COMAC CI C40 EM THERMIC User manual

CI C40 EM
THERMIC
cod. UM 10125222 AA
EN
High pressure washer
Translation of the original instructions
IT
Idropulitrice alta pressione
Istruzioni originali
DE
Hochdruckreiniger
Übersetzung der Originalanleitung
ES
Hidrolimpiadora de alta presión
Traducción de las instrucciones originales
FR
Nettoyeur haute pression
Traduction des instructions originales
PT
Lavadora a alta pressão
Tradução das instruções originais

EN
Read these instructions carefully before use. Keep these instructions for future reference. In case of problems or difficulties, contact the
consumer helpline: [e-mail] Page: 7-16
IT
Leggere attentamente queste istruzioni prima dell’uso. Conservare queste istruzioni per future consultazioni. In caso di problemi o
difficoltà, contattate l’helpline consumatori: [email protected] Pagina: 17-26
DE
Lesen Sie diese Bedienungsanleitung vor Gebrauch aufmerksam durch. Bewahren Sie diese Anleitung sorgfältig auf, damit
Sie sie auch später zu Rate ziehen können. Wenden Sie sich im Falle von Problemen bitte an die Verbraucher-Hotline:
[email protected] Seite: 27-37
ES
Leer atentamente estas instrucciones antes de usar el equipo. Guardar estas instrucciones para poder consultarlas en el futuro.
En caso de problemas o dificultades, ponerse en contacto con el servicio de asistencia al cliente:
[email protected] Página: 38-48
FR
Lire attentivement ces instructions avant emploi. Conserver ces instructions pour toute consultation à venir. En cas de problèmes ou
de difficultés, contacter l'assistance consommateur : [email protected] Page : 49-59
PT
Leia atentamente estas instruções antes de utilizar a máquina. Conserve estas instruções para consultas futuras. Em caso de
problemas ou dificuldades, contacte a helpline de atendimento aos consumidores: [email protected] Página: 60-70

3
1
E
B5
E1
E2
B1
A1-A2-A3-A4
A5
C1
B7
B9 C4
D1
B10
C3
G
B6
I D
B4
C14
B12
H
C11
B13 B11
B3
B8
C2

4
2
7
8
Ø13
B10
B10
B7
C3
C4
1
2
3
5
6
4
B6
B4
B6
C11
C3
B3
CAUTION
ADD OIL
B1
B5
C2
B4

5
3
4
D1
G
B9
I
D
ID
I
D
I
E
B4
B5
1 2
4 3
E
B5
E
B10
B3

6
5
1
2
B10
C1 EB8 C1 C2
B3
B1

EN
7
English
1
SAFETY INSTRUCTIONS
1.1 The appliance you have purchased is a technologically advanced product designed by
one of the leading European manufacturers of high pressure washers. To obtain the
best performance from your unit, read this booklet carefully and follow the instructions
each time you use it. During connection, use and servicing of the appliance, take
all possible precautions to protect your own safety and that of the people in the
immediate vicinity. Read the safety regulations carefully and comply with them on all
occasions; failure to do so may put health and safety at risk or cause expensive damage.
2
SAFETY SIGNS
2.1 Comply with the instructions provided by the safety signs and symbols fitted to the
appliance and in this manual.
The appliance and manual only feature the symbols relevant to the model purchased.
Check that the symbols and signs affixed to the appliance are always present and
legible; otherwise, fit replacements in the original positions.
Warning - Caution - Hazard
Please read these instructions carefully before use.
E2 symbol - Indicates that the appliance is intended for professional use, i.e. for
experienced people familiar with the relative technical, regulatory and legislative
factors and capable of performing the operations involved in using and maintaining
the appliance. This appliance is not intended for use by children, persons with impaired
physical, sensory or mental capabilities, or persons without the necessary experience
and knowledge.
Moving parts. Do not touch.
Risk of burns! Beware of hot components.
Risk of poisoning! Do not breathe in the exhaust fumes.
0Switch “OFF” position
ISwitch “ON” position

EN
8
English
Guaranteed sound power level
Prohibition sign, informs users that local regulations may prohibit connection of
the product to the drinking water supply system.
Danger sign, warns users not to direct the water jet at people, animals,
electrical equipment or the product itself.
The product complies with the relevant European directives.
E1 symbol - Indicates that the appliance must not be disposed of as municipal
waste; it may be handed in to the dealer on purchase of a new appliance.
The appliance’s electrical and electronic parts must not be reused for improper uses
since they contain substances which constitute health hazards.
Wear ear defenders.
Wear a protective mask.
Wear respiratory protection.
Wear protective gloves.
Wear safety footwear.
Wear protective clothing.

