Comfee MJ-WJS2009PW2 User manual

Instruction Manual
Model:
Please read the manual before operating your kettle.Retain it for future
reference.
MJ-WJS2009PW2
JUICER

1
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. Read all instructions.
2. To protect against risk of electrical shock, do not put cord, plug,
base, or motor in water or other liquid.
3. This appliance is not intended for use by persons (including
children) with reduced physical, sensory, or mental capabilities, or
lack of experience and knowledge, unless they are closely
supervised and instructed concerning use of the appliance by a
person responsible for their safety. Close supervision is necessary
when any appliance is used by or near children. Children should be
supervised to ensure that they do not play with the appliance.
4. Unplug cord from outlet when not in use, before putting on or
taking off parts, and before cleaning.To unplug, grasp the plug and
pull from the outlet. Never pull from the power cord.
5. Avoid any contact with blades or moveable parts.
6. Do not operate any appliance with a damaged cord or plug, or after
the appliance malfunctions, or is dropped or damaged in any
manner. Call our toll-free customer service number for information
on examination, repair, or electrical or mechanical adjustment.
7. The use of attachments, including canning jars, not recommended
or sold by the appliance manufacturer may cause a risk of injury to
persons.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter or touch hot
surfaces, including stove.
10.This appliance is intended for household use only. Use for food or
liquids only.
11.Always make sure juicer cover is clamped securely in place before
motor is turned on. Do not unfasten clamps while juicer is in
operation.
12.Be sure to turn switch to OFF position after each use of your
juicer. Make sure the motor stops completely before disassembling.

IMPORTANT SAFEGUARDS
2
13.Do not put your fingers or other objects into the juicer opening
while it is in operation. If food becomes lodged in opening, use food
pusher or another piece of fruit or vegetable to push it down. When
this method is not possible turn the motor off and disassemble juicer
to remove the remaining food.
14.Do not use the appliance if the rotating sieve is damaged.
15.Do not operate without the pulp container in place.
16.This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit
into a polarized outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
17.A. A short power supply cord is provided to reduce the risk
resulting from becoming entangled in or tripping over a longer cord.
B. Extension cords are available and may be used if care is exercised
in their use.
C. If an extension cord is used
(1) the marked electrical rating of the extension cord should be at
least as great as electrical rating of the appliance
(2) the longer cord should be arranged so that it will not drape over
the counter or table top where it could be pulled on by children or
tripped over unintentionally.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY

Juice cup lid
Drive shaft
Filter
Fine strainer
Juice cup
Main unit
Pusher
Note: The above picture is only for reference since the appearance of the product has lightly difference,
please see the real product in the package.
Ice cream strainer
Juice collector
Plup collector
Cleaning brush
3
Product technical parameters
Parts name and accessories
Product name
Juicer
Power Capacity Model
MJ-WJS2009PW2
Voltage
120V~
Frequency
60Hz Max.200W 1.0L

1. How to assemble the seasoning valve at the bottom of the juicing
cup.
Push the seasoning valve at the bottom of the juicing cup into the
"Hard fruits" position in the direction shown.
Note: The seasoning valve must be installed in place; otherwise
there will be leakage problems.
4
Cautions Before Use
Assembly Method
1.Please do not operate the product continuously. If it exceeds 20 minutes, please stop and cool for
20 minutes before continuing juicing to prevent damage to the product.
2.For ingredients with high fibre content (celery, etc.), please cut into pieces around 5 to 10 cm long
and 1.5 to 2.5 cm width before putting into the machine. (For fibre rich ingredients, it is best to cut
into pieces no more than 3 cm long, then slowly put into the machine.)
3.Extremely hard ingredients such as cereals, sugar cane and ginger are not suitable for juicing.
4.For hard seed ingredients such as cherries, grapefruit, etc., please make sure to deseed; For lemon,
orange and other fruits, it is best to be peeled and deseeded, so as it will not affect the fruit juice
taste.
5.When processing harder fruits and vegetables, the machine will experience "squeaky" fricative
sounds, and the product may experience slight shaking. This situation is normal and please uses it
with confidence.
6. Please use fresh fruits and vegetables for juicing, for fruits and vegetables stored in the refrigerator,
soak in water for more than 10 minutes before processing, the effect will be better.
7. When processing fruits and vegetables with deeper pigments, such as carrots, beetroots, etc., there
will be mild staining of the juice cups and other parts, which is a normal situation.
8. Before starting the machine, please confirm that the juice cup lid is installed in place.
9. When putting in ingredients, it should be put in slowly one by one; the ingredients must be
processed before putting in the next ingredients.
Seasoning valve
Complete installation in position
Hard fruits
Soft fruits
2.Install the juice cup onto the main unit.
Align the juicing cup to the fixed point on the main unit and push
down, and rotate the juicing cup lightly until it is installed in place. Fixed point

