Service Manual
JHT01

Chapter 1
System Description
Specification

Contents
Chapter 1 System Description Specification
1. SCOPE................................................................................................... 1-2
1.1 One 2.5” W, 9.5mm H Hard Disk, Up to 250GB.............................1-2
1.2 Optical Disc Drive..........................................................................1-2
1.3 Touch Pad:.....................................................................................1-2
1.4 Keyboard.......................................................................................1-2
1.5 Display Device...............................................................................1-2
1.6 Camera..........................................................................................1-3
1.7 Keyboard.......................................................................................1-3
2. Communications..................................................................................... 1-4
2.1 Wireless LAN.................................................................................1-4
2.2 Modem...........................................................................................1-4
2.3 Bluetooth .......................................................................................1-4
3. Mechanical Specification ........................................................................ 1-5
3.1 Option Pack:..................................................................................1-5
3.2 Mechanical Function......................................................................1-5
3.3 Mechanical Material.......................................................................1-5

JHT01 Service Manual
1-1
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be followed to
reduce the risk of fire, electric shock and injury to persons, including the following:
★ Do not use this product near water, for example, near a bathtub, washbowl, and kitchen
sink or laundry tub, in a wet basement or near a swimming pool.
★ Avoid using a telephone (other than a cordless type) during an electrical storm. There
may be a remote risk of electric shock from lightning.
★ Do not use the telephone to report a gas leak in the vicinity of the leak.
★ Use only the power cord indicated in this manual.

JHT01 Service Manual
1-2
1. SCOPE
This document describes the functional specifications for the Compal Notebook
personal computer JHT01 series. The system is hardware and software
compatible with the IBM PC/ATX personal computer.
1.1 One 2.5” W, 9.5mm H Hard Disk, Up to 250GB
• Support SATA 3.0Gb/s
• 5400RPM or 7200RPM
• Easily removable
• Capacity from 80GB to 250GB and bigger in future
1.2 Optical Disc Drive
• 12.7mmh, Combo (DVD/CD-RW) Drive
• 12.7mmh, DVD Super Multi Drive
1.3 Touch Pad:
• Length: 84±0.2mm
• Width: 42±0.2mm
• PCB Thickness: 1.0±0.15mm
• MAX Thickness: 3.4±0.15mm
1.4 Keyboard
• Length: 300+0.05-0.30mm
• Width: 108.9+0.05-0.20mm
• Height: 5.10+0.3-0. 3mm
• Stroke: 2.5+0-0.3mm
1.5 Display Device
LCD
• COLOR TFT/WXGA LCD (CMO N141I3-L02 Glare)
Dimensions: 320.0 (W) x 206 (H) x 5.5 (D) mm (max)
1280 x 800 WXGA Resolution
Brightness: 220 (Type)

JHT01 Service Manual
1-3
• COLOR TFT/WXGA LCD (CPT CLAA141WB05A Glare)
Dimensions: 320.0 (W) x 206 (H) x 5.5 (D) mm (max)
1280 x 800 WXGA Resolution
Brightness: 200 Nit (Type)
• COLOR TFT/WXGA LCD (LPL LP141WX3-TLN2 Glare)
Dimensions: 320.0 (W) x 206 (H) x 5.5 (D) mm (max)
1280 x 800 WXGA Resolution
Brightness: 200 Nit (Type)
1.6 Camera
• 1.3M CMOS module, fix-focus, camera module (Chicony, CNF7163)
• 2.0M CMOS module, fix-focus, camera module (Suyin)
• 2.0M CMOS module, fix-focus, camera module (Chicony CNF7247)
1.7 Keyboard
• 86 / 87 keys with 101/102 key emulation
• 2.5±0.15mm full stroke keys
• Phantom key auto detect
• Overlay numeric keypad
• Support independent pgdn/pgup/home/end keys
• Support reverse T cursor keys
• Factory-configurable different languages by OEM customer
• Window key supported

JHT01 Service Manual
1-4
2. Communications
2.1 Wireless LAN
• Wireless LAN & WiMAX mini card: module maker: Intel
PCI Express base specification compliant
2.2 Modem
• Internal Modem with MDC solution (MDC 3.3/1.5): module maker: Askey
2.3 Bluetooth
• Bluetooth module: module maker: Foxconn chipset: Broadcom Bluetooth
V2.1+EDR

JHT01 Service Manual
1-5
3. Mechanical Specification
• FOR 14.1”
13.2” (W) x 10.0” (D) x 1.5” (H) [335.0mm (W) x 255mm (D) x 38mm (H)]
6.7lb~7.2lb (including: HDD, ODD and BATT module)
3.1 Option Pack:
• AC adapter: 444g
• HDD Pack: 160g (9.5mm)
• BATT (Li-ion): 414g (8cell)
• ODD module: 259g
• FDD module: 202 g
3.2 Mechanical Function
• Removable HDD
• ODD Module
• Battery changeable (Li-ion)
• For security can use Kensington Lock
• Scissor type key board standard pitch 3.0 m/m travel length
• Express card sockets supported
• Fixed Web Camera
• Wireless switch Button
3.3 Mechanical Material
• Plastic PC+ABS (Mitsubishi, MB-8800 and TMB-1615)

