ComBlock COM-1826 User manual

COM-1826 TDRSS SPREAD-
SPECTRUM MODEM
Key Features
TDRSS spread-spectrum modem comprising
oDemodulator with two input types:
GbE LAN SDDS-formatted input
stream or RF input.
oModulator with baseband or RF output.
BPSK and SQPN spread-spectrum modulation
Convolutional Viterbi error correction: K=7
Rate ½
Programmable 1023- (forward command link)
or 2047-chip (return mode 2 link) periodic I and
Q Gold codes
Programmable bit rates from 1 to 150 Kbits s
on each channel. Two independent bit
synchronizers to acquire and track each channel
bit stream.
120-bin parallel code search for fast code
acquisition. False code lock prevention.
Built-in Bit Error Rate measurement for PRBS-
11 test sequences.
Demodulation performances: within 1.5 dB
from theory at threshold Eb No of 2 dB.
Demodulated bits encapsulated in UDP frames
and sent out to the LAN. Support for IGMPv2
multicast addressing.
Monitoring:
oReceiver lock, Carrier frequency error,
SNR
 ComScope –enabled: key internal signals
can be captured in real-time and displayed on
host computer.
90VAC – 264VAC power supply
Options:
o1-3 receivers per 1 RU chassis
oModulator with RF output
oDemodulator RF input
For the latest data sheet, please refer to the ComBlock
web site: http: www.comblock.com download com1826.pdf.
These specifications are subject to change without notice.
For an up-to-date list of ComBlock modules, please
refer to http: www.comblock.com product_list.html .
MSS • 845-N Quince Orchard Boulevard • Gaithersburg, Maryland 20878 • U.S.A.
Telephone: [phone] Facsimile: [phone] www.ComBlock.com
© MSS 2016 Issued 11 27 2016

Block Diagram
Carrier
tracking
loop (PLL+AFC)
Carrier
NCO
Code
timing
NCO
PSK symbol
decoding
Demod lated
data bits
LPF
Monitoring
Freq ency error
Code lock Monitoring
Info
Code
replica
generation
Despreading
Coherent I&D
Non-coherent I&D
Re-sampling
Digital
freq ency
translation
Noise power
x NACQ
parallel
detection
circ its
Code
tracking
loop
Skip
1/2 chips
False
code lock
detection
Code
acq isition
State
machine
Carrier lock
early
center
late
bins
3baseband
complex
samples
Despreading
with on-time
code replica to PSK
demod lator
I&D
Symbol
timing
NCO
to PSK
demod lator
Symbol
timing
loop
PSK
demodulator
DSSS
demodulator
3-channel receiver

Configuration
This ComBlock assembly comprising several ComBlock modules can be monitored and controlled centrally
over a single connection with a host computer. Connection types include built-in types:
USB
TCP-IP LAN
The module configuration is stored in non-volatile memory.
Configuration Basic)
The easiest way to configure the COM-1826 is to use the ComBlock Control Center software supplied with
the module on CD. In the ComBlock Control Center window detect the ComBlock module(s) by clicking the
Detect button, next click to highlight the COM-1826 module to be configured, next click the Settings
button to display the Settings window shown below.
3

4

5

Configuration Advanced)
Alternatively, users can access the full set of configuration features by specifying 8-bit control registers as
listed below. These control registers can be set manually through the ComBlock Control Center or by software
using the ComBlock API (see www.comblock.com download M&C_reference.pdf)
All control registers are read write. Definitions for the Control registers and Status registers are provided below.
6

