Commercial LED CLF4-100P Series Service manual

INSTALLATION INSTRUCTION MANUAL
LED FLOOD LIGHT, 100-277VAC
Rev AJuly 2017
SERIES:
CLF4-100PXYYZZ;CLF4-150PXYYZZ
Model description :X=CCT(3=3000K,4=4000K,5=5000K)
YY=Mounting Type(YK=Yoke SF=Slip fitter MA=Arm TR=Trunnion) ZZ=Finish Color
Model number parameter list:
Item
Model
Input Voltage
Power
Factor
Watt
Input
Current
Weight
A
CLF4-100PXYYZZ
100-277VAC
>0.9
100W
1.5A
6.2kg
B
CLF4-150PXYYZZ
100-277VAC
150W
1.8A
6.25kg
S F
M A
T R
YK
Commercial LED
PO BOX 668755, Pompano Beach, FL 33066
www.comm-led.com
[email protected]

1.Introduction
This LED Flood light uses the latest in solid state lighting technology for long life, low
maintenance, and high efficiency.
The same as traditional HID lighting. There are two installation methods, suitable for various
occasion.
An internal power-factor-corrected switch-mode supply allows it to be used from
any nominal 100-277V, 50~60Hz AC supply without any variation in light output.
Suitable for use in the following locations:
• Ambient Temp: -40~+40°C
• Wet Locations
Note: Save these instructions for future reference.
2.Installation
For supply connections use wire rated for at least 90°C
Warning:
To avoid the risk of fire, explosion, or electric shock, this product should be installed,
inspected, and maintained by a qualified electrician only, in accordance with all applicable
electrical codes.
Warning:
To avoid electric shock:
•Be certain electrical power is OFF before and during installation and maintenance.
•Luminaire must be connected to a wiring system with an equipment-grounding conductor.
Warning:
To avoid explosion:
•Make sure the supply voltage is the same as the rated luminaire voltage.
•Do not install where the marked operating temperatures exceed the ignition temperature of
the hazardous atmosphere.
•Do not operate in ambient temperatures above those indicated on the luminaire nameplate.
•Keep lens tightly closed when in operation.
Commercial LED
PO BOX 668755, Pompano Beach, FL 33066
www.comm-led.com
[email protected]

CLF4-100PXYYZZ
CLF4-150PXYYZZ
Installation Steps:
Refer to the following diagram when you install the fixture. Seven installation methods, directly fix to the
mounting surface or fix to a post with a knuckle.
1. Directly fix to mounting surface
2.Mounting with a Slipfitter for Models:
CLF4-100PXYYZZ;CLF4-150PXYYZZ
Step 1
Adjust the fixture orientation by turning the bolt, in the
above photo for the rocker installation hole.
Step 2
Please use a post of diameter 2.36” for mounting,
and tighten with screws.
1.Use expansion bolts to secure the fixture on mounting surface.
2.Keep enough length wires to ensure adjusting angle unhindered.
Connect wires into wiring terminal; white wire to “Neutral” terminal, black wire to “Live” terminal,
green wire to “Ground” terminal; and fix them by screws.
Wall
L(Black)
N(White)
G(Green)
Commercial LED
PO BOX 668755, Pompano Beach, FL 33066
www.comm-led.com
[email protected]

3.Mounting with Arm for Models:
CLF4-100PXYYZZ;CLF4-150PXYYZZ
Directly with the screw on the lamp post.In the above straight arm has a reserved light installation hole, for
the sensor installation hole in the bottom.You can open the side cover from the side connection.
4.Wall mounted installation
CLF4-100PXYYZZ;CLF4-150PXYYZZ
The mounting method of the straight arm is added to a wall mounted fixing plate, and the fixing plate is
mounted on the wall, and the fixing plate is fixed by a nut.
After installation, please
Check whether the lighting fixture is firmly fixed.
Check whether wires are connected correctly.
At last, turn on the power, and check if the lighting fixture works well. If not, please turn off the power
and contact with local dealer.
