COMENDA AC2 Series Operation instructions

Ed.05-2023
Use and maintenance instructions
Instructions d’utilisation et d’entretien
Anweisungen für Gebrauch und Wartung
Instrucciones de uso y mantenimiento
Istruzioni per l’uso e la manutenzione
AC2 series

ank you for choosing us and for placing your trust in us
Nous vous remercions de nous avoir choisis et de nous avoir fait conance
Danke, dass Sie sich für uns entschieden haben und uns Ihr Vertrauen schenken
Gracias por elegirnos y por conar en nosotros
Grazie per averci scelto e per aver riposto in noi la Vostra ducia

Via Galileo Galilei, 8
20051 Cassina de’ Pecchi
Milano (Italy)
DICHIARAZIONE DI CONFORMITÀ CE
I
DECLARATION OF CONFORMITY CE
GB
CE DECLARACION DE CONFORMIDAD
E
DECLARATION DE CONFORMITÉ CE
FR
KONFORMITÄTSERKLÄRUNG CE
D
CE CONFORMITEITSVERKLARING
NL
CE KONFORMITETSERKLÆRING
DK
CE DEKLARATION
SE
AC1, AC2, AC2E, AC2P, AC2EP 2023.doc
Noi dichiariamo sotto la nostra esclusiva responsabilità che il prodotto:
The undersigned hereby declares under full responsability that the following product:
Declaramos bajo nuestra responsabilidad que el produeto:
Nous soussignées attestons sous notre entière responsabilité que le produit suivant:
Die unterzeichnete Fa. erklärt unter eigener Verantwortung, dass folgende Produkte:
Ondergetekende firma verklaart dat de:
Hermed erklæres at fØlgende produkter:
Härmed bekräftas att nedanstående produkt:
LAVASTOVIGLIE – DISHWASHER – LAVAVAJILLAS – LAVE-VASSEILLE –
GESCHIRRSPÜLER – VAATWASMACHINE – TALLERKENOPVASKEMASKINE –
KORGTUNNELDISKMASKIN
AC2…, AC2P…, AC2E…, AC2EP5…, AC2EP6…, AC2EP9…,
AC1…, AC1P…, AC2…, AC2P6…, AC2P9…, AC22LP6…
al quale questa dichiarazione si riferisce, è conforme alle seguenti norme:
for which this declaration refers to in accordance to the following standards:
al que se refiere asta declaracciones de conformidad a las siguientes normas:
auquel se référe cette dèclaration,est conforme aux normes suivantes:
auf welche sich diese Erklärung bezieht, folgendem Standard entsprechen:
waarop deze verklaring betrekking heeft, volgens de standaard:
som er omfattet af denne erklæring, overholder fØlgende standarder:
som omfattas av denna deklaration motsvarar följande standard:
EN 60335-1, EN 60335-2-58, EN 55014
in base a quanto previsto dalle Direttive CEE:
on the basis of what is foreseen by the Directives CEE:
en base a lo previsto en la directiva CEE:
selon ce qui est prevu par les Directives CEE:
aufgrund der vorgesehenen Richtlinien:
gebaseerd op de CE-richtlijnen:
iht. EU-direktiv:
enligt EU-direktiv:
2006/42/CE, 2014/35/CE, 2014/30/CE
Decliniamo ogni responsabilità per sinistri a persone o a cose derivanti da manomissione da parte di terzi o da carenza di manutenzione o riparazione.
We decline any responsability for injuries or damage derived from machine misuse, abuse by others or improper machine maintenance or repairs.
Declinamos toda responsabilidad por sinostros a personas por la incorrecta manipulacion por parte de tercero e la carencia de mantenimjento o reparaciòn.
Nous déclinons toute responsabilité pour sinistres à personnes ou à objetqui derivent de l'intervention de la part de tiers non specialistes ou de carences de manutentionou reparation.
Wir lehnen jegliche Verantwortung für Schäden an Personen oder Dingen ab, die auf fehlerhaftes Eingreifen Dritter oder auf mängelhafte Wartung oder Reparation zurückzuführen sind.
Wij zijn op geen enkele manier verantwoordelijk voor schade aan personen of materrialen welke voortvloeien uit onoordeelkundig gebruik, reparatie dan onderhoud aan de machines door derden.
Vi frasiger os ethvert ansvar for skader opstàet son fØlge af fejlagtig anvendelse af maskinen, misbrug, eller utilstrækkeligt vedligehold eller reparation.
Vi fråntar oss allt ansvar för skador till följd av felaktig användning av maskinen, missbruk eller otillräckligt underhåll eller reparation.
Persona autorizzata a costituire il fascicolo tecnico.
Persona autorizzata a redigere la dichiarazione di conformità.
Person authorized to compile the technical file.
Person authorized to draw up the declaration of conformity.
Persona facultada para elaborar el expediente técnico.
Persona autorizada para expedir la declaración de conformidad.
Personne autorisée à constituer le dossier technique.
Personne habilitée à établir la déclaration de conformité.
Person, die bevollmächtigt, die technischen Unterlagen zusammenzustellen.
Person die Genehmigung zur Ausarbeitung der Konformitätserklärung.
Persoon die gemachtigd is het technisch dossier samen te stellen.
Persoon die gemachtigd is tot het opstellen van de verklaring van overeenstemming.
Person bemyndiget til at udarbejde det tekniske dossier.
Person bemyndiget til at udarbejde overensstemmelseserklæring.
Person som är behörig att sammanställa den tekniska dokumentationen.
Person som är behörig att upprätta en försäkran om överensstämmelse.
24/03/2023
Andrea Bertone
GENERAL MANAGER
3