Control Registers
The module configuration parameters are stored in
volatile (SRT command) or non-volatile memory
(SRG command). All control registers are
read write.
Several key parameters are computed on the basis
of the 125 MHz internal processing clock fclk_p:
frequency translation, chip rate, etc.
Built-in DSSS demodulator
Parameters Configuration
SDDS-
formatted
stream input
selection
1 = UDP port 29495
0 = TCP port 1028
REG0(0)
Demod input
selection
0 = SDDS LAN
2 = A D converters baseband
3 = A D converters IF undersampling
4 = internal modulator loopback
REG28(7:5)
I Code Linear feedback shift register initialization.
As per [1]
REG1 LSB
REG2(2:0) MSb
Q Code REG3 LSB
REG4(2:0) MSb
Code mode 0 = forward command link
1 = return mode 2 link
See SNIP for details
REG27(4)
reserved REG27(7:5) = “000”
CIC_R Decimation ratio.
Largest integer less than
input sampling rate 4*chip rate
REG2(7:3): lsbs
REG4(7:3): msbs
Chip rate
(fchip rate)
The nominal chip rate is 3.077799479166
Mchips s. However, the design is somewhat
more flexible. Alternative chip rates can be
entered here
32-bit integer expressed as
fchip rate * 232 fclk_p.
The maximum practical chip rate is fclk_p 2.
Nominal chip rate: 0x064DA741
The maximum allowed error between
transmitted and received chip rate is + -
100ppm.
REG5 (LSB) – REG8 (MSB)
I channel symbol
rate
fsymbol_rate
The I-channel symbol rate can be set
independently of the spreading code period
as
fsymbol_rate * 232 fclk_p
Example: “00346DC6” represents 100
Ksymbols s.
REG9 (LSB) – REG12 (MSB)
Q channel
symbol rate
fsymbol_rate
The Q-channel symbol rate can be set
independently of the spreading code period
as
fsymbol_rate * 232 fclk_p
REG13 (LSB) – REG16 (MSB)
I channel
spreading
factor
(Processing
gain)
Approximate (i.e rounded) ratio of chip
rate symbol rate
REG17 (LSB)
REG18(4:0) MSb
Q channel
spreading
factor
(Processing
gain)
Approximate (i.e rounded) ratio of chip
rate symbol rate
REG19 (LSB)
REG20(4:0) MSb
Nominal input
center
frequency (fc)
The nominal center frequency is a fixed
frequency offset applied to the SDDS input
samples. It is used for fine frequency
corrections, for example to correct clock
drifts.
32-bit signed integer (2’s complement
representation) expressed as
fc * 232 fclk_p
In addition to this fixed value, an optional
time-dependent frequency profile can be
entered. See frequency profile table.
REG21 (LSB) – REG24 (MSB)
Reserved REG25
Spectrum
inversion
Invert Q bit
0 = off
1 = on
REG26(0)
BPSK SQPN 0 = BPSK
1 = SQPN
REG26(1)
SQPN
single double
source
0 = different data on I and Q channels
(including the case when bits of a single
input bit stream are sent alternatively to the
I Q channels). Independent symbol rates on
I Q channels. Uses two FEC decoders.
1 = identical data on I and Q channels (prior
to coherent sum). Uses one FEC decoder.
7

REG26(2)
Alternating I Q
bits
Alternating bits are sent on the I and Q
channels. The symbol rate must be identical
on both I and Q channels. Two independent
FEC decoders are used on the I and Q paths
respectively.
Enabled(1) Disabled(0)
REG26(7)
½ symbol delay
on the Q path
The Q bits received with a ½ symbol delay
with respect to the I bits.
Enabled(1) Disabled(0)
REG26(6)
Encoding 0 = NRZ-L
1 = NRZ-M
2 = NRZ-S
4 = Biphase-L
REG26(5:3)
AGC response
time
Users can to optimize AGC response time
while avoiding instabilities (depends on
external factors such as gain signal filtering
at the RF front-end and chip rate). The
AGC_DAC gain control signal is updated as
follows
0 = every chip,
1 = every 2 input chips,
2 = every 4 input chips,
3 = every 8 input chips, etc….
10 = every 1000 input chips.
Valid range 0 to 14.
REG28(4:0)
Viterbi decoding Disable (0) Enable (1)
REG27(1)
Viterbi decoder
G2 parity bit
inversion
No (0) Yes (1)
REG27(2)
Select BER
tester input 0 = I,
1 = Q
REG27(3)
Built-in DSSS modulator (when instantiated)
Parameters Configuration
DSSS modulator
enable
0 = disabled
1 = enabled
REG61(7)
Channel 1
modulator input
selection
0 = disabled
1 = TCP server at port 1280
2 = PRBS11 test sequence
3 = zeros
REG63(5:4)
Channel 2
modulator input
selection
0 = disabled
1 = TCP server at port 1281
2 = PRBS11 test sequence
3 = zeros
REG65(5:4)
I Code Linear feedback shift register
initialization.
As per [1]
REG62 LSB
REG63(2:0) MSb
Q Code REG64 LSB
REG65(2:0) MSb
Code mode 0 = forward command link (see SNIP)
1 = return mode 2 link
See SNIP for details
REG65(3)
Chip rate
(fchip rate)
The nominal chip rate is 3.077799479166
Mchips s. However, the design is
somewhat more flexible. Alternative chip
rates can be entered here
32-bit integer expressed as
fchip rate * 232 fclk_p.
The maximum practical chip rate is fclk_p
2.
Nominal chip rate: 0x064DA730
REG66 (LSB) – REG69 (MSB)
I channel
symbol rate
fsymbol_rate
The I-channel symbol rate can be set
independently of the spreading code
period as
fsymbol_rate * 232 fclk_p
Example: 0x0346DC5 represents 100
Ksymbols s.
REG70 (LSB) – REG73 (MSB)
Q channel symbol
rate
fsymbol_rate
The Q-channel symbol rate can be set
independently of the spreading code
period as
fsymbol_rate * 232 fclk_p
REG74(LSB) – REG77 (MSB)
8

