Command Communications Guest Page GP-30 Manual

Table of Contents
Guest Page System – System Overview...............................................…. 3
Unpacking Guest Page............................................................................… 3
Component Overview............................................................................…. 3
Guest Page System, Model GP-30
Expansion Panel................................................................…................…. 4
C arging Rack..................................................................................…..… 4
Rec argeable Coaster Pager...........................................................……. 5
Installation and Operation................................................................….… 5
Installing t e Guest Page Transmitter..................................................… 6
Installing t e Antenna............................................................................… 6
Installing t e Expansion Panel..............................................................… 6
C arging Rack........................................................................................… 6
C arging t e Batteries .......................................................................… 6
Replacing Batteries….............................................................................… 6
Programming.........................................................................................…. 7
Programming t e Guest Page System Code.........................................… 7
Programming t e Coaster Pager............................................................... 7
Paging..................................................................................................…... 8
Normal Paging
Urgency Paging
Receiving a Page......................................................................………….… 8
Coaster Pager
In-Range Indication…………………………………………………..………… 8
Turn ON t e Pager..................................................................................… 8
Turn OFF t e Pager.................................................................................... 8
Low Battery Indication of Pager................................................................ 8
Two year limited warranty/Service information................................…… 9
International return policy................................……………….................... 10
FCC Rules Part 95................................…………………………………….… 10
Guest Page Operator's Guide 2

Model: GP-30 Guest Page System
System Overview
Guest Page System, Model GP-30, has a built-in transmitter that can page from 1 to 30 pagers. An
xpansion panel can be connected to enable the transmitter panel to page from 31 to 60 pagers.
The system works with rechargeable coaster pagers.
The System is designed to support a paging area of up to one mile. Paging distance may vary
depending on conditions.
Unpacking Guest Page
When you open the Guest Page box for the first time, inspect the contents. In the box you should find all of the items
needed for installation:
■ GP-30 Transmitter ■ 10” Antenna ■ Power Adapter ■ Mounting Bracket and four screws
If any of these items are missing or damaged, contact the dealer where you purchased the unit, or call the number listed
in the “Service Information” section of this guide.
Component Overview
Guest Page System, Model GP-30
1. ON/OFF switch
2. Power input jack - plug the supplied 12V DC power
adapter here
3. 5-pin DIN socket – used for connection of
xpansion panel
4. Power and transmitting indicator
■ Solid Red when the system is powered
■ Flashes when the system is transmitting
5. Page button
Pages the corresponding pager or cancels the page.
6. Page indicator light
■ Solid red when the Guest Pager or Coaster Pager
is paged
■ Flashes when a page receives no response after
approximately 3 minutes, or when an urgency
page is activated.
7. U Button - urgency page
8. * Button - turns all pagers OFF
9. Antenna connector
10. Antenna
11. Magnetic pager OFF contact point
12. Mounting bracket screw holes
Guest Page Operator's Guide 3

Expansion Panel (optional)
The xpansion Panel is used for larger systems requiring
more than 30 pagers. It expands the system to a maximum
of 60 pagers.
1. 5-pin DIN sockets - for connection to Guest Page
Transmitter
2. Power and transmitting indicator
Solid Red when the system is powered
Flashes when the system is transmitting
3. Page button - pages the corresponding pager, or
cancels the page
4. Page indicator light
Solid red when the Guest Pager or Coaster Pager
is paged
Flashes when a page receives no response after
approximately 3 minutes, or when an urgency
page is activated.
5. U Button - urgency page
6. Mounting bracket screw holes
C arging Rack
The charging rack is capable of charging a maximum of 30 pagers. It has 2 positions for stacking the rechargeable
coaster pagers. The charger is powered by a wall adapter that is plugged into a 120VAC wall outlet. The rack also
serves as a place to store the pagers when not in use. Pagers automatically turn ON when removed from the charging
rack and automatically turn OFF when placed on the charging rack.
The installation is simple. Place the charging rack on a flat surface and plug the wall adapter into an outlet.
Guest Page Operator's Guide 4
Wall
Adapter
Alignment
Marks
Charging Positions

