Combi High Chair User manual

Instruction Manual
CombiUSA.com
CombiUSA, Inc.
3520 Westinghouse Blvd., Suite B • Charlotte, NC 28273
Customer Service 1.800.992.6624
Read all instructions BEFORE assembly and USE of product.
KEEP INSTRUCTION FOR FUTURE USE. Record the following
information for quick reference.
Note: Illustrations and photographs are only representative and not actual.
Attach copy of sales receipt for future reference.
Date of Purchased: _________________________
Model Number:___________ - ________________ (Located near rear of basket)
Color: ______________________________________
©2013 Combi USA, Inc.
High Chair

2 High Chair Instruction Manual
WARNING///////////////////////
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN
SERIOUS INJURY OR DEATH.
AVOID SERIOUS INJURY FROM FALLING OR SLIDING OUT – ALWAYS USE RESTRAINT
SYSTEM. NEVER LEAVE CHILD UNATTENDED! PLEASE READ THESE INSTRUCTIONS
CAREFULLY AND KEEP FOR FUTURE REFERENCE.
All operating and assembly
procedures should be
performed by an adult:
• Thechildshouldbesecuredin 
 thehighchairatalltimesbythe
 restrainingsystem,either
 intherecliningoruprightposition.
 Thetrayisnotdesignedtoholdthe
 childinthechair.Itis
 recommendedthatthehighchair
 beusedintheuprightposition 
 onlybychildrencapableof
 sittinguprightunassisted.
• Preventseriousinjuryordeath
 fromfallsorslidingout.Always 
 securechildinrestraintsystem.
• Donotusethishighchairfor 
 morethanonechildatatimeand
 donotleaveotherchildrenplaying
 unattendednearthehighchair.
• Toavoidtheriskofre,neverleave
 thehighchairnearsourcesof
 strongheatsuchasopenres, 
 electricheaters,andgasstoves.If
 thehighchairisexposedtodirect
 sunlight,waitforittocooldown
 beforeplacingyourchildinit.
• Adjustthe5-pointharness 
 accordingtothesizeofyourchild.
 Adjustforeveryreclineposition.
• Donotleavethehighchairnear
 walls,curtains,orwindows,where
 thechildcanbecometangled,or
 whereachildmaybeabletouseits
 feettopushagainstthehighchair.
• Neverplacethehighchairnear 
 stairsorsteps.
• Donotadjusttheheightorrecline
 ofproductwiththechildinit.
• Donotmovetheproductwiththe
 childinit.
• ALWAYSuseseatbelt.
• Neverleavechildunattended. 
 Alwayskeepyourchildinview.
• Donotplaceanyheavybags, 
 packages,orotheritemson 
 thehighchairtray.Theymaycause
 thehighchairtotipover.
• Donotuseaccessories,spareparts,
 andcomponentsotherthanthose
 suppliedbyCombi®.
• STRANGULATION HAZARD: Do
 notplaceproductinanylocation
 wheretherearecords,suchas 
 windowblindcords,phonecords,
 etc.
• Donotforcetrayagainstchild.
 Useonlythethreeadjustment 
 positions.Alwaysensurebothsides
 oftrayarelockedinplace.
Thisproductisdesignedasahigh
chairforusewithchildupto3years
ofage.Totalmaximumweightof
childMUSTnotexceed40lbs(18kg).
Thisproductmeetsorexceedsall
requirementscoveredintheASTM
F404StandardConsumerSafety
SpecicationforHighChairs.
Note: All products specications are subject to change without notice. Sizes and weights are intended as guides and are
approximations. Combi® reserves the right to modify the products in its line during the course of the year. Non contractual media.
Colors are as accurate as the media in which they appear allows.
WARNINGS & GENERAL SAFETY INFORMATION
In the event of damage or problems, discontinue use and contact
Combi® Customer Service for instructions: 1-800-992-6624
CombiUSA.com

HighChairInstructionManual3
OVERVIEW
CombiUSA.com
Note: All products specications are subject to change without notice. Sizes and weights are intended as guides and are approximations. Due to
continuous product improvements, the pictures displayed in the instruction manual may differ slightly from the actual product. Combi® reserves
the right to modify the products in its line during the course of the year. Non contractual media. Colors are as accurate as the media in which they
appear allows.