Modulated signal
amplitude
16-bit amplitude scaling factor for the
modulated signal.
The maximum level should be adjusted to
prevent saturation. Saturation can easily be
checked by visualizing the input signal
using ComScope.
REG29 = LSB
REG30 = MSB
Output center
frequency (fc)
Fixed frequency offset applied to the
output samples.
32-bit signed integer (2’s complement
representation) expressed as
fc * 232 fclk_p
REG81 (LSB) – REG78 (MSB)
Spectrum
inversion
Invert Q bit
0 = off
1 = on
REG61(0)
BPSK SQPN 0 = BPSK
1 = SQPN
REG61(1)
SQPN
single double
source
0 = different data on I and Q channels
(including the case when bits of a single
input bit stream are sent alternatively to the
I Q channels). Independent symbol rates on
I Q channels. Uses two FEC encoders.
1 = identical data on I and Q channels.
Uses one FEC encoder
REG61(2)
Alternating I Q
bits
When enabled, the input data stream is
demultiplexed into the I and Q paths. The
symbol rate must be identical on both I and
Q channels. Two independent FEC
encoders are used on the I and Q paths
respectively.
Enabled(1) Disabled(0)
REG60(7)
½ symbol delay
on the Q path
A ½ symbol delay can be added to the Q
modulator path
Enabled(1) Disabled(0)
REG60(6)
Data format
converter
Data format conversion from the NRZ-L
input to NRZ-L M S format prior to the
FEC encoder.
0 = NRZ-L to NRZ-L
1 = NRZ-L to NRZ-M
2 = NRZ-L to NRZ-S
REG61(5:3)
Convolutional
FEC encoding Disable (0) Enable (1)
REG61(6)
Additive White
Gaussian Noise
gain
16-bit amplitude scaling factor for additive
white Gaussian noise.
Because of the potential for saturation,
please check for saturation when changing
this parameter. Saturation can easily be
checked by visualizing the input signal
using ComScope.
REG31 = LSB
REG32 = MSB
External
transmitter gain
control
When using an external transceiver such as
the COM-350x family, the transmitter gain
can be controlled through the
TX_GAIN_CNTRL1 analog output signal.
Range 0 – 3.3V.
REG59: LSB, REG60(3:0): MSb
TX_ENB
control
The TX_ENB signal at the interface
controls the RF transmit circuit.
0 = off
1 = on
REG60(4)
etwork Interface
Parameters Configuration
MAC addresses LSB In order to ensure the uniqueness of
MAC addresses, users can define bits
7:1 through REG236(7:1).
The MAC addresses upper bits are
automatically tied to the nearly unique
FPGA DNA_ID. MAC address bit 0 is
either 0 (LAN1) or 1 (LAN2).
REG236(7:1).
IP1 multicast address
(LAN xB connector
on backpanel)
4-byte IPv4 address used for SDDS
input stream.
Example : 0x E1 00 00 01 designates
address 225.0.0.1
Use 0.0.0.0 to signify that multicasting
is not supported.
REG33 (MSB) – REG36 (LSB)
IP1 static address
(LAN xB connector
on backpanel)
4-byte IPv4 address used for SDDS
input stream.
Example : 0x AC 10 01 80 designates
address 172.16.1.128
The new address becomes effective
immediately (no need to reset the
ComBlock).
REG37 (MSB) - REG40 (LSB)
IP2 address (LAN xA
connector on
backpanel)
4-byte IPv4 address used for receiver
output, modulator inputs and
monitoring and control.
Example : 0x AC 10 01 80 designates
address 172.16.1.128
The new address becomes effective
immediately (no need to reset the
ComBlock).
REG41 (MSB) - REG44 (LSB)
Destination IP
address
4-byte IPv4 address
Destination IP address for UDP frames
9