5
3.Install the filter into the juicing cup.
4.Install the drive shaft into the middle of the filter and press down
until it stops.
5.Install the juice cup lid.
Align “ ” on the juice cup lid with “▲”on the juicing cup, turn
the juice cup lid clockwise so that the juice cup cover “ ”
could align with “▲”on the juicing cup.
6.As shown in the figure, place the juice collector and pulp
collector.

Functional Description
Usage
6
Juice: For squeezing fresh juice.
Off: Stop the machine after the juicing process is completed.
Reverse: Lifts the fruits and vegetables upwards, solve the stuck issue when juicing; the stuck issue
occurs during the process of juicing or making ice cream; the machine reverses to protect
the machine from overloading of ingredients or hardened ingredients, and corrects the juice
extraction process.
Ice cream: For making fruit and vegetable ice cream.
Self clean: Simple cleaning for juicing system.
The respective fruits correspond to seasoning valve:
Soft fruits: soft fruit: orange, watermelon, red grape, pineapple, cucumber, tomato, ice cream
Hard fruits: hard fruit + fibre rich Ingredients: apple, pear, celery, carrot, pomegranate
Warning
1. Please do not press the button with wet hands. It is prohibited to idling products for a long period
Pusher
Knob
Fruit and
vegetable
cubes
Chute
Soft fruits
Hard fruits
Hard fruits
Soft fruits
Soft fruits
2. When the machine suddenly stops during operation, first revolve the knob to the “Stop” position,
then revolve to the “Reverse” position, so that the ingredients held in the drive shaft would be
pushed up, and then presses the button to the “forward” position. (Repeat three times or so).
Warning
①When the machine is in the “Reverse” mode, please hold the juice cup lid gently with your
hand (to prevent the juice cup lid getting loose).
②After the above operation, if it still does not operate, please remove the juice cup and wash
completely.
1. Put the washed large pieces of fruits and vegetables into the feeding
chute, turn the knob to pour the fruits and vegetables into the feeding
chute, and put the small pieces of fruit and vegetables from the small
feeding chute. After putting the material, push the material with a
pushing rod.
Note:
Please use fresh fruits and vegetables for juicing, for fruits and
vegetables stored in the refrigerator, soak in water for more than
10 minutes before processing, the effect will be better.
Warning
①This product is not suitable for crushing cereals, sugarcane and
other hard fruits.
②For fruits with hard cores, remove cores before juicing.
③For celery and other coarse fiber fruit, washing after juicing 0.5Kg.

Disassembly Method
7
3. You may keep the juice outlet lid closed during juicing. When the
juice output reaches a certain quantity, open the lid and receive the
juice with the juice collector.
Benefits:
①Reduce the exposure to air and slow down the oxidization
process.
②A variety of fruits and vegetables can be used to extract the
mixed fruit juice.
Juice
outlet is
closed
Juice
outlet is
open
4. After the juicing process, revolving the button to the "Off"
position and unplug the power cord.
Recommendations:
Please do not store the squeezed juice for long time.
1. Press the button to stop the machine and unplug the power cord.
Recommendations:
After the juicing process, revolving the knob to the "Reverse" position and hold for few seconds
for easy disassembly and cleaning.
2. Grasp the juice cup lid by hand, and rotate the juice cup
cover counter-clockwise as shown in Fig. ①, rotate to the
position shown in Fig. ②and pull up the juice cup lid to
disassemble.
3. Grab the juice outlet on the juicing cup and lift it upwards
to disassemble (see Figure ③).

