CombGeneratorsmodelCGO‐520 Page1of11 

(949)459‐9600 www.com‐power.com Rev.0216






INSTRUCTIONMANUAL
Forthe
CombGenerators
CGOSeries
ModelsCGO‐520
20MHzstep








CombGeneratorsmodelCGO‐520 Page2of11 

(949)459‐9600 www.com‐power.com Rev.0216


Table of Contents

Productspecifications…………………………………………………………3
Importantprecautionsandmaintenance...………………………………….4
Warrantyinformation…………………………………………………………5
ProductDescription……………………………………………………………6
Controls&Indicators…………………………………………………………..7
Theory………………….………………………………………………………..8
Application…………….………………………………………………………...9
Typicalradiatedoutput......................................................................................11














CombGeneratorsmodelCGO‐520 Page3of11 

(949)459‐9600 www.com‐power.com Rev.0216


Introduction

ThismanualprovidesonhowmaintainandusetheCombGenerator.

InformationcontainedinthismanualisthepropertyofCom‐PowerCorporation.Itisissuedwiththe
understandingthatnoneofthematerialmaybereproducedofcopiedwithoutpermissionfromCom‐Power.

ProductSpecifications

Frequencystepsize: 20MHz
Numberofantennasincluded:   Two
Antenna1Freq.range/height: 20–580MHz/(12inches/30.4cm)
Antenna2Freq.range/height: 580to4500MHz/(2inches/5cm)
OutputVariation: <±1dB(attheantennainput)*
UsableFrequencyradiated:   20MHz‐4.5GHz
InternalBatteryType: 6VRechargeableNimH
Batterychargeradapterspecifications: 
‐Input:  115/230VAC,60/50Hz

 ‐Output:  6VDC@500mA(unregulated)
  ‐Plugtype:  2.5IDx5.5ODmm(centerpinpositive)
Outputconnectortype: SMA(f)
OperatingtemperatureRange: 5°Cto40°C
Weight: 2lb.(max.) 
Circularbasedimensions(WxH):  7x0.75inches/17.7x1.9cm
Weight(lb/kg):2lb/0.9kg

*ThisisconductedoutputvariationwithCombGeneratorconnecteddirectlytoEMIreceiverorspectrumanalyzer.

OtherCombGeneratormodelsavailablefromCom‐Power
• CGO‐501CombGenerator,1MHzstep
• CGO‐505CombGenerator,5MHzstep
• CGO‐5100BCombGenerator,100MHzstep
• CGO‐51000CombGenerator,1GHzstep
• CGC‐510EConductedCombGenerator,100/500KHzstep
• CGC‐255EConductedCombGenerator,50/250kHzstep

CombGeneratorsmodelCGO‐520 Page4of11 

(949)459‐9600 www.com‐power.com Rev.0216


Important precautions and Maintenance

Precautions:

ACombGeneratorisanintentionalradiatordesignedtoproducessignalsoverwidefrequencyrange.Itwas
designedforuseinEMItestlaboratorytoverifyoperationofEMIemissionstestequipment.Theseradiated
signalsmaycauseunwantedradiofrequencyinterferencetootherequipmentoperatinginthevicinity.Ifyou
detectanyinterferenceincreasetheseparationbetweenCombGeneratorandtheotherequipment.

Maintenance:

Therearenouserserviceablepartsinsidetheunit.UsermodificationstotheCombGeneratorwillvoidwarranty.
TheCombGeneratorusesre‐chargeableNimHbatteries.Callthefactoryifthebatteryneedsreplacement.Send
CombGeneratortoauthorizedCom‐Powerservicecenterifneedsrepair.Pleasevisitourwebsiteatwww.com‐
power.comtorequestareturnmerchandiseauthorizationnumber(RMA)beforeyousendtheunitinforservice.
Batterycareandinstructions
Toavoidanyriskofexplosion
• Replacebatterieswiththesizeandtypespecifiedinthismanual.
• Donotdisposeofbatteriesinafireortrashincinerator,orleavebatteriesunderdirectsunlight.
• Donotimmersebatteriesinwaterorotherwisegetthemwet.
• Donotchargebatteries,thatappeartobeleaking,discolored,rusty,deformed;emitanodor
• UseonlybatterychargeradaptersuppliedwiththeCombGeneratortochargethebatteries.