with decoded data.
Example : 0x AC 10 01 80 designates
address 172.16.1.128
The new address becomes effective
immediately (no need to reset the
ComBlock).
REG45 (MSB) – REG48(LSB)
Destination ports I-channel data is routed to this user-defined
port number:
REG49(LSB) – REG50(MSB)
Q-channel data is routed to the incremented
port number.
Subnet mask REG51 (MSB) – REG54(LSB)
Gateway IP address REG55 (MSB) – REG58(LSB)
(Re-)Writing to the last control register REG81 is
recommended after a configuration change to enact the
change.
Status Registers
Parameters Monitoring
Hardware self-
check
At power-up, the hardware platform
performs a quick self check. The result is
stored in status registers SREG0-9
Properly operating hardware will result in
the following sequence being displayed:
SREG0-SREG9 = 01 F1 1D xx 1F 93 10
22 22 03
TCXO reference
clock presence
1 = detected
0 = missing
SREG9(0)
125 MHz internal
clock PLL lock
Indirectly confirms the presence of the
frequency reference (TCXO for firmware
option –A, external 10 MHz for firmware
option –B)
1 = locked
0 = unlocked
SREG9(1)
Input sampling rate The sampling rate, as read from the SDDS
input stream.
Format:
sampling_rate fclk *2^32
SREG10 = bit 7-0 (LSB)
SREG11 = bit 15 – 8
SREG12 = bit 23 – 16
SREG13(3:0) = bit 27 – 24 (MSB)
Time tag Last valid timetag read from the SDDS
input header. Expressed in 250ps units.
SREG14 (LSB) – SREG21(MSB)
Input frame counter Cumulative SDDS frame counter. Each
frame contains 1024 bytes = 256 complex
samples.
SREG22 (LSB) – SREG25(MSB)
Missing input frame
counter
Cumulative number of missing SDDS
frames. Should be zero.
SREG26 (LSB) – SREG27(MSB)
LAN1 MAC bad
CRC counter SREG28 (LSB) – SREG29(MSB)
MAC address Unique 48-bit hardware address (802.3). In
the form SREG30:SREG31:SREG32:
…:SREG35
Demodulator
carrier lock status
SREG36(0)
0 = unlocked or no input
1 = locked
Code lock status SREG36(1)
0 = unlocked or no input
1 = locked (1 s hysteresis)
Viterbi decoder1
synchronized
SREG36(2)
0 = not synchronized or no input
1 = synchronized
Viterbi decoder2 SREG36(3)
10