EN..............................................................................INFORMATION FOR USERS
Pursuant to Directive 2012/19/EU on waste electrical and electronic equipment (WEEE)
The crossed-out “wheelie-bin” symbol on the dishwasher's serial number plate indicates that the product must be collected separately from
.other waste at the end of its useful life.
The separate collection of the dishwasher, at the end of its life, is organised and managed by the manufacturer.
A user who wishes to dispose of this equipment must therefore contact the manufacturer and follow the system adopted by the latter to allow
the equipment to be collected separately at the end of its life.
Adequate separate collection of the dishwasher for the subsequent start-up after being disposed of for recycling, treatment and
environmentally friendly disposal helps avoid possible adverse effects on the environment and health and favours the reuse and/or recycling
of the materials, which the equipment is composed of.
The unauthorised disposal of the product by the holder leads to administrative sanctions being applied according to the current laws.
FR.........................................................................INFORMATION AUX UTILISATEURS
Aux termes de la Directive 2012/19/EU relative aux déchets d'équipements électriques et électroniques (DEEE)
Le symbole de la poubelle barrée reporté sur la plaque d’identication du lave-vaisselle indique que le produit doit être éliminé, à la n de sa
durée de vie utile, séparément des autres déchets.
Le tri sélectif du lave-vaisselle arrivé en n de vie est organisé et géré par le fabricant.
L'utilisateur qui souhaite se défaire de cet appareil devra donc contacter le fabricant et suivre le système que celui-ci a adopté pour permettre
le tri sélectif de l’appareil à sa n de vie.
Le tri sélectif approprié pour l’envoi du lave-vaisselle au recyclage, au traitement et à l’élimination compatible avec l’environnement, contribue
à éviter tout effet nocif pour l’environnement et pour la santé, et
favorise la ré-utilisation et/ou le recyclage des matériaux qui composent l’appareil.
L'élimination abusive du produit de la part du détenteur entraîne l'application des sanctions administratives prévues par la règlementation
en vigueur.
DE.......................................................................INFORMATIONEN FÜR DIE BENUTZER
Gemäß der Richtlinie 2012/19/EU über die Entsorgung von Elektro- und Elektronik-Altgeräten (WEEE)
Das Symbol mit der durchgestrichenen Mülltonne auf dem Typenschild des Geschirrspülers zeigt an, dass das Produkt am Ende seiner
Lebensdauer
getrennt von anderen Abfällen entsorgt werden muss.
Das Recycling des Geschirrspülers am Ende seiner Lebensdauer wird vom Hersteller organisiert und verwaltet.
Der Benutzer, der dieses Gerät entsorgen möchte, sollte daher den Hersteller kontaktieren und das System befolgen, das dieser vorsieht,
um am Ende der Lebensdauer die getrennte Entsorgung des Gerätes zu ermöglichen.
Die angemessene Trennung und die nachfolgende Übergabe der außer Betrieb genommenen Spülmaschine an eine Stelle für das
Recycling oder die
umweltgerechte Entsorgung trägt dazu bei, eventuelle negative Auswirkungen auf die Umwelt und auf die Gesundheit zu verhindern, und
fördert die Wiederverwendung und/oder Wiederverwertung der Materialien, aus denen das Produkt hergestellt ist.
Die illegale Entsorgung des Produkts durch den Eigentümer führt zur Anwendung von gesetzlich vorgesehen verwaltungsrechtlichen Sank-
tionen.
ES.......................................................................INFORMACIÓN PARA LOS USUARIOS
De acuerdo con la Directiva 2012/19/EU sobre residuos de aparatos eléctricos y electrónicos (RAEE)
El símbolo del contenedor tachado que aparece en la placa de la matrícula del lavavajillas indica que el producto al nal de su vida útil se
debe recoger separado de los otros desechos.
La recogida selectiva del lavavajillas cuando llega al nal de su vida útil la organiza y gestiona el productor.
El usuario que quiera deshacerse de este equipo debe ponerse en contacto con el productor y seguir el sistema que este ha adoptado para
permitir la recogida selectiva del equipo al nal de su vida útil.
La adecuada recogida selectiva para el posterior envío del lavavajillas al reciclaje, tratamiento y eliminación compatible con el medio
ambiente, contribuye a evitar posibles efectos negativos sobre el medio ambiente y la salud, y favorece la reutilización y/o el reciclaje de
los materiales que componen el equipo.
La eliminación ilegal del producto por parte del propietario conlleva la aplicación de las sanciones administrativas establecidas por la
normativa vigente.
IT...............................................................................INFORMAZIONE AGLI UTENTI
Ai sensi della Direttiva 2012/19/EU relativa ai riuti di apparecchiature elettriche ed elettroniche (RAEE)
Il simbolo del cassonetto barrato riportato sulla targhetta matricola della lavastoviglie indica che il prodotto alla ne della propria vita utile
deve essere raccolto separatamente dagli altri riuti.
La raccolta differenziata della lavastoviglie giunta a ne vita è organizzata e gestita dal produttore.
L’utente che vorrà disfarsi della presente apparecchiatura dovrà quindi contattare il produttore e seguire il sistema che questo ha adottato
per consentire la raccolta separata dell’apparecchiatura giunta a ne vita.
L’adeguata raccolta differenziata per l’avvio successivo della lavastoviglie dimessa al riciclaggio, al trattamento e allo smaltimento
compatibile a livello ambientale, contribuisce ad evitare possibili effetti negativi sull’ambiente e sulla salute e favorisce il reimpiego e/o riciclo
dei materiali di cui è composta l’apparecchiatura.
Lo smaltimento abusivo del prodotto da parte del detentore comporta l’applicazione delle sanzioni amministrative previste dalla normativa
vigente.
4