EnvironmentalConditions
ThisequipmentisdesignedforindoorandoutdooruseandissafeunderthefollowingenvironmentalConditions:
• Temperature:5°Cto40°C
• Maximumrelativehumidity:80%


CombGeneratorsmodelCGO‐520 Page5of11 

(949)459‐9600 www.com‐power.com Rev.0216


Warranty

Com‐PowerwarrantstoitsCustomersthattheproductsitmanufactureswillbefreefromdefectsinmaterialsand
workmanshipforaperiodof3years.Thiswarrantyshallnotapplyto:

a)Transportdamagesduringshipmentfromyourplant.
b)Damagesduetopoorpackaging.
c)Productoperatedoutsidetheirspecification.
d)Improperlymaintainedormodified.
e)Consumableitems,fuses,powercords,cables,etc.
f)Normalwear
g)Calibration
h)ProductisshippedoutsidetheUnitedStateswithoutthepriorknowlegeofCom‐Power.

Inaddition,Com‐Powershallnotbeobligedtoprovideserviceunderthiswarrantytorepairdamageresultingfrom
attemptstoinstall,repair,serviceormodifytheinstrumentbypersonnelotherthanCom‐Powerservice
representative.

UndernocircumstancesdoesCom‐Powerrecognizeorassumeliabilityforanyloss,damageorexpensearising,
eitherdirectlyorindirectlyfromtheuseorhandlingofthisproduct,oranyinabilitytousethisproductseperately
orincombinationwithotherequipment.

Whenrequestingwarrantyservices,itisrecommendedthattheoriginalpackagingmaterialbeusedforshipping.
Damageduetoimproperpackagingwillvoidwarranty.

Inthecaseofacomplaint,alabelshouldbeattachedtothehousingoftheinstrumentwhichdescribesbrieflythe
faultsobserved.Ifatthesametimethenameandtelephonenumber(dialingcodeandtelephoneordirectnumber
ordepartmentdesignation)isstatedforpossiblequeries,thishelpstowardsspeedinguptheprocessingof
warantyclaims.Inordertoobtainserviceunderthiswarranty,CustomersmustcontacttheCom‐Power.



CombGeneratorsmodelCGO‐520 Page6of11 

(949)459‐9600 www.com‐power.com Rev.0216


Product Description

Overview

TheCGOseriesCombGeneratorsarereferencesignalsources.TheyweredesignedforEMClaboratoriesuse.Itis
idealforquicklydetectingmalfunctioningequipmentintheradiatedemissionstestsetupinbetweenfull
calibrationintervals.Thesemalfunctionsmaygoundetected,unlessittheyarecheckedoften.Fullsitecalibration
althoughmoreaccurateistimeconsumingisnotpracticalforaquicktest.BycomparingCombGeneratordata
takenatregularly,theEMIlabcanensurethatallthetestequipmentandaccessoriesareoperatingwithinthe
expectedrange.Ifanyabnormalityisdetected,itcanbequicklyinvestigatedandrectifiedbeforeitcauses
measurementerrors.

TheCombGeneratorscanalsousedforcomparingtwoormoresiteswithsimilarsetup.Theycanalsobeutilized
asconductedsignalsourcefortestingLineImpedanceStabilizationNetwork(LISN),filtersandcables.

ItemsincludedwithCombGenerators

Equipment,accessories,anddocumentssuppliedwithCGO‐520CombGeneratorsareasfollows:
o User'sguide
o Customwoodenstoragebox
o BatteryChargeradapter
o Twoantennas
o Testdata(optionalreferencedataatextracost)



CombGeneratorsmodelCGO‐520 Page7of11 

(949)459‐9600 www.com‐power.com Rev.0216


Controls and indicators


PoweronSwitch

ThisislocatedonthesideoftheCombGenerator.Itnotonlypowersunitonoroff,italsoenablesordisablesthe
signaloutput.

Outputconnector

ThecombgeneratoroutputisavailableattheSMA(f)connectorlocatedonthetopoftheunit.Thisoutputcanbe
usedforradiatedorconductedemissionstesting.Forradiatedmeasurements,themonopoleantennaisattached
tothisconnector.TherearetwoantennaswithSMAmaleconnectorsprovidedtocovertheCombGenerator
radiatedfrequencyrange.Pleaserefertopage3todeterminetheapproximatefrequencyrangeofeachantenna.
Theantennacanbedisconnectedforconductedemissionsmeasurements.DonotconnecttheCombGenerator
conductedoutputtoaLineImpedanceStabilizationNetwork(LISN)thatisconnectedtoACpower.Wealsodo
notrecommendconnectingtheCombGeneratorconductedoutputdirectlytoapreamplifierinput.