Rec argeable Coaster Pager
The pager is equipped with 4 red, 4 green and 1 yellow L D plus a vibrating function. The pager will vibrate and flash
the red and green L Ds when paged. It is powered by 2 AAA rechargeable NiMH (Nickel Metal Hydride) batteries
which are included. The features are shown below.
Features of the Rechargeable Coaster Pager
Installation and Operation
Installing t e Guest Page Transmitter
The location of the system should be readily accessible to all
staff that will be using the system. Since this unit contains a
transmitter, obstructions such as walls, pipes, ducts, mirrored
glass, or other similar barriers may weaken or misdirect
transmitted signals. Certain materials and/or building
characteristics, especially metal, have the potential to
partially or completely block the signal. Be sure the unit is
securely mounted and safe from liquids, extreme heat, and
possible physical damage. Operate the transmitter with
the antenna in a vertical position.
Installing t e Antenna
Connect the antenna to the antenna jack on top of the Guest Page Transmitter and turn the antenna’s connector clockwise
until the antenna locks into place. For proper operation, the antenna must be in a vertical position.
Installing t e Expansion Panel
The Guest Page Transmitter and xpansion panel are interconnected and communicate through a 5-wire data link cable.
Refer to the System diagram (above). Plug the connector into the 5-pin socket located on the bottom of the xpansion
panel, then turn the fastener clockwise until tightened.
Note: The Guest Page Transmitter will check the connection of the xpansion panel when the system is turned ON. DO
NOT “power on” the Guest Page Transmitter until the connection is complete.
Guest Page Operator's Guide 5
Charging
Contact
Status
Alignment Pin
Number
abel
In range ED
Charging Contact
Battery
Compartment
23
Guest Page
Transmitter Expansion
Panel

C arging Rack
The charging rack is capable of charging a maximum of 30 pagers. It has 2 positions for stacking the rechargeable
coaster pagers. The charger is powered by a wall adapter that is plugged into a 120VAC wall outlet. The rack also
serves as a place to store the pagers when not in use. The installation is simple. Place the charging rack on a flat surface
and plug the wall adapter into an outlet.
C arging t e Batteries
While the pagers are stacked on the charging rack, the batteries are automatically charged. There is a green and red L D
in each pager located on either side of the alignment mark. A flashing green L D indicates the pager is ready for use. A
flashing red L D indicates the pager is charging and is not ready to be used. Recharging takes approximately 2 to 3
hours. If the red L D continues flashing after being on the charging rack overnight, the batteries are defective and need
to be replaced.
Replacing Batteries
WARNING
After 1 to 2 years use, the batteries may need replacing. ach pager is powered by two AAA Nickel Metal Hydride
(NiMH) batteries (supplied). Only use nickel metal hydride (Ni H) batteries. Replace both batteries. To replace
the pager’s batteries, follow these steps:
1. Loosen the battery door screw and open the battery door.
2. Insert 2 fresh AAA Nickel Metal Hydride (NiMH) batteries as indicated by the polarity symbols (+ and -)
marked inside the battery compartment.
3. Close the battery door and fasten the screw.
Only use nickel metal
hydride (NiMH) batteries.
Replace both batteries.
Guest Page Operator's Guide 6
DO NOT use alkaline or any other type of non-
rechargeable batteries. If recharged, alkaline batteries
may explode or leak causing damage and voiding the
arranty. ONLY USE NiMH (Nickel Metal Hydride)
BATTERIES WHEN REPLACING BATTERIES.
Screw
Battery
Compartment