EN
Read this manual carefully before proceeding with installation, commissioning,
adjustment and maintenance operations of dishwasher Mod. AC2.
In the event of a machine fault or malfunction, contact only an authorised technical
centre or COMENDA Ali Group srl directly.
FR
Avant de procéder à l’installation, à la mise en route, au réglage et à l’entretien
du lave-vaisselle Mod. AC2, veuillez lire attentivement ce manuel.
En cas de panne ou de mauvais fonctionnement de la machine, contactez uni-
quement un centre technique agréé ou directement COMENDA Ali Group srl.
DE
Vor derInstallation,Inbetriebnahme,EinstellungundWartungdesGeschirrspülers
Mod. AC2 lesen Sie bitte dieses Handbuch sorgfältig durch.
Im Falle eines Ausfalls oder mangelhaften Betriebs der Maschine ist direkt mit
einem autorisierten technischen Zentrum oder direkt mit Firma COMENDA Ali
Group srl Rücksprache zu nehmen.
ES
Antes de proceder a la instalación, puesta en marcha, ajuste y mantenimiento
del lavavajillas Mod. AC2, lea atentamente este manual.
En caso de avería o mal funcionamiento de la máquina, póngase en contacto
únicamente con un centro técnico autorizado o directamente con COMENDA
Ali Group srl.
IT
Prima di procedere all'installazione, alla messa in funzione, alla regolazione e alle
operazioni di manutenzione della lavastoviglie Mod. AC2, leggere attentamente
il presente manuale.
Incaso di guastoo cattivo funzionamentodella macchina rivolgersiesclusivamente
ad un centro tecnico autorizzato o direttamente alla ditta COMENDAAli Group srl.
La ditta costruttrice si riserva il diritto di apportare
modiche che si renderanno utili ai propri prodotti
senza comprometterne le caratteristiche essenziali.
El fabricante se reserva el derecho de introducir
las modicaciones necesarias en sus productos
sin comprometer sus características esenciales.
Der Hersteller behält sich das Recht vor, der Ver-
besserung seiner Produkte dienende Änderungen
vorzunehmen, ohne dabei die wesentlichen Eigen-
schaften der Produkte zu beeinträchtigen.
Le fabricant se réserve le droit d’apporter toute
modication nécessaire à ses produits sans en
compromettre les caractéristiques essentielles.
The manufacturer reserves the right to make chang-
es that will be useful to their products without com-
promising their essential characteristics.
WARNING
AVERTISSEMENT
WARNUNG
ADVERTENCIA
AVVERTENZA
5

