Dormakaba U300 Series User manual

0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
91 15
State
IN1
IN2
OUT
GND
AC- AC+
B A C
GND IN1 IN2
2
1Push
Click
DIN-Rail
AS
A+
OUT
Output
Ant.Function 0 - F
123456
ON
OFF
RS-485
InputProgrammerSupply
10-34VDC
12-27VAC 34VDC
Class II
Relay Output
27VACmax 5VDC
dormakaba
Remote Reader 91 15 - U300
04046493 - 11/2018
EN
Technical Manual

dormakaba Schweiz AG
Hofwisenstrasse 24
8153 Rümlang
Switzerland
T: [phone]
www.dormakaba.com
dormakaba Schweiz AG
Mühlebühlstrasse 23
8620 Wetzikon
Switzerland
T: [phone]
www.dormakaba.com
dormakaba EAD GmbH
Albertistraße 3
78056 Villingen-Schwenningen
Germany
T: [phone]
www.dormakaba.com
Company headquarters: Villingen-Schwenningen
Copyright © dormakaba 2018
All rights reserved.
No part of this document may be reproduced or used in any form or by any means without prior written permis-
sion of dormakaba Schweiz AG.
All names and logos of third-party products and services are the property of their respective owners.
Subject to technical changes.
04046493 - 11/2018

Technical Manual
304046493 - 11/2018 dormakaba Remote Reader 91 15 - U300
1 About this document 5
1.1 Validity 5
1.2 Target group 5
1.3 Contents and purpose 5
1.4 Document availability 5
1.5 Change log 6
1.6 Orientation in the document 6
1.7 Abbreviations/definition of terms 6
1.8 Warnings 6
1.8.1 Hazard categories 6
1.8.2 Symbols 7
1.9 Notes 7
2 Basic safety instructions 8
2.1 Designated use 8
2.2 Assembly and installation 8
2.3 Service and maintenance 8
2.4 Accessories and spare parts 8
2.5 ESD prevention measures 9
2.6 Environmental protection 9
3 Product description 10
3.1 Overview 10
3.2 Registration unit compatibility 11
3.3 Operating modes 11
3.4 Supported RFID standards with possible media definitions 12
3.5 Technical data 13
3.5.1 Overview of technical specifications 13
3.5.2 Dimensions 15
3.6 Conformity 16
3.7 Designation 17
4 Construction and function 18
4.1 RFID reader 18
4.2 Device construction 18
4.3 Firmware 19
4.4 System connection 20
4.5 System requirements 20
4.6 Behaviour when several media are present in the field (anti-collision)20
4.7 Functions 20
4.7.1 Functions with functional type U300 21
4.8 ‘Electric strike’ operating mode 22
5 Installation 23
5.1 Installation requirements 23
5.1.1 General 23
5.1.2 Installation location 23
5.1.3 Connections 23
5.2 Installation diagram (example) 24
5.3 Installation lines 25
5.3.1 Power supply cable 25
5.3.2 Line to door opener and door contacts 25
5.3.3 Coaxial cable to the registration units 25
5.3.4 Grounding concept 25

Technical Manual
4 04046493 - 11/2018
dormakaba Remote Reader 91 15 -
U300
5.4 Device fixing 26
5.5 Connections 27
5.5.1 Connections 27
5.6 Inputs IN1–IN2 28
5.7 Output 29
5.7.1 Note on using door openers 29
5.8 Configuration 30
5.8.1 Notes on configuration 30
5.8.2 Setting the switches 30
6 Putting into operation 32
6.1 32
6.2 Issuing read/write authorisation (launch) 32
6.3 Withdrawing read/write authorization 33
6.3.1 Withdrawing all write access issued via a write authorization 33
6.3.2 Withdrawing individual write access issued via a write author-
isation 33
7 Maintenance 34
7.1 Programming interface 34
7.2 Restart 34
7.3 INI reset/Reset the device to the basic state 35
7.3.1 INI reset with DIP switch 6 35
7.3.2 INI reset with the programming master 36
7.4 Question - FW Update U300 37
7.5 Firmware update 37
7.6 Updating configuration with the programmer 1364 37
7.7 Crossgrade 38
7.7.1 Device with Bxxx firmware (MRD) 38
8 Troubleshooting 39
9 Disposal / dismantling 40
9.1 Decommissioning 40
9.2 Dismantling 40
9.3 Disposal 40
10 Packaging/return 41
10.1 Complete devices 41
10.2 Electronic component assemblies 41
10.3 Labelling 41

