Comms365 H900 User manual
C365-4G-H900
COMMS365 H900 4G Router
(and C365-5G-H900 Options where applicable)
PART 2
USER MANUAL
2
C365-4G-H900 User Manual CB-V1 (May 2020)
Contents
3.5.7 SMS……………………………………………………………………………………………………………………………………… 3
3.5.8 VPN……………………………………………………………………………………………………………………………………… 11
3.5.8.1 IPSEC…………………………………………………………………………………………………………………………………. 11
3.5.8.2 PPTP…………………………………………………………………………………………………………………………………. 15
3.5.8.3 L2TP………………………………………………………………………………………………………………………………….…18
3.5.8.4 OpenVPN………………………………………………………………………………………………………………………….20
3.5.8.5 GRE Tunnel……………………………………………………………………………………………………………………….21
3.5.9 DDNS…………………………………………………………………………………………………………………………………….23
3.5.10 Connect Radio Module………………………………………………………………………………………………….27
3.6 Network Configuration………………………………………………………………………………………………………28
3.6.1 Operation Mode…………………………………………………………………………………………………………………28
3.6.1.1 LAN Ethernet Ports……………………………………………………………………………………………………………29
3.6.2 Mobile Configuration……………………………………………………………………………………………………….29
3.6.3 Cell Mobile Data Limitation…………………………………………………………………………………………….34
3.6.4 LAN Settings………………………………………………………………………………………………………………………..35
3.6.5 Wired-WAN…………………………………………………………………………………………………………………………38
3.6.6 Wi-Fi Settings……………………………………………………………………………………………………………………..40
3.6.6.1 Wi-Fi General Configuration………………………………………………………………………………………..40
3.6.6.2 Wi-Fi Advanced Configuration…………………………………………………………………………………..41
3.6.6.3 Wi-Fi Interface Configuration……………………………………………………………………………………..42
3.6.6.4 Wi-Fi AP Client………………………………………………………………………………………………………………….44
3.6.7 Interfaces Overview………………………………………………………………………………………………………….46
3.6.8 Firewall…………………………………………………………………………………………………………………………………47
3.6.8.1 General Settings…………………………………………………………………………………………………………….. 47
3.6.8.2 Port Forwards…………………………………………………………………………………………………………………. 47
3.6.8.3 Traffic Rules……………………………………………………………………………………………………………………..48
3.6.8.4 DMZ…………………………………………………………………………………………………………………………………….51
3.6.8.5 Security……………………………………………………………………………………………………………………………. 52
3.6.9 Static Routes………………………………………………………………………………………………………………………53
3.6.10 Switch………………………………………………………………………………………………………………………………… 54
3.6.11 DHCP and DNS……………………………………………………………………………………………………………………55
3.6.12 Diagnostics………………………………………………………………………………………………………………………. 57
3.6.13 Loopback Interface………………………………………………………………………………………………………... 58
3.6.14 Dynamic Routing……………………………………………………………………………………………………………. 58
3.6.15 QoS……………………………………………………………………………………………………………………………………… 61
3.6.16 Guest LAN (Guest Wi-Fi)………………………………………………………………………………………………….62
3
C365-4G-H900 User Manual CB-V1 (May 2020)
3.5.7 SMS
SMS Command
4
C365-4G-H900 User Manual CB-V1 (May 2020)
•Enable: Check the box to enable the SMS command feature.
•SMS ACK: If checked, the router will send the command feedback to the sender’s phone
number. If unchecked, the router will not send the command feedback to the sender’s phone
number.
•Reboot Router Command: Input the command for “reboot” operation, default is “reboot”.
•Get Cell Status Command: Input the command for “router cell status checking” operation,
default is “cell status”. For example, if we send “cell status” to the router, the router will
feedback the status to the sender such as “Router SN: 086412090002 cell_link_up”, which
identifies the router SN number and Cell Working Status.
•Set cell link-up Command: Input the command for the “router cell link up” operation, default
is “cell up”. If the router receives this command, the Router Cell will be online.
•Set cell link-down Command: Input the command for “router cell link down” operation,
default is “cell down”. If router gets this command, the Router Cell will be offline.
•DIO_0 Set Command: set I/O port 0 to high (1). For the SMS feature, please keep the
parameter as default.
•DIO_0 Reset Command: set I/O port 0 to low (0). For the SMS feature, please keep the
parameter as default.
•DIO_1 Set Command: set I/O port 1 to high (1). For the SMS feature, please keep the parameter
as default.
•DIO_1 Reset Command: set I/O port 1 to low (0). For the SMS feature, please keep the
parameter as default.