Space left blank intentionally
Espace laissé en blanc intentionnellement
Absichtlich leer gelassener Freiraum
Espacio dejado en blanco intencionalmente
Spazio lasciato bianco intenzionalmente
6

CONTENTS
INDEX-INHALT-ÍNDICE-INDICE
ENGLISH..................................PAGE 9
FRANÇAIS...............................PAGE 39
DEUTSCH................................SEITE 69
ESPAÑOL.............................PÁGINA 99
ITALIANO............................PAGINA129
EN
FR
DE
ES
IT
7

Space left blank intentionally
Espace laissé en blanc intentionnellement
Absichtlich leer gelassener Freiraum
Espacio dejado en blanco intencionalmente
Spazio lasciato bianco intenzionalmente
8

ENGLISHENGLISH
TRANSLATION OF ORIGINAL INSTRUCTIONS
EN
9

Space intentionally left blank
EN
10

EN
TABLE OF CONTENTS
SPECIAL WARNINGS FOR THE OPERATOR ...................................................................12
1.1 General description......................................................................................................13
1.2 Type of use and contraindications for use ...................................................................13
1.3 Transportation, shipping and storage. (Fig. 2) .............................................................13
1.4 Checks upon receipt ....................................................................................................13
1.5 Unpacking (g. 2-3-4) ..................................................................................................14
1.6 Machine identication (g. 5) .......................................................................................14
1.7 Description of the safety devices .................................................................................14
1.8 Regulatory references..................................................................................................14
USER INSTRUCTIONS........................................................................................................15
Control panel......................................................................................................................16
2.1 Before commissioning..................................................................................................18
2.2 Operation and use .......................................................................................................18
2.2.a Powering on ............................................................................................................18
2.2.b Dishwashing............................................................................................................19
2.2.c EOR function (transfer of commands in the event of a fault on the electronic board)...20
2.2.d Manual drain for machines equipped with drain pump (optional)............................20
2.2.e Self-cleaning (optional) ...........................................................................................21
2.2.f Self-cleaning and drain for machines equipped with drain pump (optional).............21
2.2.g DHM2+ module with R.E.D. external debris recovery (optional).............................22
2.2.h HPS EASY / HPS EASY PLUS (with usb) (optional) ..............................................22
2.2.i Language setting......................................................................................................23
2.2.l Display of consumption and ignition time .................................................................24
2.2.m Partial counter reset procedure (to be carried out for each individual counter) .....24
2.3.n Warnings during operation ......................................................................................24
2.2.o Shutdown and cleaning at the end of the day.........................................................25
2.3 Cleaning (g.8).............................................................................................................26
2.4 Maintenance ................................................................................................................26
2.4.a Check and clean the wash and rinse arms .............................................................26
2.4.b Descaling ................................................................................................................26
2.4.c Sanitisation................................................................................................................26
2.4.d. Tips to obtain an optimal washing result (g.8)......................................................27
2.5 Temporary decommissioning .......................................................................................27
2.6 Safety devices..............................................................................................................27
2.7 Residual risks ..............................................................................................................28
Troubleshooting .................................................................................................................29
INSTALLATION AND MAINTENANCE INSTRUCTIONS ...................................................31
3.1 Installation (g.6)..........................................................................................................32
3.1.a Positioning and connections ...................................................................................32
3.1.b Drain pipe connection .............................................................................................33
3.1.c Hot water hydraulic connection (“B” RED - if present) ............................................33
3.1.d Cold water hydraulic connection (“D” BLUE - if present) ........................................33
3.1.e Osmosis water hydraulic connection (“Y11” BLACK - if present) (optional)............34
3.1.f Steam connection (“E”) (only for machines with steam heating)..............................34
3.1.g Steam extraction .....................................................................................................35
3.1.h Electrical connection ...............................................................................................35
3.2 Torque limiter calibration..............................................................................................36
3.3 Detergent and rinse aid dispenser (optional)...............................................................37
3.4 Demolition and disposal...............................................................................................37
3.5 Scheduled maintenance ..............................................................................................37
11

