Comanche MC CAMP User manual

COMANCHE MC CAMP
STEP BY STEP
ERECTION INSTRUCTION

STEP 1.
UN-HOOK UNIT FROM CAR

STEP 2.
LEVEL UNIT WITH JOCKEY WHEEL

STEP 3.
WIND DOWN BACK CORNER STEADY WITH
HANDLE PROVIDED

STEP 4.
UNLOCK LID WITH THE KEYS PROVIDED

STEP 5.
RAISE BOTH SUPPORT LEGS OFF THE LID

STEP 6.
ATTACH BOTH SUPPORT BARS ONTO THE
LEGS

STEP 7.
LIFT THE LID UP THROUGH 180 DEGREES TILL
LEVEL ON THE GROUND

STEP 8.
WHEN OPENING THE LID, THE POLES AND
CANVAS AUTOMATICALLY OPEN OUT

STEP 9.
AT THIS STAGE IT IS EASIER TO REMOVE
BOTH THE MATTRESS AND THE BED LATS

STEP 10.
THEN REMOVE ALL 3 TABLES OUT OF THE
BODY OF THE TRAILER

STEP 11.
REMOVING THE TABLES SHOWS YOU HOW
MUCH STORAGE YOU HAVE
PACK WISELY!!

STEP 12.
PULL THE WHOLE POLE FRAME WORK OUT
FROM THE LID – LEAVING THE CENTRE
POLE IN THE UPRIGHT POSITION

STEP 13.
EXTEND ALL 3 POLE OUT TO THE FIRST
CLICK BY PULLING UPWARDS.
DO THIS BOTH SIDES

STEP 14.
NOW PULL THE CANVAS OFF THE ROOF SO
IT HANGS FREELY

STEP 15.
NOW RAISE THE MIDDLE TENSIONING POLE
AND THE OUTER POLE SO THE CANVAS
HANGS LEVEL

STEP 16.
INSIDE SECURE THE CANVAS TO THE BODY
OF THE TRAILER WITH THE VELCRO – DO
THIS FRONT AND BACK

STEP 17.
OUTSIDE PULL THE CANVAS OVER THE
BODY OF THE TRAILER AND GUIDE OUT IF
REQUIRED

STEP 18.
NOW PEG OUT THE FRONT CANVAS AND
HANG THE DRAFT SKIRT

STEP 19.
YOU CAN NOW ARRANGE THE TABLES HOW
YOU NEED THEM