Ice cream making method
8
4. Take out the drive shaft and filter assembly (as shown in
Fig. ④).
Mango and Banana Ice cream
①Cut the mango meat and banana into small cubes, and freeze for 8-12 hours in freezer.
②Remove from freezer and thaw the frozen fruits for few minutes under room temperature to relieve the
hardness;
③Place the special ice cream filter into the juicer, start the machine, put the frozen mango and banana pieces in
the feeding chute.
④The ice cream could be consumed directly.
Reminder: the banana ice cream should be consumed as soon as possible.
5. Disassemble the drive shaft and filter separately (as shown in
Fig. ⑤).
Please put fruits such as bananas (peeled), durian (deseeded), and strawberries (capped) in the
freezer for more than 8 hours. Place the special ice cream filter into the juicer. Thaw the frozen fruits
for 15 minutes before making, start the machine, and slowly put the fruits into the juicer to make
authentic fruit-flavoured ice cream.
Operating steps
1. Put the juice cup on the slag outlet and pick up the ice cream;
2. Push the seasoning valve to "Soft fruits";
3. Revolve the knob to “Ice cream”;
4. Ice cream will be discharged from the slag outlet.
Tips
When making fruit ice cream, you may add frozen milk according to personal taste (the frozen
ingredient needs to be thawed at room temperature until the surface slightly soften (more than 20
minutes of thawing in winter and more than 15 minutes in summer), and slowly mix it into the juice
machine to make a delicious ice cream.
Winter: Thawing time is more than 20 minutes; Summer: Thawing time is more than 15 minutes.
Put the frozen ingredients slowly into the feeding chute, the feeding interval has to be more than 5
seconds.

Care and Cleaning
Dragon fruit ice cream (May add in yoghurt or milk a ccording to personal taste)
①Peel the dragon fruit, cut into small cubes, and freeze for 8-12 hours in freezer.
②Remove from freezer and thaw the frozen fruits for few minutes under room temperature to
relieve the hardness;
③Place the special ice cream filter into the juicer, start the machine, put the frozen dragon fruit
pieces in the feeding chute.
④Use a push rod to gently press the fruit cubes, place the ice cream container under the slag
outlet, the dragon fruit ice cream is ready;
⑤Remove the filling from the biscuits, place it in a zip lock bag and close it tightly, break the
biscuits and serve with the ice cream.
Reminder: the dragon fruit ice cream should be consumed as soon as possible.
Peach ice cream
①Wash and peel the peach, take the peach meat cut into small cubes, and freeze for 8-12 hours in
freezer.
②Put fresh milk into refrigerator;
③Remove the prepared peach from freezer and thaw for few minutes under room temperature to
relieve the hardness;
④Put the frozen peach cubes in the feeding chute, add fresh milk according to personal taste;
⑤Use a push rod to gently press the fruit cubes, place the ice cream container under the slag
outlet, the peach ice cream is ready;
⑥Add in the favourite jam to make peach fresh milk ice cream.
Reminder: the peach ice cream should be consumed as soon as possible.
Cleaning
1. Wash each disassembled part with running water. If residues plug the filter mesh, please wash
the filter with a cleaning brush.
Note: please do not wash by using iron brush and sharp washing tool.
9

Any other servicing should be performed by an authorized service representative.
Maintenance
1. This product shall be used frequently to keep the motor dry.
2. For prolonged storage, keep it in a dry and ventilated place to prevent the motor from moisture
and affecting normal usage.
3. After cleaning, dry the washed parts and store them in a clean and well-ventilated place.
Note:
①As the dried slag may affect the disassembly and cleaning, and it may also cause deterioration
of performance. Therefore, it should be washed in time after each use.
②The rubber gasket below the juice cup is removable and washable.
Special reminder:
When washing, push the seasoning valve back and forth for easier cleaning.
10
2. Do not immerse the main unit into water, only use damped soft cloth to wipe clean.

Specifications
Product
Model
Rated voltage
Rated frequency
Power
120V~
60Hz
Max.200W
:
:
:
:
:
JUICER
MJ-WJS2009PW2