About this documentTechnical Manual
504046493 - 11/2018 dormakaba Remote Reader 91 15 - U300
1 About this document
1.1 Validity
This document describes the product:
Product designation: dormakaba Remotleser 91 15 MRD
dormakaba Remote Reader 91 15 MRD
dormakaba Remotleser 91 15 LEGIC
dormakaba Remote Reader 91 15 LEGIC
Functional type: U300 (evolo V3)
Terminal software version: BRRA31.xx…
This document describes all product variants and all optional accessories and functions. Op-
tions are subject to a charge and are thus only available if they have been purchased. Addi-
tional accessories and functions may not be available on the date of publishing and may only
be available for purchase at a later point in time.
1.2 Target group
This quick start guide is intended for skilled persons only.
The descriptions are intended for skilled persons trained by the manufacturer. The descrip-
tions are no replacement for product training.
For reasons of equipment safety, the installation, maintenance and service measures de-
scribed in this documentation should only be carried out by skilled persons in accordance with
EN 62368-1 (Audio/Video, Information and Communication Technology Equipment – Part 1:
Safety Requirements).
Skilled person is the designation for people who have the appropriate technical training and
experience in setting up the equipment. Skilled persons are expected to use their training and
experience to identify any risks to themselves and others that may arise while carrying out
these activities, and to minimise these risks as far as possible. It is the skilled person’s re-
sponsibility to ensure that the conditions stated by the manufacturer and the applicable regu-
lations and standards are complied with when carrying out these actions.
This documentation is also used to provide information for persons with the following tasks:
• Project planning and project implementation
• Commissioning the product within the network
• Connecting the product to user software by programming customer applications
• Customer-specific adjustments with product parametrisation
1.3 Contents and purpose
Contents are limited to the assembly, installation, commissioning and basic operation of the
product.
1.4 Document availability
Additional documentation is available on the dormakaba website. Technical manuals and ref-
erence manuals can be found in a protected area (extranet). It is possible to access these via
the user account of trained specialists. But a temporary account can also be created.
https://www.dormakaba.com/extranet-emea-en/login

About this document Technical Manual
6 04046493 - 11/2018
dormakaba Remote Reader 91 15 -
U300
1.5 Change log
Version number Edition Brief description
TM_RemoteReader-9115-U300 05/2017 • MRD Hardware
• First edition
1.6 Orientation in the document
This document contains the following features to help find specific topics:
• The table of contents at the beginning of the document offers an overview of all topics.
• The header contains the associated main section.
• Cross references indicate the number of the section containing additional information.
Example [ 5.7].
• An index in alphabetical order is given at the end of the document.
1.7 Abbreviations/definition of terms
Abbreviation/term Description
Remote reader • Remote reader 91 15 U300
Device • Remote reader 91 15 U300
Registration unit • Registration unit 9000
• Registration unit 9001
• Registration unit 90 03
• Registration unit 90 04
System • System software (e.g. KEM)
KMM • Kaba Media Manager
1.8 Warnings
Warnings containing information/instructions and prohibitions designed to prevent personal
injury or damage are specially marked.
Please pay attention to warnings! They are intended to help avoid accidents and prevent in-
jury and damage.
1.8.1 Hazard categories
Warnings are divided into the following categories:
CAUTION
Low risk
Indicates a possibly dangerous situation which may lead to minor physical injury.
NOTICE
Important information on the correct use of the product.
Failure to comply with these instructions could lead to malfunctions. It is possible to damage
the product.

About this documentTechnical Manual
704046493 - 11/2018 dormakaba Remote Reader 91 15 - U300
1.8.2 Symbols
Symbols with the following meaning are used for warnings, depending on the source of
danger.
General hazard Danger of damage to electronic
components from electrostatic dis-
charge
1.9 Notes
Notes are indicated by an info symbol.
Tips and useful information.
These help you make the best use of the product and its functions.

Basic safety instructions Technical Manual
8 04046493 - 11/2018
dormakaba Remote Reader 91 15 -
U300
2 Basic safety instructions
This product has been built to state-of-the-art standards and in line with established safety
regulations. However, hazards for persons and property may arise when handling the product.
Read and observe the following safety instructions before using the product.
2.1 Designated use
This product is intended for use as specified and explained in the Product description section
only. Any other use is considered non-designated use. The manufacturer is not liable for any
damage or injury due to non-designated use. The user/facility operator is the sole person to
bear risks for non-designated use.
2.2 Assembly and installation
Check the device for visible damage caused by transport or wrong storage. Do not start up
any damaged device!
Assembly and installation of the product may only be done by skilled personnel (see chapter 1
Target group).
When installing/inserting the product in end-use equipment all requirements of the men-
tioned test standards must be fulfilled.
The product should only be installed in locations which fulfil the environmental and technical
conditions specified by the manufacturer.
The manufacturer is not liable for damage arising due to improper handling or incorrect in-
stallation.
2.3 Service and maintenance
Conversions and modifications to the product may only be done skilled personnel (see chapter
1 Target group). Any conversions and modifications performed by other persons will exempt
us from any liability.
The elimination of faults and maintenance work may only be performed by skilled personnel
(see chapter 1 Target group).
2.4 Accessories and spare parts
Accessories and spare parts must meet the manufacturer's technical requirements. This is
guaranteed if original dormakaba accessories and spare parts are used.