Chapter 2
Software Specification

Contents
Chapter 2 Software Specification
1. System Components Summary .............................................................. 2-1
2. System Controls ..................................................................................... 2-5
2.1 Buttons ..........................................................................................2-5
2.2 System status indicators................................................................2-5
3. Core BIOS Features............................................................................... 2-6
3.1 Multi Boot.......................................................................................2-6
3.2 Quiet Boot......................................................................................2-6
3.3 Boot Block .....................................................................................2-6
4. Thermal management............................................................................. 2-7
5. Power Management for ACPI mode ....................................................... 2-7
5.1 Introduction....................................................................................2-7
5.2 System Time-outs..........................................................................2-7
5.3 System Power Management..........................................................2-7
5.4 Device Power Management...........................................................2-7
5.5 Hibernation....................................................................................2-8
6. ACPI (Advanced Configuration and Power Interface)............................. 2-9
6.1 Introduction....................................................................................2-9
6.2 ACPI Sleep Status.........................................................................2-9
6.3 Fast Resume .................................................................................2-9
6.4 Power State Transition Diagram ....................................................2-9
6.5 Storage Devices and Batteries ....................................................2-10
6.6 Bootable Device...........................................................................2-10
6.7 Embedded controller....................................................................2-10
7. PC2001..................................................................................................2-10
8. Miscellaneous Features.........................................................................2-10
8.1 Single BIOS ROM........................................................................2-10
8.2 USB Support................................................................................2-11
8.3 Flash utility - one BIOS ROM only...............................................2-11
8.4 Crisis Recovery ...........................................................................2-11
8.5 VGA Support................................................................................2-11
9. Customer Specific Features...................................................................2-12
9.1 Display of System Type and BIOS Version Number on Boot.......2-12
9.2 CMOS RAM management...........................................................2-12
9.3 System Management BIOS (SM BIOS) version 2.4 (DMI 2.0).....2-12
9.4 EEPROM.....................................................................................2-13

10. System Setup ........................................................................................2-14
10.1 Invoking setup .............................................................................2-14
10.2 Setup screens..............................................................................2-14
11. OS Compatibility....................................................................................2-18
12. Software Specification for EC-FW..........................................................2-18
12.1 General purpose..........................................................................2-18
12.2 Features ......................................................................................2-18
12.3 Types of EC-FW provided............................................................2-18
12.4 Hot keys for system control .........................................................2-25
12.5 External Buttons status report and control...................................2-26
12.6 IOMP button.................................................................................2-27
12.7 Adapter loading control................................................................2-27
12.8 External LEDs status report and control......................................2-27
12.9 Battery status report and control..................................................2-29
12.10 EC-FW Power management support...........................................2-30
12.11 Thermal Status Report and Fan Control......................................2-31
12.12 Three host interface channels support.........................................2-33
12.13 Support three independent devices through PS/2 channel
simultaneously.............................................................................2-33
12.14 Devices PnP configuration...........................................................2-33
12.15 ACPI EC interface Specification support......................................2-34
12.16 Internal keyboard change Configuration......................................2-34
12.17 EC name space Configuration.....................................................2-35
12.18 Embedded Controller chipset ......................................................2-43

JHT01 Service Manual
2-1
1. System Components Summary
Processor
– Intel Penryn 45nm Standard Voltage:
 2.8GHz, 1066MHz FSB, 6MB L2 cache
 2.53GHz. 1066MHz FSB, 6MB L2 cache
 2.26GHz, 1066MHz FSB, 3MB L2 cache
 2.40GHz. 1066MHz FSB, 3MB L2 cache.
FSB – 667/800/1066 MHz FSB support
Core Logic – Intel Montevina platform:
– JHL90/JHT00: Cantiga PM + ICH9M.
– HL91/JHT01: Cantiga GM + ICH9M.
System Memory
– No on board memory
– Support DDR-II 667/800MHz
– Two SODIMM with 1GB/2GB modules
– Easy upgrade from bottom side for two SODIMM.
– Max. 4GB
Display
– 15.4” (16:10) WXGA (1280x800) (glare/anti-glare and anti-
reflection)
– 15.4” (16:10) WXGA+ (1440x900) (glare/anti-glare and
anti-reflection)
– 15.4” (16:10) WSXGA+ (1680x1050) (glare/anti-glare and
anti-reflection)
– 14.1” (16:10) WXGA (1280x800) (glare/anti-glare and anti-
reflection)
HDD
– 9.5mm, 2.5” S-ATA HDD
– support with 80/120/160/250GB (5400rpm) capacity
– support with 120/160GB (7200rpm) capacity
– Easily removable no more than two screws
Optical Drives
– Fixed 12.7mm height SATA ODD:
– Combo (CD-RW/DVD-ROM/DVD Dual) (8x)
 DVD-RAM/-R/-RW readable
– DVD Super-Multi (DVD-RAM/-R/-RW/+R/+RW Super
Multi)
 DVD-RAM/-R/-RW writable
 Support Double-Layer Recording is required
High Definition Disc (BD-Multi ROM)
– Blue-Ray Writable
– Blue-Ray ROM

