COMO AUDIO SpeakEasy User manual

2
Your Guide to SpeakEasy
Front Panel
1. Power/Volume/Play/Pause:When plugged in, push in briefly to Play/Pause while
music is playing. Rotate to adjust the volume. When operating on battery power-
only, push in briefly to turn on; Press and hold to turn off. You can also ask
SpeakEasy to adjust the voume, such as “Hey Google, play it louder.”
2. Microphone:Press briefly to mute the microphones. The Assistant LEDs will turn
amber. Press again to unmute the microphones.
3. Bluetooth: Press briefly to place in Bluetooth mode; Press and hold to discover new
Bluetooth devices. Open Bluetooth on your source device and search/scan for the
“CA SpeakEasy” name, then pair and connect. Once you’ve paired you shouldn’t
need to do it again. If your source device prompts you to enter a passcode, enter
“0000”. Adjust the volume as desired.
4. Assistant LEDs: The 4 white LEDs will flash whenever Speakeasy is “thinking”. The
LEDs will change to amber color whenever the microphones are muted or during a
Factory Data Reset (refer to the Rear Panel section). The LEDs will flash blue in
Bluetooth mode.
EN

3
5. Time: The 7-segment display shows the time in 12 hour format and the brightness is
auto adjusted via the optical sensor in the front panel. SpeakEasy should be
continuously connected to your Wi-Fi in order to maintain the correct time.
6. Optical sensor: Automatically adjusts the display’s backlight based on ambient light
conditions.
7. Display icons: Battery is charging; Alarm is set; Timer is active; Snooze is active.
Top Panel
1. Press to Talk (center button): Press briefly for SpeakEasy to listen for your
command/query without having to speak “Hey, Google” first.
2. Microphones: The small round openings to the left and right are the microphones. Do
not cover or obstruct the microphones.
EN
EN

4
Rear Panel
1FDR (Factory Data Reset):To completely reset SpeakEasy, have it power cycle,
and place it in Setup mode, press and hold until the front panel assistant lights
start to turn amber color, then release the button. All network settings and user-
specific settings will be lost.

5
2. 18V/2.8A DC:Connect the included external Como Audio power supply to this input
to power SpeakEasy and to charge its battery. Attach the appropriate snap-in plug
to the power supply for your region. If the power supply is ever lost or damaged, use
only a like replacement.
3. Reboot:Press briefly to reboot SpeakEasy if an issue occurs. Unlike the FDR button
(#2 above), you will not lose any settings or need to repeat the setup in the Google
Home app.
4. USB 5V/1A:Connect a smart phone for charging. Please be sure not to exceed the 5
Volt/1 Amp rating. This jack will not play music from a USB thumb drive or an MP3
player.
5. Speaker:Connect the optional wired SpeakEasy Speaker’s audio cable to this right
channel output. Use only the Como Audio SpeakEasy Stereo Speaker with this
output.
6. Mono/Stereo:Keep this switch in the Mono position unless the optional SpeakEasy
Speaker is connected, in which case it should be placed in the Stereo position. In the
stereo configuration, SpeakEasy will reproduce the left channel only and the
SpeakEasy Speaker will reproduce the right channel only. Accordingly, it is suggested
to position the optional SpeakEasy Speaker on the right side. The more distance
between the two speakers, the better the channel separation and soundstage.
7. Battery compartment:The 2200mA 14.8V custom Li-Ion battery pack is user
replaceable. Use only a genuine Como Audio replacement battery pack, as
unauthorized batteries could pose a fire risk and are not covered under warranty.
The display’s battery icon will illuminate whenever the battery is being charged. For
more, see “Battery Playback”.
Bass Port/Carry Handle:Rest your palm on the top of the cabinet and insert
your fingers inside the port to carry. Do not obstruct the bass port otherwise.

