Communications Specialties 6010A User manual

1
MODEL 6010A
UNIVERSAL SWITCHING POWER SUPPLY
(For Use With Model 6000A Card Cage)
USER’S MANUAL
P/N: 120157 Rev. E
WORLDHEADQUARTERS
55 Cabot Court
Hauppauge, NY 11788 USA
TEL: [phone] FAX:[phone]
WWW: http://www.commspecial.com
EMAIL: [email protected]
Communications Specialties Pte Ltd
1 Beach Road
#22-09 Shaw Tower
Singapore 189702
TEL: [phone] FAX: [phone]
EMAIL: [email protected]
8
Home
Data Sheet

3
INTRODUCTION
The Model 6010A universal switching power supply plugs directly into the Model
6000A rack-mountable card cage and is designed to provide power to most combinations
of rack-mountable Pure Digital One Fiber™ , Fiberlinkor Pure Digital Fiberlink modules
(or cards). This supply occupies three adjacent positions in the card cage. For redun-
dant operation, more than one Model 6010A power supply may be used.
The Model 6010A universal switching power supply is certified to meet the safety
and EMI requirements of most regulatory agencies in the US, Canada and abroad.
TECHNICAL SPECIFICATIONS
Number of Positions Occupied 3
Input Voltage Range (Continuous) 90 to 260VAC 47/63 Hz
Output Voltage +8.5 VDC+ 1% Regulated
Output Current 0 to +50 C, 10A Continuous
-35 to +75 C, 6.5A Continuous
Over-voltage Protection Crowbar at 9.5 to 11.5V
Short Circuit Protection Current Limiting
Input Protection P/C fuse for catastrophic failure
Ripple and Noise 1% pp maximum, DC to 15 MHz
Switching Frequency Greater than 30 KHz
Efficiency 75% minimum
EMI Compliance EMI Compliance FCC 20870 Curve B,
VDE EN55022 Class B, European CE
Safety Compliance UL1950, CSA22.2 No.220, VDE
EN60950, European CE
Shock MIL-STD 810E Method 516.4
Vibration MIL-STD 810E Method 514.4
Input Power Connector IEC UniversalType
6
WARRANTY
Communications Specialties Inc. warrants that for a period of three years after
purchase by the Buyer, all fiber optic transmission systems will be free from defects in
material and workmanship under normal use and service.A Return MaterialAuthorization
(RMA) number must be obtained from the company before any equipment is returned by
the Buyer.All material must be shipped to Communications Specialties Inc. at the expense
and risk of the Buyer.
Communications Specialties Inc. obligation under this warranty will be limited, at its
option, to either the repair or replacement of defective units, including free materials and
labor. In no event shall the company be responsible for any incidental or consequential
damages or loss of profits or goodwill.
Communications Specialties Inc. shall not be obligated to replace or repair equipment
that has been damaged by fire, war, acts of God, or similar causes, or equipment that has
been serviced by unauthorized personnel, altered, improperly installed or abused.
RMA numbers and repairs can be obtained from:
Communications Specialties, Inc.
55 Cabot Court
Hauppauge, NY 11788 USA
TEL: [phone]
FAX: [phone]
or, in theAsia Pacific Region:
Communications Specialties Pte Ltd
TEL: [phone]
FAX: [phone]
(See cover of this manual for complete address)
RMA numbers can also be obtained from our web site:
http://www.commspecial.com
Please have your serial number (located underneathyour unit) available when
contacting us.

4
INSTALLATION AND OPERATION OF MODEL 6010A
1. Plug the Universal Switching Power Supply into the Model 6000A card cage. The unit
will occupy three, adjacent positions. (You may choose which three.) If redundant
operation is desired, additional Model 6010A units may also be inserted, with each
occupying an addition three positions.
2. Plug a suitable line cord into the rear IEC power connector. Note that the Model 6010A
will automatically operate from all AC power sources between 90 and 260 volts at 50 or
60 Hz. No user adjustments are required.
3. Use the front panel power switch to turn the unit on. An illuminated power indicator
LED signifies the presence of power.
The Model 6010A universal switching power supply is “hot swappable,” meaning
that it may be inserted or removed from the card cage without first turning off the power.
This feature is important when using redundant power supplies, as it gives the user
freedom to remove or add a second power supply while maintaining operation of all
transmission modules in the cage.
Do not use the Model 6010A universal switching power supply and an external
user-provided power source simultaneously. Doing so may result in damage to either
the supply or to the transmission card/modules in the card cage.
BUILT-IN ALARM FEATURE FOR REDUNDANT OPERATION
The Model 6010A contains an output voltage-sensing circuit that operates when two
or more power supplies and a model 6020AAlarm Sensing Module are employed in the
same card cage. If one supply should fail, a signal is produced that will activate the Alarm
Sensing Module. This results in a blinking LED, a piezo sounder and activation of a set of
external contacts (on the Alarm Sensing Module) that can be used to remotely signify the
occurrence of the failure.
This feature is not available when only one power supply is employed.
5
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol warns the user of uninsulated voltage
within the unit that can cause dangerous elec-
tronic shocks.
TO REDUCE THE RISK OF ELECTRONIC SHOCK, DO
NOT REMOVE COVER. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This symbol alerts the user that there are
important operating and maintenance instruc-
tions in the literature accompanying this unit.
CAUTION:
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRONIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
FCC STATEMENT
WARNING: This equipment generates, uses and can radiate radio frequency energy and if
not installed and used in accordance with the instruction manual, may cause interference to
radio communications. It has been tested and found to comply with the limits for a Class A
computing device pursuant to Subpart B of Part 15 of FCC Rules, which are designed to
provide reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause interference
in which case the user, at his own expense, will be required to take whatever measures may
be required to correct the interference.