EN
9
English
3
SAFETY RULES/RESIDUAL RISKS
3.1 SAFETY “DO NOTS”
3.1.1
Warning.
DO NOT allow children to use the appliance; supervise them to ensure
that they do not play with it.
3.1.2
Warning.
High pressure jets may be dangerous if incorrectly used.
3.1.3
Warning.
DO NOT use the appliance with flammable or toxic liquids, or any
products which are not compatible with its correct operation. Use of the
appliance in a potentially inflammable or explosive atmosphere is forbidden.
3.1.4
Warning.
RISK OF EXPLOSION. DO NOT use the appliance to spray flammable
liquids.
3.1.5
Warning.
DO NOT point the water jet at people or animals.
3.1.6
Warning.
DO NOT point the water jet at the unit itself, electrical parts or other
electrical equipment.
3.1.7
Warning.
DO NOT use the appliance with people within its range of action unless
they are wearing protective clothing.
3.1.8
Warning.
DO NOT point the jet at yourself or others to clean clothing or footwear.
3.1.9
Warning.
DO NOT use the appliance outdoors when it is raining.
3.1.10
Warning.
DO NOT allow children, incompetent persons or those who have not
read and understood the instructions to use the appliance.
3.1.11
Warning.
DO NOT jam the trigger in the operating position.
3.1.12
Warning.
Check that the data plate is affixed to the appliance; if not, inform your
dealer. Appliances without plates must NOT be used as they are unidentifiable
and potentially dangerous.
3.1.13
Warning.
DO NOT tamper with or adjust the setting of the safety valve or the
safety devices.
3.1.14
Warning.
DO NOT alter the original diameter of the spray head nozzle.
3.1.15
Warning.
DO NOT allow vehicles to drive over the high pressure hose.
3.1.16
Warning.
DO NOT move the appliance by pulling on the high pressure hose.
3.1.17
Warning.
When directed towards tyres, tyre valves or other pressurised
components, the high pressure jet is potentially dangerous. Do not use the
rotating nozzle kit, and always keep the jet at a distance of at least 30 cm during
cleaning.

EN
10
English
3.1.18
Warning.
The use of non-original accessories and any other spare parts not
specifically intended for the model in question is prohibited. All modifications to
the appliance are prohibited; any modifications shall render the Declaration of
Conformity null and void and relieve the manufacturer of all liability under civil
and criminal law.
3.1.19
Warning.
Do not bend over the exhaust or touch it. (Risk of burns).
3.1.20
Warning.
Do not touch hot mufflers, cylinders or radiator ribs. (Risk of burns).
3.2 SAFETY “MUSTS”
3.2.1
Warning.
All electrical conductors MUST BE PROTECTED against the water jet.
3.2.2
Warning.
High pressure may cause parts to rebound: wear all the protective
clothing (PPE) and equipment needed to ensure the operator’s safety.
3.2.3
Warning.
Risk of injury if the machine is left running in an unattended state.
Remove the spark plug connector prior to performing any work on the device.
3.2.4
Warning.
Before pressing the trigger, GRIP the gun firmly to counteract the recoil.
3.2.5
Warning.
COMPLY WITH the local water supply authority regulations.
Under IEC 60335-2-79, the appliance may only be connected to the mains
drinking water supply if the supply hose is fitted with a backflow preventer valve
with drain facility corresponding to EN 12729 type BA. The backflow preventer
can be ordered from the manufacturer.
3.2.6
Warning.
Water that has passed through backflow preventers is considered to
be non-potable.
3.2.7
Warning.
Maintenance and/or repair of electrical components MUST be carried
out by qualified staff.
3.2.8
Warning.
DISCHARGE residual pressure before disconnecting the hose from the
appliance.
3.2.9
Warning.
CHECK before each use and at regular intervals that the screws are fully
tightened and that there are no broken or worn parts.
3.2.10
Warning.
ONLY USE detergents which will not corrode the coating materials of
the high pressure hose / electric cable.
3.2.11
Warning.
ENSURE that all people or animals keep a minimum distance of 16 yd.
(15m) away.