EN
SPECIAL
WARNINGS FOR THE OPERATOR
• Commissioningthemachine,theoperatormusthavecarefully
readthispublication andhave acquiredextensiveknowledge
of the technical specications and of the machine controls.
• Carefully read the warnings contained in this booklet
as they provide important information regarding safe
installation, use and maintenance. Keep this booklet
carefullyfor anyfurther consultationby the variousoperators
• After removing the packaging, check the integrity of the
equipment. If in doubt, do not use it and contact qualied
personnel. The packing elements (plastic bags, expanded
polystyrene, nails, etc.) must not be left within the reach
of children as they are potential sources of danger.
• Before installing the machine, check that the installation
site is compatible with the overall dimensions.
• If it is necessary to install or remove part of the machine,
use only lifting and handling means suitable for the weight.
• Do not allow unauthorised and unqualied personnel
to start, adjust, run or repair the machine. Furthermore,
refer to this manual for the necessary operations.
• Themechanicalpartsandtheelectric/electroniccomponents
inside the machine are protected by fully closed panels.
• Before cleaning and/or servicing the machine, make sure
thatthemainswitchissetto“OFF”O inordertodisconnect
power from the machine while the operator is working on it.
• Before connecting the equipment, make sure that the
data on the plate correspond to those of the electricity
and water mains
• The electric power system must be provided with an
automatic triggering device upstream of the main switch of
themachine and a suitable earthing system whichcomplies
with all the requirements of industrial accident-prevention
standards.
• If the need arises to work on the main switch or in its vicinity,
disconnect the power to the line that the main switch is
connected to.
• All inspections and maintenance operations which
require the safety guards to be removed must be
carried out under the full responsibility of the user.
It is therefore recommended that only specialised and
authorised technical personnel perform these operations.
• Check that all the accident prevention safety
devices (barriers, guards, casings, microswitches,
etc.) are not tampered with and are in perfect
working order before operation; if not, repair them.
• Do not remove the safety devices.
• In order to avoid personal risks, use only electrical tools
which are correctly connected to the earthing system and
are compliant with the national safety regulations.
• Do not tamper with the electrical system or with
any other mechanism for any reason whatsoever.
• Wear safety gloves when cleaning the machine.
• Do not use your hands or unsuitable instruments to locate
leaks from the various hoses. Pressurised or irritating air
could cause serious harm to persons and/or property. Do
not immerse your bare hands in the hot, detergent water
of the tanks. This could cause burns and skin irritations.
If this happens, rinse them immediately and abundantly
with running water.
• Do not use your hands instead of suitable tools
to operate the machine or to stop moving parts
• PAY THE UTMOST ATTENTION TO THE RATING
PLATES ON THE MACHINE WHENEVER
OPERATING ON IT OR IN ITS VICINITY.
• The user must keep all the rating plates legible.
• The user must also replace all rating plates which for
any reason have deteriorated or are not clearly visible,
requesting new ones from the Spare Parts Service.
• In case of malfunctioning of the machine or damage
to its components, contact the maintenance
manager without performing any further repairs.
• Itisstrictlyprohibitedforanyonetousethemachineforpurposes
other than those specically intended and documented.
The machine must always be used in the ways, times and
places required by good practice standards, by current
laws in every country, even though the specic country may
not have appropriate standards that regulate the sector.
• The manufacturer will not be held liable for
accidents or harm to persons or property
resulting from failure to comply with the safety
requirements and standards indicated herein.
• These requirements, together with standards relative
to machine installation and to electrical connections,
constitute an integral part of the Industrial Accident
Prevention Regulations of each individual country.
• THESESAFETYSTANDARDSINTEGRATEANDDONOT
REPLACETHELOCAL SAFETYSTANDARDSINFORCE
• NEVER perform rushed or makeshift repairs which
could compromise correct machine operation.
• IN DOUBT, ALWAYS REQUEST THE INTERVENTION
OF SPECIALIST PERSONNEL.
• ANY TAMPERING BY THE USER RELIEVES THE
MANUFACTURER FROM ALL LIABILITY AND
MAKES THE USER SOLELY RESPONSIBLE
FOR RESPONDING TO THE COMPETENT
ACCIDENT PREVENTION AUTHORITIES.
• The appliance is not intended to be used by
persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Make sure that children do not play with the appliance.
• Itisprohibitedto spraywater onthe applianceto cleanit.
12

