Com-mw ZLPF1-M0-6G-029 User manual

Product features
High reliability, wide temperature range,
high cost performance and gold wire
bonding or manual soldering.
Other parameters
Port SMD
Work Temp. - 40 ~ + 70 ℃
Power
handling
15 W
Installation diagram
Typical data
F(GHz) S11(S) S21(L) S22(S)
0.01 1.01 -0.01 1.01
3.04 1.03 -0.20 1.05
5.06 1.26 -0.49 1.22
5.70 1.30 -0.89 1.28
5.90 1.35 -1.14 1.37
6.00 1.31 -1.40 1.40
6.10 1.54 -2.05 1.70
6.20 2.70 -3.91 2.94
6.30 5.48 -7.65 5.82
6.50 14.64 -21.32 15.29
6.90 27.30 -32.84 27.11
7.20 30.30 -35.45 27.53
7.60 33.37 -41.20 27.44
8.09 40.06 -46.56 34.45
10.00 91.65 -47.36 38.83
13.14 84.01 -51.75 44.93
15.16 357.72 -54.50 123.28
17.18 114.92 -58.87 75.94
20.70 160.88 -42.11 26.54
Main specifications
Items Technical specifications Units
Passband frequency 0-6000 MHz
BandpassLossDC-F2（Typical value.）0-6000MHz≤1.3 dB
VSWRDC-F2（Typical value.）0-6000MHz≤1.35
Stopband rejectionF4-F6（Typical value.）6900-20000MHz≥35 dB
Configuration
Typical Performance Curves
1
1.2
1.4
1.6
1.8
2
2.2
2.4
2.6
2.8
3
0 3 6 9 12 15 18 21 24 27 30
VSWR(Input)
Frequency(GHz)
1
1.2
1.4
1.6
1.8
2
2.2
2.4
2.6
2.8
3
0 3 6 9 12 15 18 21 24 27 30
VSWR(Output)
Frequency(GHz)
-5
-4
-3
-2
-1
0
1
2
3
4
5
0 3 6 9 12 15 18 21 24 27 30
IL(dB)
Frequency(GHz)
-80
-70
-60
-50
-40
-30
-20
-10
0
10
20
0 3 6 9 12 15 18 21 24 27 30
Rejection(dB)
Frequency(GHz)
Installation Notes
The installation is fixed with two M1.6 screws. It is recommended to apply conductive
adhesive on the bottom. The curve on the right side is the typical value measured without
applying conductive adhesive. The maximum storage temperature is + 125 °. Please
contact us for use beyond the limit. The loss of the product includes the loss of the test
fixture, which is about 0.4dB. Do not immerse in the cleaning solution for cleaning.
Filter ZLPF1-M0-6G-029