•DIO_2 Set Command: set I/O port 2 to high (1). For the SMS feature, please keep the parameter
as default.
•DIO_2 Reset Command: set I/O port 2 to low (0). For the SMS feature, please keep the
parameter as default.
•DIO_3 Set Command: set I/O port 3 to high (1). For the SMS feature, please keep the parameter
as default.
•DIO_3 Reset Command: set I/O port 3 to low (0). For the SMS feature, please keep the
parameter as default.
•Button Set/Reset DIO: Set the DIO to high or low immediately.
•DIO Status Command: Input the command for I/O port status. For the SMS feature, please
keep the parameter as default.
•Wi-Fi on Command: Input the command for turning on the Wi-Fi. For the SMS feature, please
keep the parameter as default.
•Wi-Fi off Command: Input the command for turning off the Wi-Fi. For the SMS feature, please
keep the parameter as default.
•Force Cellup Command: If the cell is down due to traffic limitation, then it can be brought up
by this command.
•Operator List Command: Send the modem operator list as SMS, it is only supported by some
specific modems.
•Operator set Command: Set the modem to operator manually, it is only supported by some
specific modems.
5
C365-4G-H900 User Manual CB-V1 (May 2020)
SMS Alarm
•SMS Alarm: Enable SMS alarm feature.
•Enable Signal Quality Alarm: Enable the signal quality alarm feature.
•Signal Quality Threshold: When the signal alarm is generated and the real time signal strength is
lower than the signal quality threshold, then reset the success counter to 0. If the real time signal
strength is bigger than this threshold, the success counter will add one.
•When the signal alarm is not generated and the real time signal strength is lower than the signal
quality threshold, the failed counter will add one. If the real time signal strength is bigger than this
threshold, reset the failed counter to 0.
•Failed Times Threshold: If the failed counter is more than this threshold, a signal alarm will be
generated.
•Success Times Threshold: If a signal alarm is generated, and the success counter is bigger or equal
to the success times threshold, a clear signal will alarm.
6
C365-4G-H900 User Manual CB-V1 (May 2020)
Phone Number
•Add Phone number: Input a name and click the “Add” button to add a new Phone number.
•Delete Phone number: Click the “Delete” button.
•SMS command: Enable the SMS command feature on this phone number.
•SMS alarm: This phone number can receive an SMS Alarm.
•DIO change: DIO change alarm can be sent to this phone number.
SMS Number
7
C365-4G-H900 User Manual CB-V1 (May 2020)
•Receiver Phone Number: The Phone number that receives the message.
•Message: The content of the message.
•Submit: Click the “Submit” button to send the message immediately.
•SMS Log: The SMS send and receive log.
DIO Mail
Send the email to the receiver when the DIO is changed.
.
•Enable: Activate the DIO Mail functionality.
•SMTP server: SMTP server IP address or URL.
•Port: SMTP server port.
•SMTP Authentication: If SMTP server requires SMTP Authentication, enable it.
•Username: Username for the SMTP authentication.
•Password: Password for the SMTP authentication.
•TLS: Enable or disable TLS (also known as SSL) for secured connections.
•StartTLS: Choose the TLS variant: start TLS from within the session (‘on’, default), or tunnel the session
through TLS (‘off’)..
•Check server certificate: Activate server certificate verification using a list of trusted Certification
Authorities (CAs).
•TLS trust file: Activate server certificate verification using trusted Certification Authorities (CAs).
8
C365-4G-H900 User Manual CB-V1 (May 2020)
The default email title is “[DIOx] changed”, and content is SN:8600000000, [DIOx] is changed from
[value0] to value [1]. Configure the email title and content, replace string in [ ].
9
C365-4G-H900 User Manual CB-V1 (May 2020)
DIO Default
•DIO trap: Send SNMP trap when DIO is changed from 1 to 0, or 0 to 1.
•Set DIO to high for a period of time: If setting DIO to high after a period of time, DIO will change to
low automatically, value 0 means disable.
•DIO_0 default value: DIO default value is low (0). If set to high (1), when device is up, it will be set to
high automatically.
•DIO_1 default value: DIO default value is low (0). If set to high (1), when device is up, it will be set to
high automatically.
•DIO_2 default value: DIO default value is low (0). If set to high (1), when device is up, it will be set to
high automatically.
•DIO_3 default value: DIO default value is low (0). If set to high (1), when device is up, it will be set to
high automatically.
10
C365-4G-H900 User Manual CB-V1 (May 2020)
•DIO_0 Value: DIO current value, 0 means low, and 1 means high.
