Instruction Sheet
Page 6 of 12
1. Preinstall rear cable manager as outlined in Step 3 and loosely secure the tie wraps so that cables can be
pulled out and pushed in during front termination.
2. Depress four tabs on a 6-pack module (two tabs on a 12-pack module) and remove module from panel
opening and rotate 180º so that rear of module is facing forward. Temporarily snap module backwards into
an adjacent empty panel opening for terminating as shown on previous figures.
Note: It is necessary to temporarily remove modules from opposite panel opening of module being
terminated to facilitate the front cabling procedure. If adjacent module is already terminated, pull module out
and push cables to one side to allow space to temporarily install module being terminated into opening.
3. Pull an adequate length of cables through panel opening for the terminated module and mark the jacket ring
points. Verify that the cables can be pushed back into final position without snagging.
4. Prepare cables and punch down to module using punch-down tool with M110 blade on HI setting and
termination managers per the instructions on page 4.
Note: Hold module with one hand to secure it from sliding during punch down.
5. After all cables are terminated, remove module and rotate 180º so that front of module is again facing
forward. Position module back into panel opening that cables were pulled through and snap into place.
6. After modules are terminated, check to verify proper cable positioning. If access to rear is available, proceed
to Step 3.
Rear Termination Procedure
Note: Do not remove module from panel opening.
1. Establish proper lengths of cables to the modules so they can be positioned in the rear cable troughs after
installation in Step 3 and mark the jacket ring points.
2. Prepare cables and punch down to module using the punch-down tool with M110 blade on HI setting and
the termination managers per the instructions on page 4.
3. After the modules are terminated, proceed to Step 3.