EN
11
English
3.2.12
Warning.
This appliance is designed for use with the detergent supplied or
recommended by the manufacturer. The use of other detergents or chemicals
may adversely affect the appliance’s safety.
3.2.13
Warning.
Do not allow the detergent to come into contact with the skin, and the
eyes in particular! In case of contact with eyes, rinse with plenty of water and
seek medical advice at once!
3.2.14
Warning.
High pressure hoses, fittings and joints are important for the appliance’s
safety. Use only hoses, fittings and joints recommended by the manufacturer.
3.2.15
Warning.
To ensure the appliance’s safety, only use the manufacturer’s genuine
parts, or other parts which carry its approval.
3.2.16
Warning.
Insert the pipe jet kit down to the red mark before turning the
appliance on.
3.2.17
Warning.
Only use the fuels specified in the Operations Manual. Risk of explosion
due to the use of inappropriate fuels.
In petrol engine appliances, ensure that no petrol comes in contact with hot
surfaces.
3.2.18
Warning.
Pleasefollow the specialsafetyinstructions intheOperatingInstructions
Manual for petrol engine devices.
3.2.19
Warning.
Ensure that there is adequate ventilation or provision for diverting the
exhaust gas while operating the appliance in closed rooms (risk of poisoning).
Do not close the exhaust.
Please ensure that there are no exhaust emissions near the air inlets.
3.2.20
Warning.
The engine is to be brought to a standstill and the appliance is to be
fastened properly during transportation.