synchronized 0 = not synchronized or no input
1 = synchronized
Signal presence SREG36(4)
0 = no carrier detected in FFT
1 = carrier detected in FFT
Decoder1 built-in
BER
The Viterbi decoder computes the BER on
the received (encoded) data stream
irrespective of the transmitted bit stream.
Encoded stream bit errors detected over a
1000-bit measurement window.
SREG37 LSB
SREG38 MSB
Decoder2 built-in
BER
The Viterbi decoder computes the BER on
the received (encoded) data stream
irrespective of the transmitted bit stream.
Encoded stream bit errors detected over a
1000-bit measurement window.
SREG39 LSB
SREG40 MSB
Nominal center
frequency
Expected center frequency: sum of the
fixed center frequency and the dynamic
frequency profile table.
SREG41 (LSB) – SREG44 (MSB)
Carrier frequency
offset1
Residual frequency offset with respect to
the nominal carrier frequency (i.e. after
frequency profile correction). Part 1 2.
32-bit signed integer expressed as
fcerror * * 232 fclk_p
SREG45 (LSB) – SREG48 (MSB)
Carrier frequency
offset2
Residual frequency offset with respect to
the nominal carrier frequency (i.e. after
frequency profile correction). Part 2 2.
32-bit signed integer expressed as
fcerror * * 231 fchip_rate
SREG49 (LSB) – SREG52 (MSB)
Despread signal
power S
Average signal power after despreading.
Compute the signal to noise ratio after
despreading as S N. The absolute value is
meaningless because of multiple agcs.
SREG53 (LSB) – SREG54 (MSB)
Noise power N Average noise power. Used to compute the
SNR after despreading. The absolute value
is meaningless because of multiple agcs.
SREG55 (LSB) – SREG56 (MSB)
SNR 2*(S+N) N ratio,
valid only during code lock.
Linear (not in dBs)
Fixed point format 14.2
SREG57 (LSB) – SREG58 (MSB)
Bit error rate Monitors the BER (number of bit
errors on the I- or Q-channel at the
demodulator output, counted over
80,000 received bits) when the
modulator is sending a PRBS-11 test
sequence.
Note: because the demodulator
inherent phase ambiguity, a zero
BER can be displayed as 0 or 80000
(x13880)
SREG59: LSB
SREG60: MSB
BER tester synchronized SREG36(5): 1 when the BER tester
is synchronized with the received
PRBS-11 test sequence.
Built-in modulator S R calibration
Parameters Monitoring
Measured modulated
signal power
SREG61(LSB)
SREG62
SREG63(MSB)
Measured AWGN
power (Noise
bandwidth is 6.25
MHz)
SREG64(LSB)
SREG65
SREG66(MSB)
FPGA configuration options
Parameters Monitoring
MODULATOR_EN Indicates whether the modulator is
instantiated (1) or not (0) in the
current active FPGA configuration.
SREG67(0)
ADCs_EN Demodulator ADC interface
instantiated (1) or not (0)
SREG67(1)
DACs_EN Modulator DAC interface
instantiated (1) or not (0)
SREG67(2)
AWGN_EN Additive white Gaussian noise
instantiated (1) or not (0)
SREG67(3)
Multi-byte status variables are latched upon (re-)reading
SREG7.
11

ComScope Monitoring
Key internal signals can be captured in real-time
and displayed on a host computer using the
ComScope feature of the ComBlock Control
Center. Click on the button to start, then select
the signal traces and trigger are defined as follows:
Trace 1 signals Format ominal
sampling
rate
Buffer
length
(samples)
1: Input signal I-
channel
8-bit signed Input sampling
rate
512
2: Demodulated Q-
channel
8-bit signed 1 sample
symbol
512
3: Parallel correlator
output
8-bit
unsigned
1 sample code
epoch
512
4: 2(S+N) N after
despreading. Valid
only if code is locked.
Linear (i.e. not in dBs)
8-bit
unsigned
fclk 512
Trace 2 signals Format ominal
sampling
rate
Buffer
length
(samples)
1: Input signal Q-
channel
8-bit signed Input sampling
rate
512
2: Code replica.
Compare with
spread input signals
8-bit signed 2 samples chip 512
3: Demodulated I-
channel
8-bit signed 1 sample
symbol
512
4: Averaged signal
power (valid only
during code tracking)
8-bit signed fclk 512
Trace 3 signals Format ominal
sampling
rate
Buffer
length
(samples)
1: Code tracking phase
correction
(accumulated)
8-bit signed 2 samples
symbol
512
2: Carrier fine tracking
phase
8-bit signed fclk 512
3: I-Symbol tracking
phase (accumulated)
8-bit signed 1 sample
symbol
512
4: Averaged noise
power (valid only
during code tracking)
8-bit signed fclk 512
Trigger Signal Format
1: Start of code
replica
Binary
2. Code Lock Binary
Signals sampling rates can be changed under
software control by adjusting the decimation factor
and or selecting the fclk processing clock as real-
time sampling clock.
In particular, selecting the fclk processing clock as
real-time sampling clock allows one to have the
same time-scale for all signals.
The ComScope user manual is available at
www.comblock.com download comscope.pdf.
ComScope example, showing code lock with aligned:
received spread signal (green) vs code replica (red)
ComScope example: showing demodulated I-
channel
12