EN
1.1 GENERAL DESCRIPTION
Modular execution in stainless steel with the possibility of linear and single angle conguration.
Colour code that identies each module. Insulated doors counterbalanced and equipped with safety hooks integrated in the
guides. Moulded tank bottom with multiple ltration (collection lter and pump suction microlter). Wash and rinse manifolds
in stainless steel. Central guide with stainless steel rack. Self-draining washing pumps. Electric or steam heating.
2 customisable drive speeds, temperature display and alarm diagnostics.
Optional: splash guard at the entrance, autotimer, proportional rinse (PRS), proportional wash (PWS), self-cleaning, drain
pump, RCD system, HPS EASY and HPS EASY PLUS, EOR (Emergency Over Ride), homogeniser RAH, sanitising system,
boiler for cold water, detergent and rinse aid dispensers.
Optional modules: 600mm DHM2+ intensive pre-wash, 600 and 800mm linear drying, drying on 90° or 180° curve, RC heat
recovery unit, drying with ARC recovery unit, ARC with WP heat pump, WP heat pumps.
1.2 TYPE OF USE AND CONTRAINDICATIONS FOR USE
The machines were designed and built to wash dishes in specic dish racks, using detergent and rinse aid.
• Dishes permitted: pans, baking trays, trays, plates, glasses, cups, cutlery, pans, baking trays, trays, inserted in the appro-
priate dish racks, made of material suitable for dishwashers and with small dimensions for the dish rack and the machine.
• The use of all commercially available detergents and rinse aids for commercial dishwashers for industrial use is permitted.
• Do not load dish racks with a weight that exceeds 10 kg.
ATTENTION
Any improper use of the machine relieves the manufacturer from all liability for accidents to property or persons
and terminates any warranty conditions.
1.3 TRANSPORTATION, SHIPPING AND STORAGE. (Fig. 2)
• The machine is normally shipped packed in a crate, covered by a bubble wrap protection and xed to the pallet with straps.
• Use a forklift truck or pallet truck to transport the packed machine, placing the pallet on the relevant forks.
• Do not leave the machine in environments with temperatures below 0°C.
ATTENTION
The machine must only be shipped and stored sheltered against atmospheric agents.
1.4 CHECKS UPON RECEIPT
When the supply is received, check that the packages are intact and visually not damaged.
If all is intact, remove the packaging (unless different instructions are given by the manufacturer) and check that the machine
has not been damaged during transportation.
Check for any structural damage, crushing or breakage.
If any damage or imperfections are found:
1. Immediately notify the carrier either by telephone or through registered mail with acknowledgement of receipt;
2. Inform the manufacturer through registered mail with acknowledgement of receipt.
IMPORTANT