Programming t e Guest Page System
Programming t e Guest Page System Code
Before you use the system, you should designate your own system code ( 00-99 ). The system code ensures proper
signaling between the Guest Page Transmitter and pagers.
To program the system code, follow these steps:
1. Power OFF Guest Page Transmitter
2. Press and hold U button
3. Power ON Guest Page Transmitter
4. Continue holding U button (about 2 seconds) until all 10 L Ds turn ON
5. Press the first digit of system code from Page button 1-10; the corresponding L D will turn OFF. The power
indicator light will flash for 2 seconds
6. Press the second digit of system code from Page button 1-10; the corresponding L D will turn OFF. The
power indicator light will flash for 2 seconds
7. The new system code is now stored. All L Ds will turn OFF after 2 seconds
8. If you enter a wrong code, repeat steps 1 through 7 to reset the system code
9. The system will return to normal mode if the programming process is not completed within 60 seconds
For example setting the system code to 58:
1. On step 5, press Page button 5
2. On step 6, press Page button 8
Programming t e Coaster Pager
ach pager must be programmed or taught its number before it can be used in the system.
The first time the pager is used, please be sure to firmly pull and remove the plastic shipping tab on the bottom of the
pager to activate the battery.
1. Remove the coaster from the charging rack to turn it on. After the vibrations and flashing lights stop, you have
10 seconds to press and hold the Status button for 5 seconds; the Coaster will vibrate once and the green L Ds
will flash.
2. When the green L Ds flash, the Coaster is in the learn mode.
3. Press the Page button on the Guest Page Transmitter corresponding to the Coaster’s number. This initializes the
Coaster.
4. The Coaster will flash the green L Ds 5 times and vibrate once to confirm that it has learned its code
successfully.
5. Press the corresponding Page button again; the red light will turn off. If the Page button is not turned OFF, the
Coaster Pager will receive a page.
6. If you enter a wrong setting, repeat steps 1 through 5.
Note: Pager number label -- stick the number label on the pager when the pager has learned the code. If a pager is
assigned another pager number, remove the old number label and replace with a new number label.
Guest Page Operator's Guide 7

PAGING
Normal Page
Press the Page button on the Guest Page Transmitter corresponding to the pager you want to page. The panel L D
will light and the system will page the corresponding pager until you press the same Page button to cancel the page.
The panel L D will begin flashing quickly if the guest has not responded to the page within 3 minutes.
When the pager is returned, press the Page button and the panel L D will turn OFF. To turn the Coaster OFF, see
Method 1 on page 5.
Urgency Paging
This function can be used to increase the number of times the pager vibrates, from every 60 seconds, to every 20
seconds. Press the U button and the corresponding Page button; the Page button L D will flash slowly. The Page
button L D will begin flashing quickly if the guest has not responded to the page within 3 minutes.
Receiving a Page
Coaster Pager
When a Coaster Pager receives a normal page, it will vibrate once and alternately flash the red and green L Ds.
Then the pager will vibrate and flash every 60 seconds and the red L Ds will flash once every 12 seconds as a
reminder.
When receiving an urgency page, the pager will vibrate once and alternately flash the red and green L Ds. The
pager will then vibrate and flash every 20 seconds and the red L Ds will flash once every 12 seconds as a reminder.
In-Range Indication
The Guest Page System automatically sends an in-range signal to all pagers periodically.
If a pager is within the reception area, the yellow L D will be lit.
If a pager is out-of-range and does not receive the in-range signal for approximately 2 minutes, the yellow in-range
L D indicator will start flashing. The pager turns off after 8 hours.
Turn ON t e Pager
The first time the pager is used please be sure to firmly pull and remove the plastic tab on the bottom of the pager to
activate the battery. This tab prevents the batteries from discharging during shipment.
The pager automatically turns ON when removed from the charging rack.
If the batteries are ready for use, the pager starts to vibrate. It will vibrate 3 times and the green and red L Ds will
alternately flash 2 times.
If the batteries are discharged and not ready for use, the red L D to the right of the alignment mark will flash and
the pager turns itself off. Place the pager on the charging rack until charged and ready for use. This is indicated by
the flashing green L D located to the left of the alignment mark on the pager.
Turn OFF t e Pager
Place the pager on the charging rack. The pager is automatically turned OFF when on the charging rack. While on
the charging rack, a flashing green L D indicates the pager is ready for use while a red L D indicates the batteries
are charging and the pager should not be used. Pagers should remain on the charging rack when not in use.
Guest Page Operator's Guide 8