Digital Test Points
The digital test points below are only available
when no ADCs DACs are installed.
Test PointDefinition
A1 UDP TCP input data activity.
SDDS receive data valid flag from UDP or TCP.
(8ns per input byte)
A2 SDDS input buffer underflow condition. ‘1’
when the sender is not fast enough.
A3 Recovered carrier center frequency (coarse)
A4 Carrier lock
A5 Code lock
A6 Signal present
A7 Recovered chip clock
A8 Recovered I-channel symbol clock
A9 I-code start
A10 I-code replica
A11 I-channel before despreading (compare with
code replica)
A12 Demodulated bit (I)
A13 Demodulated bit (Q)
A14 BER tester synchronized (I or Q depending on
REG27(3))
A15 Byte error detected by BER tester (I
or Q depending on REG27(3))
A16 Viterbi decoder (I) synchronized (pulse every 1K
bits)
A17 Viterbi decoder (Q) synchronized (pulse every
1K bits)
A19 Periodic pulses every 2047 bits when receiving a
PRBS-11 test sequence
Operation
Monitoring & Control
M&C is possible over USB and LAN TCP.
A pre-requisite for using USB is the prior
installation of the ComBlock USB driver.
Monitoring and control is through the USB and
LAN xA connectors on the back panel.
At manufacturing, the default M&C LAN address is
172.16.1.2. It can be subsequently changed via USB
or LAN TCP.
The LAN xA connector is also shared with TCP
connections for modulator inputs and dynamic
profiles inputs.
SDDS input stream
The LAN xB connectors on the back panel are
reserved for SDDS-formatted input streams.
The input stream can be received on UDP port
29495 or TCP-IP port 1028. Control register
REG0(0) selects UDP versus TCP.
The static IP address is defined in control registers
REG37-40.
Note: It is important to ensure that the data source is
fast enough to send 200 Mbits s of UDP or TCP
data with latency less than 2.5ms (the receiver input
elastic buffer depth). When in doubt, please check
the test point A2 with an oscilloscope.
13

The input sampling rate is read from the SDDS
preamble. The receiver design was verified at an
input sampling rate of 6.25 MSamples s, but the
design should work similarly at other sampling
rates.
The 64-bit receiver time is read from each SDDS
frame preamble. It is used to time-tag the output
frames containing the demodulated bits.
External frequency reference
A 10 MHz external frequency reference is required
for proper operation. The electrical characteristics
are as follows:
Sinewave, clipped sinewave or squarewave. AC-
coupled.
Minimum level: 2Vpp.
Maximum level: 5Vpp.
When the SDDS input stream is transmitted as
UDP, it is essential that the same 10 MHz be used
at both ends of the UDP link, otherwise buffer
underflow or overflow conditions may occur.
When the SDDS input stream is transmitted as
TCP, the 10 MHz frequency stability requirements
are not as stringent as the TCP protocol informs the
data source of flow-control conditions at the data
sink. In this case, the data source is responsible for
timing adjustments in the data throughput.
Modulator input stream
The modulator has two independent external inputs
for the I and Q channels. Inputs are through the
LAN xA connectors on the back panel.
Two TCP servers await connections from remote
TCP clients on ports 1280 and 1281 for the I and Q
channels respectively.
The TCP clients must send input data as fast as
allowed by the TCP flow control in order to prevent
an underflow condition at the modulator.
Spreading codes
The demodulator is designed to acquire two types
of Gold codes:
- All forward command link codes (1023-
chip Gold codes)
- All return mode 2 link codes (2047-chip
Gold codes)
The Gold codes selection is performed by
entering 10 or 11-bit initialization vectors for
the linear feedback shift registers. Appendix A
of document 451-PN CODE-SNIP lists these
initialization vectors as ‘I-code’ and ‘Q-code”.
For example, NASA return mode 2 link code 40 is
selected by entering 2225o (octal) and 1337o in the
appropriate control registers.
Symbol Rate
The demodulation symbol rates on the I and Q
channels are independent of the chip rate and code
period. The demodulator includes two autonomous
symbol tracking loops, separate from the code
tracking loop.
However, the full spread-spectrum processing gain
can only be achieved if the symbol period is less
than the 2047-chip code period.
Frequency Tracking
The DSSS demodulator is capable of acquiring
signals with a maximum center frequency error of
+ - 5 KHz remaining after fixed and dynamic
(frequency profile table) compensation.
Two features assist the demodulator in extending
this natural frequency acquisition range:
1. a fixed user-defined frequency offset,
entered through the GUI, is applied to the
received signal.
14