Any damage or faults must always be promptly reported within 3 days from the data of receipt of the machine.
1.5 UNPACKING (Fig. 2-3-4)
The machine is packed in a wooden crate, with bubble wrap protection and straps.
Proceed as follows to remove the machine from the packaging:
1. Cut off the straps that block the cage (2).
2. Remove the nails securing the cage (2).
3. Remove the protective lm from the machine.
4. Remove the machine from the pallet, lifting it from the bottom of the body.
5. All packaging elements must be collected and not left within the reach of children as they are sources of danger. They
must be disposed of as solid urban waste.
ATTENTION
Once the machine is unpacked, NEVER lift it by the electric components box.
Place the machine in a suitable place (as described above) and adjust the support feet (Fig. 4) to avoid possible
oscillations and make sure that the machine is completely level (use a spirit level).
Lift the machine from the bottom of the body. Place it on the forks of the forklift truck to transport it.
13

EN
1.6 MACHINE IDENTIFICATION (Fig. 5)
• The serial number and the data relating to the machine are written on the plate (3) positioned on the right
side of the electrical box.
IMPORTANT
To request technical support or to order spare parts, always include the model and serial number of the machine.
1.7 DESCRIPTION OF THE SAFETY DEVICES
• The AC2 models are equipped with a safety microswitch which blocks the washing pump in the event of
accidental opening of the tank access doors.
• Electrical parts closed by panels locked with screws.
• Equipotential earth electrode.
• The peak sound pressure level Lpc is not declared as it is well below 130dB(A).
1.8 REGULATORY REFERENCES
• The machine and its safety devices are built in compliance with the following standards:
• The essential safety requirements set out in directive 2006/42/EC, 2014/30/EC, 2014/35/EC.
• The requirements established by directive 2011/65/EU (RoHS 2).
14

USER INSTRUCTIONSUSER INSTRUCTIONS
User instructions
EN
15

EN
User instructions
CONTROL PANEL
01 02 03 05 06
04Q2
16

User instructions
EN
DISPLAY - TEMPERATURE PROBES DISPLAY
1. SUPPLY WATER TEMPERATURE PROBE 2. PRE-WASH TEMPERATURE PROBE 3. TEMPERATURE PROBE 1ST WASH 4. / 5. / 7. RINSE TEMPERATURE PROBE
MACHINE OFF MACHINE IGNITION TANK FILLING FIRST SPEED SECOND SPEED
TEMPERATURE DISPLAY TEMPERATURE PROBE ALARM TEMPERATURE DISPLAY BUTTON
H01 - LIGHT: MACHINE ENERGISED H02 - LIGHT: TANKS FULL H03 - LIGHT: CUT-OUT SWITCH ACTIVATED S1 - START/STOP BUTTON SAT - AUTOTIMER ON/OFF BUTTON FIRST SPEED PWS ACTIVATION BUTTON (OPTIONAL)
CONTROL PANEL DESCRIPON
01 02 03 04
06 05
S26 - BUTTON (OPTIONAL):
• SELF-CLEANING AND DRAIN CYCLE • SELF-CLEANING CYCLE • DRAIN CYCLE
HAT - LIGHT: AUTOTIMER ACTIVE H26 - LIGHT: SELF-CLEANING OR DRAIN CYCLE ACTIVE
17