EN
12
English
4
GENERAL INFORMATION FIG.1/PAGE 3
4.1 Use of the manual
The manual forms an integral part of the appliance and should be
kept for future reference. Please read it carefully before installing/
using the unit. If the appliance is sold, the seller must pass on this
manual to the new owner along with the appliance.
4.2 Delivery
The appliance is delivered partially assembled in a cardboard box.
The supply package is illustrated in fig.1.
4.2.1 Documentation supplied with the appliance
A1 Use and maintenance manual
A2 Safety instructions
A3 Declaration of conformity
A4 Warranty regulations
A5 Engine use and maintenance manual
4.3 Disposing of packaging
The packaging materials are not environmental pollutants but must
still be recycled or disposed of in compliance with the relevant
legislation in the country of use.
5
TECHNICAL INFORMATION FIG.1/PAGE 3
5.1 Envisaged use
This appliance has been designed for individual use for the cleaning
of vehicles, machines, boats, masonry, etc., to remove stubborn dirt
using clean water and biodegradable chemical detergents.
Vehicle engines may be washed only if the dirty water is disposed of
as per regulations in force.
- Intake water temperature: see data plate on the appliance.
- Intake water pressure: min. 0.1 MPa - max. 1 MPa.
- Operating ambient temperature: above 0°C.
The appliance is compliant with the IEC 60335-1 and IEC 60335-2-79
standards.
5.2 Operator
The symbol illustrated in fig. 1 identifies the appliance’s intended
operator (professional or non-professional).
5.3 Main components
B1 - Internal combustion engine
B3 - Pump
B4 - Gun with safety catch
B5 - Lance
B6 - High pressure hose
B7 - Oil cap
B8 - Water nozzle
B9 - Detergent tank
B10 - Hose tail with filter
B11 - Fuel tank plug
B12 - Spark plug
B13 - Fuel tank
E - Nozzle
H - Starter device
I - Water jet control lever
5.3.1 Accessories (if included in the supply package – see fig.1)
C1 Nozzle cleaning tool
C2 Rotating nozzle kit
C3 Handle
C4 Screws
C11 Brackets
C14 Wheels
5.4 Safety devices
Warning - danger!
Do not tamper with or adjust the safety valve setting.
- Safety valve and/or pressure limiting valve.
The safety valve is also a pressure limiting valve. When the gun
trigger is released, the valve opens and the water recirculates
through the pump inlet or is discharged onto the ground.
- Thermostat valve (D1) If the water temperature exceeds the tem-
perature set by the manufacturer, the thermostat valve discharges
the hot water and draws in an amount of cold water equal to the
amount of water discharged, until the correct temperature is
restored.
- Safety catch (D): prevents accidental spraying of water.
6
INSTALLATION FIG.2/PAGE 4
6.1 Assembly
Warning - danger!
Remove the spark plug connector (B12) prior to per-
forming any work on the device.
The assembly sequence is illustrated in fig.2.
6.2 Fitting the pressure release caps
To prevent oil leaks, the appliance is delivered with the oil intakes
sealed with red caps which must be replaced with the pressure
release caps supplied.
6.3 Fitting the rotating nozzle
(For models with this feature).
The rotating nozzle kit delivers greater washing power.
Use of the rotating nozzle may cause a reduction in pressure of
25% compared to the pressure obtained with the adjustable nozzle.
However, the rotating nozzle kit delivers greater washing power due
to the rotation of the water jet.
6.4 Motor
Warning - danger!
Follow the instructions given in the section "Safety Notes"!
6.4.1 Read the operating instructions of the engine manufac-
turer before start-up and follow the safety instructions
carefully.
Check oil level of the engine. Do not operate the appliance
if the oil level has fallen below "MIN". If required, top up
oil carefully.
Fill the fuel tank (B13) with unleaded petrol. Do not use
2-speed mixture.
6.5 Water supply connection
Warning - danger!
Only clean or filtered water should be supplied to
the appliance.The flow rate of the water inlet tap should be
equal to the pump flow rate.
Place the appliance as close to the water supply system as possible.
6.5.1 Connection points
l Water outlet (OUTLET)
n Water inlet with filter (INLET)
6.5.2 Connection to the mains water supply
The appliance may only be connected directly to the
mains drinking water supply if the supply hose is fitted
with a backflow preventer valve as per current regulations
in force. Make sure that the hose is at least Ø 13 mm, that
it is reinforced and that it is not more than 25 m long.
6.5.3 Suction of water from open containers
1) Screw the inlet hose with filter to the water INLET and
insert it down to the bottom of the container.
2) Vent the air from the appliance:
a) Unscrew the lance.
b) Start the appliance and keep the gun open until there
are no air bubbles in the water flowing out.
3) Switch the appliance off and screw the lance back on.
N.B.: the maximum suction height is 0.5 m. The suction
hose should be filled before use.