Basic safety instructionsTechnical Manual
904046493 - 11/2018 dormakaba Remote Reader 91 15 - U300
2.5 ESD prevention measures
NOTICE
Risk for electronic components due to electrostatic discharge.
Incorrect handling of electronic PCBs or components can result in damage which will cause a
complete breakdown or sporadic errors.
• General ESD prevention measures must be observed when installing or repairing the
product.
• Wear an anti-static wrist strap when handling electronic components. Connect the end of
the strap to a discharge box or a non-painted, earthed metal component. This way, static
discharges are channelled away from your body safely and effectively.
• Handle a PCB along its edges only. Do not touch the PCB or connectors.
• Place dismantled components on an anti-static surface or in an anti-static shielded con-
tainer.
• Avoid contact between PCBs and clothing. The wrist strap protects PCBs against an elec-
trostatic discharge voltage from the body only. However, damage can also be caused by
an electrostatic discharge voltage from clothing.
• Transport and ship dismantled modules in conductive anti-static bags only.
2.6 Environmental protection
It is prohibited to dispose of the device in your domestic waste.
Used devices contain valuable materials that should be recycled. Properly dispose of used
devices.

Product description Technical Manual
10 04046493 - 11/2018
dormakaba Remote Reader 91 15 -
U300
3 Product description
3.1 Overview
The Remote reader 91 15 U300 functional type U300 is used to manage access control at ac-
cess points.
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
91 15
State
IN1
IN2
OUT
GND
AC- AC+
B A C
GND IN1 IN2
2
1Push
Click
DIN-Rail
AS
A+
OUT
Output
Ant.Function 0 - F
123456
ON
OFF
RS-485
InputProgrammerSupply
10-34VDC
12-27VAC 34VDC
Class II
Relay Output
27VACmax 5VDC
Separation of the remote reader and the registration unit makes it possible to install the re-
mote reader in a tamper-proof room and install the registration unit in a non-tamper-proof
area.
The remote reader can be integrated into various dormakaba system solutions.
The remote reader is installed on a DIN rail.
The door components (lock elements) are directly connected to the remote reader. This is
used to control the registration units’ electric strike and optical and acoustic signal transmit-
ters.
Maximum number of registration units: 1
1 2 3
4 5 6
7 8 9
1 0 E
ENTER
21 ABC 3
DEF
5
JKL
4
GHI 6 MNO
8
0
TUV
7
PQRS 9 WXYZ
ENTER
21 ABC 3
DEF
5
JKL
4
GHI 6 MNO
8
0
TUV
7
PQRS 9 WXYZ
94 20
91 08
1460
c-lever
compact
KEM
91 04
Wireless
Ethernet
CardLink
c-lever
Extender
Wireless
gateway
90 40 90 41
91 10
c-lever
compact c-lever
Wireless (only with E3xx)
CardLink
c-lever
USB
Digital
cylinder
Digital
cylinder
Communication
with service medium
or programmer
Coaxial cable
Local access
point
management
Kaba evolo
Manager (KEM)
System
Communication
means between
KEM and Actuators
MC
cylinder
Management System
Kaba evolo Manager (KEM)
91 15
90 0390 00 90 01 90 04
90 43
MC
cylinder

Product descriptionTechnical Manual
1104046493 - 11/2018 dormakaba Remote Reader 91 15 - U300
3.2 Registration unit compatibility
The following registration units are supported:
Registration unit 9000
Registration unit 90 01
Registration unit 90 03
Registration unit 9004
3.3 Operating modes
The door configuration determines the device operating mode. A detailed description of door
configurations and their corresponding operating modes can be found in the chapter 'Electric
strike' operating mode.