4
INSTALLATION AND OPERATION OF MODEL 6010A
1. Plug the Universal Switching Power Supply into the Model 6000A card cage. The unit
will occupy three, adjacent positions. (You may choose which three.) If redundant
operation is desired, additional Model 6010A units may also be inserted, with each
occupying an addition three positions.
2. Plug a suitable line cord into the rear IEC power connector. Note that the Model 6010A
will automatically operate from all AC power sources between 90 and 260 volts at 50 or
60 Hz. No user adjustments are required.
3. Use the front panel power switch to turn the unit on. An illuminated power indicator
LED signifies the presence of power.
The Model 6010A universal switching power supply is “hot swappable,” meaning
that it may be inserted or removed from the card cage without first turning off the power.
This feature is important when using redundant power supplies, as it gives the user
freedom to remove or add a second power supply while maintaining operation of all
transmission modules in the cage.
Do not use the Model 6010A universal switching power supply and an external
user-provided power source simultaneously. Doing so may result in damage to either
the supply or to the transmission card/modules in the card cage.
BUILT-IN ALARM FEATURE FOR REDUNDANT OPERATION
The Model 6010A contains an output voltage-sensing circuit that operates when two
or more power supplies and a model 6020AAlarm Sensing Module are employed in the
same card cage. If one supply should fail, a signal is produced that will activate the Alarm
Sensing Module. This results in a blinking LED, a piezo sounder and activation of a set of
external contacts (on the Alarm Sensing Module) that can be used to remotely signify the
occurrence of the failure.
This feature is not available when only one power supply is employed.
5
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol warns the user of uninsulated voltage
within the unit that can cause dangerous elec-
tronic shocks.
TO REDUCE THE RISK OF ELECTRONIC SHOCK, DO
NOT REMOVE COVER. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This symbol alerts the user that there are
important operating and maintenance instruc-
tions in the literature accompanying this unit.
CAUTION:
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRONIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
FCC STATEMENT
WARNING: This equipment generates, uses and can radiate radio frequency energy and if
not installed and used in accordance with the instruction manual, may cause interference to
radio communications. It has been tested and found to comply with the limits for a Class A
computing device pursuant to Subpart B of Part 15 of FCC Rules, which are designed to
provide reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause interference
in which case the user, at his own expense, will be required to take whatever measures may
be required to correct the interference.

3
INTRODUCTION
The Model 6010A universal switching power supply plugs directly into the Model
6000A rack-mountable card cage and is designed to provide power to most combinations
of rack-mountable Pure Digital One Fiber™ , Fiberlinkor Pure Digital Fiberlink modules
(or cards). This supply occupies three adjacent positions in the card cage. For redun-
dant operation, more than one Model 6010A power supply may be used.
The Model 6010A universal switching power supply is certified to meet the safety
and EMI requirements of most regulatory agencies in the US, Canada and abroad.
TECHNICAL SPECIFICATIONS
Number of Positions Occupied 3
Input Voltage Range (Continuous) 90 to 260VAC 47/63 Hz
Output Voltage +8.5 VDC+ 1% Regulated
Output Current 0 to +50 C, 10A Continuous
-35 to +75 C, 6.5A Continuous
Over-voltage Protection Crowbar at 9.5 to 11.5V
Short Circuit Protection Current Limiting
Input Protection P/C fuse for catastrophic failure
Ripple and Noise 1% pp maximum, DC to 15 MHz
Switching Frequency Greater than 30 KHz
Efficiency 75% minimum
EMI Compliance EMI Compliance FCC 20870 Curve B,
VDE EN55022 Class B, European CE
Safety Compliance UL1950, CSA22.2 No.220, VDE
EN60950, European CE
Shock MIL-STD 810E Method 516.4
Vibration MIL-STD 810E Method 514.4
Input Power Connector IEC UniversalType
6
WARRANTY
Communications Specialties Inc. warrants that for a period of three years after
purchase by the Buyer, all fiber optic transmission systems will be free from defects in
material and workmanship under normal use and service.A Return MaterialAuthorization
(RMA) number must be obtained from the company before any equipment is returned by
the Buyer.All material must be shipped to Communications Specialties Inc. at the expense
and risk of the Buyer.
Communications Specialties Inc. obligation under this warranty will be limited, at its
option, to either the repair or replacement of defective units, including free materials and
labor. In no event shall the company be responsible for any incidental or consequential
damages or loss of profits or goodwill.
Communications Specialties Inc. shall not be obligated to replace or repair equipment
that has been damaged by fire, war, acts of God, or similar causes, or equipment that has
been serviced by unauthorized personnel, altered, improperly installed or abused.
RMA numbers and repairs can be obtained from:
Communications Specialties, Inc.
55 Cabot Court
Hauppauge, NY 11788 USA
TEL: [phone]
FAX: [phone]
or, in theAsia Pacific Region:
Communications Specialties Pte Ltd
TEL: [phone]
FAX: [phone]
(See cover of this manual for complete address)
RMA numbers can also be obtained from our web site:
http://www.commspecial.com
Please have your serial number (located underneathyour unit) available when
contacting us.
