Community Controls MONARCH 433TSPW2KC User manual

1A- General information
The Monarch transmitter is a 2 buttons key chain
style mini transmitter operating at 433,92MHz.It has been designed
for the control of automatic closing systems and anti-burglar systems,
thanks to its veryhigh security coding system (KeeLoq® Hopping code).
The code sent by the transmitter changes at each activation, avoiding
any scanning and copying risk. A special algorithm allows to keep
synchronizedtransmitter and receiver.
CONTENTS
1A- General information
1B- Technicalspecifications
1C- Maincomponents
1 - TRANSMITTER OVERVIEW
2 - NUMBERING
3 - PROGRAMMING
4 - OPERATION
5 - BATTERY ACCESS
1B - Technical specifications
Operating frequency 433,92 MHz
Number of keys: 2
Battery : 2 x 3V lithium batteries CR2016
Battery life: 18 ÷ 24 months
Security code: Keeloq® Hopping code
Number combinations : 2exp64
Operating temperature: -20°F÷+131°F (-20°C÷+55°C)
Overall dimensions: 2.4”x1.4”x0.51” (61x36x13 mm)
Weight: 0.49 oz. (14 gr.)
The transmitter can operate with many receivers of the range
433R. Ask your installer or reseller the product
which best fits your application. The output of the receivers can be either
wiegand26bit ( to communicate with accesscontrol systems ) or 1-2-4
relay with NO - NO/NCoutput. The CR 2016lithium batteries of the
transmitter have a shelf life of about 6 months. The product fully
complies with Part 15 of FCC Regulations and the European Directives
99/05/CE, 89/336/CEE, 73/23/CEE.
1C - Main components
Red
LED
Key
holder
ring
Dark red
push-button
6 - TROUBLESHOOTING
Manual
433TSPW2KC MONARCH
Dark grey
case
Fig. 2
Thank you for choosing a
Please read this manual carefully before using the product.
Made in Italy. Copyright
with Patented®
ChargeGuard
Circuit
Community
Controls®
Community Controls® product.
© 2013 by Community Controls®.
Community Controls®
Community Controls®

FCC ID : SU7433TSPW2KC
The warranty period of 318 transmitters is 24 months,
beginning from the manufacturing date of the transmitter. During this period,if the
product does operate correctly, due to a defective component, the product will be
repaired or replaced at the sole discretion of
The warranty does not extend to the transmitter case which can be damaged by
conditions outside the control of or to battery life.
WARRANTY
This device complies with FCC Rules
Operation is subject to the following twoconditions:
(1) This device may not cause harmful interference, and
(2) this device must accept interference received, including
interference that may cause undesired operation.
Part. 15 of the
Notice
2 - NUMBERING
To access the battery open the case with a screwdriveracting on the slot between
the cover and the bottom and remove the bottom, as shown in fig. 3a and 3b.
Slide out the old batteries and replace them with the new ones [CR2016]
respecting the polarity, with the positive (+) side upward.
NOTE: Please dispose of the batteries properly according to local laws and
regulations. Test proper battery installation by verifying that the LED illuminates
whenthe button is pushed.
5 - BATTERY ACCESS
3 - PROGRAMMING
Each transmitter is manufactured and sold with a different factory- set serial
number .
The transmitter must beprogrammed into your system memory.
Your own installer or reseller will provide you the necessary instructions for your
system.
4 - OPERATION
A- Firmly depress the button until the small red LED illuminates.
B - After the LED has illuminated, release the button.
If the device you are attempting to activate does not respond, repeat steps A and B
or consult section 7( Troubleshooting ) of this manual.
Fig. 3a
Fig. 3b
6 - BATTERY STATUS
Led GREEN Normal level ~6000 pulses [*] - Normal range
Led ORANGE Attention level Max 300 pulses - L ow range[*]
Led RED Lowlevel Replace battery - Norange
Led color Battery level TX Status
The system does not receive the
transmitter signal.
The transmitter LED is ON
Check to verify the transmitter is
programmed into your system
PROBLEM SOLUTION
The operating range is reduced Replace the transmitter batteries
7 - TROUBLESHOOTING
[ *] : Depends on batteries type and operating conditions . Batteries life calculated
with 1-sec pulses.
Community Controls®
Community Controls®.
Community Controls®
Community Controls® - Type: 433TSPW2KC
COMMUNITY CONTROLS®
2500 South 3850 West, Suite A
Salt Lake City, UT 84120
[phone] - [phone] Fax
www.communitycontrols.com
Any changes or modifications not expressly approved by Community Controls®
could void the user’s authority to operate this equipment.