Product description Technical Manual
12 04046493 - 11/2018
dormakaba Remote Reader 91 15 -
U300
3.4 Supported RFID standards with possible media definitions
The following table indicates the RFID standards and media definitions supported by the
device.
Media definitions Supported RFID technologies
LEGICprime
LEGICRF
Safe UID ✔
Card ID -
Kaba Group Header ✔
Kaba advant ID -
LEGIC access™ (advant) -
LEGIC access™ pool (prime) -
CardLink 1.0 ✔

Product descriptionTechnical Manual
1304046493 - 11/2018 dormakaba Remote Reader 91 15 - U300
3.5 Technical data
3.5.1 Overview of technical specifications
Mechanics
Assembly • Installation location: see Installation location Installation
location
• On DIN rail in accordance with EN 60715
Housing • ABS black, with connection diagram printed on
Flammability rating • HB (UL94)
Dimensions • See below
Connections • All connections are screw/plug terminals
• Max. relay load: 2A
Power supply
Input voltage • 12–27 V AC (50/60 Hz) or
10–34 V DC
• Power consumption/heat capacity: max. 5W
Clock • Without a power supply the clock will run for at least
120hours (after a minimum of 10 minutes of operation)
Only power supply units that fulfil the following requirements may be used for power supply:
LPS (Limited Power Source) and SELV (Safety Extra Low Voltage) in accordance with IEC/
EN/UL/CSA 60950-1 or ES1 and PS2 in accordance with IEC/EN/UL/CSA 62368-1.
Interfaces
HF RFID • 1 registration unit
• Coaxial cable, impedance 50 ohms
• Encrypted data transfer
• See also Supported RFID standards with possible media
definitions Supported RFID standards with possible me-
dia definitions
Programmer interface • For firmware update or programmer connection
Inputs and outputs
1 binary input • With internal power supply and common ground for con-
nection of insulated switches
• Maximum 5VDC
• LED status display

Product description Technical Manual
14 04046493 - 11/2018
dormakaba Remote Reader 91 15 -
U300
Inputs and outputs
1 relay output • Changeover contact: max. 30 V DC/AC, max. power sup-
ply 2A
• Switching cycles at 30VDC/1A
Typ. 500,000 (VdS 2358 requirement is 200,000)
• Switching cycles at 30VDC/2A
Typ. 100,000
• LED status display
Only power supply units that fulfil the following requirements may be used for power supply
of the relay inputs: LPS (Limited Power Source) and SELV (Safety Extra Low Voltage) in ac-
cordance with IEC/EN/UL/CSA 60950-1 or ES1 and PS2 in accordance with IEC/EN/UL/CSA
62368-1.
Ambient conditions • Operating temperature: -0°C to +50°C
• Storage temperature: -20°C to +65°C
• Relative humidity: 0% to 85%, non-condensing
• Protection type in accordance with IEC 60529: IP20

Product descriptionTechnical Manual
1504046493 - 11/2018 dormakaba Remote Reader 91 15 - U300
3.5.2 Dimensions
Dimensions in millimetres.
AS
AC+
AC-
Supply Output
Input
RS-485 Ant.
A+
AB
C
IN1
IN2
DIN-Rail
2
1Push
Click
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
70
87 106
45

Product description Technical Manual
16 04046493 - 11/2018
dormakaba Remote Reader 91 15 -
U300
3.6 Conformity
This product complies with the standards
EN 62368-1:2014-08
EN 301489-1 V2.1.1
EN 301489-3 V2.1.1 (Final Draft)
EN 300330 V2.1.1
EN 50364:2010
EN 60529:2014-09
according to the provisions of the EU directive
2014/53/EU - Radio Equipment Directive (RED)
RoHS This device complies with the regulations specified in Directive 2011/65/EU of the European
Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazard-
ous substances in electrical and electronic equipment.
You can download the original declaration of conformity in PDF format at www.dor-
makaba.com/conformity.
In addition, the product also complies with the following standards
UL62368-1:2014-12
CAN/CSA-22.2 No. 62368-1:2014-12
You can download the original declaration of conformity in PDF format at www.dor-
makaba.com/conformity.
Tested Standard:
FCC Code of Federal Regulations, CFR 47, Part 15, Sections 15.205, 15.207, 15.215 and 15.225
FCC ID NVI-KRR9115-K5
FCC § 15.19
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
FCC § 15.21 (Warning Statement)
[Any] changes or modifications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
FCC § 15.105
Note: This equipment has been tested and found to comply with the limits for a Class A di-
gital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reas-
onable protection against harmful interference when the equipment is operated in a commer-
cial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the inter-
ference at his own expense.
Tested Standard:
Industry Canada Radio Standards Specifications RSS-GEN Issue 4, Sections 8.8, 8.9 and 8.10
and RSS-210 Issue 8, Section A2.6 (Category I Equipment)
IC:11038A-KRR9115K5
ICES-003
This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de
la classe A est conforme à la norme NMB-003 du Canada.