6
Setup Using the free Google Home Android App
You can also watch the Setup video on our website:
ANDROID APP
1. Plug in SpeakEasy with the included external adapter. You’ll hear a spoken greeting and
the 4 Assistant white LEDs will pulsate.
2. Download and launch the free Google Home app on your Android smart device from the
Google Play store (the Como Control app is not used with SpeakEasy).
3. Follow the instructions in the app to complete the setup, currently:
4. 1 Device found will be shown. Select “Set up”.
5. Setup: select “Yes”.
6. Did you hear the confirmation tone? Select “Yes”.
7. Help improve Google: select “Yes, I’m in”.
8. Select the name of the room SpeakEasy will be located in followed by “Next”.
9. Select the name of your Wi-Fi network followed by “Next”.
10. Enter your Wi-Fi network password (password is case sensitive). Once this is done the
clock will set automatically and the white LEDs will stop flashing (initially the time might
be incorrect, but it will get updated in a minute)
11. Partners: select “More” and “Next”.
12. Voice match: select “I Agree” and speak the commands.
13. Personal results: select “I Agree”.
14. Enter your address (so Google can access the correct weather, etc. for your area) and
select “Confirm address”.
15. Add your music services and select “Next”.
16. Select your preferred default music service and select “Next”.
17. Add video services and “Next” or select “Not now”.
18. Sign up for news, etc. (optional).
19. All done: select “Continue”.
20. Ready: select “Continue”.
21. Close out the Google Home app. SpeakEasy will speak a greeting. You are now ready to
use SpeakEasy!
Setup Using the free Google Home iOS App
You can also watch the Setup video on our website:
iOS APP:

7
1. Plug in SpeakEasy with the included external adapter. You’ll hear a greeting and the
4 Assistant white LEDs will pulsate.
2. Download and launch the free Google Home app on your Apple smart device from
the app store (the Como Control app is not used with SpeakEasy).
3. Follow the instructions in the app to complete the setup, currently:
4. Select “Get started” at the bottom.
5. Select an email account to associate with the Google Home app.
6. Create a home: Select “Get started” then “Ok” at the bottom.
7. Setup: select Set up new devices”.
8. Choose a home: Select the plus icon (+) and “Next” at the bottom.
9. Create a name such as “Bedroom” and select “Next”.
10. Turn on Bluetooth: select “No thanks”.
11. Connect device to temporary Wi-Fi: select GoogleHomeXXXX
12. Select “Settings” at bottom.
13. Select SpeakEasybfad.nXXX. Close out the app. Reopen the app.
14. Did you hear the sound? Select “Yes”.
15. Help improve: select “Yes, I’m in”.
16. Where is this device: choose the same as entered in item 7 above and select “Next”.
17. Select the name of your Wi-Fi network.
18. Enter your Wi-Fi network password (password is case sensitive) and select
“Connect”. Once this is done, the clock will auto set (initially the time might be
incorrect, but it will get updated in a minute) and the white LEDs will stop flashing.
19. Set up Assistant: select “Next”.
20. Turn on settings for full experience: select “More” then “Turn on”.
21. Teach to recognize voice: select “View more” and “I agree”.
22. Access microphones: select “OK”, then select speak each command.
23. Get personal results: select “View more” and “I agree”.
24. Choose Assistant’s voice and select “Next”.
25. Allow access location: select “Allow”.
26. Enter address (so Google can access the correct weather, etc. for your area)
followed by “Next”.
27. Add media services (music): select “Next”.
28. Stay in the know: select “Sign up” or “No thanks”.
29. Almost done: select “Next”.
30. Ready: select “Continue”.
31. Start with Hey Google: select “View more”.
32. Get stuff done: select “Finish setup”.
33. Close out the Google Home app. SpeakEasy will speak a greeting. You are now ready
to use SpeakEasy!

8
Alarm:
To set the alarm with the unit on, simply speak the command with the time you wish to
wake, such as “Hey, Google, set the alarm for tomorrow at 7am.” The alarm time will
appear for 5 seconds. If you change your mind, you can say “Hey, Google, cancel the
alarm.” You can wake to a song or a radio station instead of the jingle by speaking “Hey
Google, set a music alarm for tomorrow at 7:40am”. More than one alarm can be set.
The alarm will automatically turn itself off after 10 minutes if no action is taken but
you’ll still have to tell Google to cancel the alarm. The alarm jingle volume is at a fixed
level and cannot be adjusted.
Note: If SpeakEasy is Off and the external power supply is not connected, if the battery
runs out of power before the alarm activates, the alarm will not work.
Snooze/Alarm Off:
While the alarm is sounding, you can tell SpeakEasy to put the alarm in Snooze mode,
such as “Hey, Google, Snooze for 10 minutes.” To turn the alarm off while it is sounding,
briefly press the Play/Pause knob, or just say “Hey Google, stop the alarm.” The alarm
will automatically turn itself off after 10 minutes if no action is taken but you’ll still have
to tell Google to cancel the alarm.
Timer:
To set the timer, simply specify the amount of time in your command, such as “Hey,
Google, set the timer for 20 minutes”. If you change your mind, you can say “Hey,
Google, cancel the timer.”
Outdoor use:
SpeakEasy is splash resistant but not water proof. It should never be placed under
running water or submerged. Take care to keep the real wood veneer from being
exposed to moisture.
Battery Playback/Charging time/Replacing the Battery:
Results will vary depending on use, but at approximately 60% volume with a fully
charged battery, expect roughly 8 hours of playback time. A depleated battery pack
could take up to 3 hours to fully charge (the battery icon will illuminate during charging).
When operating on battery power, lower volume levels will extend battery playback
time.
During extended periods of non-use, be sure SpeakEasy is kept at room temperature
with a 40% battery charge.