Two year limited warranty/Service information
WARRANTOR: Command Communications, Inc.
L M NTS OF WARRANTY: Command Communications, Inc. warrants, for the duration of this warranty, the Guest
Page System (hereafter referred to as the "Product") to be free from defects in materials and craftsmanship with only the
limitations or exclusions set out below.
WARRANTY DURATION: This warranty shall terminate and be of no further effect two years after the date of original
purchase of the Product or at the time the Product is (A) damaged or not maintained as reasonable and necessary, (B)
modified, (C) improperly installed, (D) repaired by someone other than the warrantor for defect or malfunction covered
by this warranty, ( ) used in a manner or purpose for which the Product was not intended, (F) damaged by an act of God
(such as a lightning strike), or (G) sold by the original purchaser.
STAT M NT OF R M DY: In the event the product does not conform to this warranty at any time that this warranty is
in effect, the warrantor shall repair the defect, return it to you without charge for parts, service, or any other costs
incurred by the warrantor or its representative in connection with the performance with this warranty. This warranty does
not cover or provide for the reimbursement or payment of incidental or consequential damages. Some states do not allow
this exclusion or limitation of incidental or consequential damages, so the above exclusion or limitation may not apply to
you.
S RVIC INFORMATION/PROC DUR FOR OBTAINING P RFORMANC OF WARRANTY:
1. Pack the Guest Page System in the original carton or equivalent.
2. nclose a copy of the bill of sale or other documentation showing original purchase date.
3. Contact the dealer where you purchased the Guest Page System, or call one of the service centers listed
below to obtain a return material authorization number (RMA #).
4. Mail the above prepaid and insured to the warrantor at:
Command Communications, Inc. Customer Service: 1-888-843-4399
14510 ast Fremont Street
Centennial, CO 80112 Customer Service email:
techsupport@commandcommunications.com
Voice: (303) 792-0890
FAX: (303) 792-0855 Web Site: www.commandcommunications.com
Command Communications, Inc. cannot be held responsible for any loss or damage in transit.
Please retain proof of purchases to establish date of original purchase. Your warranty starts with the date of original
purchase.
L GAL R M DI S: This warranty gives you specific legal rights, and you may also have rights that vary from state to
state.
Though every effort has been made to ensure accuracy, these instructions may include technical or typographical errors.
Content of these instructions may be changed from time to time due to product improvement. These changes will be
incorporated in new editions of these instructions. We disclaim liability for any changes, errors, or omissions.
NOTE: Any unit returned without an R A # clearly marked on the exterior package will be refused and
returned at the sender's expense.
Guest Page Operator's Guide 9

International return policy
If this product is purchased outside the U.S. from an authorized Command Communications' dealer, it should be
returned for repair at the location where it was purchased, as provisions have been established to handle warranty repair
outside the U.S.
If you send the product directly to Command Communications for repair, you will be responsible to pay all freight,
handling, and Custom charges (both ways).
FCC Rules Part 95
WARNING: Do not make adjustments that could result in a violation of the rules or that are recommended to be
performed by or under the immediate supervision and responsibility of a person certified as technically qualified to
perform transmitter maintenance and repair duties in the private land mobile services and fixed services by an
organization or committee representative of users of those services.
WARNING: Replacement of any transmitter component (crystal, semiconductor, etc.) could result in a violation of the
rules.
www.commandcommunications.com
© 2007 Command Communications, Inc.
All rights reserved.
Printed in USA
COMMAND COMMUNICATIONS and
the Arrow logo are registered trademarks of
Command Communications, Inc.
14510 ast Fremont Street
Centennial, CO 80112
technical support email: techsupport@commandcommunications.com
Customer Service 888-843-4399
GSS06202007
Guest Page Operator's Guide 10
Table of contents
Other Command Communications Microphone manuals