2. a frequency profile table can be sent to the
receiver. It consists of a start time followed
by 32-bit frequency offset samples read at 1
second intervals. To prevent sudden
frequency jumps, the table entries are
interpolated linearly.
Once the demodulator has confirmed carrier and
code lock, the above frequency offsets are frozen.
Once locked, the carrier tracking loops tracks the
carrier phase over a very wide frequency range.
Frequency profile table
Users can declare the expected Doppler variation
with time in the form of a frequency profile table.
The Doppler is used to correct the demodulator
expected center frequency. It is also used to correct
the demodulator expected chip rate, after scaling the
frequency by the 3.0777995 Mchips s 2.2875 GHz
frequency ratio.
The table is entered in one TCP session whereby
the user (TCP client) opens a TCP connection to
port 1024 and writes the entire frequency table.
The table consists of a 64-bit start time (same
reference as the SDDS time tag, i.e. 250ps units)
followed by up to 4096 32-bit frequency samples.
Each sample represents a nominal center frequency
expressed in units of 125 MHz 232 (about 29 mHz
steps), sampled at 1s intervals.
The byte order is MSB first.
The frequency table is read (played-back) every
second starting at the specified SDDS start time.
The receiver interpolates linearly 64x between
successive 1s samples so as to minimize
discontinuities. This ensures phase and frequency
continuity. This frequency bias is removed from the
SDDS input samples for the playback duration,
irrespective of the demodulator lock status.
Table playback is mutually exclusive with table
upload. Opening a new TCP session to upload a
new table will immediately stop any playback in
progress.
Because the table is quite small (131Kbits max), the
TCP upload time (2-5ms) is insignificant relative to
the playback duration.
A utility is included in the ComBlock Control
Center to upload a binary frequency profile table:
Code Tracking Loop
The code tracking loop is a coherent delay lock
loop (DLL) of the 1st order.
Code Acquisition
120 parallel detectors search for code aligment
during the code acquisition phase. During the
subsequent code tracking phase, 3 detectors track
the early center late code while the other 117
detectors scan for false lock. The detectors are
staggered ½ chip apart.
Detection is performed in two steps: first a coherent
detector averages the despread signal over ½ a
symbol period. The result is squared and further
averaged over 100 symbols.
The received chip rate must be within + - 4ppm of
the nominal 3.077799479166 Mchips s value.
Demodulated data output
Demodulated data is encapsulated within variable-
length UDP frames and send to the specified
destination IP Port.
15

The output format is as follows:
- fixed-length preamble consisting of (in the order
of transmission)
- 2-byte length of payload data (excluding
preamble). In the range 1 to 1024 bytes.
- 2-byte frame counter, modulo 216
- 4-byte currently undefined
- 8-byte timestamp (last timestamp read from the
SDDS input frames, latched at the first demodulated
byte in the transmit frame).
The output frames are sent when one of two trigger
conditions is met:
- at least 1024 demodulated data bytes are waiting
in the transmit queue, or
- at least 0.5second has elapsed since the last output
frame and at least one demodulated data byte is
waiting in the transmit queue.
The payload data size is thus variable in the range 1
through 1024 bytes.
Bytes are packed MSb first. Only full bytes are
transmitted (no partially filled bytes).
Modulator
The built-in modulator includes the FEC encoding
and DSSS baseband modulation functions. The
modulator output can be directed to the internal
demodulator when the loopback control is enabled.
Depending on the ordering option, the modulator
output can also be directed to analog baseband or
RF.
Load Software Updates
From time to time, ComBlock software updates are
released.
To manually update the software, highlight the
ComBlock and click on the Swiss army knife
button.
The receiver can store multiple personalities. The
list of personalities stored within the ComBlock
Flash memory will be shown upon clicking on the
Swiss army knife button.
The default personality loaded at power up or after
a reboot is identified by a ‘D’ in the Default
column. Any unprotected personality can be
updated while the Default personality is running.
Select the personality index and click on the
“Add Modify” button.
16

