OPERATION MANUAL
H-422
40/20/15/10M Quad-Band Trapped Dipole Antenna
Features:
1. New compact design for even the most restrictive mounting locations, providing
wide band-width in a small footprint.
2. Assemble as either a “straight” dipole, and/or in a “V” configuration. When
assembled in the “V” shape, good performance is provided even from a minimum
height of only 10 feet!
3. CBL-2000 high power 2kW/SSB balun is included, and helps to prevent TVI and
other interference.
4. Specially designed high power traps assure constant high power QSOs
5. Three radiator lengths - Low - Mid - High – are illustrated for easy tuning.
Specifications:
Frequencies: 7, 14, 21, 28MHz
Impedance: 50 Ohm
VSWR: Less than 1.5:1 at center frequency
Max Power Input: 1kW SSB / 500W FM
Max Wind Survival: 67MPH
Wind Load: 3.01 sq ft
Length: 33’10” (straight assembly)
24’ 5” (V assembly)
Weight: 11’ 14”
Rotation Radius: 17’ 5” (straight assembly)
12’ 6” (V assembly)
Req’d Mount Mast: 1.5” – 2.5” diameter

40M band angle of radiation in the
horizontal (straight) configuration
10 feet above ground 33 feet above ground
40M band angle of radiation in the
“V” configuration
10 feet above ground 33 feet above ground