•DIO_1 Value: DIO current value, 0 means low, and 1 means high.
•DIO_2 Value: DIO current value, 0 means low, and 1 means high.
•DIO_3 Value: DIO current value, 0 means low, and 1 means high.
•DIO_0 Function: DIO function can be set to None, GPS and Wi-Fi. DIO value is set to high to turn on
functionality, set it to low to turn it off. If the value is None, it will do nothing.
•DIO_1 Function: DIO function can be set to None, GPS and Wi-Fi. DIO value is set to high to turn on
functionality, set it to low to turn it off. If the value is None, it will do nothing.
•DIO_2 Function: DIO function can be set to None, GPS and Wi-Fi. DIO value is set to high to turn on
functionality, set it to low to turn it off. If the value is None, it will do nothing.
•DIO_3 Function: DIO function can be set to None, GPS and Wi-Fi. DIO value is set to high to turn on
functionality, set it to low to turn it off. If the value is None, it will do nothing.
DIO SMS
When the DIO value is changed, it sends an SMS text accordingly. It must enable the DIO change on the
phone number. If the user-defined text is empty, it will send a system default SMS to the phone number.
The default format is SN:[86000000000], [DIOx] is changed from [value1] to [value0].
11
C365-4G-H900 User Manual CB-V1 (May 2020)
3.5.8 VPN
3.5.8.1 ISPEC
This page is a list of configured IPSec instances and their state. Click the “Edit”button to modify it or
click the “Delete”button to delete an instance.
The default setting is Policy-based IPSec, if Enabled the Route-based IPSec box is ticked, after click
“Save & Apply”, it will then switch to Route-based IPSec.
12
C365-4G-H900 User Manual CB-V1 (May 2020)
13
C365-4G-H900 User Manual CB-V1 (May 2020)
•Enable: Enable the IPSEC feature.
•Exchange mode: IKEv1-Main, IKEv1-Aggressive, and IKEv2-Main modes are supported.
•Operation Level: For IPSec backup. One level is Main and the other is Backup. If the Main instance is
down then switch to the backup instance.
•Authentication method: PSK Client, PSK Server, RSA X.509 Client and RSA X.509 Server. Client is the
device which starts the IPSEC connection.
•Remote VPN endpoint: Domain name or IP address of the remote endpoint. It can be visited from
the Internet.
•Local endpoint: Domain name or IP address or interface name of this device.
•Local IKE identifier: Identity the use of the local device authentication.
•Remote IKE identifier: Identity the use of the remote device authentication.
•Preshared Keys: Pre-shared key authentication, known as PSK.
•Perfect Forward Secrecy: Confirm whether Perfect Forward Secrecy of keys is desired on the
connection's keying channel.
•DPD action: Controls the use of the Dead Peer Detection protocol (DPD, RFC 3706) where
R_U_THERE notification messages (IKEv1) or empty INFORMATIONAL messages (IKEv2) are
periodically sent in order to check the activeness of the IPsec peer. The values are clear, hold, and
restart, all of which activate the DPD and determine the action to perform on a timeout. Clear: The
connection is closed with no further actions taken. Hold: Installs a trap policy, which will catch
matching traffic and tries to re-negotiate the connection on demand. Restart: Immediately
triggers an attempt to re-negotiate the connection. The default is none which disables the active
sending of DPD messages
•DPD delay: Defines the period time interval with which R_U_THERE messages/INFORMATIONAL
exchanges are sent to the peer.
•DPD timeout: Defines the timeout interval, after which all connections to a peer are deleted in case
of inactivity.
•NAT Traversal: Indicates whether the device is behind a NAT device or not.
•Local subnet: The local subnet which connects to the IPSEC VPN.
•Remote subnet: The remote subnet which connects to the IPSEC VPN.
•Local source ip: The internal source IP of the local device to use in a tunnel, also known as virtual IP.
•Remote source ip: The internal source IP of the remote device to use in a tunnel, also known as
virtual IP.
14
C365-4G-H900 User Manual CB-V1 (May 2020)
Note: All the configurations in the Phase 1 Proposal and Phase 2 Proposal must match the remote
endpoint to establish an IPSEC connection.
15
C365-4G-H900 User Manual CB-V1 (May 2020)
3.5.8.2 PPTP
This page is a list of configured PPTP instances and their state. Click the “Edit” button to modify it or
click the “Delete”button to delete an instance.
PPTP NAT enable: Enable PPTP interface NAT.