EN
13
English
7
ADJUSTMENTS FIG.3/PAGE 5
7.1 Adjusting the spray nozzle
Water flow is adjusted by regulating the nozzle (E).
7.2 Adjusting the detergent
To deliver detergent at the correct pressure, set the nozzle (E) on " "
as shown.
7.3 Adjusting the working pressure
The regulator (G) is used to adjust the working pressure.
8
INFORMATION ON USE OF THE APPLIANCE FIG.4/PAGE 5
8.1 Controls
- Starter device (H).
Start the engine according to the operating instructions of the
engine manufacturer.
- Water jet control lever (I).
Warning - danger!
During operation the appliance must be positioned as
shown in fig. 4 on a firm, stable surface.
8.2 Start-up (see fig. 4)
1) Fill the fuel tank (B13).
2) Turn on the water supply tap fully.
3) Release the safety catch (D).
4) Depress the gun trigger for a few seconds and start the engine
according to the operating instructions of the engine manufacturer.
Warning - danger!
Before starting up the appliance check that it is
receiving water correctly; use of the appliance without water
will damage it. Do not cover the ventilation grilles when the
appliance is in use.
To prevent damage to the appliance, do not allow it to
operate dry and check that it is properly supplied with water.
8.3 Stopping
1) Press the regulator lever at the engine to "STOP" till the engine
comes to a halt and turn off the fuel tap.
2) Depress the gun trigger and discharge the residual pressure
inside the pipes.
3) Engage the safety catch (D).
8.4 Restarting
1) Release the safety catch (D).
2) Depress the gun trigger and discharge the residual air inside
the pipes.
3) Start the engine according to the operating instructions of the
engine manufacturer.
8.5 Storage
1) Turn off the water supply tap.
2) Discharge the residual pressure from the gun until all the water
has come out of the appliance.
3) Press the regulator lever at the engine to "STOP" till the engine
comes to a halt and turn off the fuel tap.
4) Remove the spark plug connector.
5) Drain and wash out the detergent tank at the end of the working ses-
sion. To wash out the tank, use clean water instead of the detergent.
6) Engage the gun safety catch (D).
8.6 Refilling and using detergent
The detergent must be delivered using the accessories and by
the procedures described in point 7.3.
Use of a high pressure hose longer than the one originally supplied
with the appliance, or the use of an additional hose extension, may
reduce or completely halt the suction of detergent.
Fill the tank (B9) with highly biodegradable detergent.
8.7 Recommended cleaning procedure
Dissolve dirt by applying the detergent mixed with water to the
surface while still dry.
When dealing with vertical surfaces work from the bottom upwards.
Leave the detergent to act for 1-2 minute but do not allow the
surface to dry. Starting from the bottom, use the high pressure jet
at a minimum distance of 30 cm. Do not allow the rinse water to run
onto unwashed surfaces.
In some cases, scrubbing with brushes is needed to remove dirt.
High pressure is not always the best solution for good cleaning
results, since it may damage some surfaces. The finest adjustable
nozzle jet setting or the rotating nozzle should not be used on
delicate or painted parts, or on pressurised components (e.g. tyres,
inflation valves, etc..).
Effective cleaning depends on both the pressure and volume of the
water used, to the same degree.
9
MAINTENANCE FIG.5/PAGE 6
Any maintenance operations not covered by this chapter should be
carried out by an Authorised Sales and Service Centre.
Warning - danger!
Risk of injury if the machine is left running in an
unattended state. Remove the spark plug connector prior
to performing any work on the device.
Risk of burns! Do not touch hot mufflers, cylinders or
radiator ribs.
9.1 Inspect the power cable, high pressure hose, fittings, trig-
ger gun and lance at each use.
9.2 Cleaning the nozzle
1) Disconnect the lance from the nozzle.
2) Remove any dirt deposits from the nozzle hole using the tool (C1).
9.3 Cleaning the filter
Inspect the inlet filter (L) and detergent filter (if fitted) before each
use, and clean in accordance with the instructions if necessary.
9.4 Oil level
Check the pump oil level and add oil through the intake hole to
restore the correct level.
Refer to the “Technical data” table for the oil characteristics.
9.5 End-of-season storage
Treat the appliance with non-corrosive, non-toxic antifreeze before
storing it away for winter.
Put the appliance in a dry place, protected from frost.
9.6 Engine mantenance
See the original instructions of the engine manufacturer.
10
EXTRAORDINARY MAINTENANCE
Warning - danger!
Extraordinary maintenance must be performed by
an authorised sales and service centre.
10.1 Check the hydraulic circuit, inspect the fixtures and mountings
for damage every 200 working hours.
10.2 Replace the oil, nozzles and filters every 500 working hours.
10.3 Check the safety devices every 500 working hours.
11
STORAGE AND TRANSPORTATION FIG. 5/PAGE 6
Store the accessories as shown in fig. 5.
Transport the machine as shown in fig. 5.