Product descriptionTechnical Manual
1704046493 - 11/2018 dormakaba Remote Reader 91 15 - U300
Canada RSS-GEN 8.4
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions: (1) This device may not cause interference; and (2) This device must
accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) l’appareil ne
doit pas produire de brouillage; 2) l’utilisateur de l’appareil doit accepter tout brouillage radi-
oélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
3.7 Designation
The rating plate is located on the side of the device.
The nameplate contains the following information:
• Device designation
• Article number
• Serial number
• Functional type
• Connection data (supply voltage)
• CE mark
• WEEE mark in accordance with German industrial standard EN 50419

Construction and function Technical Manual
18 04046493 - 11/2018
dormakaba Remote Reader 91 15 -
U300
4 Construction and function
4.1 RFID reader
The device is only available as a version of LEGIC.
4.2 Device construction
0
1
2
3
4
5
6
7
8
9
A
B
C
91 15
State
IN1
IN2
OUT
GND
AC-
AC+
B A C
GND IN1 IN2
2
1Push
Click
DIN-Rail
AS
A+
OUT
Output
Ant.Function 0 - F
123456
ON
OFF
RS-485
InputProgrammerSupply
10-34VDC
12-27VAC 34VDC
Class II
Relay Output
27VACmax 5VDC
1 2 3 4
5
6
7
8910
1 not used
2 DIP switch
3 Rotary switch
4 Registration unit connection
5 LED indicators
6 not used
7 Relay output OUT
8 Inputs IN1–IN2 (IN2 not in use)
9 Interface for Programmer
10 Power supply

Construction and functionTechnical Manual
1904046493 - 11/2018 dormakaba Remote Reader 91 15 - U300
4.3 Firmware
The hardware of this product is used in various dormakaba system solutions. The functions
and possible uses of the product are determined by the firmware used.
This handbook solely applies to the Remote reader with the firmware for functional type
U300.
Firmware designation
Reader type MMIFARE
ALEGIC
NNone
BMRD (Multi RFID Device)
LEGIC or MIFARE
(determined on commissioning)
Device type RC Compact reader
RP Compact reader 91 12
RR Remote reader 91 15
RE Remote reader 91 25
AM Access manager
Function type AE3xx or N300/T300/U300 V3
BAccess manager
CSubterminal
EAMC/II (cDML)
Version number xx.xx Version
Add-on 1 RFinal and approved version
Add-on 2 ASubversion
Add-on 3 _Reserved
Example
Firmware designation for remote reader 91 15 functional type U300:
• BRRA31.xx... (MRD)
Designation of the firmware on the product
Compact readers with firmware of the functional type U300 V3 bear the designation ‘Type:
U300’ on the nameplate.

Construction and function Technical Manual
20 04046493 - 11/2018
dormakaba Remote Reader 91 15 -
U300
4.4 System connection
User n
Master
User 1
91 15
State
IN1
IN2
OUT
GND
AC- AC+
B A C
GND IN1 IN2
2
1Push
Click
DIN-Rail
AS
A+
OUT
Output
Ant.Function 0 - F
123456
ON
OFF
RS-485
InputProgrammerSupply
10-34VDC
12-27VAC 34VDC
Class II
Relay Output
27VACmax 5VDC
1
2
3
ENTER
21
ABC
3
DEF
5
JKL
4
GHI
6
MNO
8
0
TUV
7
PQRS
9
WXYZ
The Remote reader (2) can be programmed in the following ways:
• With programmer 1364 (1) (authorisation list or CardLink)
• With master and user media
It is not possible to program time functions and perform traceback read-outs (event
memory) with this type of programming.
Remote reader functions
• Authorisation check
• Relay control (e.g. for electric strikes)
• The Functions [}4.7] chapter provides information on additional functions
Registration unit functions
• Reading the media presented (RFID)
• Optical and acoustic signalling
4.5 System requirements
Standalone mode
System software
KEM KEM 3.0 and above
Kabaexos Kaba exos 2.3 and above
4.6 Behaviour when several media are present in the field (anti-
collision)
The device (Remote reader 91 15 U300) can simultaneously recognize several LEGIC advant
user media (ISO 14443 A) within its detection field. Only the first user medium that corres-
ponds to the search criteria defined in the system is taken into account. All other user media
are ignored.
4.7 Functions
Depending on the configuration, the following functions are supported.
• Authorisation check using badges and time-dependent authorisation
• Control of the Registration unit (signal transmitter, optical and acoustic)
• Control of the electric strike (doors with electric locking components)
