

Chapter 1: Introduction 20
DRAFT
Syntax conventions
This manual uses the following formatting conventions.
Example Description
Network When referring to the management tool
web interface, items in bold type identify
menu commands or input fields. They are
presented exactly as they appear on
screen.
Network > Ports When referring to the management tool
web interface, submenus are indicated
using the ‘>’ sign. The example refers to
the Ports submenu, which is found under
the Network menu.
ip_address Items in italics are parameters that you
must supply a value for.
use-access-list=usename Monospaced text is used to present
command line output, program listings, or
commands that are entered into
configuration files or profiles.
ssl-certificate=URL [%s] [%n] Items enclosed in square brackets are
optional. You can either include them or
not. Do not type the brackets.