EN
14
English
12
TROUBLESHOOTING
Problem Possible causes Remedy
Pump does not reach working
pressure
Nozzle worn Replace nozzle
Water filter fouled Clean filter (L) (fig.5)
Insufficient water supply Turn on water supply tap fully
Air being sucked into system Check tightness of hose fittings
Air in pump
Switch off the appliance and keep depressing and releas-
ing the gun trigger until the water comes out in a steady
flow. Switch the appliance back on again.
Adjustable nozzle not positioned correctly Set nozzle (E) on (+) setting (fig.3)
Thermostatic valve tripped
Wait for correct water temperature to be restored
Water being sucked from an open container from a
height of more than 0.5 m.
Reduce the suction height.
Pump pressure drops during
suddenly use
Water being sucked from an external tank Connect appliance to the mains water supply
Inlet water too hot Reduce temperature
Nozzle clogged Clean nozzle (fig.5)
Inlet filter (L) fouled Clean filter (L) (fig.5)
Water leakages Seals worn Have the seals replaced at your nearest Authorised
Service Centre
Safety valve tripped and discharging Contact an Authorised Service Centre
Appliance noisy Water too hot Reduce temperature (see technical data)
Oil leakages Seals worn Contact your nearest Authorised Service Centre
No detergent sucked in
Adjustable nozzle on high pressure setting Set nozzle (E) on " " setting (fig.3)
Detergent too dense Dilute with water
High pressure hose extension being used Fit original hose
Deposits or restriction in detergent circuit Flush with clean water and eliminate any restrictions. If the
problem persists, contact an Authorised Service Centre
Water escapes from thermo-
stat valve
Water temperature inside pump head has
exceeded max. rated value stated on nameplate
With appliance in operation, do not stop the water
jet for more than 5 minutes at a time
MODEL SERIAL NUMBER

EN
15
English
12
HOW TO AVOID DAMAGING SURFACES
WARNING
12.1 Using the appliance to wash tyres may damage the tyre and can be dangerous.
12.2 Never point the high pressure jet straight at the tyre.
12.3 Always use the appliance at the lowest pressure setting when cleaning in the vicinity of wheels and tyres.
12.4 Never use the“Turbo Lance” for washing any part of the vehicle.
12.5 For further information refer to section: “8.7 Recommended cleaning procedure”.
EC Declaration of Conformity
We, COMAC S.p.A, declare that the following Machine(s):
Designation of machine High pressure washer
Model No. CI C40 EM THERMIC
Rated power 8,2 kW
conform(s) to the following European Directives: 2006/42/EC, 2011/65/EU, 2012/19/EU, 2014/30/EU and 2000/14/EC (Italian Legislative Decree 262/2002)
and are (is) manufactured in accordance with the following standards or standardised documents: EN 60335-1; EN 60335-2-79; EN ISO 12100; EN ISO 14982,
IS0 3744.
Name and address of the person appointed to issue the technical file:
Giancarlo Ruffo / Via Maestri del Lavoro, 13 - 37059 Santa Maria di Zevio (VR), Italy
The conformity assessment procedure required by Directive 2000/14/EC has been performed in accordance with Annex V
Model No. CI C40 EM THERMIC
Measured sound power level: 100,1 dB (A)
Guaranteed sound power level: 103 dB (A)
Date: 22.12.2022
Santa Maria di Zevio - VR (I)
Giancarlo Ruffo
WARRANTY
The validity of the warranty is in accordance with the relevant legislation in the country where the product is sold (unless otherwise stated by the producer).
The warranty covers materials, construction and conformity defects during the warranty period, during which time the manufacturer will replace defective
parts and repair the product if not excessively worn, or replace it.
The warranty does not cover components subject to normal wear and tear (valve, piston, water gasket, oil gasket, springs, O-rings, accessories such as the
hose, gun, brushes, wheels, etc.);
The warranty does not cover defects caused by or arising from:
- improper use, misuse, negligence,
- hire or professional use if the product has been sold for domestic use,
- failure to comply with the maintenance instructions provided in this manual,
- repair by unauthorised sta or centres,
- use of non-genuine parts or accessories,
- damage caused by transport, by dirt or foreign bodies, accidents,
- storage or warehousing problems.
Proof of purchase must be submitted to obtain warranty cover.
For assistance, contact the point of sale where your appliance was purchased

EN
16
English
Technical Data
T echnical Data Unit CI C40 EM THERMIC
Flow rate l/min 13,8
Maximum ow rate l/min 16
Pressure MPa 23
Maximum pressure MPa 28
Maximum inlet temperature °C 60
Maximum inlet pressure MPa 1
Gun repulsive force at maximum pressure N 47,40
Pump oil type kg
0,154 SAE 15W40
Motor type -
G390F
Maximum power at 3600 giri/1’ kW/HP 8,2/11
Operating speed 1/min 3400±200
Fuel tank l
6,5
Fuel
-
Petrol, unleaded
Sound pressure level LPA (IS0 3744)(K = 2,5 dB(A)) dB (A)
88,6
Sound power level LWA (IS0 3744)(K = 2,5 dB(A)) dB (A)
103
Appliance vibration (K = 1 m/s
2
): m/s
2
<2,5
Weight kg
58,4
Subject to technical modification!