The software configuration files are named with the
.bit extension. The bit file can be downloaded via
the Internet, from the ComBlock CD or any other
local file.
The option and revision for the software currently
running within the FPGA are listed at the bottom of
the advanced settings window.
Two firmware options are available for this
receiver:
-A firmware uses an internal VCTCXO frequency
reference.
-B firmware option requires an external 10 MHz
frequency reference.
Recovery
This module is protected against corruption by an
invalid FPGA configuration file (during firmware
upgrade for example) or an invalid user
configuration. To recover from such occurrence,
connect a jumper in J3 and during power-up. This
prevents the FPGA configuration and restore USB
communication [LAN communication is restored
only if the IP address is known defined for the
personality index selected as default]. Once this is
done, the user can safely re-load a valid FPGA
configuration file into flash memory using the
ComBlock Control Center.
UDP Reset
Port 1029 is open as a UDP receive-only port. This
port serves a single purpose: being able to reset the
modem (and therefore the TCP-IP connection)
gracefully. This feature is intended to remedy a
common practical problem: it is a common
occurrence for one side of a TCP-IP connection to
end abnormally without the other side knowing that
the connection is broken (for example when a client
‘crashes’). In this case, new connections cannot be
established without first closing the previous ones.
The problem is particularly acute when the COM-
1826 is at a remote location.
The command “@001RST<CR><LF>” sent as a
UDP packet to this port will reset all TCP-IP
connections within the COM-1826.
TCP-IP connections can also be cleared remotely
from the ComBlock Control Center as illustrated
below:
17

Trou leshooting Checklist
Receiver is not responsive after power up:
The device typically takes up to 30 seconds
to boot up after power up.
If still not responsive after 30 seconds,
recycle the power. Wait at least 15 seconds
after power off to turn the power on again.
Receiver does not communicate with the ComBlock
Control Center:
Make sure an external 10 MHz frequency
reference is present prior to powering up
the receiver. This applies only when the –B
firmware option (external 10 MHz
frequency reference) is selected by default.
Demodulator can’t achieve lock even at high signal-
to-noise ratios:
Make sure the modulator baseband I Q
signals do not saturate, as such saturation
would strongly distort the modulation phase
information. (this is a phase demodulator!)
Demodulator can demodulate BPSK but not QPSK:
A spectrum inversion may have occurred in
the RF transmission chain. If so, invert the
spectrum inversion flag at the demodulator.
Configuration Management
This specification is to be used in conjunction with
VHDL software revision 0 and ComBlock control
center revision 3.10g and above.
It is possible to read back the option and version of
the FPGA configuration currently active. Using the
ComBlock Control Center, highlight the COM-
1826 module, then go to the advanced settings. The
option and version are listed at the bottom of the
configuration panel.
FPGA utilization
FF: 57673 (45%)
LUT: 51204 (80%)
BRAM: 76
DSP48: 51
BUFG:6
MMCM: 2
PLL: 1
Reference Documents
[1] Space Network Interoperable PN Code Libraries
451-PN CODE-SNIP
ComBlock Ordering Information
COM-1826 TDRSS Spread-Spectrum modem
Options:
1,2 or 3 baseband receivers per 1RU chassis
RF modulator output
TCP-IP modulator input
ECCN: 5A001.b.3
MSS • 845 Quince Orchard Boulevard Ste N•
Gaithersburg, Maryland 20878-1676 • U.S.A.
Telephone: [phone]
Facsimile: [phone]
E-mail: [email protected]
18