PowerOnindicator

ThegreenpoweronLEDislit,theCombGeneratorispoweredonandoutputisavailableformeasurement.

BatteryLowindicator

WhenredbatteryLowLEDislit,theinternalbatteryneedsrecharging.Theoutputmaynotbereliable.Turnoff
CombGeneratorandchargethebatterywiththesuppliedadapter.Theapproximatetimetofullychargethe
batteryis8hours.TheCombGeneratorcanoperateapproximately18hourswhenfullycharged.Pleasenote
however,thattheoperatingtimegiveninthismanualisapproximateanddependsontheconditionofbattery,
storageperiodandthenumbertimesithasbeenchargedanddischarged.Iftheoperatingtimekeepsdecreasing,
youmayneedtoreplacethebattery.




CombGeneratorsmodelCGO‐520 Page8of11 

(949)459‐9600 www.com‐power.com Rev.0216


Theory


TheCombGeneratorusesanimpulsetogenerateitsstepfrequencyoutput.Itusesastablepowersupplyand
signalshapingcircuittoobtainrelativelystablesignaloutputwithfrequencycomponentsextendingbeyond1GHz.

TheCombGeneratoroperatesonbatterypower.Thebatteryoutputiscontrolledbyavoltagetheregulatorcircuit
toprovidestablepoweroutputtothesignalgeneratingcircuit.Thesignalgeneratingcircuitconsistsofaclock
generator,impulsegenerator,waveshapingcircuitandoutputmatching.Thesignalfrequencyisgeneratedbya
crystaloscillator.

Animpulseintimedomaincorrespondstoaflatoutputacrosstheentirefrequencyspectruminfrequency
domain.Anidealimpulse,bydefinitionisaninfinitemagnitudepulsewithzeroriseandfalltimewithzero
duration.Suchapulseisnotpractical;however,theModelCGO‐520CombGeneratorsusethisprincipletogetan
outputacrossawideband.Thehighlystablefrequencyoutputfromtheoscillatorisusedtogenerateanimpulse
withveryshortdurationandsharpriseandfalltimes.Theshapingcircuitwasdesignedforimprovedstability,
extendedfrequencyresponse,andoutputimpedancematchingto50ohms.

Theradiatedreferencesignalistransmittedbytheantennasaffixedontopoftheunit.Anelectricallyshort
monopoleantennaisanantennathatisshortcomparedtothewavelengthofthefrequencyitradiates.Suchan
antennageneratesaradiatedfieldproportionaltoitslength.Theradiatedfield,therefore,compensatesfor
decreasingsignaluptoafrequency,wheretheantennacannotbecalledelectricallyshort.Thistheorydescribes
thegeneralbehaviorofthefield,buteachCombGeneratormaybehaveslightlydifferentthantheotherdueto
circuitvariation.SincetheCombGeneratorsweredesignedtoprovideareferencereadingatagivenfrequency,
thislimitationisnotaproblem.



CombGeneratorsmodelCGO‐520 Page9of11 

(949)459‐9600 www.com‐power.com Rev.0216


Application


RadiatedEmissions
EMItestsitessuchasOpenAreaTestSite(OATS)orAnechoicchambersareconstructedwithspecific
requirementsandarecalibratedinaprecisemannertooptimizethereliabilityoftheemissionsmeasurements.
Thetimeandexpenseincurredisconsideredessentialtoincreasetherepeatabilityofthedata.

Thedatatakenontheabovesitesaregenerallyreliable.However,insomeinstances,discrepanciesdooccur,and
thereliabilityofdataisquestionable.Suchdiscrepanciescouldbediscoveredwheneither(a)datafromtwosites
forthesameequipmentdonotmatch,or(b)thedatafromtwodifferentoccasionsforthesameequipmentatthe
sameOATSarenotconsistent.Itisimportanttofindthecauseforsuchinconsistency.Thisisgenerallyaverytime
consuminganddifficultprocessbecausethereasoncouldbeoneoffourcomplexfactors.

(1)Equipmentundertest(EUT),
(2)TheTestSite
(3)Instrumentation
(4)Testpersonnel.

Eachofthesefactorsmayhavemanypossiblecauses.TheEUT,forexample,mayhavechangeddueto
componentvariation,temperature,operatingmode,wearandtear,designetc.Thetestsitemaybeacausedueto
areflectiveobjectnearthesite,variationofgroundsaturationorambientsignalpresence.Italsocouldbedueto
malfunctioningtestinstrumentation.