9
To replace SpeakEasy’s battery, remove the battery cover and follow the instructions
included with the replacement Como Audio battery pack (sold separately).
Software updates:
SpeakEasy periodically checks for new software updates and downloads them
automatically.
Google Cast:
Play audio from any Cast-enabled music service app by selecting the Cast icon in the
music app, selecting SpeakEasy as the output device, and selecting Play.
Multiroom:
You can use multiple SpeakEasys for whole house audio by setting a group in the free
Google Home app and controlling them via the app; Play the same source on all
SpeakEasys or different sources on each.
Connecting The Como Audio Turntable via Bluetooth:
1. Switch the Como Audio Turntable’s Bluetooth switch On (switch is located on right side
of turntable).
2. Press and hold SpeakEasy’s Bluetooth knob (last knob on right) for 4 seconds and
release. You will hear a chime confirming connection.
3. SpeakEasy’s lights might continue to flash blue for some time. This is normal. If the
turntable doesn’t pair and connect within a minute or so, switch the Turntable’s
Bluetooth switch off and on again.
4. Whenever you change SpeakEasy from the turntable to a different source such as
playing Internet radio or a music service, to go back to listening to the turntable, or if
the turntable won’t connect, switch the turntable’s Bluetooth switch Off and back On
again and repeat step 2 above.
Some examples of how you can interact with SpeakEasy (always begin with “Hey,
Google”, or “Okay, Google”):

10
Enjoy Entertainment
Control Compatible Devices
Around Home
Plan Your Day
Play some jazz
Turn up the thermostat
Tell me about my day
Play some music
Set the thermostat to 72
degrees
Is my flight on time?
Pause
Dim the lights in the kitchen
When’s my first event
tomorrow?
Next song
Is the light on in in the living
room?
Will I need an umbrella today?
Manage Tasks
Get Answers
Set a 13 minute timer for pizza
What’s ‘nice to meet you’ in Korean?
Wake me up at 6 AM tomorrow
Who was the first US president?
Add butter to my shopping list
What’s the weather today?
Set a timer for 15 minutes
How far away is the moon?
Be sure to locate SpeakEasy in an area without a lot of noise so the microphones
can clearly pick up your voice.
SpeakEasy must be continuously connected to your Wi-Fi network in order to
work properly.
Troubleshooting:
Should you experience any unusual behavior, please reboot your router before trying
the rear panel FDR button described in the “Rear Panel” section.
Warranty
Como Audio, Inc. provides a two-year parts and labor warranty to the original owner
from the date of purchase.
This warranty does not cover accidental damage, cosmetic damage, normal wear and
tear, improper installation, negligence, commercial applications, acts of God,
lightening/power surges, unauthorized modifications, or service by unauthorized
facilities.