17
Italiano
IT
1
ISTRUZIONI PER LA SICUREZZA
1.1
La macchina da Voi acquistata è un prodotto ad alto contenuto tecnologico realizzato da una delle
più esperte ditte europee di idropulitrici ad alta pressione. Per ottenere il meglio delle prestazioni,
abbiamo compilato queste righe da leggere attentamente e osservare a ogni utilizzo. In fase di
allacciamento, uso e manutenzione della macchina adottare tutte le precauzioni possibili per
salvaguardare la propria incolumità e quella delle persone nelle immediate vicinanze. Leggere
attentamente e rispettare le prescrizioni di sicurezza poiché se trascurate possono mettere a
rischio la salute e la sicurezza delle persone o provocare danni economici.
2
SEGNALAZIONI DI INFORMAZIONE
2.1 Rispettare le segnalazioni dettate dalle targhe e dai simboli applicati sulla macchina e su
queste istruzioni Sono presenti sulla macchina e sul libretto solo i simboli opportuni per la
macchina acquistata. Verificare che simboli e targhe applicati sulla macchina siano sempre
integri e leggibili; in caso contrario, sostituirli applicandoli nella posizione originale.
Attenzione - Pericolo
Leggere attentamente queste istruzioni prima dell’uso.
Icona E2 - Indica che la macchina è destinata all’uso professionale, cioè alle persone che
hanno esperienza, conoscenza tecnica, normativa, legislativa e in grado di svolgere le attività
necessarie all’uso e alla manutenzione della macchina. La presente macchina non è destinata
all’uso da parte di persone (compresi i bambini) con capacità fisiche, sensoriali o mentali
ridotte, o mancanza di esperienza e conoscenze.
Organi in movimento. Non toccare.
Pericolo di ustioni! Attenzione: Componenti calde!
Pericolo di avvelenamento! Non inalare i gas di scarico.
0Posizione interruttore spento
IPosizione interruttore acceso

18
Italiano
IT
Livello di potenza sonora garantito
Divieto, segnala all’utilizzatore che le normative nazionali possono proibire il colle-
gamento del prodotto alla rete di distribuzione dell’acqua potabile.
Segnale di pericolo, segnala all’utilizzatore di non indirizzare il getto d’acqua
verso persone, animali, equipaggiamenti elettrici o verso il prodotto stesso.
Questo prodotto è conforme con le direttive Europee applicabili in materia.
Icona E1 - Indica l’obbligo di non smaltire la macchina come rifiuto urbano; può
essere riconsegnata al distributore all’atto dell’acquisto di una macchina nuova. Le parti
elettriche ed elettroniche costituenti la macchina non devono essere riutilizzate per usi
impropri per la presenza di sostanze dannose alla salute.
Utilizzare cuffie di protezione.
Utilizzare maschera di protezione.
Utilizzare dispositivi di protezione dell’apparato respiratorio.
Utilizzare guanti protettivi.
Utilizzare scarpe antiinfortunistiche.
Utilizzare abbigliamento di protezione.