EN
User instructions
2.1 BEFORE COMMISSIONING
Before use make sure that:
• the wall switch is on;
• the water and steam (*) gate valves are open;
• there is no water or steam (*) shortage;
• the tank and pump suction lters are in place;
• the overow is inserted;
• the curtains are positioned correctly;
• the inspection doors are closed;
• the temperatures are as prescribed, i.e. approx. 55°C for washing and approx. 85°C for rinsing;
• the detergent and rinse aid containers are full;
• the dimensions of the dishes to be washed do not exceed the useful washing dimensions;
• the crockery used is not old or otherwise cracked, as the roughness offers more grip for dirt and shelter for
bacterial ora.
• Knives and other sharp tools must be placed in the dish rack with the tips pointing downwards or horizontally
in order to avoid causing injury
(*) only for machines with steam heating.
2.2 OPERATION AND USE
2.2.a Powering on
Turn on the machine by turning the selector “Q2” into the
“I” position.
The light “H01” comes on. Tank lling will commence.
Coming on of the light “H02” indicates that the tanks are full.
The temperature regulation will be activated.
It is possible to view the temperatures on the display by repeatedly pressing
the “04”button.
Wait for the washing temperature to reach 55/60°C.
At this point the machine is ready to start the washing operations.
Using selector “Q2”, select the forward speed of the dish racks according to the type of dirt:
-pos.I: rst speed, for very dirty plates or dishes;
-pos.II: second speed; for normally soiled plates or dishes;
Press the “S1” button to start or stop the washing operations.
The “H03” light indicates that one of the motors has overheated, therefore
the intervention of a technician is required.
The machine is equipped with an automatic reset Autotimer: the dishwasher stops if it runs empty without
dishes. It restarts automatically with the insertion of the dishes.
The autotimer cannot be deactivated.
18

User instructions
EN
2.2.b Dishwashing
1. First remove solid leftovers and any oily mas-
ses.
This operation is not necessary for machines
equipped with DHM2+.
2. Perform prior soaking of the cutlery and also of
the dishes when they are being washed a long
time after use.
3. Arrange the dishes in the appropriate dish racks.
Knives and other sharp tools must be placed in
the dish rack with the tips pointing downwards or
horizontally in order to avoid causing injury
4. Push the dish rack towards the entrance of
the machine. The drive bar will automatically
advance it along the entire washing tunnel.
5. Make sure that the dishes in the dish racks
are facing the exit of the machine and that the
trays in the relative dish racks are parallel to
the direction of advancement of the drive bar.
6. If the operator is unable to remove the dish racks
from the outfeed shelf, a limit switch ensures
that the drive and rinsing stops. To resume
work, simply remove the dish rack from the limit
switch.
ATTENTION
When the items being washed have burned encrustations or an extended amount of
time has passed before washing, they must be soaked in water with an appropriate
emollient product.
Do not use manual washing products as they could generate foam inside the machine.
19

EN
User instructions
2.2.b.1 Machines equipped with automatic reverse osmosis rinsing (Optional)
The machines equipped with automatic reverse osmosis rinsing are fitted with various sensors which are used
to detect the stainless steel dish racks. When one of these dish racks enters the machine, the pre-wash is
deactivated and the rinse with osmotic water is activated.
2.2.c EOR function
(transfer of commands in the event of a fault on the electronic board)
In case of a fault with the electronic board, it is
possible to continue the washing operations
using the EOR function. On the left-hand side
of the control panel, start the dishwasher by
turning the key to position 1.
To stop the dishwasher, press the emergency
button or open one of the doors.
2.2.d Manual drain for machines equipped with drain pump (Optional)
Turn selector “Q2” to position “I” .
Press the "S26" button.
The “H26” light coming on indicates its activation.
At the end of the drain cycle, press the "S26" button again before turning
the Q2 switch to "O" to switch off the machine.
20