11
Como Audio will repair or replace the defective product at its discretion. Please retain
the original receipt and packing materials.
Contact your point of purchase for warranty service.
Please contact Como Audio for an authorization number before returning anyproduct
to us at: [e-mail]
Specifications:
Model name: SpeakEasy by Como Audio
Max power output: 30 watts RMS per channel;Class DDigital amplifier
Power input: 18VDC/2.8A: Use only a like power adapter if a replacement adapter is ever
needed.
Battery: LI-Ion 2200mA/14.8V (For your safety and optimal performance, replace only with a
genuine Como Audio Amico battery pack). Dispose of a spent battery pack according to your
country’s requirements.
Transducer configuration: ¾” soft dome tweeter and 3” custom woofer
Wi-Fi networks: 802.11a/b/g/n & 2.4
Supported audio codecs: MP3, WAV, FLAC, HE-AAC, LC-AAC, Vorbiz, Opus
Wi-Fi frequency range: 2400-2483.5MHz
Energy efficiency: Consumes 1 watt maximum in standby; Consumes 37 watts at full volume (38
watts with the SpeakEasy Speaker connected).
Dimensions: 242 mm Hx 125 mm W x 130 mm D
Weight: 1.68kg/3.7 lbs
This manual was written by Peter Skiera. This document, as well as all specifications and
features, are subject to change without notice.
Como Audio, Inc. is not liable for technical or editorial errors/omissions.
Como Audio, the Como Audio logo, SpeakEasy by Como Audio, and SpeakEasy Speaker
are trademarks or registered trademarks of Como Audio, Inc.
Google, Google Home, Android, Google Play, Chromecast built-in and other related marks and
logos are trademarks ofGoogle LLC.
Controlling other devices in your home requires compatible products.
EN

12
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG,
Inc. and any use of such marks by Como Audio, LLC is under license. Other trademarks and
trade names are those of their respective owners.
Thompson Licensing: MP3 audio decoder
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
Fraunhofer: MPEG-4 HE & LC AAC Audio decoder
MPEG-4 HE-AAC & LC-AAC audio coding technology licensed by Fraunhofer IIS.
http://www.iis.fraunhofer.de/amm/
Certain features and services may not be available in all areas.
Subscription(s) may be required and additional terms, conditions, and/or charges may
apply.
For FAQs, help videos, blog articles, and instruction manuals, please visit:
www.comoaudio.com
Como Audio, Inc.
Boston, MA USA
[e-mail]
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.

13
3. Heed all warnings.
4. Follow all instructions.
5. Warning: Batteries shall not be exposed to excessive heat such as sunshine, fire, or
the like.
6. WARNING- To reduce the risk of fire or electric shock, do not expose this apparatus
to rain or moisture.
7. Apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
8. Clean only with a dry cloth.
9. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
10. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifies) that produce heat.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table, specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
13. Operate this product only from the type of power source indicated on the rear
panel. For products using an external power supply, use an exact replacement if lost
or damaged.
14. For added protection for this product during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet. This
will prevent damage to the product from lightning storms and power line surges.
15. Unplug this product from the wall outlet and refer servicing to qualified personnel
under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled or objects have fallen into the product.
c. If the product has been exposed to water or rain.
d. If the product does not operate normally by following the operating
instructions.
e. If the product has been dropped or damaged in any way.
f. When the product exhibits a distinctive change in performance.
16. When replacement parts are required, be sure your service technician has used
replacement parts specified by the manufacturer or have the same
characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
17. Upon completion of any service, ask the service technician to perform safety checks
to confirm the product is in proper operating condition.
EN

14
18. Keep this product a safe distance away from naked flame.
19. The recommended operating temperature range is 5C – 40 C (41 F – 104 F).
20. Complies with Canadian ICES-003 & RSS-210.
21. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
22. The external power adapter serves as the disconnect device and should remain
readily accessible.
23. WARNING- The mains are not disconnected in the standby position when the
external adapter is connected.
Waste from Electrical and Electronic Equipment (WEEE): This directive mandates the
collection and recycling of electronics and component materials in order to reduce the
amount going to landfills. Outside North America, when the user decides to discard this
product, it must be sent to a separate collection facility for recycling. Please contact
your point of purchase for more details.
Como Audio models comply with the RoHS (Restriction of Hazardous Substances)
directive.
Federal Communication Commission (FCC) Interference Statement
FCC Part 15: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna.
EN

15
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Industry Canada Licence-exempt RSSs. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Note: The wood veneers we apply to our nearly ½” thick cabinets are indeed real wood.
They are quite literally products of nature, and as such, have their own color and grain
characteristics which can vary from tree to tree, often times greatly so. It is exactly
these naturally occurring variations that result in each wood cabinet being truly unique.
Thus, there may not be a precise match between the SpeakEasy and the SpeakEasy
Speaker. Also, the wood veneer can darken over time, particular when exposed to
sunlight.
SEM52319
EN