JHT01 Service Manual
2-2
Video Chip
JHL91/JHT01
– Intel Cantiga GM for Int. Gfx
– Main Memory shared for Int. Gfx
– Default setting: VRAM 256MB shared from system
memory
JHL90/JHT00
Chipset Size Bus width Type
MXM-II NB9M-GS 256M 64bit 32M16*4
MXM-II NB9P-GS 512M 128bit 32M16*8
Audio
– Realtek ALC268
– HD Audio
– Microphone-in and headphone-out
– Two stereo speakers
– JHL90/JHT00:Two internal analog Microphone,
Microphone array supported
– JHL91/JHT01: One internal analog Microphone.
On-board
Comms
– Askey/AgereAM5/CastleNet/Moto
 V.92/56K bps; V.90/56K bps
– JHL91/JHT01 LAN: 10/100Mbps, Realtek RTL8102e
– JHL90/JHT00 LAN: 10/100/1000Mbps, Realtek RTL8111c
– Wireless LAN, 802.11a/g/n, Intel Shirley Peak (option)
– 802.16e Mobile WiMAX and 802.11abgn, Intel Echo Peak
(TBC)
– Antenna: WiMAX x 2
– Bluetooth USB type, ver 2.1, Foxconn (Broadcom) (Option)
Keyboard
– 85/86 keys support with 101/102 key emulation without
stick-point.
– Windows key, Application key
– Standard pitch, 3.0mm travel length.
– Multi-Langue support.
– The plate of K/B for Intel is different with the plate for A30
customers
– The printing of K/B is same for both Intel and A30
Pointing Device – Touch pad with two buttons (left & right)

JHT01 Service Manual
2-3
Web Cam
JHL90/JHT00:
– 2.0M pixel CMOS via USB 2.0 interface.
 Auto-focus (ME dimension).
 Face detect function (Compal SW).
 Business card scanner.
 A4 scanner.
JHL91/JHT01:
– 1.3M/2.0M pixel CMOS via USB 2.0 interface. (option)
 Auto-focus (ME dimension).
 Face detect function (Compal SW).
 Business card scanner.

A4 scanner.
I/O Ports
– PCI-Express Card, 34/54mm. x 1
– USB V2.0, x 3, Power USB V2.0 x 3
– RGB; VGA port x 1, 15pins
– S-Video in x 1
– Microphone-in x 1
– Headphone-out jack x 1
– DC-in jack x 1
– Mini Card x3 (JHL90) / Mini Card x2
(JHL91/JHT01/JHT00)
– Media Card Reader (SD/MMC/MS/MS pro) x 1
– RJ-11 jack x 1 for 56Kbps V.90/92 Modem x 1
– RJ-45 jack x 1
– Kensington lock x 1
– HDMI x 1
– RF-in x 1 (option)
User keys
– Power Button. x 1
– Magnetic Lid Switch. x 1
– Wireless switch x 1
– Power USB Button x 1
– Program DJ x 1
– JHL90/JHT00: Wow Video. Four modes: Movie, Photo,
Office, Nature x 1
– JHL90/JHT00: Wow Audio.
Security
– JHL90/JHT00: Fingerprint
TPM 1.2 by Infineon/Winbond
 Design ready for Windows Vista
– Kensington lock
Controls – Power button x 1
– Magnetic lid switch control for system standby or suspend
AC adapter – Universal AC Adapter, 19V DC, 3 pins 240V 90W and
65W

JHT01 Service Manual
2-4
Battery
– Life Cycle: 70% Design Capacity after 300 Cycles in 25
degrees C.
 6-cell Li-On, 18650 type, 4800/5200mAh, CBB-look
A30.
 9-cell Li-On, 18650 type, 7200/7800mAh.(Option for
JHL90)
Software
– Phoenix First BIOS
– 2048KB Flash BIOS ROM
– Suspend to RAM/Disk
– No support APM
– USB memory Boot support
– Support SMBIOS 2.4, PCI2.2.
– ACPI 2.0 compliance with Intel Speed-step Support C-State
and S3, S4 for mobile CPU
Operating
System
– Windows Vista 32-bit/64-bit Premium design ready for
Discrete.
– Windows Vista 32-bit/64-bit Basic design ready for UMA.
Keyboard
Controller – ENE KB926 K/B Controller