4HighChairInstructionManual
1. Place the seat cushion on the
seating area of your high chair.
Route the shoulder straps through
the slots in the backrest.
6. Pull bottom portion of seat
cushion over middle post.
4. Route the waist belt portion of the harness into the
slots at the rear of the high chair. Repeat on the
opposite side of seat.
5. Route the crotch belt portion of the harness into the
slot behind the middle post.
2. Gently pull the top portion of the
seat cushion over the backrest.
7. Attach snaps to both side of the
seat cushion as shown.
3. Fit the recline lever through the
slot at the top of the seat cushion.
8. Attach the Velcro to the post of
the footrest.
ATTACHING THE SEAT CUSHION AND HARNESS
HIGH CHAIR ASSEMBLY
CombiUSA.com

HighChairInstructionManual5
REMOVING THE SEAT CUSHION AND HARNESS
HIGH CHAIR ASSEMBLY
Follow the previous directions of “Attaching the Seat Cushion and Harness” in reverse.
ATTACHING/REMOVING THE SNACK TRAY
Attaching The Snack Tray
Place the snack tray over the tray and snap into place
on both sides.
Removing The Snack Tray
Pull up on both sides to release the snack tray from the
main tray.
ADJUSTING THE TRAY
1. Squeeze the adjuster lever located under the tray
and position the tray to the desired use position.
2. Pull the tray to ensure that it is secure before use.
CombiUSA.com
ATTACHING/REMOVING THE TRAY
Attaching The Tray: Squeeze the adjuster lever
located under the tray while placing the tray onto the
main body of the high chair. Pull the tray to ensure that
it is secure before use.
Removing The Tray: Squeeze the adjuster lever for
the tray while pulling the tray away from the high chair.
WARNING: Do not force tray against child. Use only the three adjustment positions. Always ensure
both sides of tray are locked in place.

6 High Chair Instruction Manual
HIGH CHAIR OPERATION
CombiUSA.com
1. To unfold the high chair, hold the backrest while
pushing down on the rear leg assembly until the rear
leg assembly locks into position
2. To fold the high chair, pull up on the folding
mechanism on each side of the high chair while
leaning the high chair back, then pull up on the rear
leg assembly until the rear leg is upright.
UNFOLDING AND FOLDING THE HIGH CHAIR
1. Squeeze the height adjustment buttons on both
sides of your high chair while pulling up or lowering
down to adjust the high chair to your desired
position. There are 5 height use positions.
STORAGE POSITION
ADJUSTING THE HEIGHT
WARNING: The lowest position is not a use position.
This position is for storage purposes only.
WARNING: Do not adjust the height of product with the child in it.

High Chair Instruction Manual 7
Buckling the Harness
1. Place the crotch belt between the baby’s legs.
2. Insert buckle tongues into each side of buckle.
3. Lift buckle with tongues inserted and attach
right and left harness hooks to holes in buckle
tongues.
4. To adjust the harness or waist belt, loosen the
slack on both sides of each buckle and adjust to
desired position.
Unbuckling the Harness
1. Press levers down on right and left harness
hooks to detach shoulder straps from buckle
tongues.
2. Press center buckle button down while gently
pulling buckle tongues from buckle to release.
HIGH CHAIR OPERATION
CombiUSA.com
USING THE HARNESS
ADJUSTING THE RECLINING BACKREST MOVING THE HIGH CHAIR
1. Pull up on the recline lever and adjust the
backrest to the desired position. There are 3
recline positions.
1. Lift up the front legs off the oor. You can then
move the high chair freely on the rear wheels.
WARNING: Avoid serious injury from falling or sliding out. Always use the 5-point harness.
WARNING: Do not adjust recline of product with the
child in it.
WARNING: Do not move the high chair with the child
in it.

8HighChairInstructionManual
HIGH CHAIR OPERATION
CombiUSA.com
PREPARING THE HIGH CHAIR FOR STORAGE
1. Adjust the height of the high chair to the storage
position.
2. Fold the rear legs as shown.
3. Remove the tray from the main body.
4. Notice the location shown on the tray and rear
leg to retain the tray for storage.
5. Place the tray on the rear leg.

High Chair Instruction Manual 9
Store in a cool and dry area, especially in the summer.
To avoid damaging stroller, NEVER place items on top
of the high chair during storage.
Seat Cushion and Restraint System:
Wipesoiledareawithawarm,dampcloth.
High Chair Frame
Tocleantheframe,wipewithawarm,dampcloththen
wipeoutanytracesofmoistureontheframewithadry
cloth.
Intheeventofdamageorproblem,discontinue
useandcontactCombiCustomerServicefor
instructionsat1-800-992-6624.
ROUTINE MAINTENANCE
TROUBLESHOOTING
CLEANING THE SEAT
HandWash
DoNotUseBleach
DryFlat
Do Not Iron
DoNotDryClean
CombiUSA.com

10HighChairInstructionManual
CombiUSA.com

HighChairInstructionManual11
CombiUSA.com

12HighChairInstructionManual
CombiUSA, Inc.
3520 Westinghouse Blvd., Suite B • Charlotte, NC 28273
Customer Service 1.800.992.6624 2/13
CombiUSA.com