19
Italiano
IT
3
PRESCRIZIONI DI SICUREZZA/RISCHI RESIDUI
3.1 AVVERTENZE: NON FARE
3.1.1
attenzione.
NON permettere l’uso della macchina ai bambini, ma sorvegliarli per
accertarsi che non giochino con essa.
3.1.2
attenzione.
I getti a pressione possono essere pericolosi se utilizzati in modo
improprio.
3.1.3
attenzione.
NON utilizzare la macchina con fluidi infiammabili, tossici o aventi
caratteristiche non compatibili con il corretto funzionamento della macchina
stessa. È vietato utilizzare la macchina in atmosfera potenzialmente infiammabile
od esplosiva.
3.1.4
attenzione.
PERICOLO DI ESPLOSIONE. NON irrorare liquidi infiammabili.
3.1.5
attenzione.
NON dirigere il getto dell’acqua contro persone o animali.
3.1.6
attenzione.
NON dirigere il getto dell’acqua contro la macchina stessa, parti
elettriche o verso altre apparecchiature elettriche.
3.1.7
attenzione.
NON impiegare la macchina entro il raggio in cui si trovano persone
che non indossano abbigliamento di protezione.
3.1.8
attenzione.
NON dirigere il getto contro la propria persona o altri per pulire abiti
o calzature.
3.1.9
attenzione.
NON utilizzare la macchina all’aperto in caso di pioggia.
3.1.10
attenzione.
La macchina NON può essere azionata da bambini, da incapaci e da
coloro che non abbiano letto e compreso le istruzioni.
3.1.11
attenzione.
NON bloccare la leva della pistola in posizione di funzionamento.
3.1.12
attenzione.
Controllare che la macchina sia provvista della targhetta
caratteristiche, se sprovvista avvertire il rivenditore. Le macchine sprovviste
di targhetta NON devono essere usate, essendo anonime e potenzialmente
pericolose.
3.1.13
attenzione.
NON manomettere o variare la taratura della valvola di regolazione
e dei dispositivi di sicurezza.
3.1.14
attenzione.
NON variare il diametro originale del getto della testina.
3.1.15
attenzione.
Evitare il transito di veicoli sul tubo alta pressione.
3.1.16
attenzione.
NON spostare la macchina tirando il tubo alta pressione.

20
Italiano
IT
3.1.17
attenzione.
Il getto alta pressione su pneumatici, valvole di pneumatici e altri
componenti in pressione è potenzialmente pericoloso. Evitare l'utilizzo del kit
ugello rotante e comunque mantenere una distanza del getto di almeno 30 cm
durante la pulizia.
3.1.18
attenzione.
È vietato utilizzare accessori non originali e non specifici per il model-
lo. È vietato eseguire modifiche alla macchina; l’esecuzione di modifiche fa deca-
dere la Dichiarazione di Conformità ed esonera il costruttore da responsabilità
civili e penali.
3.1.19
attenzione.
Non piegarsi sopra il foro di uscita del gas di scarico né toccarlo.
(Pericolo di ustioni).
3.1.20
attenzione.
Non toccare il sistema di scarico, cilindri o alette di raffreddamento
quando sono caldi.(Pericolo di ustioni).
3.2 AVVERTENZE: DA FARE
3.2.1
attenzione.
Tutte le parti conduttrici di corrente DEVONO ESSERE PROTETTE
contro il getto dell’acqua.
3.2.2
attenzione.
L’alta pressione può causare il rimbalzo di parti, usare tutti quegli
indumenti e protezioni (PPE) che consentano la messa in sicurezza e l’incolumità
dell’operatore.
3.2.3
attenzione.
Prima di eseguire lavori sull'apparecchio, estrarre la spina delle
candele. Pericolo di lesioni causato dall'avviamento accidentale dell'apparecchio.
3.2.4
attenzione.
A causa del rinculo, IMPUGNARE saldamente la pistola quando si tira
la leva.
3.2.5
attenzione.
RISPETTARE le prescrizioni dell’ente locale di distribuzione dell’acqua.
Secondo la IEC 60335-2-79 la macchina può essere collegata direttamente alla
rete pubblica di distribuzione dell’acqua potabile solamente se nella tubazione
di alimentazione è installato un dispositivo antiriflusso con svuotamento tipo
BA conforme alla norma EN 12729. Il dispositivo antiriflusso può essere ordinato
presso il fabbricante.
3.2.6
attenzione.
L’acqua fluita nei dispositivi antiriflusso non è considerata potabile.
3.2.7
attenzione.
La manutenzione e/o la riparazione dei componenti elettrici DEVE
essere effettuata da personale qualificato.
3.2.8
attenzione.
SCARICARE la pressione residua prima di staccare il tubo dalla macchina.
IT - 4