Byestablishingsimplemeasurementproceduresimilartotheonedescribedbelowthetestlabcanreduce
occurrenceoftheseproblems.Therebyincreasingthereliabilityofmeasurementstakenonthesite.The
proceduredescribedisjustaguideandcanvariedaccordingtoyourneeds.

MeasurementProcedure

Asmentionedbefore,takingmeasurementmorefrequentlyisimportant.Createalogwithfrequencyandlevels
thatyouwouldliketorecord.Thiscanbedaily,weeklyormonthlylog.WerecommendtakingCombGenerator
measurementbeforetostartingaradiatedemissionstest.SetuptheCombGeneratorwiththeappropriate
antenna(seefrequencyrangeonpage3).PuttheCombGeneratorwheretheequipmentundertest(EUT)is
normallyplacedduringthetest.

MakeameasurementlikeyouwouldonaEUT.Werecommendusingdiscretefrequencypointsratherthanawide
frequencysweep.Suchas30MHz,40MHz,100Hz,900MHz,etc.Recordthelevelforeachfrequency.


CombGeneratorsmodelCGO‐520 Page10of11 

(949)459‐9600 www.com‐power.com Rev.0216


Comparetheselevelswithallsubsequentmeasurementstomakesurethatthepatterndoesnothaveabrupt
changefromtheestablisheddailylogatanyfrequency.Themorehigherthenumberoffrequencypointsthe
highertheaccuracyofthereferencemeasurements.
Thislogisusedtodetectanytestequipmentortestsiterelatedproblemasdescribedbelow.

ProblemsRelatedtoTestEquipment

VariationonthelogoftheCombGeneratoroutputdataisdependentonthetestequipmentaswellassite.The
CombGeneratorreplacestheEUT.TheCombGeneratornotonlygeneratestheoutputsimultaneouslyatallthe
harmonics,butitminimizesanyvariationofitsoutput.Thisisachievedbyutilizingastabilizedsignalcircuitaswell
asgeometryoftheradiator.Thecircuitstabilityismaximizedbydesign,whereasthegeometryoftheradiated
sourceisoptimizedbyeliminatingallcablesduringtheRadiatedEmissionMode.ThetypicalvariationofComb
Generatoroutputatanyfrequencyislessthan±1dB.

WiththevariationsduetotheEUTpracticallyeliminated,onlyvariationsremainingareduetootherfactors,
mainlythetestinstrumentationandthesite.Thevariationduetotestinstrumentationislimitedtothesumtotal
ofthetoleranceonalltestequipmentused(spectrumanalyzer,antenna,preamplifier,cables).Afewdaysofdata
willestablishtherangeofvariationtobeexpectedatasite.Thisisgenerallylessthan±3dB.Anyvariationinthe
readingsabovenormalvariationindicatesapotentialproblem.

Afterthedailylogisestablishedforafewdays,anyproblemiseasilydetectedasalargervariation.Thisprocedure
allowsimmediatedetectionofamajorproblemwiththetestequipment.

ProblemsRelatedtosite

Theaboveprocedurecannotdistinguishtheproblemsrelatedtothetestsite.TheCombGeneratorcanbeusedin
twowaystodetectanyproblemwithatestsite.Onemethodistostartthedailylogimmediatelyafterthetestsite
iscalibrated.Thisway,oneiscertainaboutthevalidityofthedatatakenonthetestsite.Thesecondmethodisto
calibratetheCombGeneratorradiatedoutputasabsoluteemissionlevel.Suchcalibrationisprovidedasanoption
withtheCombGenerators.

Inaddition,whendifficultyariseswithanyEUTdatatakenattwodifferentsites,theCombGeneratorcanbeused
todetermineifbothsitesgivereliableresults,justbycomparingthedataatthetwositeswiththeComb
Generator.Inthiscase,ifthetwositesdonotproducecomparableresults,aCombGeneratorwithcalibrateddata
iscertainlyrequiredtodeterminethefaultysite.

ProblemsRelatedtoTestPersonnel

TheCombGeneratorcannotdirectlyhelptoeliminatethetestpersonnelrelatedproblems.However,by
increasingtheconfidencelevelandestablishingdefiniteproceduresforeliminatingsiteandequipmentrelated
problemsithelpstremendouslytoreducetheproblemsrelatedtoEMImeasurements.

CombGeneratorsmodelCGO‐520 Page11of11 

(949)459‐9600 www.com‐power.com Rev.0216


Typical radiated output


TheseareCombGeneratorradiatedoutputat3meterdistancewiththereceivingantennaheightvariedfrom1to
4meterstakeninanopenareatestsite.



Figure1:20MHzstepsize