16
C365-4G-H900 User Manual CB-V1 (May 2020)
PPTP Client configuration
•Enable: Enable this instance.
•Server: The domain name or IP address of the PPTP server.
•Username: Server authentication username.
•Password: Server authentication password.
•Remote LAN subnet: The remote subnet which can be accessed via the PPTP tunnel, such as
192.168.10.0
•Remote LAN netmask: The netmask for the remote LAN subnet, such as 255.255.255.0
•MTU: Maximum transmission unit.
•Keep Alive: Number of unanswered echo requests before considering the peer is dead. The
interval between the echo requests is 5 seconds.
•Use DNS servers advertised by peer: If unchecked, the advertised DNS server addresses are
ignored.
17
C365-4G-H900 User Manual CB-V1 (May 2020)
•MPPE Encryption: Microsoft Point-to-Point Encryption.
•Debug: Add verbose PPTP log in the system log.
•Restart module when PPTP connects failed: Some network PPTP cannot connect until module is
restarted.
PPTP Server Configuration
•PPTP Local IP: Indicate server’s IP address.
•PPTP remote IP start: The remote IP address leases start.
•PPTP remote IP end: The remote IP address lease end.
•ARP Proxy: If the remote IP has the same subnet as the LAN, check it for connecting one another.
•MPPE Ecryption: Microsoft Point-to-Point Encryption.
•Debug: Add verbose PPTP log in the system log.
•Username: Server authentication username.
•Password: Server authentication password.
18
C365-4G-H900 User Manual CB-V1 (May 2020)
3.5.8.3 L2TP
This page is a list of configured L2TP instances and their state. The user can click the “Edit”button to
modify it or click the “Delete”button to delete an instance.
L2TP Client configuration
19
C365-4G-H900 User Manual CB-V1 (May 2020)
•Enable: Enable this L2TP instance.
•Server: Domain name or IP address of L2TP server.
•Username: Server authentication username.
•Password: Server authentication password.
•Remote LAN subnet: The remote LAN subnet can be accessed via the L2TP tunnel, such as 192.168.10.0.
•Remote LAN netmask: The netmask for remote LAN subnet, such as 255.255.255.0
•MTU: Maximum transmission unit.
•Keep Alive: Number of unanswered echo requests before considering the peer is dead. The interval
between the echo requests is 5 seconds.
•Checkup Interval: Number of seconds passed before checking if the interface is not up since the
last setup attempt and retrying the connection. Set it to a value sufficient for a successful L2TP
connection for you. It's because the netifd sent the connect request yet the xl2tpd failed to
complete it without the notice of netifd.
•Debug: Add L2TP verbose log into the system log.
L2TP Server configuration
20
C365-4G-H900 User Manual CB-V1 (May 2020)
•Local IP: Indicate the server’s IP address.
•Remote IP range begin: The remote IP address leases start.
•Remote IP range end: The remote IP address lease end.
•Remote LAN IP: The remote LAN subnet can be accessed via the L2TP tunnel, such as 192.168.10.0.
•Remote LAN netmask: The mask of the L2TP client IP, the default value is 255.255.255.0.
•ARP Proxy: It allows the remote L2TP client to access the local LAN subnet. The remote IP range should
be included in the LAN subnet, for example if the local LAN subnet is 192.168.1.0/24, then configure the
remote IP range starting with 192.168.1.20 and the remote IP range ending in 192.168.1.30, and enable
the ARP Proxy.
•Debug: Add the L2TP verbose log into system log.
•Username: Server authentication username
•Password: Server authentication password.
3.5.8.3 Open VPN
This page is a list of the configured OpenVPN instances and their states. You can click the “Edit”
button to modify it or click the “Delete”button to delete an instance.
You can click the “Start”button to start or “Stop”button stop a specific instance.
Note: For the OpenVPN configuration page, you can put the mouse on the title of the item to get more
help information.
If the item you needed is not shown on the main page, please check the “Additional Field”dropdown
list at the bottom of the page.
This manual suits for next models
1
Table of contents
Other Comms365 Wireless Router manuals
Popular Wireless Router manuals by other brands
ARCHITECTURE TECHNOLOGY CORPORATION
ARCHITECTURE TECHNOLOGY CORPORATION CRR-1000 quick start guide
Huawei
Huawei Mobile wifi e5330 quick start
Crosley
Crosley BTD-3M11-5 quick start guide
Innosys
Innosys IDB-02S user manual
Airlink101
Airlink101 AR420W user manual
NETGEAR
NETGEAR WNHD3004 - High Performance Wireless-N HD Home Theatre... datasheet
